nor-tec RH2 Instruction Manual

Quick Start Installation Guide
hum idity.com
RH2+
Mounting
Plumbing
Electrical
Steam Distribution

Note: 1) If a modulating control is
connected to the RH2+ then
jumper J10 must be removed from
the control board.
2) If Air Proving Switch is wired to
terminals 1 and 2 of the low
voltage terminal strip (for RH2+
Duct), jumper must be installed
between terminals 1 and 8
(supplied with equipment).
RH2+ Installation Check

Mounting Procedure
1. The RH2 humidifier is wall mounted using a keyhole
located on the back of the humidifier.
2. Use #8 x 2 in. (5 cm) screws mounted into 2x4 studs
or better if there is drywall or other spacers. 2 screws
are needed, one for hanging the unit and one for
securing it so it will not lift off the keyhole.
3. Install the top screw so that 1/4 in. (6 mm) is exposed.
Raise the unit and place the screw head through the
keyhole.
4. Make sure the unit is level and then insert and tighten
the second screw through the bottom hole. Tighten
the top screw.
Mounting Requirements
Nortec does not accept responsibility for installation
code violations.
1. Install as close as possible to the steam distributor.
2. Minimize the use of turn or bends in the steam line as
much as feasibly possible.
3. Mount on a suitable wall or vertical surface. Do not
sit the on the floor, where freezing can occur, or on
vibrating surfaces.
4. Allow clearances for plumbing and electrical
connections. Consult local and national codes prior
to final location and installation.
5. Install only in areas with ambient temperature 41-
104°F (5 – 40°C), and relative humidity 5 - 95% (non-
condensing).
6. When possible, mount the RH2 humidifier at a height
convenient for servicing.
Side clearance
for space models
only, see table
36 in. (92 cm)
duct model
min. front clearance
Additional front clearance
for space models,
see table
24 in.(61 cm)
min. height
Mount humidifier
level
As close as
possible to steam
distributor
5-95%
Overhead clearance
for space models
only, see table
7 ft (2.1 m)
min. height
for space
models only.
Humidifier Output lb (kg) Side in. (cm)
<4 (1 .8) 12 (30) 12 (30)
6 (2 .7)
16 (40)
18 (46)
8 (3. 6) 18 (46) 18 (46)
36 (92)
42 (107)
48 (120)
Additional Clearance for Space Models Only
Overhead in. (cm) Front in. (cm)
Mounting

Electrical
WARNING Wiring needs to be preformed by a
licensed Electrician.
Install Requirements
Nortec does not accept responsibility for installation
code violations.
1. All electrical connections to the humidifier are to be
done while the unit is switched off, and the external
disconnect is open.
2. Wiring should be done by a licensed electrician.
3. Install a labeled disconnect switch within view of the
humidifier.
Note:
1. Install jumper between P and terminal that
corresponds to supply voltage.
2. Dedicated external fused disconnect must be
installed. Fusing must not exceed max circuit
protection as indicated on the specification label.
3. Ensure that adequate power is available to carry full
humidifier amp draw as indicated on the specification
label.
4. Do not use neutral wire as a ground, connect to
ground lug.
5. All Wiring to be in accordance with national and local
electrical codes.
Neutral
Hot
Ground P
120
208
240
L1
Ground
208 VAC (1 phase)
E
X
T
I
N
T
120 VAC (1 phase)
Hot
240 VAC (1 phase)
Hot
Ground
Hot
Hot
Ground
P
120
208
240
L1
Ground
P
120
208
240
L1
Ground
Note: Connect 120 VAC,
“Hot”, to L1
Note: Power wires can
also be routed through
opening in back of cabinet

Plumbing
Water Supply Requirements
Nortec does not accept responsibility for installation
code violations. All drain and fill line connections
should be installed in accordance with local plumbing
codes by a licensed plumber.
1. Use ½” OD copper or plastic supply lines within 4
feet of the humidifier.
2. Install water shut off valve and coupler to facilitate
servicing.
3. Do not use reverse osmosis or de-ionized water.
4. Flush supply lines with fresh clean water after
installing, prior to operating the humidifier.
5. Do not solder/braze copper lines while connected to
the humidifier or the fill solenoid can melt or deform.
6. Water conditions must meet the following criteria
for optimal operation, consult factory for water
conditions outside of this range.
a. Pressure: 30 to 80 PSIG
b. Conductivity: 150-1200 Microsiemens
c. Temperature: 33.8-68°F/1-20°C
d. Harness 0-10 GPG and Silica 0-4 PPM
–OR–
Hardness 0-3 GPG and Silica 0-14 PPM
Drain Line Requirements
1. Use 7/8 Copper. Do not use PVC.
2. Install an air gap within three feet of the humidifier.
A copper reducer from 2.5”-7/8” is ideal, do not allow
the drain hose to bottom out in the funnel cup.
3. The drain line should not end in a sink used
frequently by personnel, or where plumbing codes
prohibit it. Route to a floor drain or equivalent for
safety reasons.
4. Insure drain line is adequately sloped and sized to
provide free and easy draining.
1.2 in. (30 mm). OD
un-threaded outlet
with factory supplied
bent hose and clamp.
Always install a water
shut-off valve.
1/8 in. NPT
Use 1/4 in.
compression
fitting to connect
supply line to
unit.
*Pipe and water shut-off valve not supplied by Nortec.
Use 1/2 in. OD copper to within 4 ft (1.2 m) of humidifier
Note:
1 Fill and drain lines
can also be routed
through opening in
back of cabinet.
2 Optional cover
2548313 Is available
to conceal plumbing
connections.
Air gap required. 2 1/2 in. to 7/8 in.
Copper reducer is ideal. (NORTEC option
P/N 2522172) Hose must not
touch the bottom of the funnel.
Min. 7/8 in. OD drain line.
Keep as short as possible.
Slope down to floor
drain or main drain.

Steam Distribution
Install Requirements
1. Steam lines must not have any restrictions which
could result in back pressure.
2. Follow recommended materials, size and length, see
table.
3. Slope the steam lines a minimum of 2” for every 12”
horizontal run against the flow of steam and 0.5” for
every 12” horizontal run with the flow of steam.
4. Insulate copper or SS tube with 1.0 in. (2.5 cm) pipe
insulation.
5. Trap low points in steam line with full size ‘T’ fittings,
and off of the distributor condensate connection.
Condensate traps must be a minimum of 3 in. in
height or duct static pressure + 2 in. (whichever is
greater) and drop a minimum of 12 inches prior to the
top of the trap.
6. Do not over tighten hose clamp at cylinder steam
outlet. The maximum torque is 12 in-lbs.
7. Support the steam line so the weight does not rest on
the cylinder.
Voltage Steam Output
lbs/hr (kg/hr)
Material∗Maximum
Steam Line
Length
ft (m)
Possible
Losses
lbs/hr (kg/hr)
Nortec Steam
HoseNo
MED-L Copper
Tube
Stainless Steel
Tube
110-120V 5 (2.3)
Part Number
1328810 (7/8”) 3/4” 0.875 X 0.049W
7 (2) 0.5 (0.2)
208V 8.7 (3.3) 10 (3) 1 (0.5)
220-240V 10 (4.6) 12 (3.5) 1.5 (0.7)
Oversized Steam Line (used for longer steam runs)∗∗
110-120V Not
recommended Not
Recommended 1” 1.125 X
0.049W
Not Recommended
208V 8.7 (3.3) 12 (3.5) 2 (0.9)
220-240V 10 (4.6) 24 (7) 3 (1.4)
∗ The use of steam line other than copper, stainless steel tube or Nortec supplied steam line will void the warranty
and may adversely affect the operation of the humidifier.
∗∗ T hese diameters require a reducer at humidifier and steam distributor connection. Use Nortec part number
1115444 at humidifier to prevent backpressure caused by condensation collecting at the reduction.
Steam
Direction
Steam
Direction
Steam
Direction
2 in.
(5 cm)
1 ft (30 cm)
1ft (30 cm)
0.5 in.
(12 mm)
10 Degrees
2 Degrees
Use Appropriate Slope Insulate Pipe
1 in. (2.5 cm) pipe
insulation

Printed in Canada 2573068-C
hum idity.com
USA 835 Commerce Park Drive, Ogdensburg, New York 13669
Canada 2740 Fenton Road, Ottawa, Ontario K1T 3T7
1.866.NORTEC1
[e-mail]
All information contained in this quick start guide is
for general information purposes only. This is NOT an
installation manual and nothing in this guide is meant to
constitute installation instructions. For complete Nortec
installation/operation recommendations for your Nortec
equipment, please refer to the installation manual for your
specifi c system, accessories, and components.
All electrical connections must be installed in accordance
with local and national electrical code requirements by a
licensed electrician.
All water supply and drain line connections must be
installed in accordance with local plumbing codes by a
licensed plumber.
Nortec does not accept any liability for installations of
humidity equipment installed by unqualifi ed personnel
or the use of parts/components/equipment that are not
authorized or approved by Nortec.
Get complete installation, operation, engineering manuals
and more from our website: www.humidity.com
Member of the Condair Group
