neverdark FIRETEC F Guide

Technical documentation
Smart fireplace
FIRETEC
(F)
neverdark.one

1200
250
1100 line of fire
Automatic ethanol fireplace Firetec •
Manufacturer NEVERDARK •
This document is part of the device •
For decorative and domestic use only •
Keep away from children •
Ensure that the wall/table/floor on which you place the appliance can support its weight •
Install only in a place protected from through ventilation / draughts •
Slots for convection air and overhead vents mast not be covered •
Do not place flammable objects on the appliance •
Keep a carbon dioxide fire extinguisher within sight •
Automatic ethanol fireplace Firetec
Z
X-100
Line of fire
X
Y
Power consumption 900 W
weight 31.16 kg
SN A12_____
Automatic bioethanol fireplace
"Firetec"
Automatic bioethanol fireplace Firetec •
Manufacturer: Neverdark LLC, Ukraine •
This document is part of the device •
For decorative and domestic use only •
X Y Z
Model Code Length, mm Width, mm Height, mm Weight, kg
Firetec 700 F7 700
250 205
20.5
Firetec 800 F8 800 21.1
Firetec 1000 F10 1000 26
Firetec 1200 F12 1200 29
Firetec 1500 F15 1500 32.3
Firetec 2000 F20 2000 48
Firetec 2500 F25 2500 58
2
NEVERDARK Firetec
Technical documentation
General view
neverdark.one

100
8
X-100
50
GB
Glass border
CT
Custom Top
EFT
Enlarged Fuel Tank
Standard
top panel
(black gloss)
Стеклянный бортик •
Покрытие черный мат (без доплаты) •
Верхняя поверхность из нержавеющей стали •
Покраска в любой чвет по RAL •
Внешний модуль управления и заправки ARS500 •
Пульт дистанционного управления •
Подключение к умному дому (сухие контакты) •
Доступные опции
Standard configuration
Available options
GB(1,2) Glass border
CT
(RG,RM,M,I)
Custom Top (RAL
Glossy, RAL Matte,
Matte, Inox)
EFT Enlarged Fuel Tank
ARS
External module for
control and refueling
RC Remote Control
SH
Smart Home
Connection Module
Fireplace 1pc
Handles for mounting 2pc
Power cable with plug (euro) 1pc
Filling hose 1pc
Fuel drain hose (service only) 1pc
Instructions 1pc
Warranty card 1pc
Micro USB cable (service only) 1pc
Packaging 1pc
3
NEVERDARK Firetec
Technical documentation
Options
neverdark.one

1
B
B
C
C
min 20
min 20
227
Clearance 6 Clearance 6
240
Cutout
min 20
min 20
200
Clearance 6
X-22
X-10
±1
Cutout
min220
214
C-C (1 : 10)
X
250
X-100
Line of fire
Screw in
handles for mounting
(unscrew after installation)
4
NEVERDARK Firetec
Technical documentation
Dimensions
neverdark.one

min 50
min 100
min 50
min 1000
To curtains
or easily
flammable objects
min 400
240
±1
X-10
±1
min 220
Heat-resistant material
Heat-resistant material
Upper part needs to be
made of heat-resistant
material - temperature
up to130
С
Hot air output
for mounting without a thermobox
The surface can be heated up to 80
C
The canopy can be used
to divert hot air
from the surface
Outlet
or connection point
in the niche
3x2.5 cable
Required
air supply
into the fireplace niche
at least 100 cm²
Align horizontally
WARNING!
The manufacturer does not recommend placing objects above or next to the fireplace that are
sensitive to high temperatures, as this can significantly shorten their service life. If the technical
documentation were not followed, the manufacturer is not responsible for any damage to objects
above or next to the fireplace resulting from exposure to high temperatures.
5
NEVERDARK Firetec
Technical documentation
Niche requirements
neverdark.one

Required air supply horizontally
into the fireplace niche at
least 100 cm²
min 1000 mm from burner to
flammable objects
(curtains or upholstered furniture, etc.)
Align horizontally
Outlet
or connection point
3x2.5 cable
220V connection must be
carried out by a
qualified technician
Screw in
handles for mounting
(unscrew after installation)
The use of a separate line is compulsory
separate line
with a fuse and/or circuit breaker
WARNING!
Installation of the fireplace not on a horizontal level can lead to malfunction of the fireplace and •
possible fuel spillage;
Only a qualified specialist should connect the cable to the power grid; •
The fireplace must be mounted in the prepared niche by holding the previously installed handles •
for installation, then the handles must be removed (unscrewed) and not used during the operation
of the fireplace;
If it is necessary to remove the fireplace from the niche, reinstall the installation handles; •
Ensure that the product is correctly installed and read the user manual supplied with it; •
Do not fill the fuel tank and do not turn on the fireplace without first reading the user manual; •
If it becomes necessary to remove the fireplace from niche, wait until the fuel has burned out •
сompletely and the display shows the message that the tank is empty, switch the fireplace off, and
disconnect it from the power supply, then remove it from the niche.
There must be a fire extinguisher in the room within sight
6
NEVERDARK Firetec
Technical documentation
Installation
neverdark.one

Air vents
Drainer
(for service
professionals
only)
Air vents
Glow plug
(auto ignition)
Fire burning line
No-touch sensor
Control panel cover
with automatic opening
D
Power cable 220V
H
I
D
Filler neck
Touch Screen
F
F (1 : 5)
F
G
H
I
Power button
USB port
(for service professionals only)
7
NEVERDARK Firetec Technical
documentation
Fireplace interface
neverdark.one

Держите подальше от детей. •
Убедитесь, что стена / стол / пол, на котором вы размещаете прибор,может •
выдержать его вес.
Устанавливайте только в защищенном от сквозняков месте. •
Верхние и боковые вентиляционные решетки не должны быть закрыты. •
Не ставьте легковоспламеняющиеся предметы на прибор. •
Для комфортного использования камина необходимо обеспечить приток •
свежего воздуха и удаление продуктов горения. Это может быть вытяжка, •
рекуператор или открытое окно.
Держите углекислотный огнетушитель в пределах видимости. •
Производитель не рекомендует размещать рядом с камином предметы, •
чувствительные к высоким температурам, так как это может значительно
сократить срок их службы.
Производитель не несет ответственности за любой ущерб предметам над •
камином, возникший в результате воздействия высоких температур.
Keep away from children; •
Ensure that the wall/table/floor on which you place the appliance can support its weight; •
Install only in a place protected from draughts; •
Do not cover top and side ventilation grids; •
Do not place flammable objects on the appliance; •
Keep a carbon dioxide fire extinguisher within sight; •
The use of a separate line with a fuse and/or circuit breaker is compulsory; •
For comfortable use of the fireplace it is necessary to ensure the supply of fresh air into the •
room and a removal of combustion products. It can be a ventilation extractor, recuperator
or an opened window;
Keep these installation instructions for the life of the fireplace. •
8
