Air Hoe Drill Specifications
P2050
Page 1 of 2
3-SECTI N M DEL, ft. (m) 27 (8.2) 28 (8.5) 33 (10.1) 34 (10.4) 39 (11.9) 40 (12.2)
DIMENSI NS
Transport, ft. (m) Length 29 (8.8) 29 (8.8) 29 (8.8) 29 (8.8) 29 (8.8) 29 (8.8)
ft. in. (m) Height 11’ 6” (3.5) 11’ 6” (3.5) 14’ 6” (4.4) 14’ 6” (4.4) 17’ 6” (5.3) 17’ 6” (5.3)
ft. in. (m) Width 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2)
NUMBER F SHANKS
Spacing, in. (cm) 7.2 (18.3) 45 — 55 — 65 —
in. (cm) 10 (25.4) — 34 40 ——48
in. (cm) 12 (30.5) — 28 — 34 — 40
5-SECTI N M DEL, ft. (m) 45 (13.7) 46 (14.0) 51 (15.5) 52 (15.8) ——
DIMENSI NS
Transport, ft. (m) Length 29 (8.8) 29 (8.8) 29 (8.8) 29 (8.8) ——
ft. in. (m) Height 13’ 6” (4.1) 13’ 6” (4.1) 17’ 6” (5.3) 17’ 6” (5.3) ——
ft. in. (m) Width 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2) 20’ 6” (6.2) ——
NUMBER F SHANKS
Spacing, in. (cm) 7.2 (18.3) 75 — 85 ———
in. (cm) 10 (25.4) — 56 62 ———
in. (cm) 12 (30.5) — 46 — 52 ——
TIRES
P2050 C NFIGURATI N ft. (m) 27, 28, 33 and 34 39, 40, 45 and 46 51 and 52
(8.2, 8.5, 10.1 and 10.4) (11.9, 12.2, 13.7 and 14.0) (15.5, 15.8)
Single caster tires on front Dual caster tires on front Dual caster tires on front
(11L-15FI D-rating - 6-bolt hubs) (9.5L-15FI D-rating - 6-bolt hubs) (11L-15FI D-rating - 6-bolt hubs)
Tires on rear walking beams Tires on rear walking beams Tires on rear walking beams
(9.5L-15FI D-rating - 6-bolt hubs) (9.5L-15FI D-rating - 6-bolt hubs) (11L-15FI D-rating - 6-bolt hubs)
Tires on wing sections Tires on wing sections Tires on wing sections
(9.5L-15FI 6-ply - 6-bolt hubs) (9.5L-15FI 6-ply - 6-bolt hubs) (9.5L-15FI 6-ply - 6-bolt hubs)
SPACING
4-row, in. (cm) ....................................................................................................7.2, 10 or 12 (18.3, 25.4 or 30.5) spacings ..................................................................................
FRAME/GR UND CLEARANCE
in. (cm)..............................................................................................28 to 32 (71.1 to 81.3) depending on openers and depth settings ................................................................
CULTIVAT R-STYLE TRIPS
lb. (kg) in. (cm) ........................................................................350 (160) with 1” x 2” (2.5 x 5.1) shank, 2 1/4” (5.7) centers fit 50° sweeps........................................................
lb. (kg) in. (cm) ........................................................................550 (250) with 1” x 2” (2.5 x 5.1) shank, 2 1/4” (5.7) centers fit 50° sweeps........................................................
PRESS WHEELS
Rubber, in. (cm)......................................................................................................................3 x 22 (7.6 x 55.9)......................................................................................................
in. (cm) ..................................................................................................................................4 x 22 (10.2 x 55.9).....................................................................................................
in. (cm).................................................................................................................................5 1/2 x 22 (14 x 55.9) ...................................................................................................
Steel, in. (cm) ......................................................................................................................3 1/2 x 22 (8.9 x 55.9)...................................................................................................
in. (cm) ...............................................................................................................................4 1/2 x 22 (11.4 x 55.9)..................................................................................................
PTI NS .........................................................................................................Shim kits to lower shanks behind tractor wheels ..............................................................................
.........................................................................................................................................Single or dual end markers ...............................................................................................
..........................................................................................................................................Press wheel mud scrapers................................................................................................
.............................................................................................................................................Tow hitch for H3cart...................................................................................................
...................................................................................................................................Bolt-on caps for steel press wheels.........................................................................................
............................................................................................................................1-bar heavy harrow for 4-row configuration..................................................................................
................................................................................Dual offset caster for the center section of 27’, 28’, 33’ and 34’ (8.2, 8.5, 10.1 and 10.4 m) models......................................
......................................................................................................................Dual offset caster for the wing sections (all models) ...........................................................................
ASAE 279.11 transport lighting is standard equipment

New Holland
Air Hoe Drill Specifications
P2060
Page 2 of 2
BASE SIZE, ft. (m) 60 (18.3) 70 (21.3)
o. of sections 55
o. of ranks 44
W RKING WIDTHS, ft. (m) (outside shank to outside shank + spacing)
7.5 (19.1) in. (cm), spacing 60 (18.3) /A
10 (25.4) in. (cm), spacing 60 (18.3) 70 (21.3)
12 (30.5) in. (cm), spacing 60 (18.3) 70 (21.3)
NUMBER F SHANKS
7.5 (19.1) in. (cm), spacing 96 /A
10 (25.4) in. (cm), spacing 72 84
12 (30.5) in. (cm), spacing 60 70
FRAME WIDTHS, ft. in. (m)
Main frame 10' 0" (3.05) 10' 0" (3.05)
Inner wing 15' 0" (4.57) 15' 0" (4.57)
Outer wing 10' 0" (3.05) 15' 0" (4.57)
Transport width 17' 8" (5.38) 17' 8" (5.38)
Transport height (max) 13' 6" (4.11) 13' 6" (4.11)
WEIGHTS, lb. (kg) (All with 350 lb. trips and 3 in rubber packers)
7.5 (19.1) in. (cm), spacing 36,300 (16,466) /A
10 (25.4) in. (cm), spacing 32,800 (14,878) 36,500 (16,556)
12 (30.5) in. (cm), spacing 31,100 (14,107) 34,400 (15,604)
TIRES
Main frame casters 11Lx15FI (Duals) 11Lx15FI (Duals)
Inner wing casters 11Lx15FI (Duals) 11Lx15FI (Duals)
Outer wing casters 11Lx15FI (Singles) 11Lx15FI (Singles)
Rear transport wheels 11Lx15FI (Single) 11Lx15FI (Single)
Packer options, 7.5" (19.1 cm), spacing......................................................................................Steel - 3-1/2" / Rubber - 3" in line gang style ...............................................................
Packer options, 10" and 12" (25.4 or 30.5 cm), spacing.............Steel - 3-1/2", 4-1/2"/ Rubber - 3", 4”, 5-1/2" in line gang style / and 5-1/2" or 6-1/2" pneumatic walking beam style.......
Packer wheel mud scrapers................................................................................................................Optional for steel and rubber wheels......................................................................
Stone kickers ............................................................................................................................................................Standard............................................................................................
Openers........................................................................................................................................................... EW edge-on Stealth..................................................................................
Seed boots ................................................................................................................................Wide range of Flexicoil ground openers available............................................................
Air kits..............................................................................................................................................Single shoot and double shoot available...................................................................
Blockage monitors...........................................................................................Basic or expanded blockage monitors available; pin sensors and optical sensors...................................
Tandem wheels for center ..............................................................................................Standard; also 12.5x15FI D-rating / 15 high-flotation available .................................................
Tandem wheels for wings ...............................................................................................Optional; also 12.5x15FI D-rating / 15 high-flotation available..................................................
In-frame harrow ....................................................................................................................................Optional single-bar heavy harrow ........................................................................
Disc levellers .............................................................................................................................................................Optional ............................................................................................
Trip assemblies, 7.5" (19.1 cm), spacing ..........................................................................................................350 lb. & 550 lb. .....................................................................................
Trip assemblies, 10" and 12" (25.4 or 30.5 cm), spacing..................................................................................350 lb. & 550 lb. .....................................................................................
Trip assemblies ..............................................................................................................................1" x 2" 50° C-shank or 1" x 2" 84° edge-on.................................................................
Rank to rank spacing, in. (cm) ..................................................................................................................................26 (66).............................................................................................
Frame depth, in (cm)..............................................................................................................................................108 (274.3) .........................................................................................
Caster to packer depth, in. (cm)...............................................................................................148 (375.9) at 1-inch / 2.54 cm of seeding depth ...........................................................
Frame/ground clearance .............................................................................................................28 to 32 (71.1 to 81.3) depending on openers..............................................................
Hydraulic system................................................................................................High-quality parallel cylinders performing both depth and wing lift. functions .....................................
Depth control ....................................................................................Each wing follows ground independently (not affecting adjacent sections); single point adjustment....................
Safety chain and lights .............................................................................................................................................Standard............................................................................................
Transport locks .........................................................................................................................................................Standard............................................................................................
Rear tow hitch ..................................................................................................Optional; patented steering design to aid in cornering and limit sidehill skewing ...................................
Packing pressure adjustment.......................................................................................................Each frame section independently adjustable...............................................................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2008 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
