Nextar X3-02 Assembly Instructions

1
，
POWER SUPPLY:
Connect the supplied adaptor to the side of the unit in the slot marked “DC 5V IN”. Plug
the two-prong end of the power cord to anAC100-240V outlet. If you have difficulty
inserting the plug, turn it over and reinsert it. If the unit will not the used for a long time,
disconnect the plug from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections
have been made.
CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Refer to service manual for servicing instructions. To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.
Important
S
a
f
ety
Instructions

2
NOTES
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a damp cloth.
7) Do not block any of the ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. When the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15) Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
To prevent the GPS from being damaged, be sure to keep the GPS out of direct
sunlight or heat.
Important
S
a
f
ety
Instructions

3
Warning
Failure to avoid the following potentially hazardous situations may result in injury or
property damage.
The unit is designed to provide you with route suggestions. It does not reflect road
closures or road conditions, traffic congestion, weather conditions, or other factors that
may affect safety or timing while driving.
Use the unit only as a navigational aid. Do not attempt to use the unit for any purpose
requiring precise measurement of direction, distance, location, or topography. This
product should not be used to determine ground proximity for aircraft navigation.
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
The batteries (or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the
Global Positioning System (“GPS”) hardware, operating software or other aspects of this
product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s
Standard(s) for Safety [Note-Consider referencing specific UL standard].
UL Certification does not cover the performance or reliability of the GPS hardware and
GPS operating software.
UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS
WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS
RELATED FUNCTIONS OF THIS PRODUCT.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Important
S
a
f
ety
Instructions

4
Note: This equipment has been tested and found to comply with limits for Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the receiver. Connect the
equipment into an outlet on a circuit different from that to which the receiver is
connected.
3. Consult the dealer or an experience radio/TV technician for help.
The images in this manual are only for reference and they may appear
different from the actual items.
Important
S
a
f
ety
Instructions

5
Accessories List
ITEM NAME QTY
Instruction Manual 2
Car Adaptor 1
Mounting Bracket 1
USB Cable 1
Mounting Cradle 1
Stylus 1
Dashboard Mount Disk 1
Pouch 1
NOTE
Accessories and their parts numbers are subject to modification without prior notice due
to improvements.
Accessories

6
…………………………………..………..1
……………………………….…………...5
……………………………….…………...7
……………………………….……….…..8
…………………………….……….….….9
……………………………….…………..10
…………………………….……………..14
……………………………….…………..16
……………………………….…………..18
……………………………….…………..19
……………………………….…………..20
Important Safety Instructions
System Connections
Power Supply Preparation
Troubleshooting
Specifications
Accessories
V
iew of Main Uni
t
Use of the Mount Accessories
Contents
Playing Music
Photo Viewer
General Setup

7
1. POWER Button
Press for a longer time to enter or exit the standby mode.
2. Card Slot
Insert the SD card into the slot.
3. Earphone Jack
Used to connect earphones for private listening. When the earphones are
connected to this jack, the speaker will be turned off automatically.
4. DC 5V Input Jack
Used to connect to the supplied car adapter.
5. LCD Screen
6. USB Port
Used to connect to the USB device.
7. RESET button
Press to reset the system.
View of Main Unit

8
 Always ensure that the unit and any other external device connected to the unit are
switched off and unplugged from the power supply before you attempt to connect
the unit to any external device.
Inserting SD Card
The unit is designed with SD Card slot which allows you to insert the SD card into the
unit as shown below:
Connecting to Earphones
Connect the earphones to the right side of the unit for private listening.
When earphone is connected, the speakers will automatically turn off.
Note: Excessively loud volume could damage your hearing. So turn down the volume
before you connect the earphones, and then raise the volume to comfortable level.
System
Connections

9
Using the Car Adaptor
The unit is supplied with a Car Adaptor for powering it while in a vehicle.
Attention
 Place the unit in a proper position for viewing.
 Disconnect the unit from the Car Adaptor when starting the vehicle.
Your portable GPS unit comes with a built-in rechargeable battery. Please see details in
the following segment.
Working conditions and precautions for the rechargeable battery
 Battery should only be used and charged when temperatures are between
32-100F.
 Maintain well-ventilated conditions around the product to avoid overheating. Don’t
put the product on a bed, sofa or anything that may block ventilation to the product.
 When the battery is weak, an indication menu will appear on the LCD screen and
the unit will power off automatically after a while.
Charging the Battery Pack
The battery must be charged by using the supplied Car Adaptor.
Connect the Car Adaptor Power Plug to
the unit’s power jack and plug the other
end to the vehicle’s 5V accessory/
cigarette socket, as shown on the right
figure.
Power Supply
Pre
p
aration

10
General Setup
When turn on the unit, the screen will display the main menu later as shown below:
In the main menu, there are four items for selecting. Touch the corresponding item to
enter.
Tap to enter navigation mode; tap to enter the MP3 player; tap to
enter the Photo Viewer; tap to enter the setting menu.
Setting Menu
In the main menu, tap to enter the setting menu, the screen will display as below:
In the menu, tap to return to the main menu.
General Setup

11
Language
Tap in the setting menu to enter Language setting menu for language selecting, as
shown below:
Tap the buttons to select language. Then tap to confirm or tap to cancel.
Backlight
Tap in the settings menu to enter Backlight setting menu for backlight adjusting, as
shown below:
Tap the first group  buttons to adjust the backlight level.
Tap the second group buttons to adjust the sleep time. There are 6 choices for sleep
time (--/5/10/30/60/120).
--: The system will keep backlight always on and will not enter sleep mode.
5: The system will keep backlight on for 5 minutes and then enter sleep mode.
10: The system will keep backlight on for 10 minutes and then enter sleep mode.
30: The system will keep backlight on for 30 minutes and then enter sleep mode.
60: The system will keep backlight on for 1 hour and then enter sleep mode.
120: The system will keep backlight on for 2 hours and then enter sleep mode.
After setting, tap to confirm or tap to cancel.
General Setup

12
Date & Time
Tap in the settings menu to enter Date & Time setting menu for changing to the
current time zone, as shown below:
Tap the  buttons to select the proper Time Zone. Tap the  buttons of Date group
to change the corresponding date and tap the  buttons of Time group to change the
corresponding time. Tap to return.
Power
Tap in the settings menu to enter Power menu for the current battery status, as
shown below:
The power menu will display the current battery status. Tap to return.
General Setup

13
Calibrate
Tap in the settings menu to calibrate, the screen will display as below:
This item is used to calibrate the sensitivity of the touch screen. Tap the center of “+” as it
moves around the screen. If you touch the center of “+” every time, it will disappear after
having moved through a cycle (center→top left→bottom left→bottom right→top right).
Tap the screen to return to the settings menu.
Note: If “+” doesn’t disappear, you should calibrate again.
Volume
Tap in the settings menu to enter Volume settings menu for volume adjusting, as
shown below:
Tap the  buttons to adjust the volume. Then tap to confirm or tap to cancel.
General Setup

14
The unit is designed with SD card slot and supports MP3 and WMAformat files playback.
You can insert the SD card with MP3 or WMA files in the unit for music enjoyment.
Note: Do not store MP3 or WWA format files in the Flash storage, for the flash
storage is used to store map data, any attempt to open the Flash storage may
result in the map data missing and lost.
Take the following steps to play:
Loading MP3 format files:
1. Insert the SD card with MP3 files.
2. Turn on the unit.
A note regarding the MP3 function:
The unit has the ability to play your favorite MP3 music files. This is accomplished by
using the unit’s SD card slot, located on the right side.
 MP3 files should previously reside on the users SD card.
 MP3 files can be imported to the users SD card on a PC, using a variety of
programs such as Windows Media Player.
 This process should be performed independent of the navigation unit.
Do not attempt to use the unit to read and burn MP3 files from an external source.
Playing Music.
In the main menu, tap to enter the playback menu, as shown below:
In the MP3 player, tap in the top left corner to exit.
Playing Music

15
“” displays the battery status.
Tap to begin to play the music.
During playback, tap to pause the playback and the mark will change to , tap it
again to resume.
During playback, tap to stop the playback and tap to play from the beginning of the
track.
During playback, tap to go to the beginning of the current track; tap twice to go to
the previous track.
During playback, tap to go to the next track.
During playback, tap to adjust the volume.
During playback, tap to select the track
time.
Tap to enter the menu as shown below:
Tap to activate or close this function. When this function is activated, the player
will play the music in random order.
Tap to cycle through the repeat modes: track, all or off.
Tap to return to the previous menu.
Playing Music

16
The unit is designed with SD card slot and supports JPEG format files playback. You can
insert the SD card with JPEG files in the unit for picture view.
Note: Do not store JPEG format files in the Flash storage, for the flash storage is
used to store map data, any attempt to open the Flash storage may result in the
map data missing and lost.
Take the following steps to play:
Loading JPEG format files
1. Insert the SD card with JPEG format files.
2. Turn on the unit.
Playing Picture
In the main menu, tap to enter the Photo Viewer main screen, as shown below:
In the menu, tap to enter the folder menu, as shown below:
Photo Viewer

17
In the folder menu, double tap the memory card icon to open it, the pictures stored in the
memory card will be listed on the screen.
If the pictures list consists of more than one screen, tap the up arrow for the
previous page and the down arrow for the next page. Tap to return to previous
menu. Tap a picture to select it and tap to confirm your selection.
In the pictures list, double tap a picture to play it on screen, as shown below.
On the playback screen, the Photo Viewer has following playback features:
Tap to rotate the picture.
Tap to back to previous picture; tap to switch to next picture.
Tap ,to zoom the picture in or out.
Tap to play the picture in full-screen mode; double tap the screen again to return to
Photo Viewer main screen.
Tap to return to the pictures list.
Photo Viewer

18
When using the unit in vehicle, you can use the supplied mount accessories (mount
bracket, mount cradle and dashboard mount disk) to mount the unit in the vehicle. Take
the following steps to operate:
1. See Fig. 1. According to the arrow to slide the mount cradle to fix it to the mount
bracket.
2. See Fig. 2. First, set the bottom edge of the unit onto the mount cradle. Then press
the two buttons in arrow ①direction and meanwhile push the mount cradle
forwards to embed it in the unit.
3. See Fig. 3. Lift the suction cup lever and then press the suction cup to the
windshield. According to arrow ① to press down the suction cup lever. Then
rotate the knob to adjust the unit to proper position.
To mount to dashboard, use the included adhesive disk. Choose a clean, dry spot
on your dashboard, peel off protection liner from the back of the disk, and then
attach the disk to your dashboard.
Warning:
When you mount the device in your vehicle, ensure it has a clear line of sight to the sky.
The device must not be mounted so that it impairs the driver’s view of the road. Please
take extra precaution to ensure the airbags are not obstructed by the device.
Use of the Mount
Accessories

19
Take these steps described in the tables below to solve simple problems before
contacting customer service.
If you suspect something wrong with this unit, immediately turn the power off and
disconnect the power connector from the unit. Never try to repair the unit yourself
because it is dangerous to do so.
Other possibilities:
Static or other external interference may cause the unit function abnormally. In order to
recover normal status, please unplug the power supply cord and then plug it into the
outlet again to reset the unit. If the problems still exist, please cut off the power supply
and consult your service center or the qualified technician.
POSSIBLE SOLUTION
There is no sound The volume may be turned
down. Turn up the volume.
There is no picture. The brightness may be
turned down.
A
djust the brightness of the
LCD.
PROBLEM POSSIBLE CAUSE
Troubleshooting
