PRECISION DIGITAL vantageview Safe Touch PD6700-0L1 User manual

PD6700-0L1 Field-Mount Loop-Powered
Process Meter with Bargraph
Instruction Manual
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel [phone] • Fax [phone]
www.predig.com
•NEMA 4X, IP66 Loop-Powered Field-Mount Process Meter
•4-20 mA Input with ±0.03% Accuracy
•3.0 Volt Drop (6.0 Volt Drop with Backlight)
•Easy Field Scaling in Engineering Units without Applying an Input
•0.6" (15.2 mm) 5 Digits Upper Display
•0.4" (10.2 mm) 7 Alphanumeric Characters Lower Display
•Display Mountable at 0°, 90°, 180°, & 270°
•SafeTouchTM Through-Window Button Programming
•Display Input in Two Different Scales Simultaneously - Great for Level Applications
•20-Segment Level Indicator Bargraph
•Open Collector Output Assignable to High or Low Alarm
•HART®Protocol Transparent
•Loop or External DC-Powered Backlight Standard
•Operating Temperature Range: -40 to 75°C (-40 to 167°F)
•Conformal Coated PCBs for Dust and Humidity Protection
•Password Protection
•32-Point Linearization
•Wide Viewing Angle
•Flanges for Wall or Pipe Mounting
•Plastic NEMA 4X, IP66 Enclosure
•Three 3/4" NPT Threaded Conduit Openings (Two Plugs Installed)
•Stainless Steel Tag Available
•3-Year Warranty

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
2
Disclaimer
The information contained in this document is
subject to change without notice. Precision
Digital Corporation makes no representations
or warranties with respect to the contents hereof;
and specifically disclaims any implied warranties
of merchantability or fitness for a particular
purpose.
•Read complete instructions prior to installation
and operation of the meter.
•Risk of electric shock or personal injury.
•This product is not recommended for life support
applications or applications where malfunctioning
could result in personal injury or property loss.
Anyone using this product for such applications
does so at his/her own risk. Precision Digital
Corporation shall not be held liable for damages
resulting from such improper use.
•Failure to follow installation guidelines could
result in death or serious injury. Make sure only
qualified personnel perform the installation.
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Limited Warranty
Precision Digital Corporation warrants this
product against defects in material or
workmanship for the specified period under
“Specifications” from the date of shipment from
the factory. Precision Digital’s liability under this
limited warranty shall not exceed the purchase
value, repair, or replacement of the defective unit.
See Warranty Information and Terms &
Conditions on www.predig.com for complete
details.
© 2020 Precision Digital Corporation.
All rights reserved.
Introduction
The PD6700-0L1 is a rugged, field-mount,
loop-powered meter fully featured for demanding
applications in harsh environmental conditions. The
bargraph representation of the process input is
perfect for level applications and allows for quick
assessment of current conditions. The meter derives
all its power from the 4-20 mA loop. It is programmed
using the four SafeTouch through-window buttons,
without removing the cover, and can be scaled with or
without a calibration signal. The numeric display will
read up to 99999 and the alphanumeric display can
be programmed to show any combination of numbers
and letters up to seven characters long for use as
engineering units, the process identification tag or a
display for the calculated volume when using for level
applications. The backlight lets you see the display
under any lighting condition and can be powered from
either the 4-20 mA loop or from a separate DC power
supply.
The enclosure is provided with three threaded conduit
holes and integrated pipe or wall mounting slotted
flanges.
Ordering Information
Model
Description
PD6700-0L1
Field-Mount Loop-Powered Process
Meter with Bargraph
Accessories
Model
Description
PDAPLUG75P
3/4" NPT Plastic Conduit Plug
PDA1024-01
24 VDC Power Supply for DIN Rail
PDA6846
Steel 2" U-Bolt Kit. All Material: Zinc
Plated Steel; (1) U-Bolt for 2" Pipe
with (2 each) Washers, Lock
Washers, and Nuts.
PDA6846-SS
Stainless Steel 2" U-Bolt Kit. All
Material: Stainless Steel; (1) U-Bolt
for 2" Pipe with (2 each) Washers,
Lock Washers, and Nuts.
PDA-SSTAG
Custom Stainless Steel Tag (see
website for convenient ordering
form)

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
3
Table of Contents
Introduction..........................................................................................................2
Ordering Information...........................................................................................2
Specifications.......................................................................................................5
General.............................................................................................................5
Input..................................................................................................................5
Open Collector Output....................................................................................5
Safety Information ...............................................................................................6
Installation............................................................................................................6
Unpacking........................................................................................................6
Pre-Installed Conduit Plug..............................................................................6
Mounting ..........................................................................................................6
Dimensions......................................................................................................6
Connections.....................................................................................................7
Wiring Diagrams..............................................................................................8
External Acknowledge Connection................................................................8
Open Collector Output Connections..............................................................8
Setup and Programming.....................................................................................9
Overview...........................................................................................................9
SafeTouch Buttons..........................................................................................9
SafeTouch Button Operation.........................................................................9
SafeTouch Button Tips and Troubleshooting................................................9
Buttons and Display......................................................................................10
Main Menu Display Functions & Messages................................................11
Main Menu......................................................................................................11
Setting Up the Meter (SETUP) ........................................................................12
Setting Numeric Values...............................................................................12
Setting the Level Decimal Point (DECIMAL).................................................12
Scaling the Meter (SCaLe)...........................................................................13
Minimum Input Span...............................................................................13
Scale Error Message (SPN ERR).............................................................13
Scaling the Tank Level Indicator (PERCENT)................................................13
Configuring the Display (DISPLAY)..............................................................13
Setting the Tag (TAG)..............................................................................14
Setting Up the Password (PASSWRD)............................................................14
Locking the Meter........................................................................................14
Making Changes to a Password Protected Meter.......................................14
Disabling Password Protection....................................................................14
Advanced Features Menu (ADVANCE)...........................................................15
Advanced Features Menu & Display Messages..........................................16
Alarm Output (OUTPUT)................................................................................17
Input Signal Filter (FILTER).........................................................................17
Volume Display Scaling (VOLSCAL).............................................................17
Level Input Live Signal Calibration (LVL CAL).............................................18
Internal Calibration (ICAL)...........................................................................18
Calibration Error Message ( SPN ERR ) ..........................................................18
Level Input Multipoint Linearization (MULTIPT)............................................18
Information (INFO).......................................................................................18
Operation............................................................................................................19
Front Panel Buttons Operation....................................................................19
Display Maximum, Minimum, and Input Current........................................19
Reset Meter to Factory Defaults...................................................................19
Factory Defaults & User Settings.................................................................20
Troubleshooting.................................................................................................20
Troubleshooting Tips....................................................................................20
Quick User Interface Reference........................................................................21

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
4
Table of Figures
Figure 1. Enclosure Dimensions –Front View....................................................6
Figure 2. Enclosure Dimensions –Side Cross Section View............................6
Figure 3. Connector Board....................................................................................7
Figure 4. Connections without Backlight............................................................8
Figure 5. Connections with Loop-Powered Backlight........................................8
Figure 6. Connections with Externally-Powered Backlight..................................8
Figure 7. External Alarm Reset/Acknowledge Connections..............................8
Figure 8. Connection to Device with Internal Pull-Up........................................8
Figure 9. Output Connections ..............................................................................8

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
5
Specifications
Except where noted all specifications apply to operation at +25°C.
General
Display
Five digits
(-9999 to
99999)
0.60" (15.2 mm) high,
7-segment,
automatic lead zero
blanking.
Seven
characters
0.4" (10.2 mm) high,
14-segment.
Symbols
Bargraph which displays
process input from
0-100% of scaled value.
Display
Orientation
Display may be mounted at 90° increments
up to 270° from default orientation.
Display
Assignment
Lower display may be assigned to custom unit
or tag, volume, volume and tag, percent height,
percent height and tag, or off.
Display
Update Rate
Ambient > -25°C: 2 Updates/Second
Ambient < -25°C: 1 Update/5 Seconds
Backlight
White; Loop-powered or externally powered.
Backlight can be enabled or disabled via
alternative wiring of terminal block. Loop-
powered backlight brightness will increase as
the input signal current increases. Externally
powered backlight has consistent brightness.
Externally
Powered
Backlight
Voltage
Range:
Maximum Power
9-36
VDC
9
VDC
12
VDC
24
VDC
36
VDC
0.2 W
0.25 W
0.5 W
0.75 W
Display
Overrange
Display flashes 99999
Display
Underrange
Display flashes -9999
Programming
Method
Four SafeTouch through-window buttons when
cover is installed. Four internal pushbuttons
when cover is removed.
Noise Filter
Programmable LO,med,HI, or OFF
Recalibration
Recalibration is recommended at least every
12 months.
Max/Min
Display
Max/Min readings reached by the process are
stored until reset by the user or until power to
the meter is turned off.
Advanced
Function
Linear, square root, or programmable
exponent
Password
Programmable password restricts modification
of programmed settings.
Non-Volatile
Memory
All programmed settings are stored in non-
volatile memory for a minimum of ten years if
power is lost.
Normal Mode
Rejection
64 dB at 50/60 Hz
Environmental
Operating temperature range: -40 to 75°C
Storage temperature range: -40 to 75°C
Relative humidity: 0 to 90%
non-condensing
Connections
Screw terminals accept 12 to 22 AWG wire
Enclosure
NEMA 4X, IP65 plastic field enclosure
Color: grey
Three ¾" NPT threaded conduit openings.
Two ¾" NPT plastic conduit/stopping plugs
with 1.29" wrenching flats and screwdriver
slot.
Mounting
May be mounted directly to conduit. Two
slotted flanges for wall mounting or NPS
1½" to 2½" or DN 40 to 65 mm pipe
mounting. See Dimensions on page 6.
Overall
Dimensions
5.67" x 5.25" x 4.18" (W x H x D)
(144 mm x 133 mm x 106 mm)
Weight
1.65 lbs (26.4 oz, 0.75 kg)
Warranty
3 years parts and labor. See Warranty
Information and Terms & Conditions on
www.predig.com for complete details.
Input
Input
4-20 mA
Accuracy
±0.03% of calibrated span ±1 count,
square root & programmable exponent
accuracy range:
10-100% of calibrated span.
Maximum
Voltage Drop &
Equivalent
Resistance
Without Backlight
or with Externally
Powered Backlight
With Loop-Powered
Backlight
3.0 VDC @ 20 mA
6.0 VDC @ 20 mA
150 Ω @ 20 mA
300 Ω @ 20 mA
Temperature Drift
50 PPM/C from -40 to 75C ambient
Multi-Point
Linearization
2 to 32 points
Decimal Point
User selectable decimal point
Minimum Span
Input 1 & Input 2: 0.10 mA
Calibration Range
An Error message will appear if input 1 and
input 2 signals are too close
together.
Input
Range
Minimum Span
Input 1 & Input 2
4-20 mA
0.10 mA
Input
Overload
Over current protection to 2 A max.
HART
Transparency
The meter does not interfere with existing
HART communications; it displays the 4-20
mA primary variable and it allows the
HART communications to pass through
without interruption.
The meter is not affected if a HART
communicator is connected to the loop.
The meter does not display secondary
HART variables.
Open Collector Output
Rating
Isolated open collector, sinking NPN
30 VDC @ 150 mA max.
Alarm Output
Assign to level or volume for high or low
alarm trip point.
Deadband
0-100% FS, user selectable
Acknowledge
Front panel ENTER button and external
RESET terminals resets output and screen
indication.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
6
Safety Information
•Read complete instructions prior to installation
and operation of the meter.
•Installation and service should be performed only
by trained service personnel.
•If the meter is installed in a high voltage
environment and a fault or installation error
occurs, high voltage may be present on any lead.
Installation
Wiring connectors are accessed by opening the
enclosure. To access electrical connectors, remove
the 2 captive screws, then disconnect the ribbon
cable from the display module and set the display
module aside.
Unpacking
Remove the meter from box. Inspect the packaging
and contents for damage. Report damages, if any, to
the carrier.
If any part is missing or the meter malfunctions,
please contact your supplier or the factory for
assistance.
Pre-Installed Conduit Plug
The PD6700-0L1 is supplied with two pre-installed
conduit plugs for installations that do not require the
use of all three conduit entries.
Mounting
The PD6700-0L1 has two slotted mounting flanges
that may be used for pipe mounting or wall mounting.
Alternatively, the unit may be supported by the
conduit using the conduit holes provided.
Refer to Figure 1and Figure 2below.
•Do not attempt to loosen or remove flange bolts
while the meter is in service.
Dimensions
All units: inches [mm]
Figure 1. Enclosure Dimensions –Front View
Figure 2. Enclosure Dimensions –
Side Cross Section View

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
7
Connections
To access the connectors, remove the enclosure
cover and unscrew the two captive screws that fasten
the display module. Disconnect the ribbon cable and
remove the display module. Signal connections are
made to a four-terminal connector in the base of the
enclosure.
SIGNAL +
4-20 mA signal input positive
terminal connection
SIGNAL -
4-20 mA signal return/negative
terminal connection when not
using loop powered backlight.
BACKLIGHT +
+9-36 VDC when powering
backlight from external supply.
BACKLIGHT -
4-20 mA signal return/negative
terminal when using the
installed loop powered backlight
or ground/negative when
powering backlight from external
supply.
OUTPUT+
NPN open collector output
positive.
OUTPUT-
NPN open collector output
negative.
RESET +
Contact closure alarm
acknowledge, pull up to 3 VDC.
RESET-
Contact closure alarm
acknowledge ground/negative.
Refer to Figure 3for terminal positions.
•Observe all safety regulations. Electrical wiring
should be performed in accordance with all
agency requirements and applicable national,
state, and local codes to prevent damage to the
meter and ensure personnel safety.
•Static electricity can damage sensitive
components.
•Observe safe handling precautions for
static-sensitive components.
•Use proper grounding procedures/codes.
•If the meter is installed in a high voltage
environment and a fault or installation error
occurs, high voltage may be present on any lead
or terminal.
Figure 3. Connector Board
SAFE-TOUCH
BUTTONS BACKLIGHT
POWER
UNLOCK LOCK LOOP
9-36 VDC
+-+-
SIGNAL BACKLIGHT
+-+-
OUTPUT RESET

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
8
Wiring Diagrams
Signal connections are made to a four-terminal
connector mounted in the base of the enclosure per
Figure 3. Connector Board. The enclosure also
provides one internal and one external earth
grounding screw.
For installations that don’t use the backlight, the
maximum voltage drop is 3 V and connections are
made per Figure 4.
For installations that use the backlight powered from
the loop, the maximum voltage drop is 6 V and
connections are made per Figure 5.
For installations that use the backlight powered from
an external source, the maximum voltage drop is 3 V
and connections are made per Figure 6.
Figure 4. Connections without Backlight
Figure 5. Connections with Loop-Powered Backlight
Loop-powered backlight brightness will increase as
the input signal current increases. If constant
backlight brightness is desired, the backlight should
be powered by an external source.
Figure 6. Connections with Externally-Powered Backlight
It is possible to use the same transmitter (signal loop)
power supply for the externally powered backlight.
The backlight circuit will draw 25 mA in addition to the
loop circuit.
External Acknowledge Connection
External acknowledge connections are made to two
terminals labeled RESET. Connect to a contact closure
source such as a relay or a pushbutton as shown in
Figure 7.
Figure 7. External Alarm Reset/Acknowledge
Connections
Open Collector Output
Connections
Output connections are made to two terminals labeled
OUTPUT. The output can be connected to an input
device such as alarm indicator as shown in Figure 8, or
to drive a relay as shown in Figure 9.
•To avoid damaging the PD6700-0L1’s amplifying
components, use care not to wire incorrectly or
exceed output ratings. A diode, such as 1N4000
series, will provide protection from relay
transients.
Figure 8. Connection to Device with Internal Pull-Up
Figure 9. Output Connections
4-20 mA
Transmitter
+-+-
SIGNAL BACKLIGHT
Power
Supply
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER
+-+-
OUTPUT RESET
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER
4-20 mA
Transmitter
+-+-
SIGN AL BAC KL IG HT
Slide Switch to
LOOP
Power
Supply +-+-
OUTPUT RESET
4-20 mA
Transmitter
+-+-
SIGN AL BAC KLIGHT
Slide Switch to
9-36 VDC
Power Supply
Power
Supply +-+-
OUTPUT RESET
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER
+-+-
SIGN AL BAC KLIGHT
+-+-
OUTPUT R ESET
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER
+-+-
SIGN AL BACKL IGHT
+-+-
OU TPUT RESET
+
AlarmRecorder
or Annunciator
(e.g. PD8-158) -
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER
+-+-
SIGN AL BACKLIGHT
+-+-
OUTPUT R ESET
UNLOCK LOCK
SAFE-TOUCH
BUTTONS
LOOP9-36
VDC
BACKLIGHT
POWER

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
9
Setup and Programming
There is no need to recalibrate the meter when first
received from the factory. Simply scale the meter to
display the process in engineering units.
The meter is factory calibrated and it is scaled to read
0.0 to 100.0%, which correspond to a 4-20 mA input. The
calibration equipment is traceable to NIST standards.
Overview
Setup and programming is done through the infrared
through-window SafeTouch buttons or using the
mechanical buttons when uncovered. There are two
slide switches located on the connector board. One is
used to select backlight power and the other is to lock
or unlock the SafeTouch Buttons.
After all connections have been completed and
verified, connect the ribbon cable to the display
module, fasten the display module to the base, install
enclosure cover, and then apply power.
SafeTouch Buttons
The PD6700-0L1 is equipped with four sensors that
operate as through-window buttons so that it can be
programmed and operated without removing the
cover and exposing the electronics to the
environment. These buttons can be disabled for
security by selecting the LOCK setting on the SAFE-
TOUCH BUTTONS switch located on the connector
board in the base of the enclosure.
SafeTouch Button Operation
To actuate a button, press and remove one finger to
the window directly over the marked button area.
Remove finger to at least 4 inches away from the
window in between button activations. SafeTouch and
mechanical buttons may be held to cycle through
menus or digits in place of repeatedly pushing a
button. The sensors are disabled when a mechanical
button is pressed and will automatically be re-enabled
after 60 seconds of inactivity.
SafeTouch Button Tips and
Troubleshooting
The SafeTouch buttons are designed to filter normal
levels of ambient interference and to protect against
false triggering, however, it is recommended that the
SafeTouch buttons be disabled (slide switch to LOCK)
if there is an infrared interference source in line-of-
sight to the display.
SafeTouch Button Tips:
•To the extent possible, install the display facing
away from sunlight, windows, reflective objects
and any sources of infrared interference.
•Keep the window clean.
•Tighten the cover securely.
•Use a password to prevent tampering.
•If the cover has not been installed and secured
tightly, it may take a moment for the SafeTouch
buttons to properly self-calibrate when the cover
is tightened.
•SafeTouch buttons will not work if two or more
buttons are detected as being pressed
simultaneously. As a result, be careful to avoid
triggering multiple buttons or reaching across one
button location to press another.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
10
Buttons and Display
Button
Symbol
Description
Symbol
Status
Menu
20-Segment
Tank Level
Indicator
Bargraph
Right
arrow/
Reset
Password
Enabled
Up arrow/
Display
Enter
Menu Button
•Press the Menu button to enter Programming
Mode.
•Press the Menu button during Programming
Mode to return to the previous menu
selections.
•Hold the Menu button for 1.5 seconds at any
time to exit Programming Mode and return to
Run Mode.
•Press and hold the Menu button for 5 seconds
to access the Advanced Features of the meter.
Right / Reset Button
•Press the Right arrow button to reset the
maximum or minimum value while it is being
displayed (see Up / Display Button below).
•Press the Right arrow button to move to the
next digit or decimal position during
programming.
•Press Right to go backward through most
selection menus.
Up / Display Button
•Press Display when in Run Mode to cycle
through displaying the maximum value,
minimum value, and the loop input value in
mA. The display will time out in 12 seconds.
Press Display again to resume normal lower
display operation (lower display will read
RESUME).
•Press the Up arrow button to scroll forward
through the menus, decimal point, or to
increment the value of a digit.
Enter Button
•Press the Enter button to access a menu or to
accept a setting.
•Press Enter to acknowledge alarm (if enabled).
MENU
RESET
DISPLAY
ENTER

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
11
Main Menu Display Functions &
Messages
The meter displays various functions and messages
during setup, programming, and operation. The
following table shows the main menu functions and
messages in the order they appear in the menu.
Display
Parameter
Action/Setting
SETUP
Setup
Enter Setup menu
DECIMAL
Decimal Point
Enter the decimal point
location
SCALE
Scale
Enter the Scale menu
for engineering units
INPUT 1
Input 1
Set input 1 value in mA
DSPLY 1
Display 1
Set display 1
engineering units
INPUT 2
Input 2
Set input 2 value in mA
DSPLY 2
Display 2
Set display 2
engineering units
SAVE ?
Save?
Save entered scale
parameters?
SPN ERR
Span Error
Scale point 1 and 2
span error
PERCENT
Percent
Scale the tank indicator
full and empty values
0 PCT
0 Percent
Set the tank empty
value
100 PCT
100 Percent
Set the tank full value
DISPLAY
Display
Enter Bottom Display
menu
TAG
Tag
Display a custom unit or
tag
VOLUME
Volume
Display volume
VOL+TAG
Volume + Tag
Display volume and
custom tag
PCT HT
Percent Height
Display percent height
PCT+TAG
Percent Height
+ Tag
Display percent height
and custom tag
OFF
Off
Disable lower display
ADVANCE
Advanced
Advanced Features
Menu (See Advanced
Features Menu
(ADVANCE) on page 15)
PASSWRD
Password
Enter the Password
menu
UNLOCKD
Unlocked
Program password to
lock meter
LOCKED
Locked
Enter password to
unlock meter
SETUP
Setup
Enter Setup menu
Main Menu
The main menu consists of the most commonly used
functions: Setup, Advanced, and Password.
Press MENU button to enter Programming Mode then
press the Up Arrow button to scroll through the main
menu.
Hold MENU, at any time, to exit and return to Run
Mode. Changes made to settings prior to pressing
ENTER are not saved.
Press the MENU button during Programming Mode to
return to the previous menu selections.
Changes to the settings are saved to memory only
after pressing ENTER.
The display moves to the next menu every time a
setting is accepted by pressing ENTER.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
12
Setting Up the Meter (SETUP)
The Setup menu is used to select:
1. Decimal point location
2. Scale in engineering units
3. Tank indicator 0 and 100%
4. Lower display selection
5. Turn on/off bargraph (Tank indicator)
Press the ENTER button to access any menu or
press UP arrow button to scroll through choices.
Hold MENU, at any time, to exit and return to Run
Mode. Changes made to settings prior to pressing
ENTER are not saved.
Press the MENU button during Programming Mode to
return to the previous menu selections.
Setting Numeric Values
The numeric values are set using the RIGHT and UP
arrow buttons. Press RIGHT arrow to select next digit
and UP arrow to increment digit.
The digit being changed blinks.
Press the ENTER button, at any time, to accept a
setting.
Hold MENU, at any time, to exit and return to Run
Mode. Changes made to settings prior to pressing
ENTER are not saved.
Press the MENU button during Programming Mode
to return to the previous menu selections.
Setting the Level Decimal Point
(DECIMAL)
Decimal point may be set with up to four decimal
places or with no decimal point.
Pressing the Right arrow moves the decimal point
one place to the right and pressing the Up arrow
moves the decimal point one place to the left.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
13
Scaling the Meter (SCaLe)
The 4-20 mA input can be scaled to display the
process in engineering units. To scale the meter,
enter the value in milliamps (mA) for input 1, and then
the corresponding engineering units display value. Do
the same for input 2.
After entering the display 2 value, confirm the new
scale by pressing ENTER at the Save menu.
A signal source is not needed to scale the meter;
simply program the inputs and corresponding display
values.
For instructions on using multipoint scaling, see Level
Input Multipoint Linearization (MULTIPT) on page 18.
Minimum Input Span
The minimum input span is the minimum difference
between input 1 and input 2 signals required to
complete the calibration or scaling of the meter. The
minimum span is 0.10 mA.
Scale Error Message (SPN ERR)
If the minimum span is not maintained, the meter will
show a span error (SPN ERR) and revert to input 1,
allowing the appropriate input signals to be applied.
Note: The Scale and Calibrate functions are exclusive
of each other. The meter uses the last function
programmed. Only one of these methods can be
employed at a time. The Scale and Calibrate
functions can use up to 32 points (default is 2). The
multi-point linearization should be enabled in the
Advanced Features menu under the Level Input
Multipoint Linearization (MULTIPT)menu selection,
prior to scaling and calibration of the meter, see
Advanced Features Menu
(ADVANCE)on page 15.
Scaling the Tank Level Indicator
(PERCENT)
The display includes a 20-segment tank level
indicator. This menu sets full and empty values,
in engineering units, for the tank level indicator.
This value may differ from the 20 mA full-scale and
4 mA empty-scale values programmed in the Scale
menu. This is ideal for level transmitters that output
less than 20 mA at the maximum height of the tank
or pit or more than 4 mA at the minimum height.
As an example, when using a level transmitter that
outputs 20 mA at 25 meters, the tank height indicator
may be set for a maximum of 10 meters. When the
meter reaches 10 meters on the display, the tank
height indicator will show full, even though the input
is not 20 mA.
Configuring the Display (DISPLAY)
The lower (BOTTOM) display may be configured to
display a custom tag (TAG), volume (VOLUME), volume
and tag (VOL+TAG), percent of full height (PCT HT),
percent of full height and tag (PCT+TAG), or be blank
(OFF).
A custom tag of up to seven alphanumeric characters
may be programmed for identification (e.g. TANK 3) or
for engineering units (e.g. GALLONS).
Percent full height shows the percent full of the tank
height level indicator programmed in the Scaling the
Tank Level Indicator (PERCENT)menu.
The tank level indicator (GRAPH) may also be turned
on or off from the display menu.
Note:
Volume is a separate, second scale of the input
process variable. This is configured in Volume Display
Scaling (VOLSCAL) on page 17.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
14
Setting the Tag (TAG)
Any lower display setting that includes a tag will
require the tag to be entered.
The fully alphanumeric values for the tag are set
using the RIGHT button to select the digit, the UP and
RIGHT arrow buttons to select the digit reading, and
the ENTER button to confirm and select the next digit.
Setting Up the Password
(PASSWRD)
The Password menu is used to program a five-digit
password to prevent unauthorized changes to the
programmed parameter settings. A password
protected meter will display LOCKED when the MENU
button is pressed.
Locking the Meter
Enter the Password menu and program a five-digit
password.
For instructions on how to program numeric values
see Setting Numeric Values, page 12.
Record the password for future reference. If
appropriate, it may be recorded in the space provided.
Model:
Serial Number:
Password:
__ __ __ __ __
Making Changes to a Password
Protected Meter
If the meter is password protected, the meter will
display the message LOCKED when the Menu button
is pressed. Press the Enter button while the message
is being displayed and enter the correct password to
gain access to the menu. After exiting the
programming mode, the meter returns to its password
protected condition.
Disabling Password Protection
To disable the password protection, access the
Password menu and enter the correct password, as
shown below.
If the correct five-digit password is entered, the meter
displays the message UNLOCKD (unlocked) and the
protection is disabled until a new password is
programmed.
If the password entered is incorrect, the meter
displays the message LOCKED and returns to Run
Mode. To try again, repeat the above procedure.
Did you forget the password?
The password may be disabled by entering a
master password. If you are authorized to make
changes, enter the master password 50865 to
unlock the meter.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
15
Advanced Features Menu
(ADVANCE)
To simplify the setup process, functions not needed
for most applications are located in the Advanced
Features Menu. Access the Advanced Features Menu
by pressing ENTER at the ADVANCE menu in the Main
Menu defined on page 11.
The Advanced Features Menu is used to select:
1. Open collector output configuration (OUTPUT)
2. Input filter (FILTER)
3. Volume display scale (VOLSCAL)
4. Live signal level display calibration
(LVL CAL)
5. Internal Calibration (ICAL)
6. Multipoint linearization enable (MULTIPT)
7. Meter system information display (INFO)

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
16
Advanced Features Menu &
Display Messages
The following table shows the Advanced features
menu functions and messages in the order they
appear in the menu.
Display
Parameter
Action/Setting
OUTPUT
Output
Enter output menu
OFF
Off
Disable output
ALARM
Alarm Output
Enter alarm output
menu
LEVEL
Level Alarm
Assign alarm output to
level
SET
Set Point
Set alarm set point
RESET
Reset Point
Set alarm reset point
VOLUME
Volume Alarm
Assign alarm output to
volume
FILTER
Filter
Set noise filter
LO
Filter Low
Set noise filter to low
setting
mED
Filter Medium
Set noise filter to
medium setting
HI
Filter High
Set noise filter to high
setting
OFF
Filter Off
Disable noise filter
VOLSCAL
Volume Scale
Scale the volume
display
vOl
DECIMAL
Volume
Decimal
Set the decimal position
for volume scaling
NO PTS
Number of
Points
Set the number of
points for volume
scaling
INPUT 1
Input 1
Set volume input 1 on
the level display
DSPLY 1
Display 1
Set volume display 1
INPUT 2
Input 2
Set volume input 2 on
the level display
DSPLY 2
Display 2
Set volume display 2
Display
Parameter
Action/Setting
SAVE ?
Save
Save entered volume
scale parameters
LVL CAL
Level
Calibration
Calibrate the level
display
INPUT 1
Input 1
Calibrate input 1 value
DSPLY 1
Display 1
Set display 1 feet and
inches
INPUT 2
Input 2
Calibrate input 2 value
DSPLY 2
Display 2
Set display 2 feet and
inches
SAVE ?
Save
Save entered calibration
parameters
ICAL
Internal
Calibration
Enter internal reference
calibration
4.000
4.000 mA
Calibrate input at 4 mA
20.000
20.000 mA
Calibrate input at 20 mA
SPN ERR
Span Error
Error with calibration
point 1 and 2 span
MULTIPT
Multipoint
Set level display
multipoint linearization
DISABLE
Disable
Disable multipoint
linearization
ENABLE
Enable
Enable multipoint
linearization
INFO
Meter
Information
Show software number
and version, or reset to
factory defaults
SOFT
Software
Software number
ver
Software
Version
Software version
DFALTS?
Reset to
Defaults?
Restore factory default
parameter settings

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
17
Alarm Output (OUTPUT)
The PD6700-0L1 is equipped with an NPN open
collector output that may be set up for high or low
alarm trip point based on the level display (LEVEL) or
the volume scale (VOLUME). The output may be
disabled by selecting OFF.
When the alarm is enabled for level and the alarm set
point has been reached, the level display will flash,
accompanied by the lower display alternating
between normal display and ALARM. A tank height
indicator segment will flash at the level the alarm is
set to while the level indicator is at or above the alarm
point.
When the alarm is enabled for volume and the alarm
set point has been reached, the lower display will
flash, alternating between its normal display and
ALARM.
To set a high alarm, program the set point value to be
greater than the reset point.
To set a low alarm, program the set point value to be
less than the reset point.
To acknowledge an alarm, press the ENTER button
once for acknowledge prompt and a second time to
confirm. Acknowledging an alarm will turn off the
alarm output and stop the display from flashing. The
lower display will continue to alternate between its
normal display and ALARM until the alarm condition is
cleared.
The alarm status will show on the display even if the
output is not wired.
Input Signal Filter (FILTER)
The noise filter is available for unusually noisy signals
that cause an unstable process variable display. The
noise filter averages the input signal over a certain
period. The filter level can be set to low (LO), medium
(MED), high (HI), or off (OFF). The higher the filter
setting, the longer the averaging time and so the
longer the display may take to find its final value.
The filter contains a noise filter bypass feature so that
while small variations in the signal will be filtered out,
large, abrupt changes to the input signal are
displayed immediately.
Volume Display Scaling (VOLSCAL)
Volume may be scaled as a function of the level
display. It may use up to 32-point linearization. The
multi-point linearization can be used to linearize the
display for non-linear signals such as those from level
transmitters used to measure volume in odd-shaped
tanks.
To scale the volume display, select the decimal point
location (0, 1, 2, 3, or 4), then enter the level in
engineering units for input 1, the corresponding
volume display value, and the same for input 2.
After entering the display 2 value, confirm the new
volume scale by pressing ENTER at the Save menu.
Note:
To display the volume, see Configuring the Display
(DISPLAY)on page 13.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
18
Level Input Live Signal Calibration
(LVL CAL)
The meter can be calibrated using a current source
instead of scaling. This process will override
previously programmed scaling of the level display.
The use of a calibrated signal source is strongly
recommended.
Internal Calibration (ICAL)
There is no need to recalibrate the meter when
first received from the factory.
The meter is factory calibrated prior to shipment.
The calibration equipment is traceable to NIST
standards.
The internal calibration is the meter’s master
calibration that makes scaling the meter without a
signal source possible. Use of a calibrated signal
source is necessary to perform an internal calibration
of the meter. Check calibration of the meter at least
every 12 months. Incorrect calibration will affect the
ability of the meter to properly read, scale, and display
the input.
Press MENU, navigate to ADVANCE and press ENTER
to access the Advanced Features Menu. Press the
UP arrow button to scroll to the Internal Calibration
menu (ICAL) and press ENTER.
The meter displays 4.000. Apply a 4.000 mA signal
and press ENTER. The display flashes for a moment
while the meter is accepting the signal. After the
signal is accepted, the meter displays 20.000. Apply a
20.000 mA signal and press ENTER. The display
flashes for a moment while the meter is accepting the
signal.
Notes:
1. The signal source must have a full-scale
accuracy of 0.002% or better between 4 and
20 mA in order to maintain the specified
accuracy of the meter.
2. Allow the meter to warm up for at least
15 minutes before performing the calibration
procedure.
Calibration Error Message
( SPN
ERR )
An error message indicates that the calibration
process was not successful. After the error message
is displayed, the meter will revert to the INPUT 1
calibration menu. The error message might be caused
by inadvertently leaving the signal at the previous
level or not maintaining the minimum span. Press the
MENU button to cancel the current calibration process
if necessary.
Level Input Multipoint
Linearization (MULTIPT)
This menu enables multipoint linearization for scaling
and calibrating of the level display.
Setting MULTIPT to ENABLE allows the level display to
be scaled or calibrated using up to 32 points. See
Scaling the Meter (SCaLe) on page 13 and Level Input
Live Signal Calibration (LVL CAL) on page 18, to
include a Number of Points (NO PTS) parameter
before entering Input 1. The 32-point linearization is
used to linearize the display for non-linear signals.
PD6700L Displaying Height in Feet and Volume
(Using Multi-Point Linearization Feature) in Gallons
in a Round Horizontal Tank.
Information (INFO)
The Information menu shows the software
identification number and version number. To
determine the software version of a meter:
Go to the Information menu (INFO) and press ENTER
button.
Continue pressing ENTER to scroll through the
software release number and software version.
Following the information display, the meter will exit
the Advanced Features menu and return to run mode.

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
19
Operation
Front Panel Buttons Operation
Button Symbol
Description
Press to Enter or Exit
Programming Mode
Used to Reset Maximum and
Minimum Values
Press to Cycle Displaying
Maximum Value, Minimum
Value, and Input Current in mA
Press to Resume Run Mode in
Lower Display
Press to Acknowledge Alarm (if
Enabled)
Display Maximum, Minimum,
and Input Current
The maximum and minimum values and the
measured input loop current may be displayed
temporarily on the lower display. To display these
values, press the DISPLAY button. The meter will
display the word MAXIMUM on the lower display and
the maximum value reached (since the last maximum
reset) on the top display. Press the DISPLAY button
again and the meter will display the word MINIMUM on
the lower display and the minimum value reached on
the top display. Pressing the RESET button while
either of these values is displayed will reset that value
to the current display value.
Press the DISPLAY button a third time and the meter
will display LOOP MA on the lower display and the
measured input current in milliamps (mA) on the top
display. The current display will remain for 10
seconds and then the lower display will return to
normal run mode as programmed in Configuring the
Display (DISPLAY) on page 13. Press the DISPLAY
button a fourth time to return to the normal operation.
The meter will display RESUME followed by the run
mode lower display.
Reset Meter to Factory Defaults
When the parameters have been changed in a way
that is difficult to determine what’s happening, it might
be better to start the setup process from the factory
defaults.
Instructions to load factory defaults:
Enter the Advanced Features Menu.
Press and hold Reset button when INFO is shown.
For information on navigating to the Information
menu, refer to Advanced Features Menu
(ADVANCE) on page 15.
Press Enter when RESET DFALTS? prompt is shown.
Note: If Enter is not pressed within three seconds, the
prompt will stop flashing return to showing INFO.
MENU
RESET
DISPLAY
ENTER

PD6700-0L1 Field-Mount Loop-Powered Process Meter
Instruction Manual
20
Factory Defaults & User
Settings
The following table shows the factory setting for most
of the programmable parameters on the meter. Next
to the factory setting, the user may record the new
setting for the particular application.
Model: _____________________________________
S/N: _______________________________________
Date: ______________________________________
Parameter
Display
Default
Setting
User
Setting
Basic Setup
Level
Decimal Point
DECIMAL
1111.1
Input 1
INPUT 1
4.000 mA
Display 1
DSPLY 1
0.0
Input 2
INPUT 2
20.00 mA
Display 2
DSPLY 2
100.0
Tank Indicator
0%
0 PCT
0.0
Tank Indicator
100%
100 PCT
100.0
Lower Display
BOTTOM
Tag
Bargraph
GRAPH
On
Tag
TAG
TANK 1
Advanced Features
Output
OUTPUT
Off
Filter
FILTER
Low
Volume
Decimal Point
vOl
DECIMAL
0000000
Volume Scale
Number of
Points
NO PTS
02
Volume Scale
Input 1
INPUT 1
0.0
Volume
Display 1
DSPLY 1
0
Volume
Scale Input 2
INPUT 2
100.0
Volume
Display 2
DSPLY 2
100,000
Multipoint
MULTIPT
Disable
Password
Password
PASSWRD
00000
(unlocked)
Troubleshooting
Due to the many features and functions of the meter,
it’s possible that the setup of the meter does not
agree with what an operator expects to see. If the
meter is not working as expected, refer to the
Diagnostics menu and consult the recommendations
described in the following table.
Troubleshooting Tips
Symptom
Check/Action
No display or faint
display
Check input signal
connections.
Perform hard reset by shorting
S+ and S- terminals.
Level display
unsteady
Increase filter setting in
Advanced menu.
Meter displays error
message during
calibration
(SPN ERR)
Check signal connections.
Verify minimum input span
requirements.
Level display flashes
99999 or -9999
Check input signal and scaling
within range of 99999 & -9999
Volume display
flashes
9999999 or -999999
Check level display within
volume scale range of
9999999 & -999999.
Display response is
too slow
Check filter setting to see if it
can be lowered to LO or OFF.
If the display locks
up or the meter does
not respond at all
Perform hard reset by shorting
S+ and S- terminals.
Backlight does not
appear.
Backlight may not be
noticeable under good lighting
conditions.
Check connections are as
shown in Figure 5 or Figure 6
on page 8.
SafeTouch buttons
do not respond
Mechanical button was
pushed or SafeTouch slide
switch is in lock position. The
SafeTouch buttons will be re-
enabled automatically 60
seconds after the last button
push.
If slide switch on connector
board is in Lock position,
switch to Unlock.
Sunlight can interfere with the
sensors. It is recommended to
shield the window from
sunlight while operating the
buttons by standing so as to
block direct sunlight.
Other symptoms not
described above
Call Technical Support for
assistance.
