KDS HD View4 User manual

Operating Instructions
HD View4: 4-channel
Distribution Amplifier with
cable compensation
adjustments
Manual for
HD View4
DISTRIBUTION AMPLIFIERS
4-Channel Component Video
(YPrPb) and Left & Right analog
audio, Composite Video and PCM
digital audio (up to 24 channels)
Distribution Amplifier with 16
adjustable outputs for compensa-
tion of cable runs up to 1000 feet
www.keydigital.com
Model#: KD-ADA4

HD View4
2
Introduction
Included in this package:
• One KD-ADA4 HD View4
• One external power supply
• One 75 Ohm terminator
• One Operating Manual with included Warranty statement
The KD-ADA4 HD View4 is a very versatile and novel Distribution Amplifier
(DA) that will suit your needs for crystal-clear distribution of HDTV and SDTV
Component Video (YPrPb) or Composite Video (CV) sources to Component
Video "HDTV-ready" monitors, or Composite Video monitors. Signal process-
ing circuitry permits excessive distribution cable runs of up to 1000 feet, sim-
ply by adjusting the front-panel knobs. And you can drive four component or
composite monitors simultaneously. Each unit handles Left and Right stereo
audio, or digital PCM audio.
HD View4 provides so much flexibility, yet will not degrade the image quality
of your input signals. Each unit can be cascaded to other KD-ADA4, KD-DA6,
or KD-CDA12 DA’s by Key Digital Systems, to drive as many outputs as
desired from one source. HD View4 has an added feature (via internal DIP-
switch control) whereby you can distribute only Composite Video (CV) or digi-
tal PCM audio inputs to as many as 24 destinations.
DISTRIBUTION AMPLIFIERS
Tech Support: Toll Free USA/Canada 888-258-2028 [email protected]
Customer Support: 718-796-7178 Ext. 23 [email protected]
Manual for HD View4
Product Overview
Why do you need a Distribution Amplifier?
For installations where you need to distribute your HD and SD video and analog or dig-
ital audio to more than one destination, you need a high-quality Distribution Amplifier
(DA). Perhaps you have a configuration where you need to distribute an HDTV Set
Top Box output to several different display monitors. You’ll want to feel confident that
the DA introduces little or no degradation to your signals.
Our DA’s produce crystal-clear images which do not harm your input signals, can drive
long cables (typically up to 300 feet, and our ADA4 which can drive up to 1000 feet),
and can be cascaded to accommodate future expansion requirements. Let us help you
choose exactly the right DA for your specific installation application.
The KD-ADA4 HD View4 Distribution Amplifier offers versatility, convenience, and well
thought-out features:

HD View4
3
KD-ADA4
• Enables HDTV and SDTV signal distribution to up to four separate
destinations:
• Component Video (YPrPb) sources to Component Video HDTV-ready
monitors
• Composite Video (CV) sources to Composite Video monitors
• L&R analog audio or digital PCM audio
• All known video formats accepted
• Can drive up to four Component Video or up to four Composite Video
monitors simultaneously with analog audio
• Can be configured via internal DIP switches to distribute Composite Video or
digital PCM audio in, to 24 CV or digital PCM out
• Can be cascaded to other KD-ADA4 DA’s, or other Key Digital Systems
Distribution Amplifiers like KD-DA6 or KD-CDA12 DA’s to drive as many
outputs as desired from one source
• Can drive equal-length video cables, up to 1000 feet each
Sales Support: 718-796-7178 Ext. 10 [email protected]
Marketing Support: 718-796-7178 Ext. 11 [email protected]
HD View4 www.keydigital.com
KD-ADA4 Input Connectors
• There is 1 HDTV/SDTV Input
Group, consisting of 6
color-coded RCA female
connectors for inputting:
• Component Video (YPrPb) with
composite sync on "Y"
• Composite Video (CV) or digital
PCM audio
• One analog audio (standard
line-type Left & Right pairs)
KD-ADA4
Output Connectors
• There are 4 discrete Output
Groups, and each Output Group
consists of 6 color-coded RCA
female connectors for outputting:
• Component Video (YPrPb) with
composite sync on "Y"
• Composite Video (CV) or digital
PCM audio
• One analog audio (standard
line-type Left & Right pairs)

HD View4
4
Introduction
DISTRIBUTION AMPLIFIERS
Tech Support: Toll Free USA/Canada 888-258-2028 [email protected]
Customer Support: 718-796-7178 Ext. 23 [email protected]
Quick Set Up
Connecting and using your KD-ADA4 HD View4 is a simple process.
KD-ADA4
STEP A: Configure your KD-ADA4 HD View4 Distribution Amplifier.
NOTE: Do not attempt to connect power to the unit during any of
the configuration steps.
STEP A1: Determine your configuration requirements. The KD-ADA4 HD
View4 has an "ADA4 Mode" and a "PCMD4 Mode" as described below.
Typical "ADA4 Mode" applications:
• Distribution of your YPrPb and Left & Right analog or digital PCM audio inputs
to as many as four separate Component Video monitors. In this case, the I/O
Connectors Groups would be used as shown:
KD-ADA4
Pr Y
LRPCM
Pb

HD View4
5
KD-ADA4
Sales Support: 718-796-7178 Ext. 10 [email protected]
Marketing Support: 718-796-7178 Ext. 11 [email protected]
HD View4 www.keydigital.com
• Distribution of your YPrPb and Left &
Right analog audio and Composite Video
(CV) inputs simultaneously to as many as
four separate Component Video and
Composite Video displays. In this case, the
I/O Connector Groups would be used as
shown:
Typical "PCMD4 Mode" applications:
• Distribution of your single digital PCM audio input to as many as 24 separate
destinations. In this case, the Input Connector Group would be used as
shown:
And each of
the four
Output
Connector
Groups would
be used as
shown:
And each of
the four
Output
Connector
Groups would
be used as
shown:
• Distribution of your single Composite Video (CV) input to as many as 24 sepa-
rate destinations. In this case, the Input Connector Group would be used as
shown:
KD-ADA4
Pr Y
L R CV
KD-ADA4
PCM
KD-ADA4
CV
KD-ADA4
PCM
PCM
PCM PCM PCM
PCM
KD-ADA4
PCM
PCM
PCM PCM PCM
PCM
Pb

HD View4
6
Introduction
DISTRIBUTION AMPLIFIERS
Tech Support: Toll Free USA/Canada 888-258-2028 [email protected]
Customer Support: 718-796-7178 Ext. 23 [email protected]
STEP A2: Set the internal DIP switches to match the Configuration Mode
you need for your application.
• Remove the front panel using a screwdriver, and find the six 8-bit DIP
Switches. Be sure to configure the six 8-bit DIP Switches as shown in the table
below for either the ADA4 or PCMD4 Mode:
STEP B: Connect your KD-ADA4 HD View4 Distribution Amplifier to your
Input and Output sources.
NOTE: Do not attempt to connect power to the unit during the
cable hook-up.
STEP B1: Based on your configuration selection, be sure to set the DIP
Switches as described in STEPS A. Use color-coded RCA cables to con-
nect the Inputs and Outputs to the back of the KD-ADA4 HD View4 unit.
Output runs should not exceed 1000 feet. Each run of YPrPb cable MUST
be of equal length per Output Group.
STEP B2: For the ADA4 Mode where less than four video outputs are
distributed, be sure to use the 75 Ohm terminator (supplied) to terminate
either Y, Pr, or Pb of the first unused Output Group. For example, if dis-
tributing with only Output Groups 1 and 2, then place the terminator on Y,
Pr, or Pb of Output Group 3. You should use the Output Groups in
sequential order.
STEP C: Apply power to the unit:
• Use ONLY the external wall-plug power supply provided with your unit, 110-
240V AC, 50-60 Hz, 0.9 Amps
• Connect the 5-pin DIN external power supply connector to your unit, and plug
the power supply into a power outle
SW1 SW2 SW3 SW4 SW5 SW8
BIT ADA4 PCMD4 ADA4 PCMD4 ADA4 PCMD4 ADA4 PCMD4 ADA4 PCMD4 ADA4 PCMD4
1 ON OFF ON OFF OFF ON OFF ON OFF ON ON OFF
2 OFF ON OFF ON ON OFF ON OFF ON OFF OFF ON
3 OFF OFF OFF ON ON OFF OFF ON OFF ON OFF ON
4 OFF OFF ON OFF OFF ON ON OFF ON OFF ON OFF
5 ON OFF ON OFF ON OFF OFF ON OFF ON ON OFF
6 OFF ON OFF ON OFF ON ON OFF OFF OFF OFF ON
7 OFF ON ON OFF OFF ON OFF ON ON OFF OFF ON
8 ON OFF OFF ON ON OFF OFF OFF OFF ON OFF ON

HD View4
7
KD-ADA4
Sales Support: 718-796-7178 Ext. 10 [email protected]
Marketing Support: 718-796-7178 Ext. 11 [email protected]
HD View4
Technical Specifications
www.keydigital.com
STEP D: Adjust the front-panel potentiometers to compensate for the long
cable Output runs of Y, Pr, Pb, and CV (Composite Video).
• The front panel of the KD-ADA4 HD View4 unit has four groupings, labeled
Output 1 through Output 4, which match the physical distribution Output Groups
1-4.
• You will need an Ohmmeter set in the range of 75 Ohms. You will need to per-
form the following procedure for each signal (CV, Pb, Y, Pr) for each Output
Group (1-4).
• For the PCMD4 Mode distribution of PCM digital audio, be sure to set all KD-
ADA4 Resistance values to 75 Ohms in the following procedures.
NOTE: POWER MUST BE TURNED OFF FOR THE KD-ADA4 AND ALL
OTHER UNITS CONNECTED TO THE I/O CABLES WHEN PERFORMING
THESE STEPS AND DIP SWITCHES SET TO ADA4 MODE.
STEP D1: Determine the resistance of each cable at the KD-ADA4 HD View4
end, when the cable is terminated at its destination. Use your Ohmmeter to
measure the resistance of the cable, by removing the cable from the back of the
KD-ADA4 HD View4 unit. This measurement is from the center point of the RCA
jack to the outside of the RCA jack. Make note of this resistance value, called
"Rload".
STEP D2: Determine the resistance of the KD-ADA4 HD View4. It is a simple
calculation, KD-ADA4 Resistance = 150 Ohms - Rload.
STEP D3: Set the KD-ADA4 HD View4 resistance. First, insert the Ohmmeter
cables into the top and bottom test sockets on the front of the KD-ADA4 HD
View4 for the signal corresponding to the cable you measured. Using a small,
slotted screwdriver or other implement, set the corresponding potentiometer (to
the lower left of each signal’s Ohmmeter test socket) to the value calculated
above for KD-ADA4 Resistance by comparing the Ohmmeter value to the desired
value for KD-ADA4 Resistance.
STEP D4: Repeat the above procedure in its entirety for each output cable.
Inputs (on back panel):
• There is 1 HDTV/SDTV Input
Group, consisting of 6 color-coded
RCA female connectors for
inputting:
• Component Video (YPrPb) with
composite sync on "Y"
• Composite Video (CV) or digital
PCM audio
• One analog audio (standard line-
type Left & Right pairs)
Outputs (on back panel):
• There are 4 discrete Output Groups, and
each Output Group consists of 6 color-coded
RCA female connectors for outputting:
• Component Video (YPrPb) with composite
sync on "Y"
• Composite Video (CV) or digital PCM audio
• One analog audio (standard line-type Left &
Right pairs)

Manual
DISTRIBUTION AMPLIFIERS
Technical Support
T[email protected]
1888-258-2028 / 1203-778-0295
HD View4
Customer Support
[email protected]
1718-796-7178 ext.23
Adjustments (on front
panel):
• Independent gain con-
trol adjustment provided
for all four Output Groups
for all video signals
(YPrPb & Composite
Video) to compensate for
excessive cable lengths
up to 1000 feet
• Sixteen, front-panel
adjustment potentiome-
ters
• Adjustment procedure is
based on measured out-
put cable resistance
• Each run of YPrPb
cable must be the same
length per output
Mechanical
• Easy to install and inte-
grate -- Custom Installer’s
dream
• Connectors and cables
are all located on the rear
of the unit
• All video and audio
inputs and outputs have
color-coded RCA female
connectors
• 5-pin DIN power con-
nector
• Cable compensation
adjustment potentiome-
ters are on the front of the
unit
• Rack mountable: 1U
• Size: 17" x 8" x 1.5"
• Weight: 4 lbs.
• Enclosure type: Metal
• Input Power: External
power supply provided,
110-240V AC, 50-60 Hz,
0.9A
Signal Properties:
• All known video
formats are accepted
• Output scanning
format is always the
SAME as the input
scanning format
• Component Video
• Bandwidth -3 dB at 120
MHz, linear-phase pass-
band
• Unity-gain, 1 volt p-p, ter-
minated to 75 ohms
• Composite sync on "Y"
channel
• Audio
• Bandwidth flat 20 Hz to 50
MHz
• Analog (standard line-type Left &
Right pairs) or digital PCM audio
• Digital PCM audio
Modes of Operation:
• You must set the six 8-bit DIP
Switches as described in the
Operation Manual to the desired
Operating Mode
• ADA4 Mode:
• Distribution of your YPrPb and
Left & Right analog or digital
PCM audio inputs to as many as
four separate Component Video
monitors
• Distribution of your YPrPb and
Left & Right analog audio and
Composite Video (CV) inputs
simultaneously to as many as
four separate Component Video
and Composite Video displays
• PCMD4 Mode:
• Distribution of your single digital
PCM audio input to as many as 24
separate destinations
• Distribution of your single
Composite Video (CV) input to as
many as 24 separate destinations
