Nexxia NX-089B-RR User manual

Please read the instructions thoroughly before installing this device. Autoleads will not accept liability for failure
of any part of vehicle (including audio system) if the instructions are not adhered to.
For ampl
ified vehicles low level from ISO
Designed for use
in
L
a
n
d
r
o
v
e
r
s
a
n
d
Range Rovers
NX
-089B-RR User Guide Ver 1.2. 02-06-09
Note:
If fitting Parrot kits you can also use Autoleads adaptors leads such as 06-423B, 06-
426B or 06-427B.
NX-089B-RR
Carphone kit does not work when stereo is off;
This is as expected. The stereo is responsible for powering an on-board amplifier, if
this is off, there is no access to any speakers in the vehicle
No audio present when in a call:
Disconnect the Telemute speaker jack plug and insert the original H/F speaker. Test
again, and if no audio is present, turn the ignition/stereo on. If audio is now present, then refer to
the top paragraph of this page. If audio still cannot be heard, then check for the presence of a
permanent live, mute signal and earth at the hands-free kit connector. If this still doesn't remedy the
problem, then call the Technical Helpline on 01480 832944
Troubleshooting Guide
Ignition supply and mute wire:
1) Remove head unit as per the manufacturers guide lines.
2) Connect NX-089B-RR in-line between head unit and radio harness.
3) Check mute operation by making a test call. The head unit should mute during a call
and come on again after the call is completed. Phone audio will be routed through the
front speakers.
4) Adjust the volume of both the phone and kit to standard levels, then adjust phone
audio level (not volume) through the stereo by use of the thumbwheel on the side of the
06-015 module.
Installation

NX-089B-RR Cont…..
WARNING: These instructions are for OEM audio systems only. Due to the vast array of aftermarket head units, careful checks must be made to
ensure that other head units will work with the Telemute system. Every effort has been made to ensure compatibility, and accuracy of the supplied
information. However, users are strongly advised to check the position of the permanent and ignition live before installation.
Copyright Nexxia Designs Ltd 2009.
Do not dispose as m unicipal waste. R euse or rec ycle whenever
possible. Electrical & Electronic waste may contain substances
harmful to the environm ent. For environmentally sound disposal
methods open to you, please contact your local council.
Products marked with the crossed out wheelie bin symbol should not
be treated as municipal waste.
A hands free kit adapter lead is needed when using a phone which is not a Nokia 6 pin molex. See catalogue for details.
Technical Enquiries:
Tel: [phone]
Email: [e-mail]
