New Air MINIDRYER36W User manual

MINIDRYER36W
Portable Dryer
3.6 Cubic Feet
OWNERS MANUAL
Read and save these instructions.

2
http://www.NewAir.com
A Name You Can Trust
Trust has to be earned and we will earn yours. Customer happiness is the
focus of our business.
From the factory to the warehouse, from the sales floor to your home, the
whole NewAir family promises to provide you with innovative products,
exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots
here, real people shipped your product and real people are here to help
you.
Thank you for your purchase and remember NewAir, A Name You Can
Trust.
Call us today at 855-963-9247
Or email [e-mail]
For future reference, we recommend you attach a copy of your sales receipt here and
record the following information. You will need this information if it becomes
necessary to contact the manufacturer for service inquiries.
Date of Purchase:
Serial Number:
Model Number:
Connect with us online.

3
A Name You Can Trust
READ AND SAVE THESE INSTRUCTIONS
TABLE OF CONTENTS
Introduction ..................................................................................................................... 2
Need to Contact Us..............................................................................................2
Table of Contents............................................................................................................3
Product Specifications.......................................................................................... 3
Important Safeguards......................................................................................................4
For Your Safety .................................................................................................... 4
Parts Lists ....................................................................................................................... 7
Installation Instructions....................................................................................................8
Where to Place Your Dryer...................................................................................8
Wall Mounting Instructions..............................................................................................8
Operating Your Dryer.................................................................................................... 10
Electrical Requirements...................................................................................... 10
Loading the Dryer............................................................................................... 10
Tips Before Drying.............................................................................................. 11
Drying Time...................................................................................................................11
Control Panel Functions................................................................................................ 12
Heat Selector Button .......................................................................................... 12
Drying Program Selector .................................................................................... 12
Operation Precautions................................................................................................... 12
Maintenance.................................................................................................................. 14
Cleaning the Lint Filter........................................................................................ 14
Cleaning of the Air Intake Filter .......................................................................... 15
Cleaning the Interior & Exterior of the Dryer....................................................... 15
Troubleshooting ............................................................................................................ 16
Limited Manufacturer’s Warranty ..................................................................................17
PRODUCT SPECIFICATIONS
Model No.:
MiniDryer36W
Drying Capacity:
13.2Lbs
Power Source:
120V AC 60Hz
Rated Input:
1500W
Dimensions:
23.6 x 21.5 x 27.6 inches
Net Weight:
50.7Lbs

4
http://www.NewAir.com
IMPORTANT SAFEGUARDS
WARNING: When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric shock,
and/or injury.
FOR YOUR SAFETY
Read all instructions carefully, even if you are familiar with the appliance.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is in use.
This appliance is not intended for outdoor use, INDOOR USE ONLY.
Do not place flammable objects, such as candles, on the appliance.
Do not place the appliance or cord near heat sources, such as radiators, heaters, air
ducts, or direct sunlight.
Do not block any of the ventilation openings. Ensure that the vents are not covered
by newspapers, tablecloths, curtains, etc.
Do not run the cord under floor coverings. Instead, arrange the cord where it will not
become a trip hazard.
To disconnect the appliance do the following: turn the appliance off, switch off the
power outlet, and remove the plug from the power outlet.
Do not misuse the cord. Never carry the appliance by the cord, or pull to disconnect
it from the outlet. Instead, grasp the plug and pull to disconnect.
If any of the following occur do not operate the appliance: if it has a damaged cord or
plug, if the appliance malfunctions, or it has been dropped or damaged in any way.
Consult the manufacturer as soon as possible.
Do not attempt to repair, disassemble, or modify this appliance. The warranty
becomes void if not serviced or repaired by a qualified person.

5
A Name You Can Trust
Do not reach into the appliance if the drum is moving.
Do not place items that have been soiled with flammable liquids inside the dryer
without washing them with detergent thoroughly before hand.
Do not excessively bend, stretch, twist, or bind the power cord, or place heavy
objects on it.
Do not install in a tight fitting cabinet.
Do not overload the tumble dryer.
Do not dry items that have been previously cleaned in, washed in, soaked in, or
spotted with gasoline, dry cleaning solvents, or other flammable or explosive
substances, as they give off vapors that could ignite or explode.
Before the appliance is removed from service or discarded, remove the door to the
drying compartment.
Do not install or store this appliance where it will be exposed to the weather.
Do not tamper with controls.
Do not repair or replace any part of the appliance or attempt any servicing, unless
specifically recommended in this manual that you understand and have the skills to
carry out.
Do not use fabric softeners or products to eliminate static, unless recommended by
the manufacturer of the fabric softener or product.
Do not use heat to dry items containing foam rubber or similarly textured rubber-like
materials.
Keep the area around the exhaust opening and adjacent surrounding areas free
from the accumulation of lint, dust, and dirt.
The interior of the appliance and exhaust duct should be cleaned periodically by
qualified service personnel.
Do not place items exposed to cooking oils in your dryer. Items contaminated with
cooking oils may contribute to a chemical reaction that could cause the load to catch
fire.
Ensure foreign objects do not find their way into the tub of the tumble dryer.

6
http://www.NewAir.com
Clean lint screen before or after each load.
Do not dry unwashed items in the tumble dryer.
Items that have been soiled with substances, such as cooking oil, acetone, alcohol,
petrol, kerosene, hair care products, spot removers, turpentine, waxes, and wax
removers should be washed in hot water with an extra amount of detergent before
being dried in the tumble dryer. This will reduce, but not eliminate the hazard.
Fabric softeners, or similar products, should be used as specified by the fabric
softener instructions.
The final part of a tumble dryer cycle occurs without heat, this is the cool down cycle
that ensures the items are left at a temperature that the items will not be damaged.
WARNING: Oil affected items can ignite spontaneously, especially
when exposed to heat sources, such as in a tumble dryer. The items
become warm, causing an oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape, the items can become hot
enough to catch fire. Piling, stacking, or storing oil affected items
can prevent heat from escaping and so create a fire hazard.
The installation for this portable dryer must be performed by a qualified installer
according to the manufacturer’s instructions and local codes.
Do not install flexible plastic venting materials to clothes dryer. If flexible foil metal
duct is installed, it must be a specific type that has been identified by the appliance’s
manufacturer and is suitable for use with clothes dryers. Flexible venting materials
are known to collapse, be easily crushed, and trap lint. These conditions will
obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
Connect to individual branch circuit.
This appliance must be grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance
for electric current. This appliance is equipped with a cord having an equipment
grounding conductor and grounded in accordance with all local codes and
ordinances.
Improper connection of the equipment grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service representative or
personnel if you are in doubt as to whether the appliance is properly grounded.

7
A Name You Can Trust
Do not modify the plug provided with the appliance. If it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
Do not place the dryer on carpet, as this will block the intake. It must be placed on
firm horizontal ground. There should be at least 4 inches between the dryer and the
walls.
WARNING: This dryer cannot be used upside down.
PARTS LIST
NOTE: Consistent with our continuing product development policy,
improvements may have been made which render the contents of this
package slightly different to that shown.

8
http://www.NewAir.com
INSTALLATION INSTRUCTIONS
WARNING: This dryer cannot be used upside down.
WHERE TO PLACE YOUR DRYER
Place the dryer in a dry, well ventilated area. It should be positioned away from heat
and direct sunlight.
If the dryer is not wall mounted, it must be placed on firm horizontal ground. Do not
place the dryer on carpet, as this will block the intake. There should be at least 6 inches
between the dryer and the walls.
The dryer comes with fixed legs that need to be
assembled to ensure stability.
If the dryer is rack mounted, a secure bracket is required to ensure stability and prevent
vibration. At least 6 inches are required between the dryer and walls. (The bracket is
not included.)
WALL MOUNTING INSTRUCTIONS
1. Determine the position on the wall for the dryer and mark the required bracket
position. This dryer is not suitable to be directly placed on top of a washing
machine.
A minimum of 2 inches is needed between the top of the dryer and the
ceiling for ease of installation.
If mounting above a washing machine, allow sufficient room to open
the lid of the washer.

9
A Name You Can Trust
2. Fix the wall hanging brackets (two supplied) to the wall securely (i.e., into the stud.)
Fit a timer slat between the studs to mount the brackets onto if the stud position is
too wide.
3. To install the hanging hook to timber, start at
Fig. 2.
4. Align the hanging hooks and fasten the screws tightly.
5. Install the Exhaust Connector. Adjust the
direction to suit the installation (as per Fig. 3).
6. Rotate the Connector clockwise to fix the pipe
to the Connector Base. Tighten.

10
http://www.NewAir.com
7. Use 4 x 12mm screws (provided) to fix the 2
spacers as per Fig. 4.
8. With assistance, mount dryer on wall bracket.
See Fig. 5
OPERATING YOUR DRYER
ELECTRICAL REQUIREMENTS
The unit is required to be plugged into a three pin
socket that is reliably grounded.
The power supply must be 120V. Plus the power
cord into the socket.
LOADING THE DRYER
It is recommended that items are placed into the
dryer one at a time. This ensures they are not
tangled, which results in uneven drying. When
closing the dryer door prior to starting the unit,
ensure that items are not jammed in the door.

11
A Name You Can Trust
TIPS BEFORE DRYING
Prior to loading the dryer, check that the items
do not have the following symbols anywhere
on them. If they do, do not tumble dry these
items.
Check that the items that are going to be dried
do not have combustible materials or foreign
objects within them (i.e., lighters, hair pins,
coins.)
Turn items with zippers inside out and fasten
buckles.
Dryer heat may permanently set stains, ensure you check prior to drying that stains
are removed.
Separate dark and light colored items as you would do when washing.
For best results, load dryer with similar fabrics. Place small delicate items in a mesh
bag and do not overload the dryer.
The maximum capacity is 13.2 pounds of dry textile material, do not overload. The
tumble dryer is intended only for drying textile material washed in water.
DRYING TIME REFERENCE TABLE
Drying
Capacity
Dry Time
High
Low
Approx. 4.4Lb
Approx. 60 min
Approx. 110 min
Approx. 8.8Lb
Approx. 1220 min
Approx. 150 min
Approx. 13.2Lb
Approx. 200 min
-
Drying times can be affected by many factors, such as material, bulkiness, how full the
dryer is, etc. The above list is a guide only.

12
http://www.NewAir.com
CONTROL PANEL FUNCTIONS
HEAT SELECTOR BUTTON
Select HIGH for items that are particularly bulky or
large quantities.
Select LOW for delicate items, such as silk, nylon,
linen, etc.
DRYING PROGRAM SELECTOR
OPERATION PRECAUTIONS
Delicate items should be placed into a nylon net
bag prior to drying. It is not recommended to dry
underwire bras in this unit.
Ensure that foreign objects do not find their way
into the dryer. All pockets should be emptied,
buttons, buckles, and zips fastened. This will also
help reduce impact noise when the items hit

13
A Name You Can Trust
against the turning drum.
Do not add items into the dryer while it is in
operation.
If drying large items, such as a blanket, it is
recommended that from time to time, you open the
dryer door, shake the items, place the item back in
the dryer and close the door. This will ensure
even drying.
If any of the labels shown are on items that you
are going to place in the dryer, do not place in the
dryer, for it may damage the item.
Electrical Requirements: A three pin socket must
be used (reliably grounded.)
To ensure you get the most out of the anti-wrinkle
function, do not overload the dryer and remove the
dried items from the dryer immediately and hang
on coat hangers. If desired, iron the items
afterwards.
To minimize the risk of fire in a tumble dryer, the following should be observed:
Items that have been spotted or soaked with vegetable or cooking oil constitute a
fire hazard and should not be placed in a tumble dryer.
Oil affected items can ignite spontaneously, especially when exposed to heat
sources, such as in a tumble dryer. The items become warm, causing an
oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling, stacking, or storing oil
affected items can prevent heat from escaping and so create a fire hazard.
If fabrics contain vegetable or cooking oil or have been contaminated by hair care
products, they should first be washed in hot water with extra detergent –this will
reduce, but not eliminate, the hazard.
The “cool down” cycle of tumble dryers should be used to reduce the
temperature of the items. The items should not be removed from the tumble
dryer or piled or stacked while hot.

14
http://www.NewAir.com
Items that have been previously cleaned in, washing in, soaked in or spotted with
petrol/gasoline, dry cleaning solvents, or other flammable or explosive
substances should not be placed in a tumble dryer.
Highly flammable substances commonly used in domestic environments include
but are not limited to: acetone, denatured alcohol, petrol/gasoline, kerosene, spot
removers (some brands), turpentine, waxes, and wax removers.
Items containing foam rubber (also known as latex foam) or similarly textured
rubber-like materials should not be dried in a tumble dryer on a heat setting.
Foam rubber materials can, when heated, produce fire by spontaneous
combustion.
Fabric softeners, or similar products, should not be used in a tumble dryer to
eliminate the effects of static electricity, unless this practice is specifically
recommended by the manufacturer of the fabric softener or product.
Undergarments that contain metal reinforcements should not be placed in a
tumble dryer. Damage to the tumble dryer can result if metal reinforcements
come loose during drying. If available, a drying rack could be used for such
items.
Plastic articles, such as shower caps or babies’ waterproof napkin covers should
not be placed in a tumble dryer.
Rubber backed articles, clothes fitted with foam rubber pads, pillows, galoshes,
and rubber coated tennis shoes should not be placed in a tumble dryer.
MAINTENANCE
CLEANING THE LINT FILTER
Please unplug the power cord prior to any cleaning. The lint filter must
be in place whenever drying. It must be cleaned before each use.
1. Removing the filters. The filter is in three parts:
exhaust vent shroud, lint filter, and exhaust
filter (as shown in Fig. 1.) Remove by pulling
outwards with fingers, by inserting into the four
holes around the exhaust vent shroud.

15
A Name You Can Trust
2. Cleaning the filter. Separate the “exhaust vent
shroud,” the “lint filter,” and the “exhaust filter.”
Clean the lint on the lint filter and exhaust filter
with a soft brush or vacuum cleaner. Do not
damage the filters (as shown in Fig. 2.)
3. Re-installing the filter. After cleaning the filter,
assemble in the sequence of the “exhaust
filter,” the “lint filter,” and the “exhaust filter.”
Alight the recesses in the center with the
projection in the center of the drum. Make
sure that it is firmly inserted (as shown in
Fig. 3.)
The filter fixed in the bottom of the drum should also be cleaned with a
soft brush.
CLEANING OF THE AIR INTAKE FILTER
The filter should be cleaned once a month.
Remove by pulling outwards holding the upper
and lower ends of the air intake shroud. Remove
the filter inside the shroud and clean it with a soft
brush. Reassemble and install as before.
Slightly push upwards with your thumb until the latch hook disconnects, and then
remove.
CLEANING THE INTERIOR & EXTERIOR OF THE DRYER
1. Do not wash directly with water.
2. Do not use thinner, gasoline, or alcohol.
3. Do not use any type of spray cleaner when cleaning the interior. If dryer drum
becomes stained, clean the drum with a damp cloth.
4. Remove any residue before drying the next load.
5. Clean cabinet with mild soap and water. Do not use harsh or abrasive cleansers, this
could damage the dryer.
CAUTION: HOT SURFACE!! Do not touch the intake during the drying
cycle due to high temperatures.

16
http://www.NewAir.com
TROUBLESHOOTING
Review the following pages before calling for service.
Problem
Possible Causes
Solution
Timer knob does not
work
The power cord is not
inserted firmly
Insert the power cord firmly
Drum does not turn
The door is not closed
Close the door
The power cord is not
inserted
Insert the power cord firmly
The receptacle does not
have power
Check the power cord
receptacle
Hot air is not blowing out
The timer is set incorrectly
on cold air
Set the time to hot air
The laundry is not
thoroughly dried
The front and back filters
are clogged
Clean the filter
There is too much clothes
in the dryer
Reduce the amount of
clothes in the dryer
Items were added while the
dryer is in operation
Re-dry the items again
The clothes became twisted
while drying
Untwist the items and
re-dry
The dryer is placed in a
small and badly ventilated
area
Place the dryer in a well
vented area
The set on the dryer is set
to ANTI-WRINKLE
Try using WARM or HOT
setting instead
Dryer does not start
Power failure
Try again when there is
power
The power cord is not
inserted firmly
Insert the power cord firmly
The door is not closed
Close the door
The timer is set to the OFF
position
Set the dry time

17
A Name You Can Trust
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year from the
original date of purchase, the manufacturer will repair or replace any parts of this
appliance that prove to be defective in materials and workmanship, provided the
appliance has been used under normal operating conditions as intended by the
manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective due to
materials or workmanship will be repaired or replaced, at the manufacturer’s discretion,
at no charge to the original purchaser. The purchaser will be responsible for any
removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
Power failure
Damage in transit or when moving the appliance
Improper power supply such as low voltage, defective household wiring or
inadequate fuses
Accident, alteration, misuse or abuse of the appliance such as using non-
approved accessories, inadequate air circulation in the room or abnormal
operating conditions (extreme temperatures)
Use in commercial or industrial applications
Fire, water damage, theft, war, riot, hostility or acts of God such as hurricanes,
floods, etc.
Use of force or damage caused by external influences
Partially or completely dismantled appliances
Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with purchase
date available. Once confirmed that your appliance is eligible for warranty service, all
repairs will be performed by a NewAir™ authorized repair facility. The purchaser will be
responsible for any removal or transportation costs. Replacement parts and/or units will
be new, re-manufactured or refurbished and is subject to the manufacturer’s discretion.
For technical support and warranty service, please email [e-mail].
