WGU624
Double 108 Mbps Wireless Firewall Router
Take the Fast Lane with Double 108 Mbps!
The NETGEAR Double 108 Mbps Wireless Firewall Router (WGU624) delivers two
simultaneous 108 Mbps networks to ensure the highest speeds and the best quality of service.
In addition to the 108 Mbps 802.11 b/g network, users can access a "Fast Lane" – the
802.11a network. The "Fast lane" is ideal for the most demanding of applications including
high quality video streaming and serious home office use. With new XR technology, the
Double 108 delivers unparalleled range – over 400 feet indoors*!
*actual results will vary depending upon operating environment
The NETGEAR Double 108 Mbps Wireless Firewall Router uses Super A+G technology to
provide two parallel 108 Mbps networks at the same time. The first network – the 802.11g
network is based on the most commonly used standard and is fully backward compatible with
802.11b devices. It’s lightning fast 108 Mbps is ideal for web surfing, email, and downloads. The
second network – the 802.11a "Fast Lane" delivers a speed and quality that is required by the most
demanding applications such as video streaming – where even the slightest hiccup produces an
unpleasant user experience. The Double 108 is tested and validated to work with Microsoft Media
Center Extenders and Xbox game consoles. The "Fast Lane" is also great for home office users –
who require the highest quality of service available.
Say goodbye to "dead spots" in your home! The NETGEAR Double 108 Mbps Wireless Firewall
Router (WGU624) is the first product to include Extended Range (XR) Technology. XR provides
three times the range of standard 802.11g by maintaining connectivity when signals are made faint
when passing through dense walls, floors, or other barriers. When used with the Double 108 Mbps
Wireless PC Card (WG511U), users can enjoy range of over 400 feet! XR requires no additional
configuration by end-users and is fully interoperable with standard 802.11 technologies.
With Double 108, users can separate themselves from the crowded 2.4 GHz frequency. Since 2.4
GHz has only three non-overlapping channels, many users are actually sharing this frequency with
their neighbors wireless networks. Further, cordless phones and microwave ovens also competing
for space on the 2.4 GHz frequency. But with Double 108, users can access the 5 GHz 802.11a
"Fast Lane" and avoid all of the crowds and congestion.
The Double 108 takes the guesswork out of securing your home network. WPA-PSK (Wi-Fi
Protected Access Pre-Shared Key) is already activated to protect your network from unauthorized
usage. And for online gamers, a dedicated hardware DMZ port is provided for secure gaming.
Two Networks in One
Extra Range
Avoid the Crowd
Security Made Simple
• Help is there when you need it!
NETGEAR provides 24x7
technical support* in English,
with selected local language
support during office hours.
router
10 8
/5
2x

Home Office with
WG311T Wireless
PCI Adapter
Gaming console with
WGE111 Game Adapter
NETGEAR
3
Broadband
modem
802.11g
Notebook PC with
WG511U Wireless
PC Card TV with
Media Player
Dedicated 108 Mbps path for
high quality video streaming
Media Center PC
802.11a
Everybody’s Connecting. ™
Product Specifications
• Standards:
-IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
• Dimensions:
-6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
• Weight:
-.7 lbs (.3 kg)
• Warranty:
-NETGEAR 1-year warranty(see information
enclosed)
Key Features
• Ease of Use:
-Smart Wizard: Automatic detection & connection
to Internet Service Provider
-Allows sharing of an Internet connection
-Interactive installation demonstration & tutorial
-Assisted upgrade: automatically finds & installs
software upgrades
-Fully compatible with 802.11a, 802.11b,and
802.11g devices
• Speed and Range:
-Two networks, each with up to 108 Mbps, 10x
the speed of 802.11b
-XR Technology for whole home/small office
coverage for extended range
-Five10/100 (1 Internet, & 4 LAN) ports
equipped with auto-sensing technology
-Utilizes 2.4 GHz and 5.0 GHz frequencies for 15
non-overlapping channels Automatic MDI/MDIX
-No special cable required
• Performance Boosting Features (all automatic):
-Dynamic packet bursting for priority traffic
-Fast frames for faster transmission
-Hardware compression for large file transfers
-Dynamic 108 for concurrent interoperability of
11a, 11b, 11g and 108-mode clients
• Security:
-Double Firewall:
- Network Address Translation (NAT) to hide PCs
& files from outside users
- Stateful Packet Inspection (SPI) firewall to deny
outside requests for personal information
-Denial of Service (DoS) attack prevention
-Intrusion Detection and Prevention (IDS)
-Wired Equivalent Privacy (WEP) 64-bit,
128-bit encryption
-Wi-Fi Protected Access (WPA, Pre-Shared Key)
-Wireless Access Control to identify
authorized wireless network devices
WGU624 Double 108 Mbps Wireless Firewall Router
-Multiple VPN Tunnels (Pass-Through, IPSec, and
multiple L2TP & PPTP)
-Exposed Host (Hardware DMZ port) for secure gaming
-MAC address authentication
• Privacy Control & Management:
-"Trusted user" controls
-Time-based usage controls
-Web site logging
-Remote management
-URL content filtering
System Requirements
-Broadband (cable, DSL) Internet service and modem
with Ethernet connection
-2.4 GHz 802.11 b/g or dual band 2.4/ 5 GHz 802.11
a/b/g wireless adapter Alternatively, an Ethernet adapter
and cable for each computer
-Windows®98, Me, NT, 2000, XP, Mac®OS,
NetWare®, UNIX®, or Linux®
-Internet Explorer 5.0 or Netscape®4.7 or higher
-Recommended: WG511U Double 108 Mbps Wireless
PC Card
Package Contents
-Double 108 Mbps Wireless Firewall Router
(WGU624)
-5V, 2.8 A power adapter, localized to country of sale
-Vertical stand
-Ethernet cable
-Setup Guide
-Resource CD
-Warranty/Support information card
NETGEAR Related Products
-WG511U Double 108 Mbps PC Card
-WG111 54 Mbps USB 2.0 Adapter
-WG311T 108 Mbps PCI Adapter
-MP101 Digital Music Player
-WGE111 54 Mbps Game Adapter
4500 Great America Parkway
Santa Clara, CA 95054 USA
Phone: 1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
©2004 NETGEAR, Inc. NETGEAR®, the
Netgear Logo, Auto Uplink, and
Everybody’s connecting are trademarks or
registered trademarks of Netgear, Inc. in
the United States and/or other countries.
Microsoft, Windows, and the Windows
logo are trademarks, or registered
trademarks of Microsoft Corporation in
the United States and/or other countries.
Other brand and product names are
trademarks or registered trademarks of
their respective holders. Information is
subject to change without notice. All rights
reserved.
* Free basic installation support provided
for 90 days from date of purchase.
Advanced product features and
configurations are not included in free
basic installation support; optional
premium support available.
D-WGU624-0
Max Range (Indoor)
*Actual results will vary depending upon operating environment
WGU624 with new XR Technology
400
+
ft.
0336 !
0768 !
0560 !
