NetComm NP1020 User manual

USB
NP1020
USB 2.0 Fast Ethernet LAN Key
Plug into any Ethernet network - instantly, Hot or Cold
Designed for USB-enabled PCs and Notebooks
Fast Ethernet 10Base-T & 100Base-TX connection
Frees up Desktop CPI Bus and Notebook PCMCIA slots
No external power supply required
Microsoft Windows 98se, Me, 2000 & XP
Plug Into Any Ethernet Network - Instantly!
Logging onto a Local Area Network (LAN) has
never been quicker or easier with this Plug &
Play USB 2.0 LAN Key. There is no need to
dismantle your computer to install a NIC card
or replace your PCMCIA card. Simply plug the
USB 2.0 LAN Key into the USB port, connect
the Ethernet cable to the back of the LAN key
and you are network ready!
The NP1020 is ideal for users that have run
out of PCI slots on their Desktop or want to use
their remaining PCI slots for other devices.
TECHNICAL SPECIFICATIONS
Features
• Complies with USB specifi cation 1.0, 1.1 & 2.0
• Full-Speed USB device
• Supports USB suspend/resume detection logic
• Supports Windows® Plug & Play
• Hot Attachment
• IEEE 802.3 for 10Base-T and IEEE 802.3u for
100Base-TX compliance
• Automatically negotiates 10 or 100Mbps
connection rate
• Provides full duplex to enhance throughput
• 3.3V low power consumption
Network Interface
• One RJ-45 to connect with a 10Base-T or
100Base-TX Hub or Switch
LEDS
• Activity
• 10Mbps
• 100Mbps
Host USB Interface
• One USB, type A, male connector to connect
to host computer
System Requirements
• Pentium 1GHz or faster
• 256MB RAM
• Windows® 98se, Me, 2000, XP
• One available USN 2.0 socket
Driver Support
• Windows®98se, Me
• Windows®2000(NDIS 5), XP
Package Contents
• USB 2.0 LAN Key
• Quick Start Guide
• Mini CD Driver
• Cat5 network cable
Warranty
• USB 2.0 LAN Key
10/100MbpsPlug & Play
