POWER SUPPLY:
Connect the supplied adaptor to the side of the unit in the slot marked “DC 5V IN”. Plug
the two-prong end of the power cord to an AC100-240V outlet. If you have difficulty
inserting the plug, turn it over and reinsert it. If the unit will not the used for a long time,
disconnect the plug from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections
have been made.
CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Refer to service manual for servicing instructions. To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.
Important
S
a
f
ety
Instructions

2
NOTES
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a damp cloth.
7) Do not block any of the ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. When the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15) Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
Important
S
a
f
ety
Instructions

3
Warning
Failure to avoid the following potentially hazardous situations may result in injury or
property damage.
The unit is designed to provide you with route suggestions. It does not reflect road
closures or road conditions, traffic congestion, weather conditions, or other factors that
may affect safety or timing while driving.
Use the unit only as a navigational aid. Do not attempt to use the unit for any purpose
requiring precise measurement of direction, distance, location, or topography. This
product should not be used to determine ground proximity for aircraft navigation.
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
The batteries (or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the
Global Positioning System (“GPS”) hardware, operating software or other aspects of this
product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s
Standard(s) for Safety [Note-Consider referencing specific UL standard].
UL Certification does not cover the performance or reliability of the GPS hardware and
GPS operating software.
UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS
WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS
RELATED FUNCTIONS OF THIS PRODUCT.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Important
S
a
f
ety
Instructions

4
Note: This equipment has been tested and found to comply with limits for Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the receiver. Connect the
equipment into an outlet on a circuit different from that to which the receiver is
connected.
3. Consult the dealer or an experience radio/TV technician for help.
The images in this manual are only for reference and they may appear
different from the actual items.
Important
S
a
f
ety
Instructions

5
Accessories List
ITEM NAME QTY
Instruction Manual 2
Interchangeable Face Plates 2 in different colors
AC Adaptor 1
Car Adaptor 1
Mounting Bracket 1
USB Cable 1
Mounting Cradle 1
Stylus 1
Dashboard Mount Disk 1
SD Card 1
Pouch 1
NOTE
Accessories and their parts numbers are subject to modification without prior notice due
to improvements.
Accessories

6
…………………………………..………..1
……………………………….…………...5
……………………………….…………...7
……………………………….……….…..9
…………………………….……….….….11
……………………………….…………..13
…………………………….……………..17
……………………………….…………..19
……………………………….…………..21
……………………………….…………..22
……………………………….…………..24
Important Safety Instructions
System Connections
Power Supply Preparation
Troubleshooting
Specifications
Accessories
V
iew of Main Uni
t
Use of the Mount Accessories
Playing Music
Photo Viewer
General Setup
Contents

7
Front and bottom panel
1. POWER Button
Press for a longer time to enter or exit the standby mode.
2. Card Slot
Insert the SD card into the slot.
3. Earphone Jack
Used to connect earphones for private listening. When the earphones are
connected to this jack, the speaker will be turned off automatically.
4. DC 5V Input Jack
Used to connect to the supplied adaptor.
5. LCD Screen
6. USB Port
Used to connect to the USB device.
View of Main Unit

8
Rear Panel
7. RESET Button
Press to reset the system.
8. Stylus
Changing the face plate in different colors
You can change the face plate of the GPS unit by yourself in three different colors
supplied: champagne, black and pink. See the figure below for details:
Lift up the face plate in the arrow direction to remove it. Then set another face plate in
different color on the unit and press down in the arrow opposite direction until the face
plate and the unit are completely integrated.
View of Main Unit

9
 Always ensure that the unit and any other external device connected to the unit are
switched off and unplugged from the power supply before you attempt to connect
the unit to any external device.
Connecting to PC
The unit is designed with a USB port which allows you to connect the unit to a PC for
map updating. See the figure below for details:
System requirements:
-Windows 98SE, ME, 2000, and XP
(Driver required for Windows 98SE)
-DVD Rom Drive (for map upgrade purposes)
-Intel Pentium II 233 Mhz
-64 MB RAM
-50 MB available hard drive space
-Available serial port and/or USB Port
-256-color display adaptor and monitor
(16 bit color required)
In the near future, map updates will be available for down load from our website. Please
check www.nextar.com periodically for the information on downloads.
System
Connections

10
Inserting SD Card
The unit is designed with SD card slot which allows you to insert the SD card into the unit
as shown below:
Connecting to Earphones
Connect the earphones to the right side of the unit for private listening.
When earphone is connected, the speakers will automatically turn off.
Note: Excessively loud volume could damage your hearing. So turn down the volume
before you connect the earphones, and then raise the volume to comfortable level.
System
Connections

11
Using the AC Adaptor
The unit is supplied with an AC adaptor for powering it and charging its battery.
Note:
 Turn unit's power off before unplugging.
 When using the adaptor, the LCD screen will be brighter than with the
rechargeable battery.
Using the Car Adaptor
The unit is supplied with a Car Adaptor for powering it while in a vehicle.
Attention
 Place the unit in a proper position for viewing.
 Disconnect the unit from the Car Adaptor when starting the vehicle.
Your portable GPS unit comes with a built-in rechargeable battery. Please see details in
the following segment.
Connect the Car Adaptor Power Plug to
the unit’s power jack and plug the other
end to the vehicle’s 5V accessory/
cigarette socket, as shown on the right
figure.
Power Supply
Pre
p
aration
1. Connect AC adaptor to the right side
of the unit in the jack marked DC 5V
IN, as shown on the right.
2. Plug the two-prong end of the powe
r
cord into a grounded electrical
outlet.

12
Working conditions and precautions for the rechargeable battery
 Battery should only be used and charged when temperatures are between
32°-100°F.
 Maintain well-ventilated conditions around the product to avoid overheating. Don’t
put the product on a bed, sofa or anything that may block ventilation to the product.
 When the battery is weak, an indication menu will appear on the LCD screen and
after a little while, the unit will power OFF automatically.
Charging the Battery Pack
The battery must be charged by using the supplied adaptor.
.
Power Supply
Pre
p
aration

13
System Main Menu
When in navigation mode, tap button in the Menu screen. A confirmation message
appears asking if you want to exit the program now, as shown below.
In the confirmation screen, tap and the system main menu appears.
In the main menu, there are four items for selecting. Touch the corresponding item to
enter.
Tap to enter navigation mode; tap to enter the MP3 Player; tap to enter
the Photo Viewer; tap to enter the settings menu.
Setting Menu
In the main menu, tap to enter the settings menu, the screen will display as below:
In the menu, tap to return to the main menu.
General Setup

14
Language
Tap in the settings menu to enter Language setting menu for language selecting, as
shown below:
Tap the buttons to select language. Then tap Dto confirm or tap Uto cancel.
Backlight
Tap in the settings menu to enter Backlight setting menu for backlight adjusting, as
shown below:
Tap the  buttons to adjust the backlight level.
After setting, tap Dto confirm or tap Uto cancel.
General Setup

15
Date & Time
Tap in the settings menu to enter Date & Time setting menu for changing to the
current time zone, as shown below:
Tap the  buttons to select the proper Time Zone. Tap the  buttons of Date group
to change the corresponding date and tap the  buttons of Time group to change the
corresponding time. Tap to return.
Power
Tap in the settings menu to enter Power menu for the current battery status, as
shown below:
The power menu will display the current battery status. Tap to return.
General Setup

16
Calibrate
Tap in the settings menu to calibrate, the screen will display as below:
This item is used to calibrate the sensitivity of the touch screen. Tap the center of “+” as it
moves around the screen. If you touch the center of “+” every time, it will disappear after
having moved through a cycle (center→top left→bottom left→bottom right→top right).
Tap the screen to return to the settings menu.
Note: If “+” doesn’t disappear, you should calibrate again.
Volume
Tap in the settings menu to enter Volume settings menu for volume adjusting, as
shown below:
Tap the  buttons to adjust the volume. Then tap Dto confirm or tap Uto cancel.
General Setup

17
The unit is designed with SD card slot and supports MP3 and WMA format files playback.
To use the music player, you will need to have an SD card with your MP3 music files
preloaded. Please note you cannot use the navigation function of the device at the same
time as using the music player. Remove the mapping software SD card that comes with
the device from the SD card slot on the side of the unit. Then insert your SD card with
your MP3 or WMA music files.
Note: Please take care of the mapping SD card if you remove it to use the music
player as the navigation function will not work without it.
Warning: For your own safety, do not use the earphones when driving.
A note regarding the music playing function:
The unit has the ability to play your favorite MP3 music files. This is accomplished by
using the unit’s SD card slot, located on the right side.
 MP3 files should previously reside on the user’s SD card.
 MP3 files can be imported to the user’s SD card on a PC, using a variety of
programs such as Windows Media Player.
 This process should be performed independent of the navigation unit.
Do not attempt to use the unit to read and burn MP3 files from an external source.
Playing Music
In the main menu, tap to enter the playback menu, as shown below:
In the music player, tap in the top left corner to exit.
Playing Music

18
In the menu, tap the MENU button to enter the music play list menu, as shown below:
When you open the play list, the system will look for audio files on its SD memory card
and create a play list automatically. If the play list consists of more than one screen, tap
the up arrow for the previous page and the down arrow for the next page.
In the play list, double tap the songs to start playback.
Tap ; when the button changes to orange, the player will repeat all the songs in the
play list.
Tap ; when the button changes to orange, the player will play the songs in the list
randomly.
Tap to return to the music player main screen.
On the playback screen as shown right, the music
player has standard playback features:
Tap button to start playing the songs in the play list.
Tap to stop the playback.
Tap to pause the playback, and then tap to resume the playback.
Tap to go back to the previous song; tap to skip to the next song.
Use to adjust the volume of the speaker.
Playing Music

19
The unit is designed with SD card slot and supports JPEG format files playback. To use
the Photo Viewer, you will need to have an SD card with your JPEG picture files
preloaded. Please note you cannot use the navigation function of the device at the same
time as using the Photo Viewer. Remove the mapping software SD card that comes with
the device from the SD card slot on the side of the unit. Then insert your SD card with
your JPEG picture files.
Note: Please take care of the mapping SD card if you remove it to use the Photo
Viewer as the navigation function will not work without it.
The unit lags when reading high-resolution JPEG files in the SD Card. We suggest
low-resolution (within 640*480) pictures playback.
Playing Picture
In the main menu, tap to enter the Photo Viewer main screen, as shown below:
In the menu, tap to enter the folder menu, as shown below:
Photo Viewer

20
In the folder menu, double tap the memory card icon to open it, the pictures stored in the
memory card will be listed on the screen.
If the pictures list consists of more than one screen, tap the up arrow for the
previous page and the down arrow for the next page. Tap to return to previous
menu. Tap a picture to select it and tap to confirm your selection.
In the pictures list, double tap a picture to play it on screen, as shown below.
On the playback screen, the Photo Viewer has following playback features:
Tap to rotate the picture.
Tap to go back to the previous picture; tap to switch to the next picture.
Tap ,to zoom the picture in or out.
Tap to play the picture in full-screen mode; double tap the screen again to return to
Photo Viewer main screen.
Tap to return to the pictures list.
Photo Viewer
