netvox R718PDA User manual

Model：R718PDA
Wireless RS232Adaptor
0
Wireless RS232 Adaptor
User manual

1
Table of Content
1. Statement................................................................................................................................................................................................................................................................ 2
2. Appearance.......................................................................................................................................................................................................................................................... 2
3. Introduction..........................................................................................................................................................................................................................................................2
4. Main Characteristics..........................................................................................................................................................................................................................................2
5. Operation.............................................................................................................................................................................................................................................................. 3
6. Installation.............................................................................................................................................................................................................................................................6
7. Important Maintenance Instruction............................................................................................................................................................................................................... 6

2
1. Statement
Reproduction, transfer, distribution and storage of any part of this document in any form without the prior written permission of Netvox.
Netvox follows a strategy of continuous development. Therefore, Netvox reserves the right to make changes and improvements to any of the products described in this
document without prior notice.
Under no circumstances will Netvox be liable for any loss of data or income, or for any special, incidental, incidental or consequential damages, regardless of the cause of
the loss.
The contents of this document are provided "as is". Except as otherwise provided by applicable law, no warranty of any kind, express or implied, as to the implied warranties
of merchantability and fitness for a particular purpose, is made with respect to the accuracy, reliability or content of this document. Netvox reserves the right to revise or
withdraw this document at any time without prior notice.
2. Appearance
3. Introduction
The R718PDA is a Class C type device based on the LoRaWAN open protocol of Netvox and is compatible with the LoRaWAN protocol.
The R718PDA can transmit the serial port transparently and directly report the information received by the serial port to the corresponding gateway. Serial port transparent
transmission only supports RS-232 protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other communication methods,
LoRa spread spectrum modulation method greatly increases to expand the communication distance. Widely used in long-distance, low-data wireless
communications. For example, automatic meter reading, building automation equipment, wireless security systems, industrial monitoring. Main
features include small size, low power consumption, transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and gateways from different
manufacturers.
4. Main Characteristics
Compatible with LoRaWAN
Power is supplied from an external 12V power supply
Support RS232 series port
Simple operation and setting

3
5. Operation
On/Off
Power on External 12V power supply
Turn on Press and hold the function key for 3 seconds till the green indicator flashes once.
Turn off
(Restore to factory setting) Press and hold the function key for 5 seconds till the green indicator flashes for 20 times.
Power off Remove power
Note:
1. At 1st -5th second after power on, the device will be in engineering test mode.
2. Remove and supply the power; the device is at off state by default. Need to be turned on to use.
3. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor
inductance and other energy storage components.
Network Joining
Never joined the network
(Or at factory setting )
Turn on the device to search the network.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Had joined the network
(Not at factory setting.)
Turn on the device to search the previous network.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Fail to join the network
(when the device is on)
First two mins: wake up every 15 seconds to send request.
After two mins: enter sleeping mode and wake up every 15 minutes to send request.
Note: Suggest to remove batteries if the device is not used to save power.
Suggest to check the device verification information on the gateway
or consult your platform server provider.
Function Key
Press and hold for 5 seconds
Restore to factory setting / Turn off
The green indicator flashes for 20 times: success
The green indicator remains off: fail
Press once
The device is in the network: 87+ReceiveData
(ReceiveData is the most recently received data) format packet
The device is not in the network: the green indicator remains off
Serial Transmission Rate Configuration
Serial Transmission Rate Default Value 9600
Configuration Method Downlink instructions through LORANWAN
Serial Transmission Rate Option
00 Baudrate = 115200；01 Baudrate = 57600；02 Baudrate = 38400；
03 Baudrate = 28800；04 Baudrate = 19200；05 Baudrate = 9600；
06 Baudrate = 4800；07 Baudrate = 2400；

4
Data Report
The device will send a version package report immediately after powering on the device.
The device has no operation until any configuration is done.
The device sends a down-link command configuration with LOLAWAN for the data that needs to be sent
through the R232 and sends the data received by the R232 to the gateway.
The device sends a down-link command with LoRaWan to send the data periodically.
When the RS232 interface of the R718PDA receives the serial port data sent from the RS232 device connected
to it, it will actively report the received data to the gateway in the format of 87+ReceiveData.
The data report can be decoded by the Netvox LoraWAN Application Command document and
http://www.netvox.com.cn:8888/page/index
Data Report Cycle Configuration Example:
Configure device cycle Period = 30s
Downlink: 03001E
Device returns:
8300 (configuration successful)
8301 (configuration failed)
(1) Read device parameters
Downlink: 04
Device returns:
84001E (current device parameters)
Data Report Configuration Example:
Description Device CmdID NetvoxPayLoadData
SetPollSensorPer
iodReq
R718PD
A
0x03 Period(2Byte，Unit：1s)
SetPollSensorPer
iodRsp
0x83
Status(0x00_success)
GetPollSensorPe
riodReq
0x04
GetPollSensorPe
riodRsp
0x84 Period(2Byte，Unit：1s)
Description Device CmdID NetvoxPayLoadData
SetPollSensorR
awCmdReq
R718PDA
0x05 SensorRawCmd
SetPollSensorR
awCmdRsp
0x85 Status(0x00_success)
GetPollSensor
RawCmdReq
0x06

5
Data Report Configuration Example:
(2) Configuring the device SensorRawCmd
Downlink: 05112233445566
Device return: 8500 (configuration is successful)
8501 (configuration failed)
(3) Read SensorRawCmd
Downlink: 06
Device return: 86112233445566 (device current SensorRawCmd)
Serial Transmission Rate Configuration Example:
For example, the configuration serial transmission rate is 115200.
Downlink: 0800
Device return: 8800 (configuration succeeded)
8801 (configuration failed)
Read device serial transmission rate parameter
Downlink: 09
Device return: 8900 (device current parameter)
GetPollSensor
RawCmdRsp
0x86 SensorRawCmd
Description Device CmdID NetvoxPayLoadData
SetBaudRateRe
q
R718PD
A
0x08 BaudRateType（1Byte）
SetBaudRateRs
p
0x88 Status(0x00_success)
GetBaudRateR
eq
0x09
GetBaudRateR
sp
0x89 BaudRateType（1Byte）

6
6. Installation
7. Important Maintenance Instruction
Your device is a product of superior design and craftsmanship and should be used with care. The following suggestions will help you use the warranty
service effectively.
• Keep the equipment dry. Rain, moisture, and various liquids or moisture may contain minerals that can corrode electronic circuits. In case the device
is wet, please dry it completely.
• Do not use or store in dusty or dirty areas. This can damage its detachable parts and electronic components.
• Do not store in excessive heat. High temperatures can shorten the life of electronic devices, destroy batteries, and deform or melt some plastic parts.
• Do not store in a cold place. Otherwise, when the temperature rises to normal temperature, moisture will form inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate structures.
• Do not wash with strong chemicals, detergents or strong detergents.
• Do not apply with paint. Smudges can block debris in detachable parts and affect normal operation.
• Do not throw the battery into a fire to prevent the battery from exploding. Damaged batteries may also explode.
All of the above suggestions apply equally to your device, battery and accessories. If any device is not working properly.
Please take it to the nearest authorized service facility for repair.
1. The LoRa to RS-232 adapter (R718PD) has
a built-in magnet (see Figure 1 below). It can
be attached to the surface of an object with
iron material during installation, which is
convenient and quick. To make the installation
more secure, please use screws (purchased
separately) to fix the device to the wall or
other objects (as shown below).
Comment
Do not install the device in a metal shielded
box or in an environment surrounded by other
electrical equipment to avoid affecting the
wireless transmission of the device.
1. Connect the yellow wire (RXD), white wire (TXD), and
black wire (GND) to the corresponding interfaces of the
RS232 serial device.
2. LoRa to RS-232 adapter (R718PD) supports serial port
transparent transmission, and sends commands or reads data
to the connected RS232 device according to the configured
cycle time. The read information will be reported directly to
the gateway.
LoRa to RS-232 adapter (R718PD) can be applied to
equipment with RS232 serial port.
E.g:
UPS un-interruptible power supply
Access control
Hard disk player
Other devices with RS232 serial port
