Nextlevel Acoustics UTF 10 User manual

UTF 10 / UTF 12 / UTF 12 LE
Mounting Instructions

UTF 10 / UTF 12 / UTF 12 LE Mounting Instructions
Included Parts:
Ceiling Isolation Foam
Tools required:
Screw shooter with long (6”) Philips # 2 bit
½” wrench
7/16” socket, ½” socket
Ratchet bar
Isolation foam is supplied to optimize signal transfer and prevent vibration. Simply
cut the foam to the desired length and press into place. When finished your UTF
subwoofer should look as below with the 4 outside edges, inside port edge and
enclosure midpoint covered in the foam.
***Foam is to be used on the front (ported) side only. It is this side of the subwoofer that
contacts the underside of the floor***
In most cases, simply drilling into the UTF side walls and adjacent ceiling rafters
and installing (4) 5/16” x 2.5” long lag screws (not supplied) is sufficient; however,
the additional rigidity, coupling and isolation achieved by the custom mounting kit
system will further enhance the UTF’s performance.
The custom mounting kit can be created by obtaining the following additional parts:
(4) vertical mounting brackets
(4) 3” L x 5/16-18 carriage bolts
(4) 3/8” lock washers
(16) 1” L # 6 sheet rock screws
(4) 5/16 –18 nuts
(4) 5/16 – 18 lock nuts
(8) 5/16” lock washers
(4) standard 5/16” washers
(2) pcs of perforated 24” long x 1.5” wide angle iron
Step # 1
Assemble vertical mounting
bracket. Place 3/8” lock washer over
carriage bolt and push through bracket
hole. Secure from the underside with
5/16” lock washer and 5/16”
standard nut. Tighten securely.
Custom Mounting Kit Instructions
Standard Mounting

Step # 2
After cutting the oor opening
(approx 4” x 12”) where desired, measure and mark
beam for mounting vertical brackets as shown. Ideal
spacing between brackets is 16” -19”. Be sure that
bottom of bracket plate is about ½” above bottom
beam edge.
Step # 3
Install vertical brackets using (4) #6 drywall
screws. Note: Vertical brackets mount to the outside
of the beam and are directly across from one another
allowing for a clear span on the inside. Install across
beams 1 pc of angle iron. Push onto the threads.
Use (1) 5/16” washer, (1) 5/16” lock washer and
(1) 5/16” lock nut per side. Do both sides.
Thread securely.
Step # 4
Slide the UTF subwoofer, foam side up, into place and install second angle
iron as above. Tighten all 4 nuts progressively until the front side foam compresses
about 1/8”.
Step #1
Cut the opening in the oor to t your desired oor vent grille.
The oor opening must be at least as large as the size of the UTF port:
Step #2
Port Opening Dimensions:
UTF 10 – 2.5” h x 11.5” l
UTF 12 / UTF 12 LE – 2.5” h x 12.5” l
Step #3
• Secure the air intake plate to the oor.
Floor Vent Installation

nextlevelacoustics.com
tel + 617.237.2875
[e-mail]
5-Years for Drivers, Cabinets, and Brackets, 2-years on ampliers for any defects or performance is-
sues realized during the product’s normal use, and 90 days for defects in manufacture or workmanship
covering the exterior t and nish for peeling and cracks.
JS Speaker Technology, LLC (herein “JS Speaker Technology”), warrants to the original retail
purchaser only that products manufactured by JS Speaker Technology (the “Product”) will be free
from defects in material and workmanship for a period of ve (5) years covering drivers, cabinets and
brackets, 2-years on ampliers, and ninety (90) days covering the exterior t and nish for peeling and
cracks from the date of the original purchase from a JS Speaker Technology Authorized Dealer. If the
Product is defective in material or workmanship, JS Speaker Technology or its Authorized Dealer will,
at its option, repair or replace the warranted product at no additional charge, except as set forth below.
All replaced parts and Product(s) become the property of JS Speaker Technology. The product that
is repaired or replaced under this warranty will be returned to you, within a reasonable time, freight
collect. This warranty is non-transferable and is automatically void if the original purchaser sells or
otherwise transfers the Product to any other party. This Warranty does not include service or parts to
repair damage caused by accident, misuse, abuse, negligence, inadequate packing or shipping proce-
dures, commercial use, voltage in excess of the rated maximum of the unit, cosmetic appearance of
cabinetry not directly attributable to defects in material or workmanship. This warranty does not cover
the elimination of externally generated static or noise, or the correction of antenna problems or weak
reception. This warranty does not cover labor costs or damage to the Product caused by installation
or removal of the Product. JS Speaker Technology makes no warranty with respect to its products
purchased from dealers or outlets other than JS Speaker Technology Authorized Dealer. The warranty
is automatically void if: 1) The product has been damaged, altered in any way, mishandled during
transportation, or tampered with. 2) The product is damaged due to accident, re, ood, unreasonable
use, misuse, abuse, customer applied cleaners, failure to observe manufacturers warnings, neglect or
related events. 3) Repair or modication of the Product has not been made or authorized by JS Speak-
er Technology. 4) The product has been improperly installed or used. The product must be returned
(insured and prepaid), together with the original dated proof of purchase to the Authorized Dealer from
whom the Product was purchased, or to the nearest JS Speaker Technology factory service center. The
product must be shipped in the original shipping container or its equivalent. JS Speaker Technology is
not responsible or liable for loss or damage to the Product in transit. This limited warranty is the only
express warranty that applies to your product. JS Speaker Technology neither assumes nor authorizes
any person or entity to assume for it any other obligation or liability in connection with your product
or this warranty. All other warranties, including but not limited to express, implied, warranty of mer-
chantability or tness for a particular purpose, are expressly excluded and disclaimed to the maximum
extent allowed by law. All implied warranties on products are limited to the duration of this expressed
warranty. JS Speaker Technology has no liability for acts of third parties. JS Speaker Technology’s
liability, whether based on contract, tort, strict liability, or any other theory, shall not exceed the pur-
chase price of the product for which a claim has been made. Under no circumstance will JS Speaker
Technology bear any liability for incidental, consequential, or special damages. The consumer agrees
and consents that all disputes between the consumer and JS Speaker Technology shall be resolved in
accordance with Connecticut in Hartford County, Connecticut. JS Speaker Technology reserves the
right to modify this warranty statement at any time. Some states do not allow the exclusion or limita-
tion of consequential or incidental damages or implied warranties, so the above limitations may not
apply to you. This warranty gives you specic legal rights, and you may also have other rights which
vary from state to state.
LIMITED WARRANTY
UNDER THE FLOOR (“UTF”) SUBWOOFER SYSTEM
