NetZero UMX Instruction Manual

START HERE
UMXTM 4G LTE Hotspot
Key Features
•Supports up to 10 Wi-Fi
enabled devices
•Continuous battery use available
up to 4 hours
•4G LTE with 3G backup
•Compact size with integrated
battery
STEP: 1 Charge Battery
a) CHARGE BATTERY even if the battery already has some charge,
it is recommended that you charge the battery prior to using
your device.
STEP: 2 Power and Position
a) POWER ON the device by pressing the Power button down
for no less than 5 seconds and wait for the Indicator light to
turn on.
b) ACTIVATING DEVICE The device will automatically go through
a self-activation process that will take several minutes,
depending on network traffic and signal strength.
c) POSITION DEVICE for the three Signal Strength lights
(located on the front edge) to show the most lights possible.
This will indicate if the device has a strong enough signal to
connect. If this indicator has one or no lights, then the signal
is too weak.
Tips to Improve Signal Strength:
•Make sure you’re in a network coverage area.
•Try re-orienting your device.
•Move your computer to another location —you may be in
or near a structure that is blocking the signal. Every obstacle
(for example, walls, ceilings, furniture) decreases the signal
strength.
•Make sure there’s plenty of space around your device to
provide the best signal reception.
•If you cannot obtain service, contact your data service
provider —a network or account problem may be
preventing you from obtaining service.
STEP: 3 Wi-Fi Connection
Default Wi-Fi Security Key is: netzerowifi
Complete one of the following, depending on your operating
system, to establish a Wi-Fi connection:
a) Windows 10, 8 and 7: Right-click the Wi-Fi icon in the
system tray.
b) Windows Vista: Click Control Panel > Network and Internet
> Network and Sharing Center > Connect to a network.
c) Windows XP: Click Control Panel > Network Connections >
Wireless Network Connections > View available wireless
networks.
d) Mac: Click the AirPort icon in the upper right corner of
your screen.
**Once you have established a Wi-Fi connection with your
Hotspot device, please create a personalized Wi-Fi Security Key
as described in Step 4.

For additional assistance please visit our support site:
http://help.netzero.net
To contact us by email:
[e-mail]
CHARGING
When charging, the battery status lights up and dims down, similar
to the sleeping mode.
Power status of the LED lights are as follows :
•When the device is below 30% charged, the lights blink red
•When the device is between 30% ~ 60% charged, the lights blink
yellow
•When the device is above 60% charged, the lights blink green
•When fully charged the lights stop blinking and remain solid green
INDICATORSSTEP: 4 Personalized Wi-Fi Security Key
For added security, please personalize a Wi-Fi Security Key to
prevent any un-authorized connection to your Hotspot device.
a) Launch a web browser, such as Internet Explorer, Chrome, Safari
or Firefox, and type 192.168.1.1/index.asp in the address bar.
b) From the login screen use Password: 123456
c) Click on the WiFi Tab
From the Security Type dropdown field: select WPA/WPA2
Mixed
From the WPA Algorithms dropdown field: select TKIP+AES
From the WPA Key dropdown field: enter a minimum 8
character Security Key.
d) Press Apply
e) Press Reboot to save the setting
Note: Once complete, you will have to reconnect your device with
the newly created Security Key. See Step: 3
Power Key:
To turn On, hold for 5 seconds.
To turn Off, hold until the Battery Light blinks red.
For Sleep Mode, press and hold the Power button for 2 seconds.
Signal Strength Light:
Three white lights: Signal strength is strong
Two white lights: Signal strength is better
One white light: Signal is weak
No light: No signal, or network obstacle
Battery Light:
Green: Battery level is good (100-60%)
Yellow: Battery level is low (60-30%)
Red: Battery needs to be charged (30-0%)
Sleep Mode Light:
On: Wi-Fi is in sleep mode
Off: Wi-Fi is turned on
Reset Button:
Press and hold for 5 seconds. This is equivalent to removing the
battery.
