Nimrof AT550 Manual

Technical User's Guide

Nimrof Series Water Leak Detection Devices
Sayfa 1
Warnings and Safety Terms
•Check the connections before operating the device.
•Make sure the device is turned off after using the device.
•Before putting the device in its bag, check whether it is turned on or not.
Nimrof –XXXX
AT550 –Dirty water pipe, Clean Water pipe and Gas Leakages
AT560 –Dirty water pipe, Clean Water Leakages

Nimrof Series Water Leak Detection Devices
Sayfa 2
Contents
Security Terms ………………………………………………………….
Contents…………..………………………………………………………
1 introduction………………………………………………………….
1.1 General Description……………………………………….
1.2 Application………………………………………..............
2 Technicial Specifications…………………………………………
3 Content Delivery……….. …………………………………………
4 Device Functions…………………………….……………………..
4.1 AB Sensor Setup…………………..…………………….
4.2 Listening Sensor Setup……….…………………………
4.3 Gas Sensor..……………………………………………..
4.4 Functions on the Device ….……………..……………..
4.4.1 Function of AT550…………………………..
4.4.2 Function of AT560……………………….…
5 Measurement Menu…………………………..…………………..
5.1 AB sensor…………………….……………………………..
5.2 Listening Sensor..…………………………………………..
5.3 Gas Sensor………………………………………….……….
6 Garanti Koşulları……………………………………………………
7 İletişim Bilgileri……………………………………………………...
1
2
3
3
3
3
4
4
5
6
6
7
7
8
9
9
9
10
10
10

Nimrof Series Water Leak Detection Devices
Sayfa 3
1 –Introduction
1.1 General Description
AT550 and AT560 make point determination of dirty and clean water leaks in
water pipe lines the device has two seperate sensors, one is acoustic listening
which helps to find clean water pipe network leaks. The other one is system that
is not required headphone and obliged of connection to test pumps and the leak
can be detected on a LCD screen.
1.2 Aplication
•Pipe Lines Leak
•Wastewater pipeline leaks
•Isolation Leaks
•Gas Leaks (for AT550)
2 –Technical Specifications
The technical specifications of the AT550 and AT560 devices are listed in figure
Tablo 2.1: Specifications of the AT550 and AT560
Nominal Ratings
AT550
AT560
Operating Voltage (DC)
14V(Li-ion Battery)
12V(Li-ion Battery)
Display
Numerical LCD
128x64 Graphic LCD
Resolution
16 bit
12 bit
Operating time
10 hours
10 hours
Operating temperature
10°C …+50°C
10°C …+50°C
Storage temperature
-25°C …+70°C
-25°C …+70°C
Weight
560 g
430 g
Device Dimensions
188 x 133 x 55 mm
105 x 201 x 41 mm
Warranty
2 years
2 years

Nimrof Series Water Leak Detection Devices
Sayfa 4
3 –Content Delivery
•Device
•Headphone
•Gas sensor(İt is valid for AT550 model)
•Listening sensor
•AB Sensors(A ve B Elektrotları)
•Extension Metal for A sensor
•25 and 3 meters cable
•Listening sensor cable
•Adapter
4 –Device Function
Nimrof AT550 and AT560 devices detect dirty water and clean water leaks in
water lines as a point. There are two separate sensors for water leaks, one of which
is an acoustic listening sensor that will only help you find clean water leaks. The
other is the AB sensor, which we call “non-listening”, which you can monitor both
dirty water leaks and clean water leaks without wearing headphones, without
connecting a test pump to the water leak line, via LCD. Natural gas leaks can also be
found with the natural gas sensor, which is only in the AT550 model..
•With metal electrode sensors, it can find both dirty and clean water leaks.
•Detects earth ground water leaks.
•Shows acoustic listening in graphic form.
•Ability to use acoustic listening sensor and metal electrode sensor together.
•Ability to use more than 10 water leaks with a ones charge.
•No need for channel imaging or thermal camera thanks to electrode sensors.

Nimrof Series Water Leak Detection Devices
Sayfa 5
4.1 AB sensor Setup
İmages of A and B sensors in the figüre
Sensor A Sensor B
Sensor A : The sensor cable that will stay in the downstairs apartment or in the area
where the water leak is located is 25 meters.Below is the threaded round metal piece
to be connected to the A sensor This part should be touched to the leaking area.
Sensor B : It is the sensor that should be in the upstairs apartment or next to the
user. It is touched to the suspected places and the values are observed on the
screen.
Note: The ends of the cables are colored and must be connected to the 25-meter red
sensor A. The end of the 3 meter cable is black and must be connected to the B
sensor. The free ends of the cables should be connected to the A and B inputs of the
device in color.

Nimrof Series Water Leak Detection Devices
Sayfa 6
4.2 Listening Sensor Setup
Listening Sensor consists of three parts. Cylinder metal part, Short rod and Sensor
Note : The cylindrical metal piece attached to the end of the sensor is used in both A
sensor and the listening sensor.
4.3 Gas Sensor Installation
The gas sensor consists of one piece. Applicable for At550 model only
Note: The cable used is the same as the listening sensor.

Nimrof Series Water Leak Detection Devices
Sayfa 7
4.4 Functions on the Device
4.4.1 Function of AT550
Water Signal A
A sensor input
Water Signal B
B sensor input
Sensor
Gas and Listening Sensor input
Ear
Headphone jack
Volume
Volume Up and Down for listening
sensor
Menu
It is the menu entry button and the
confirmation key.
Gas Shortcut key and up key in the
menu
AB sensor Shortcut key and down key in
the menu

Nimrof Series Water Leak Detection Devices
Sayfa 8
4.4.2 Function of AT560
A
A sensor input
B
B sensor input
Sensor
Listening Sensor input
Ear
Headphone jack
Volume
Volume Up and Down for listening
sensor
It is the menu entry button and the
confirmation key.
Back button or cancel button
The left button
The right button also it is mute button
in listening menu

Nimrof Series Water Leak Detection Devices
Sayfa 9
5 –Measurement Menu
5.1 AB Sensor
•Activated from the menu button.
•Connections are made as described in 4.1
•The red electrode A is touched to the leaked area and fixed there (25 meters).
•The black B electrode is touched by the user to the suspected places in the
upstairs apartment.
•The numbers on the LCD are observed, the highest values are noted.
•Then the A electrode is removed from the downstairs apartment to the
upstairs apartment. This time, tap and water expenses are touched and
compared with the values taken from the lower flat.
•The numbers appearing on the LCD screen are observed, the highest value is
the area with the leak.
•The AT550 has a Shortcut button for this feature.
Note:
•This feature can be used for both dirty drain water leaks and clean water
leaks.
•You can also use the listening sensor while taking AB measurements
•The values you get from the wall indicate that there is a leak in the wall.
•Garden water leaks are used in the same way as in the apartment.
5.2 Listening Sensor
•Set the volume to the lowest level
•Turn on the device
•Activate the listening sensor from the menü
•Install the listening sensor as described in 4.2
•Plug in the headset
•Connect the listening sensor to the device
•In the Listening sensor menu, this button is the mute button.

Nimrof Series Water Leak Detection Devices
Sayfa 10
Note: You can also observe numerically and graphically on the LCD screen. but be
sure of the water leakage by ear. Do not trust the values on the screen.
5.2 Gas Leaks
This feature is only valid for the AT550 product.
•Install the sensor as described in 4.3.
•Connect the cable to the sensor and the device.
•Shortcut key on homepage
Note: Wait for the sensor to calibrate itself at each start.
6 –Terms and Conditions
Nimrof are warranted for 2 (two) year starting from the delivery date of the product. The
consumables (cables, USB memory or CD .) supplied with the device are not covered by the warranty.
All of the goods, including all parts (against defects that may occur due to production and assembly
errors and/or defective parts), are within the scope of our company's warranty. In the event that the
product fails during the warranty period, due to material and workmanship or assembly errors, it will be
repaired without any charge under any other name, such as labor cost, replacement part cost or any
other name. The repair undertaken with this guarantee will be made by authorized services of Birrenk
Bilgisayar Sistemleri LTD
The Nimrof electronic products are out of warranty in case of user error, uses not in accordance
with recommended practice presented in this datasheet, internal circuits are tampered with and/or the
cover is removed. Probes, cables CD or USB sticks are out of warranty. In case of malfunction of the
device, please send it to Birrenk Bilgisayar Elektronik Ltd Şti or authorized distributor.
7 –Contact
Birrenk Bilgisayar Elektronik Ltd. Şti.
Address: Merkez Mahallesi - Fatih Sokak - No:29/A Avcılar / Istanbul
Phone: [phone]
E-Mail: [e-mail]
Facebook: https://www.facebook.com/nimrof
Web: www.nimrof.com
Coordinate : 40.981705, 28.723324
