Foreword
This manual applies to EDFAB+PON 2U series fiber amplifier. It mainly
describes the performance characteristics, technical parameters, installation and
debugging, common troubleshooting, and other related content of the product. In
order to ensure that the equipment can be successfully installed and safely operated,
please read this manual carefully before installing and debugging the equipment. And
the installation and debugging should be strictly according to the specified steps on
the manual to avoid unnecessary damage to equipment or accident harm to the
operator. Any questions, please contact with us in time.
Special Tips:
■ Er Yb Codoped Fiber Amplifier is high end professional equipment, and its
installation and debugging must be operated by special technician. Read this
manual carefully before operating to avoid damage to equipment caused by fault
operation or accident harm to the operator.
■ While the fiber amplifier is working, there is an invisible laser beam from the
optical output adapter on the front panel. Avoiding permanent harm to the body
and eye, the optical output should not aim at the human body and human should
not look directly at the optical output with the naked eye!
■ Please make sure that the ground terminal of the case and power outlet has been
reliably grounding before turning on the power (Grounding resistance should be
＜4Ω) to prevent the static damage the pump laser device and harm to human
because of case charged.
■ To ensure the equipment can work stable over a long time, in voltage unsteady or
poor voltage wave region, it´s recommend to the customer that he equips special
AC regulated power supply, or even AC uninterrupted power supply (UPS) system
for conditional users. In the region with large temperature variation environment
(The equipment's ideal work environment temperature is 25°C) or bad room

-
-
-
3
3
3 -
-
-
environment, it´s recommend to the customer that he equips special air-condition
system to improve the work environment.
1. Application
 Single-mode fiber 1550 amplification network
 FTTH network
 CATV network
2. Performance Characteristics
EDFAB+PON 2U is a low noise high-performance Er Yb codoped fiber amplifier.
Each output built-in CWDM (1310/1490/1550) wavelength division multiplexer.
Conveniently multiplex the data stream of OLT and ONU to the fiber amplifier output
by 1310nm and 1490nm optical connector. Thus reduced the equipment quantity,
improved the system indexes and reliability. It is the ideal equipment for FTTx
network, provides a flexible and low cost solution for the integration of three
networks and the FTTH.
 Adopts Er Yb Codoped double-clad fiber technology;
 Output ports: 4-16 optional;
 Optical output power: total output up to 5W;
 Low noise figure: <5dB when input is 0dBm;
 Perfect network management interface, in line with standard SNMP network
management;
 Intelligent temperature control system make the power consumption lower;

-
-
-
4
4
4 -
-
-
3. Block diagram
Built-in WDM schematic diagram
4. Technique Parameter
4.1 Technique Parameter
Item Unit Technique parameters
CATV pass through wavelength nm 1545 - 1565
PON pass through wavelength nm 1260 - 1360
1480 - 1500
PON insertion loss dB <0.8
Isolation db >15
CATV optical input power range dBm -5 - +10
Maximum optical output power dBm 36

-
-
-
5
5
5 -
-
-
Output power stability dBm ±0.5
Noise figure dB ≤ 5.0 (Optical input power 0dBm,
λ=1550nm)
Input dB ≥ 45
Return loss Output dB ≥ 45
Optical Connector Type SC/APC
C/N dB ≥ 50
C/CTB dB ≥ 63
C/CSO dB ≥ 63
Test condition
according to
GT/T 184-2002.
Power supply voltage V A: AC160V - 250V(50 Hz); B: DC48V
Consumption W ≤ 70
Operating temperature range °C -10 - +42
Maximum operating relative
humidity % Max 95% no condensation
Storage temperature range °C -30 - +70
Maximum storage relative
humidity % Max 95% no condensation
Dimension mm 483(L)× 440(W)× 88(H)

-
-
-
6
6
6 -
-
-
4.2 Model and Power Comparison Table
Model Total output
power dBm
Output ports
number
Output power per
port dBm
EDFAB+PON 2U 4x18dB 25 4 18
EDFAB+PON 2U 4x19dB 26 4 19
EDFAB+PON 2U 4x20dB 27 4 20
EDFAB+PON 2U 4x21dB 28 4 21
EDFAB+PON 2U 4x22dB 29 4 22
EDFAB+PON 2U 4x23dB 30 4 23
EDFAB+PON 2U 4x24dB 31 4 24
EDFAB+PON 2U 8x15dB 26 8 15
EDFAB+PON 2U 8x16dB 27 8 16
EDFAB+PON 2U 8x17dB 28 8 17
EDFAB+PON 2U 8x18dB 29 8 18
EDFAB+PON 2U 8x19dB 30 8 19
EDFAB+PON 2U 8x20dB 31 8 20
EDFAB+PON 2U 8x21dB 32 8 21
EDFAB+PON 2U 8x22dB 33 8 22
EDFAB+PON 2U 8x23dB 34 8 23
*EDFAB+PON 2U 8x24dB 35 8 24
EDFAB+PON 2U 16x15dB 29 16 15
EDFAB+PON 2U 16x16dB 30 16 16
EDFAB+PON 2U 16x17dB 31 16 17
EDFAB+PON 2U 16x18dB 32 16 18
EDFAB+PON 2U 16x19dB 33 16 19
EDFAB+PON 2U 16x20dB 34 16 20
*EDFAB+PON 2U 16x21dB 35 16 21
The models with “*” are ultra high power output EDFA.

-
-
-
7
7
7 -
-
-
5. External Function Description
5.1 Front Panel Description
Schematic diagram of the front panel
1) Power indicator: One switching power supply is working – yellow; two switching
power supplies are working – green.
2) Optical input power indicator：This light turns on when the optical input power is
> -10dBm.
3) Pump working status indicator: Red light means the pump is not working, but the
machine parameters are normal; flashing red light means the machine has broken
down, related fault reason see the alarm menu of the display menu; green light
means the pump is working normal.
4) Optical output power indicator: This light turns on when the optical output power
is > +10dBm.
5) 160×32 dot-matrix LCD screen: used to display all the parameters of the
machine.
6) Display the exit or cancel key of the setup menu.
7) Display the up or increase key of the setup menu.
8) Display the down or decrease key of the setup menu.
9) Display the enter key of the setup menu.
10) 1310&1490nm signal in/out (PON port).
11) Optical signal input: The default connector type is SC/AP C. Other specification
requirements are specified by the customer.
12) Pump laser switching key: used to control the working status of pump laser.
“ON” means the pump laser is open and “OFF” means the pump laser is closed.
Ensure the key is on “OFF” position before power on. After passing self-test,
rotate the key to “ON” position according to the displayed message.
13) Public port (COM port): This interface is the 1550nm signal output port of the
device, also is the 1310&1490nm signal in/out port. Ports number: 4-16 optional.
Warning: There is an invisible laser beam from this port while working normal.
So the port should not be aligned to the human body or the naked eye to avoid
accidental injury.

-
-
-
8
8
8 -
-
-
5.2 Rear Panel Description
Schematic diagram of the rear panel
1) Fan outlet.
2) RS232 interface: Used for configuring the network management parameters.
3) LAN interface: correspond to IEEE802.3 10Base-T, used for network management.
4) The AC 220V input port of power supply 1.
5) The fuse of power supply 1.
6) The switch of power supply 1.
7) The AC 220V input port of power supply 2.
8) The fuse of power supply 2.
9) The switch of power supply 2.
10) Ground stud of the chassis: used for the connection of device and ground wire.
5.2.1 DC Power Module Introduction
1 Mounting screws 2 + Positive terminal block 3 - Negative terminal block

-
-
-
9
9
9 -
-
-
6. Menu System
6.1 Main Menu
Name display discription
xxxxxxx Manufacturers’ logo
xxxxxxx Equipment model
System Starting
xxxxxxx Start countdown / lock status
Sus pend Page In: xx.x out: xx.x
Unit: dBm Display the optical input / output power
1.Disp Parameters Entry of parameter display menu
2.Set Parameters Entry of parameter setup menu
Main Page
3.Alarm Status Entry of alarm information menu

-
-
-
1
1
10
0
0 -
-
-
6.2 Display Menu
Input Power: xx.x dBm Input power, accurate to 0.1 dBm
Output Power: xx.x dBm Output power，accurate to 0.1 dBm
Pump1 Power: xx .x mW Power of pump1, accurate to 0.1 dBm
Pump1 Bias: x.x A Bias current of pump1, accurate to 0.1 A
Pump1 Temper: xx.x ℃ Temperature of pump1, accurate to 0.1°C
Pump1 Cooling: x.xx A Cooling current of pump1, accurate to 0.01 A
Pump2 Vol: x.x V Drive voltage of pump2, accurate to 0.1 V
Pump2 Bias: x.x A Bias current of pump2, accurate to 0.1 A
* Pump2 Temper: xx.x ℃ Temperature of pump2, accurate to 0.1 °C
* Pump2 Tec Vol: x.x V Cooling voltage of pump2, accurate to 0.1 V
* Pump2 Cooling: x.xx A Cooling current of pump2, accurate to 0.01 A
TEC Vol: x.x V The first stage voltage of pump2 cooler, 0.1 V
1.Disp Parameters
+5V Read: x.x V +5V power supply voltage , accurate to 0.1 V

-
-
-
1
1
11
1
1 -
-
-
-5V Read: -x.x V -5V power supply voltage , accurate to 0.1 V
Box Temper: xx.x ℃ Box temperature, accurate to 0.1 °C
S/N: xxxxxxxx Device serial number
IP Address: xxx.xxx.xxx.xx x IP address
Subnet Mask:xxx.xxx.xxx.xxx Subnet mask
Net Gateway:xxx.xxx.xxx.xxx Gateway
Mac: xxxxxxx xxxxx Physical address
Trap1: xxx.xxx.xxx.xxx trap1 address
Trap2: xxx.xxx.xxx.xxx trap2 address
Software Version: Vx.xx.x.x Firmware version number
The ultra high power output EDFA no the “*” menu.
6.3 Setup Menu
Set Low Input Threshold
Set the low optical input power alarm
threshold, range -3.0～10.0dBm
Set High Input Threshold
Set the high optical input power alarm
threshold , range -3.0～10.0dBm
*Set Output ATT Set the optical output power attenuation
Set Local IP Addr Set IP address
Set Subnet Mask Set subnet mask
Set Gateway Set gateway
Set Trap1 Address Set trap1
Set Trap2 Address Set trap2
Set Buzzer cfg Set the switch of beeper
2.Set Parameters
Restore Factory config Restore the factory configuration，set

-
-
-
1
1
12
2
2 -
-
-
content as shown above
The ultra high power output EDFA no the “*” menu.

-
-
-
1
1
13
3
3 -
-
-
6.4 Warning menu
xxx= LOLOW: Very low optical input power alarm
xxx= LOW: Low optical input power alarm
xxx= HIGH: High optical input power alarm
Input Status: xxx
Xxx= HIHIGH: Very high optical input power alarm
xxx= LOLOW: Very low optical output power alarm
xxx= LOW: Low optical output power alarm
xxx= HIGH: High optical output power alarm
Output Status: xxx
Xxx= HIHIGH: Very high optical output power alarm
xxx= LOLOW: Very low power of pump x alarm
xxx= LOW: Low power of pump x alarm
xxx= HIGH: High power of pump x alarm
Pumpx Power:
xxx
Xxx= HIHIGH: Very high power of pump x alarm
xxx= LOLOW: Very low bias current of pump x alarm
xxx= LOW: Low bias current of pump x alarm
xxx= HIGH: High bias current of pump x alarm
Pumpx Bias: xxx
Xxx= HIHIGH: Very high bias current of pump x alarm
xxx= LOLOW: Very low temperature of pump x alarm
xxx= LOW: Low temperature of pump x alarm
xxx= HIGH: High temperature of pump x alarm
Pumpx Temper:
xxx
Xxx= HIHIGH: Very high temperature of pump x alarm
xxx= LOLOW: Very low cooling current of pump x alarm
xxx= LOW: Low cooling current of pump x alarm
xxx= HIGH: High cooling current of pump x alarm
Pumpx Tec: xxx
Xxx= HIHIGH: Very high cooling current of pump x
alarm
xxx= LOLOW: Very low +5V DC power supply alarm
xxx= LOW: Low +5V DC power supply alarm
xxx= HIGH: High +5V DC power supply alarm
+5V Status: xxx
Xxx= HIHIGH: Very high +5V DC power supply alarm
xxx= LOLOW: Very low -5V DC power supply alarm
xxx= LOW: Low -5V DC power supply alarm
xxx= HIGH: High -5V DC power supply alarm
-5V Status: xxx
Xxx= HIHIGH: Very high -5V DC power supply alarm
xxx= LOLOW: Very low chassis temperature alarm
xxx= LOW: Low chassis temperature alarm
xxx= HIGH: High chassis temperature alarm
3.Alarm Status
Device Temper:
xxx
xxx= HIHIGH: Very high chassis temperature alarm

-
-
-
1
1
14
4
4 -
-
-
7. Communication Setup Descriptions
7.1 Communication Interface Description
1) RS232 communication interface
Adopt DB9 standard connector, the pin definitions as follow:
The serial communication uses the standard NRZ form, 1 starts bit, 8 data bits,
1 stop bit and the baud rate is 38400.
2) LAN communication interface
Adopt RJ45 standard connector, the pin definitions as follow:
1: No Connect
4: No Connect
7: No Connect
2: TX
5: GND
8: No Connect
3: RX
6: No Connect
9: No Connect
1: TX+
4: No Connect
7: No Connect
2: TX-
5: No Connect
8: No Connect
3: RX+
6: RX-

-
-
-
1
1
15
5
5 -
-
-
7.2 Set up the Hyper Terminal
If you have not set up the Hyper Terminal in your Windows system, follow these
steps:
Click “start menuprogramaccessorycommunication Hyper Terminal”;
This results in the following screen:
Then you input your connection name, such as “SNMP38400”; and choose the serial
port to connect with your equipment. As follows:
Press the “OK” button shows the configuration page of serial port. As follows:
Change the serial port configuration to 38400-baud rate, 8 data bits, no parity bit, 1
stop bit, no data flow control, press the “OK” key, you have set up the Windows serial
port Hyper Terminal.

-
-
-
1
1
16
6
6 -
-
-
You can click “filesave” menu to save this configuration of Hyper Terminal for
later using.
Operating Paramete r Configuration
Under the condition of power off, use the serial port lines to connect the RS232
port with the computer port. Open the Windows Hyper Terminal which you have set
up. Then turn on the power, you will see the page as follows:
The application program starts normally. You can input your command in this page,
and then configure the operating parameter of the application program.
System supports the following commands:
help
ethcfg
settrap
setatt
List internal commands of the system;
Configure the Ethernet operating parameter;
Configure the aim host IP address of the SNMP Trap;
Show or modify the output attenuation.

-
-
-
1
1
17
7
7 -
-
-
Specific use as follows:
help
This command is used to show the current application program internal orders list as
follows:
You can also use the “help” command to show help information of other orders, such
as “help ethcfg”，ethcfg’s help information appears as follows:
ethcfg
This command configures the Ethernet parameters, including IP address, subnet mask,
gateway and physical address. You can refer to the help information for its using.
Direct input the command “ethcfg” as follow to see the parameters:
To set the IP address:

-
-
-
1
1
18
8
8 -
-
-
settrap
This command shows or modifies the aim host IP address lists of the SNMP Trap,
“settrap” command is used to display the current configured trap IP, as follows:
trap IP address set as follows:
setatt
This command is used to show or modify the output attenuation. Specific use as
follows:

-
-
-
1
1
19
9
9 -
-
-
The attenuation range is 0-3dB.
