Nextar X3E Mounting instructions

X3E

© gate5 AG, 2006. All rights reserved.
1
Contents
Typographic conventions........................................................................................
Icons……………………………………………………………………………………..…..
Introduction………………………………………………………………………………...
Key features…………………………………………………………………………...…
First steps……………………………………………………………………………..…….
Choosing a language…………………………………………………………..……….
Safety precautions……………………………………………………………..……….
Set time……………………………………………………………………….………….
GPS connection……………………………………………………………..…………..
Detailed description…………………………………………………………….…………
Using the map…………………………………………………………………..……….
Tracking mode and selection mode………………………………….…………
Choosing and finding locations……………………………………………….……….
Choosing a location on the map………………………………………..……….
Search for an address…………………………………………………..………..
Searching for and choosing POIs………………………………………..……..
Search for a location by recent…………………………………………………..
Favourites………………………………………………………………………….
Navigation………………………………………………………………………………..
Navigation screen…………………………………………………………………
Options during navigation………………………………………………………..
Planning a route………………………………………………………………………….
Settings…………………………………………………………………………………...
Route options………………………………………………………………….….
Language…………………………………………………………………………..
3
4
5
5
6
6
6
6
7
8
8
8
10
10
11
14
16
17
20
20
21
23
25
25
27

© gate5 AG, 2006. All rights reserved.
2
Map settings……………………………………………………………………..
Volume………………………………………………………………………..…
Optional features…………………………………………………………………..…….
Guides……………………………………………………………………………..……
Traffic Message Channel (TMC)…………………………………………………………
Route Recording…………………………………………………………………………..
Speed Camera Alert………………………………………………………………………
smart2go™ Setup Assistant……………………………………………………………
Frequently asked questions……………………………………………………………
Index……………………………………………………………………………..………...
Copyright and license notes…………………………………………………………..
27
28
29
29
29
30
30
31
34
35
37

TYPOGRAPHIC CONVENTIONS
© gate5 AG, 2006. All rights reserved.
3
TYPOGRAPHIC CONVENTIONS
Bold
Items you must select, such as menu options, command buttons, or items in a list.
• Bullet
Step-by-step procedures. You can follow these instructions to complete a specific
task.
Comment
Especially important or remarkable information.
Monospace
Information that you must type, or information like folders and filenames.
CAPITALS
Names of keys on the keyboard. For example, SHIFT, CTRL, or ALT.

ICONS
© gate5 AG, 2006. All rights reserved.
4
ICONS
The following icons and symbols are used throughout the application:
Icon Name Function
Menu icon Opens a menu with various options.
Back icon Go back to the previous screen.
Navigation icon Start navigation.
Search icon Opens a search screen
Confirmation icon Apply settings. Select/deselect all.
Exit icon Exit the application. Only visible in the
tracking mode (see page 8).
GPS icon Press this icon to move map back to your
GPS position. Only visible in the selection
mode (see page 8).

INTRODUCTION
© gate5 AG, 2006. All rights reserved.
5
INTRODUCTION
You have chosen a cutting-edge navigation system. Congratulations! Please enjoy
using it. This navigation system leads you straight to your destination, whether you
are travelling by car or on foot. You may navigate and plan your route with an easy to
use and intuitive interface, just by using your finger. You may also use this application
to plan your trip to suit your personal preferences and interests and to save
interesting destinations before you set off on your trip. This manual leads you through
the main features of the system.
Key features
• Cross-border navigation in Europe through map of Europe (optional
feature)
• Dynamic Traffic Information, TMC (optional feature)
• Real pedestrian mode
• Look-ahead search function
• State-of-the art polygon view of individual houses for selected European
cities (optional feature)
• Earth browsing
• Unique night mode
• Improved guidance engine
• Premium content through branded guides (optional feature)

FIRST STEPS
© gate5 AG, 2006. All rights reserved.
6
FIRST STEPS
Please make sure that the battery of your device is fully charged.
• Switch on the unit and tap on NAVI or NAVIGATION in the first screen.
Choosing a language
If more than one language is available on your device, you are prompted to choose
your language.
• Click on the flag representing your country/language.
• On the following screen, choose the voice skins used for the voice
commands during navigation (e.g. female or male voice).
Safety precautions
Next, a screen with safety precautions will be shown.
• Read those safety precautions.
• Mark the Hide at startup checkbox to hide these notes for future
start-ups.
• Press the forward arrow.
Set time
Your PND is able to automatically determine the time through the GPS signal. For this
purpose, you need to set your time zone.
• Choose your time zone from the list. You can later change this (see page
27).
• During Summer Time, please mark the corresponding check box in order to
adjust the time shown forward by one hour.
Press the confirmation icon.

FIRST STEPS
© gate5 AG, 2006. All rights reserved.
7
GPS connection
Your PND uses GPS technology for navigation. Your device receives signals from a
number of GPS satellites in order to determine your current position.
• Place your PND in a position with an unobstructed view to the sky to set up
your first satellite connection. In the car this will usually be on the
dashboard.
It may take up to 10 minutes to establish the first connection. Subsequent
connections will be faster (30 seconds to 1 minute), but if you have not used
the unit for several days or are very far away from the last location you used
it, it may take up to 5 minutes again to find a strong signal.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
8
DETAILED DESCRIPTION
This chapter describes the functions of your Personal Navigation Device in detail. On
the following pages you will learn how to
- Use the map (see page 8)
- Find and choose locations (see page 10)
- Navigate to your destination (see page 20)
- Use the route planner (see page 23)
- Configure the application (see page 25)
Using the map
The map is the core component of your Personal Navigation Device. It will be centred
on your current location by default, provided you have a GPS connection. You can
browse the map, display information about the different locations shown on it and e.g.
choose them for routing and navigating.
Tracking mode and selection mode
The map knows two basic states, the tracking and the selection mode.
In the tracking mode, the map follows your actual position (GPS position), displaying
information about your geographic position, your speed, etc:

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
9
Speed
Geographic
coordinates
Time
Elevation
above mean
sea level
GPS status
Menu icon Info box Exit application
As soon as you browse the map, you enter the selection mode:
Current (GPS)
position
Menu icon Info box Tracking icon
• Use a pen or your finger to browse the map. The actual position will be
identified by a cursor.
Clicking on an icon on the map opens an overlay window with information
about the selected item.
• To zoom in or out, press the +or -icons. As soon as you press one of the
icons, the zoom slider will be shown, which can be used for smooth
zooming.
Zoom out
Zoom in
GPS position
Compass rose
Compass rose
Zoom out
Cursor
Zoom in

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
10
• With the compass icon (in the bottom left hand corner) you may adjust the
orientation.
• If you want to return to the tracking mode, press the tracking icon. To exit
the application, press this button again.
Choosing and finding locations
This section describes the different ways of finding and choosing locations. You may
choose locations on the map, search for an address, choose a favourite (like home
and work address, your bookmarks and recently visited locations), and browse POI
directories and guides.
Choosing a location on the map
• Point the cursor at any place on the map. The name of a selected
location/street will be shown in the info box.
• Press that info box to open a screen with details:
By pressing the menu icon you can access further options:

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
11
• Press Navigate to navigate to the location (see page 20).
• Press Via to use the location for routing (see page 23).
• Press Save to save the location as a bookmark (see page 19).
Search for an address
Through the address search you can find an address by entering information about
the desired target (street and town/city). You may then select a hit from the results list
and use the address found for different purposes, like pinpointing it on a map,
planning your route, and navigating.
 On the map, select the menu icon.
The main menu will be opened:
 Select Find Destination.
 Select By Address.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
12
The Find Address window will be displayed:
Enter the appropriate data to find your address.
How to search
Your Personal Navigation Device offers a convenient interactive look-ahead search
function to prevent misspelling. Only keys that lead to a search result can be pressed
– all others are greyed out!
• Enter the first character.
You will see that the some keys on the keypad turn grey. You can only
choose black keys:
• Enter the second character.
Again, some keys will turn grey, others will turn black, depending on your
choice.
• Keep on entering characters until you have narrowed down the search to
only one result.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
13
OR
• Press the search icon (magnifying glass).
A result list will be displayed.
• Choose the appropriate entry from the list.
Switch between letter and number mode by pressing 123 or ABC. Switch
between upper case and lower case by pressing ^.
If at any point you want to backspace and delete characters, press the
backspace button <- on screen. To add a space, press the space bar _.
If you need to enter an apostrophe (‘) use the space key instead.
Set the country
• Press Country to select your country.
• Choose your country from the list.
The Country field will be populated with the name of the chosen country.
Enter a post code
Instead of a city you may enter a post code.
• Press Post Code to enter a post code.
• Enter the post code of the town/city you are looking for.
• Press the search icon (magnifying glass).
A hit list will be displayed.
• Choose the appropriate town/city from the list.
You will return to the Find Address screen. The City and Post Code fields will be
populated with the chosen city/post code.
You can also enter a unique 7-digit postal code. In that case, you do not
need to enter a street name. (Optional feature).
Search for the city
• Press City to select a city.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
14
Search for the city, as described above.
A result list will be displayed.
• Choose the appropriate town/city from the list.
You will return to the Find Address screen. The City field will be populated with the
name of the chosen town/city.
Search for the street
• Press Street to select a street.
Search for the street, as described above.
A result list will be displayed.
• Choose the appropriate street from the list.
You will return to the Find Address screen. It will be filled with the previously found
data.
Additionally you may enter the number.
Navigate to the address found
Once you have narrowed down your search to a unique address, you can start
navigation.
• Press the forward arrow.
The address will be displayed in the navigation map. Here you can choose to be
guided to the address, use it for route planning, etc. (see page 20).
Searching for and choosing POIs
With the POI finder you can quickly find points of interest like petrol stations and
restaurants that are chosen from a database of millions of POI, either nearby or at a
remote location.
• On the map, select the menu icon.
• On the following screen, select Find Destination.
• Select By POI Search.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
15
A menu of POI categories will be shown:
In the title bar of this screen, you might see an address. You will be presented POIs
that are close to this location. Through the menu icon you open a set of options:
• Press Open to open a guide (see page 15).
• Press Text search to search for a POI (see page 16).
• Press Current location to select POIs near your current location.
• Press Other location to select another address as a starting point for the
POI selection (see page 11).
The starting point will be shown in the title bar of the POI categories screen.
Choosing a POI
• Choose the desired POI category.
A menu with subcategories will be shown.
• Choose a subcategory.
A list of POIs will be shown.
• Select a POI by clicking on it.
The location will be shown on the map:

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
16
• Press the arrows next to the location’s name to switch between results.
• Press ito open a screen with details about the location.
By pressing the menu icon you access to a set of actions:
• Press Navigate to navigate to the location (see page 20).
• Press Via to use the location for routing (see page 23).
• Press Save to save the location as a bookmark (see page 19).
Press On Map to show the location on the main map.
Searching for a POI
• Press the menu icon, then select Text search.
In the search window, enter a search term (at least three characters), and start
searching by pressing the right arrow.
A list of POIs will be shown.
• Select a POI by clicking on it.
The POI will be shown on the map, as described above.
Search for a location by recent
With the By Recent button you can quickly find recently visited or looked-up
destinations.
• On the map, select the menu icon.
• On the following screen, select Find Destination.
• Select By Recent.
The list of recent items will show on the screen.
Use the up and down arrows to scroll up and down in the list.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
17
• Select an item by clicking on it.
The location will be shown on the map.
• Press the arrows next to the location’s name to switch between results.
• Press ito open a screen with details about the location.
By pressing the menu icon you access to a set of actions:
• Press Navigate to navigate to the location (see page 20).
• Press Via to use the location for routing (see page 23).
• Press Save to save the location as a bookmark (see page 19).
Press On Map to show the location on the main map
Favourites
Use your frequently used or favourite destinations for guidance. You can choose
among your home, your work place, a set of personal bookmarks, and recently visited
locations.
• On the map, select the menu icon.
• On the following screen, select Find Destination.
• Select By Favourites.
The Favourites menu will show on the screen:
My Home
• Press My Home.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
18
Your home address will be displayed on a map:
• Select the menu icon.
• On the following screen, choose Navigate to be guided to your home
address (press Change or Delete if you want to change/delete your home
address).
Navigation will start immediately.
If no home address has been set, you are prompted to do so. You can
choose it by searching for an address, through your current GPS position or
by choosing a recently visited location.
My Work
• By pressing My Work, your work address will be displayed on a map.
• Select the menu icon.
• On the following screen, choose Navigate to be guided to your work
address (press Change or Delete if you want to change/delete your work
address).
Navigation will start immediately.

DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
19
If no work address has been set, you are prompted to do so. You can
choose it by searching for an address, through your current GPS position or
by choosing a recently visited location.
Bookmarks
The bookmarks list contains the destinations you have saved as favourites (from the
guides, by choosing it on a map, etc.). This means that you do not need to perform
repeated searches for those destinations.
• Press Bookmarks.
The bookmark list will show on the screen:
Use the up and down arrows to scroll up and down in the list.
• Select an item by clicking on it.
The location will be shown on the map.
• Press the arrows next to the location’s name to switch between results.
• Press ito open a screen with details about the location.
By pressing the menu icon you access to a set of actions:
• Press Navigate to navigate to the location (see page 20).
• Press Via to use the location for routing (see page 23).
• Press On Map to show the location on the main map.
All user information like e.g. settings, bookmarks and recently visited
locations will be stored on the device and not on the memory card.
