Elechomes SH8820 User manual

Model: SH8820
User Manual
Cool & Warm Mist
Ultrasonic Humidifier

THANK YOU FOR PURCHASING THE HUMIDIFIER
BY ElECHOMES
Should you have any questions or concerns about your new product, feel
free to contact us on Monday-Sunday at 9:00 am-5:00 pm PST via
[email protected]. We hope you enjoy your new product!
GET LATEST INFO & INSPIRATION
Find @Elechomes on social media for healthy lifestyle inspiration. Share your life with us.
@Elechomes
#Elechomeslifestyle • #Elechomeslifelover

Contents
1. Diagram
2. Specifications
3. Electrical Schematic Diagram
4. Safety Precautions
5. Essential Function
6. Humidifier Operation
7. Application
8. Important Notes
9. Maintenance
9. Replacing the Remote Control Battery
10. Troubleshooting
11. Warranty Information
12. Customer Support
--------------------------------------------------------------------------01
-------------------------------------------------------------------02
----------------------------------------------02
------------------------------------------------------------03
-------------------------------------------------------------04
----------------------------------------------------------04
-----------------------------------------------------------------------06
----------------------------------------------------------------08
--------------------------------------------------------------------10
-----------------------------------11
--------------------------------------------------------------12
--------------------------------------------------------14
-----------------------------------------------------------15

Thank you for choosing Elechomes! Please read this manual carefully to ensure
safe use and keep it on hand for future reference.
1. LED Display
2. ON/OFF Button
3. Timer Button
4. Screen-off Button
5. Child Lock Button
6. Max/Min Button
7. Humidity Button
8. Heating Button
9. Sleep Button
10. Unit
11. Water Tank
12. Aromatherapy Cover
13. Aromatherapy Plate
14. Head Cover
15. Water Tank Cover
16. Air Channel
17. Atomizing Plate
18. Water Level Sensor
19. Float Ball
20. PTC Heater
21. Water Box
22. Air Outlet
23. Anti-scale plate
DiagramEN
- 01 -

Model
Capacity
Voltage
Electric Shock Safeguard Grade
SH8820
5.5L
AC 120V / 60Hz
II
Max Cool Mist Capacity
Max Warm Mist Capacity
Power
Space Application
300mL/H
600mL/H
280W
430-755 ft²(40-70m2)
Note:
To guarantee its accurate humidity
detection, keep the humidifier (especially
the humidity sensor) dry before use.
Specifications
Electrical Schematic Diagram
Humidity Sensor
DC Fan
Atomizing Plate
Heater
Power
Board
Main
Control
Board
Power
Switch
- 02 -
AC 120V / 60Hz

Safety Precautions
Failure to follow the instructions exactly as they are specified may result in fire,
electric shock, and/or serious injuries.
● Only operate the device on a smooth, stable surface.
● Keep the device away from heat sources like radiators, ovens, and vents.
● Aim the mist away from furniture, appliances, and people.
● Do not scratch the atomizing plate.
● Do not touch the water or internal elements while the device is operating.
● Do not move the device while it is operating.
● Do not cover the mist nozzles.
● Do not touch the mist when in warm mist mode.
● Do not attempt to repair the device. All repairs must be performed by a
qualified service professional.
● Do not let children operate the device without adult supervision.
● Do not dismantle the air channel if the tank is filled with hot water.
● Always unplug the device when not in use and store it in a cool, dry place.
● Turn off the device immediately if strange sounds or odors occur.
● Always unplug the humidifier when not in use. Drain the water tank and sink,
clean, wipe, and dry all parts, and then store them in original packing box.
● This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.Children shall not play with the appliance.Cleaning and user
maintenance shall not be made by children without supervision.
● Care should be taken when using the appliance due to the emission of hot
water vapour.
● Unplug the appliance during filling and cleaning.
● If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to aviod a hazard.
- 03 -

● This device can humidify a large area quickly and evenly.
● This humidifier can emit both warm and cool mist to cater to diverse needs.
● Thanks to the intelligent humidification, the room will remain at a fixed
humidity percentage automatically.
● The steam level can be adjusted among low, medium, and high.
● The sleep function ensures ultra-quiet operation.
● The LED display can be turned off at any time.
● While in child lock mode, the control panel is deactivated to prevent children
from mishandling the product.
● The dual mist nozzles can be rotated 360° independently.
● The humidifier is equipped with 12 preset timing settings.
● Add a few drops of essential oil into the aromatherapy box for a soothing
aromatherapy experience.
● Water shortage protection prevents dry operation and maximizes product
lifespan.
● An included remote can be used to control all functions of the humidifier.
● The Elechomes Warm and Cool Mist Humidifier is compliant with hazardous
substances management ordinances.
Operating Environment
● Only operate the humidifier in indoor environments
between 41-113° F and lower than 80% relative
humidity.
● Do not fill the tank with water hotter than 105°F.
● Filling the tank with purified water is recommended.
Getting Familiar with the Control Panel
Humidifier Operation
Essential Functions
- 04 -

ON/OFF Button
Once the power cable has been successfully plugged into an outlet, a beep will
sound and the humidifAier will be in standby. The LED screen will display the
current ambient humidity.
Press the ON/OFF button to begin operation. The LED screen will display the
current humidity and the humidifying grade.
Press the ON/OFF button again to cease operation. The humidifier will go into
standby and will display the current ambient humidity.
Note:
1.If the humidifier has been turned off but has not been unplugged, the previ-
ous settings will be restored automatically.
2. After the humidifier has been turned off, the internal fan will run for 3 minutes
to dry the air channel and prevent bacteria generating.
Timer Button
Press the timer button to set your desired humidifying time ranging from 1 to 12
hours. Each button press adjusts the time by 1 hour. (Press and hold the button
for 2s to turn off the timing setting.)
The first time the Timer button is pressed, the LED screen will display
(default mode). In default mode, the device will humidify continuously until the
water runs out.
The second time the button is pressed, the LED screen will display .
The humidifier will automatically turn off after one hour. Each subsequent press
of the button will increase the time by 1 hour.
LED screen displays remaining time in Hour after you complete settings. The
humidifier will automatically stop work and enter standby state after time
completes. The LED screen will display and flash the current ambient humidity.
- 05 -

You need to press ON/OFF button again to restore humidifying (it doesn’t work
if the device is in water shortage protection state). Once the time setting has
been selected, the LED screen will display the remaining time.
Screen-off Button
1. Press screen-off button in any working state to manually turn off the LED
display. It won't affect the previous operating effects.
2. Press any button to restore LED display.
Note: The humidifier beeps 6 times and the LED display restores when the
water tank is short of water under any working state except sleep mode.
Child Lock Button
Press and hold the child lock button for 3s. You will hear a beep sound and the
LED screen will display and the control panel cannot be operated.
Press and hold the child lock button for 3s to deactivate the child lock mode
and the LED screen will display .
Note: When using the remote control, just press the button to enter the child
lock mode.
Max/Min Button
Press the Min/Max button to adjust mist strength. Press Max/Min once for low,
twice for medium, and three times for high.
After once button press, the LED screen will display (default high).
After the second button press, the LED screen will display (low).
After the third button press, the LED screen will display (medium).
After the fourth button press,the LED screen will display (back to high).
- 06 -

Humidity Button
Press the Humidity button to set your desired humidity value(from 30% to 90%,
each press increases level 5% ). Once the room has reached your specified
humidity level, the device will shut off automatically（The LED screen will
display the current humidity continually). The humidifier will automatically spray
mist for 1 minute after being turned on, even if the room has reached the set
humidity level.
When the ambient humidity drops to 5%RH（Relative Humidity）below the set
humidity, the humidifier will reactivate. The cycle will continue until the tank
runs out of water or until the device is turned off.
After one button press, the LED screen will display (default). Mist will
spray no matter the ambient humidity level.
After the second button press, the LED screen will display “30%”. Each subse-
quent press increases the humidity level by 5 %, until the maximum 90% is
reached. (Press and hold the button for 2s to turn off the humidity setting.)
Heating Button
Press this button for a warm mist. Press the button again to increase mist
temperature.
After one button press, the LED screen will display (cool).
After the second button press, the LED screen will display (low heat).
After the third button press, the LED screen will display (medium heat).
After the fourth button press, the LED screen will display (high heat).
It cycles when you continue to press the button.
Note: When using the Heating Button for warm mist, always make sure it is
placed in a secure location out of child's reach to avoid scalding.
- 07 -

Note 1:
Water Shortage Alert:
The device beeps 6 times and the “ERR” icon (see above) will appear on the
LED screen display if the water is insufficient. The humidifier will shut off
automatically and will resume once the water is sufficient.
Note 2:
High Temperature Alert:
When the detected surface temperature of PTC is ≥140°C / 284℉or the
atomized plate is detected to run dry during operation, the humidifier will
automatically enter high temperature alert program. The device displays “HOT”
and beeps once every second for continuous 8 times. The atomizing plate and
PTC stop work, while the fan stops work after continuing 3 minutes. All buttons
are invalid except ON/OFF button (the device will alert again if you press the
ON/OFF button). You can only restart the humidifier after all malfunctions have
been settled.
How to Use the Humidifier
1.Open the head cover (Figure 1).
2.Take the water tank out of the unit (Figure 2),fill the water tank with water and
put it back to the unit; or you can pour water into the water tank,then close the
cover (Figure 3);
Important Notes
- 08 -
Sleep Button
Once the Sleep button is pressed, the humidifier will enter sleep mode and the
LED screen will display 3 times and then will turn off. While in sleep
mode, button tones will be silenced. All functions can be activated in sleep
mode,The heating function will turn off by default (to avoid boiling noise).
Note: If you want to activate this function (in sleep mode), just press the
Heating button again. The humidifier will continue to work as sleep mode after
setup completes.

Note:
a. The water level must lower the tank handle.
b. Please do not pour water into the air channel. If so, the machine will not work
normally. Please pour out all the water in the machine and refill the water
tank before starting the machine.
c. Make sure to use the product with the water tank. Do not remove the water
tank and pour water directly into the machine.
3. Plug the power cord into an outlet and press the ON/OFF button to activate
the device. For information on setting adjustment, see the “Getting Familiar
with the Control Panel” section.
4. For aromatherapy, follow the steps below.
a) Remove the aromatherapy cover (Figure 1).
b) Pour several drops of fragrance or essential oil into the box until the cotton is
wet (Figure 1).
c) Reinsert the aromatherapy cover and turn on the humidifier.
- 09 -
Aromatherapy Cover
Figure 1 Figure 2 Figure 3
Fill the tank with water The water level must lower
the tank handle Close the cover

Note:
a.If you no longer wish to use the aromatherapy function, simply remove the
cotton, wash it in warm water, and reinsert it once it is dry.
b.You can take the aromatherapy plate and insert your desired fragrance at
any time.
c.Do not pour fragrances, essential oils, or abrasive liquids directly into
the water tank.
1. Cleaning the Humidifier
The atomizing plate and heater are particularly prone to lime-scale accumula-
tion. Clean the anti-scale cotton with clean water each time you fill the water
tank, and clean the atomizing plate with dish detergent regularly (once two weeks).
Follow the cleaning method specified below:
a. Before cleaning, remove the head cover, water tank, air channel and other
movable parts (figure 1). These parts can be washed directly under the
water faucet.
b. Use water and brush to clean the water box and other parts in the machine.
Then pour the water from the rear of the machine according to the direction
shown in (figure 2). Please do not pour water from the front of the machine
(figure 3) to avoid water entering the machine from the air outlet.
Maintenance
- 10 -
Figure 1 Figure 2 Figure 3
Please pour the water from
the rear of the machine.
Please do not pour water from
the front of the machine.
Please remove the head cover, water tank,
air channel and other movable parts.
closeopen
1.Head cover
2.Water tank
3.Air channel
4.Screw nut

c. When cleaning the water tank cover and seal ring, do not distort them and
the water tank, air channel, head cover should be installed back in place
after finish cleaning.
d. Due to the higher water hardness in some areas, the surface of atomizing
plate and heating plate are prone to accumulate scale. Users should wash
them regularly with detergent, and clean the inside of the water tank and the
water box every week under the following instruction: Place 5 drops of dish
soap on the surface of the atomizing plate and 5 drops of dish soap on the
heater. Pour in approximately 30mL of water. Use a dish brush or sponge to
clean the atomizing plate, heater, and sink until all lime-scale is removed.
Drain the dirty water and rinse the device twice.
Note: Make sure that the fan remains dry at all times.
2. After entering heating function, the water temperature in the water box is
very high. Therefore, do not clean the machine immediately after shutting
down the machine to avoid scalding. The machine should be shut down for
1 hour before cleaning.
3. Do not soak the water box, water tank with hot water while cleaning.
4. There is an air inlet at the bottom of the machine. When cleaning, do not
immerse the bottom of the machine in water to avoid water entering into the
machine from the air inlet and damaging the machine.
1. Press the locking tab toward the pulling slot to remove the battery
compartment (figure 1).
2. Properly dispose of the old battery.
Figure 1 Figure 2
Replacing the Remote Control Battery
- 11 -

3. Place a new 3V CR2025 battery into the battery compartment with positive
side facing up (figure 2).
4. Replace the battery compartment into the remote.
Note: The remote-controlled distance is 5 m (16 ft.).
Troubleshooting
- 12 -
Problem Possible Cause Solution
The device doesn’t work or
shuts down abnormally. The device is not plugged. Plug and start the device.
The device stops working
and "001" is displayed on
the LED screen.
Abnormal working temperature of the
PTC heater.
Unplug the device and clean the
water box and PTC heater after the
water temperature gets down.
The device stops working
and "002" is displayed on
the LED screen.
Abnormal working temperature of the
atomizing plate.
Unplug the device and clean the
water box and atomizing plate after
the water temperature gets down.
The device has not been plugged in. Plug the cord into an outlet.
The device has not been turned on. Press the ON/OFF button to start the
device.
There is foreign matter on the atomizing
plate.Clear away the foreign matter.
There is foreign matter on mist nozzle. Clear away the foreign matter.
The water level in the water box is too
high.
1.Unplug the device and make sure
the water tank cover is covered in
right place and the water level in the
water box is not too high.
2.Pour out the water and refill the
water tank under the guide of the
user manual.
There is not enough water in the tank. Pour more water to into the tank.
The machine is brand new.
Remove the humidifier from the
packaging and let it sit in a well-
ventilated area for 12 hours.
The water in tank is dirty. Empty the tank and pour in clean
water.
There is no wind and mist or
"003" is displayed on the
LED screen.
The mist has a strange
smell.
There is not enough water in the tank. Pour more water to into the tank.
The device has been placed on an uneven
surface.
Operate the device on a level surface.
The humidifier is making an
odd noise.

- 13 -
Mist is emitted from the
sides of the nozzle. The mist nozzle is too dry.
Soak the mist nozzle in water for a few
minutes or the phenomenon will
automatically disappear 30 minutes
after being powered on.
Water shortage. Fill more water into the water tank.
Water level sensor gets stuck by foreign
matter (see the "diagram section" No.18).
The float ball gets stuck by foreign
matter(see the "diagram section" No.19).
The water tank is not installed correctly. Reinstall the water tank.
The water tank is leaking. The water tank may leak. Do not add essential oil into the water
tank.
The mist leaves white marks
on the furniture. The hardness of the water is too high.
Fill distilled water or purified water
Please use the dedicated filter of
Elechomes SH8820 humidifier. (This
filter is available on amazon. Just
search ELECHOMES and buy it)
into the water tank.
The mist wets the floor.
The humidifier is placed directly on the
ground or on a low position, therefore
the vapor does not have enough time to
volatilize.
It's recommended to place the
humidifier on a table or chair in a
higher position to allow more time to
volatilize in the air.
The warm mist doesn't
work.
Sleep mode is set. The humidifier won't
emit warm mist in sleep mode. Reset to other working modes.
There is no warm mist after
pressing the heating
button.
The activation time of the heating
function is not long enough.
Make sure the heating function is
on,then check the mist 1.5 hours later.
The humidifier stops
working after cleaning. The water may come into the air channel.
Follow the cleaning instructions in
the user manual to prevent water
from entering the air channel.
The remote control doesn't
work.
The plastic insulation sheet isn't removed
from the remote battery compartment.
Remove the plastic insulation sheet
from the battery compartment.
There is fan spinning sound
after turning off the device.
The fan will continue to work 3 minutes
to blow-dry the air channel so as to
eliminate germs after powering off the
humidifier.
The fan will automatically stop
spinning 3 minutes later.
"Err" is displayed on the LED
screen.
Check whether there is foreign
matter in the water box.
If your device does not work for unknown reason, please unplug the power cable
and restart the machine. If this still doesn’t work, please contact our Elechomes
customer service for support.
Note: This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.

Warranty Information
- 14 -
Product Name
Model Name
Default Warranty Period
For your own reference, we strongly recommend that you record your order number and
date of purchase.
Date of Purchase
Order Number
Cool & Warm Mist Ultrasonic Humidifier
SH8820
18 Months
TERMS & POLICY
This warranty does not apply to the following situations:
● Damage due to abuse, accident, alteration or vandalism.
● Improper or inadequate maintenance.
● Damage in return transit.
● Unsupervised use by children under 18 years old.
The Elechomes products are premium in material, craftsmanship, and service. They
are effective from the date of purchase.
Elechomes will replace defective products based on eligibility. Refunds are available to
the original purchasers of our products within the first 30 days of purchase. This
warranty extends only to personal use instead of commercial, rental, or any other uses
in which the product is not intended for. Each product has no other warranties other
than the already provided warranties.
This warranty is non-transferable. Elechomes is not responsible for any damages,
losses or inconveniences caused by equipment’s failure, user’s negligence, user’s
abuse, or improper operation that does not follow the included user manual.

Customer Support
- 15 -
All expressed and implied warranties, including the warranty of merchantability,
are limited to the period of the limited warranty.
Defective Products & Returns:
Should your product prove defective within the specified warranty period, please
contact the Customer Support via [email protected] with your invoice and order
number. Once our Customer Support team has approved your request, please return
the product with a copy of your invoice and order number.
Additional 6-month Warranty:
You can enjoy additional 6-month warranty . Just log onto
www.elechomes.com/support/warranty and enter your order number (i.e. Amazon )
within the first 14 days of purchase to register your new product for the extended
warranty.
If you are unable to provide the order number for your product, please type a short
note in the order number field along with the date you received your product.
Your satisfaction is our goal! Should you encounter any issues or have any questions
about your new product, feel free to contact our Customer Support Team on
Monday-Sunday at 9:00am-5:00pm PST via [email protected].
Elechomes and its subsidiaries are only responsible for damages caused by the
intended use or as instructed in the user manual. Some states do not allow this
exclusion or limitation of incidental or consequential losses so the above disclaimer
may not apply to you. This warranty gives you specific legal rights and you may also
have other rights which may vary from state to state.
* Please have your order invoice and order number ready before contacting Customer
Support.
Note:
Filling the tank with hard water may cause limescale buildup
overtime. Only use genuine Elechomes Filter to minimize
limescale. To purchase more filters for your humidifier, scan the
QR code or go to elechomes.com for more information.

US Importer : Thousandshores Inc., 37707 Cherry St, Newark, CA 94560, USA
EU Importer : Thousandshores Deutschland GmbH, Bredowstraße 17, Hamburg 22113,DE
JP Address : 東京都千代田区鍛治町1−10−6 BIZ SMART神田402
Website : hps://www.elechomes.com
Customer Service : [email protected]
Connect us with @Elechomes
