Neptronic SK300 series Manual

SK300-ENG/131024
Steam Humidifier
SK300 series
Y
Installation instruction & user
manual
READ AND SAVE THESE INSTRUCTIONS

SK300 Humidifie
r
User Manual
34
13. Exploded view & Bill of Material
13.1. Exploded view
A
B
A
B
C
C
D
DE E
F
F
G
G
HI
IJ
J
N
O
P
Q
R
T
U
V
W
XY
Steam Trap Assembly
Plastic
gril
SDU Cabinet
Evaporation chamber base
SK310 to SK360
Evaporation chamber base
SK302 to SK306
S
AA
K
Z
M
L
(Illus. 55)

SK300 Humidifie
r
User Manual
35
13.2. Bill of material
Item Description Model Part number
SK302 to 306 SW CONTSMA-ASSY
SK310 to SK330 SW CONTMED-ASSY
A Container of evaporation chamber
SK340 & SK360 SW CONTLAR-ASSY
SK302 to 306 (1 phase) SP 4018-M
SK304 to 306 (3 phases) SP 4019-M
SK310 & SK314 SP 4183A
SK320 & SK330 SP 4183B
SK340 SP 4186
B Cover of evaporation chamber
SK360 SP 4185A
SK302 to 306 SP 1008
SK310 to SK330 SP 1021
C Evaporation chamber gasket
SK340 & SK360 SP 1022
D Heater element See table below
SK302 to 306 SP 4196-M
SK310/314/320/340 SP 4197-M
E Level sensor chamber
SK330 & SK360 SP 4198-M
F Washer (elements) SK302 to SK360 SP 1005
G S/S hex. Jam nut (elements) SK302 to SK360 SP 2330
H High temperature switch (klixon) SK302 to SK360 SP 3035
SK302 to 306 SW FOAMSM-ASSY
SK310/314/320/340 SW FOAMMED-ASSY
I Foam sensor
SK330 to SK360 SW FOAMLG-ASSY
SK302 to 306 SW PROBSM-ASSY
SK310/314/320/340 SW PROBMD-ASSY
J Water level sensor
SK330 & SK360 SW PROBLAR-ASSY
K Water supply valve SK302 to SK360 SP 6007
SK302 to 306 SW TRAPSMA-P
SK310 to SK330 SW TRAPMED-P
L Fill and drain trap assembly
SK340 & SK360 SW TRAPLAR-P
Silicone tubing ½” SP 1023A
Silicone tubing ¾” SP 1023B
M PCV tubing ½”
SK302 to SK360
SP 1027
N Alphanumeric display SK302 to SK360 SW SK300DISPL-ASSY
O ''AUTO/OFF/DRAIN'' rocker switch SK302 to SK360 SW SKSWITCH-ASSY
P Terminal block and high voltage connectors SK302 to SK360 /
Q Cooling fan SK302 to SK360 SP 3007
R Transformer See table below
S Contactor See table below
50 A SP 3102
90 A SP 3103
T Solid State Relay
125 A SP 3105
U Main printed circuit board SK302 to SK360 NW SK300MAIN-TEST
V Modulating printed circuit board SK302 to SK360 NW SK300MODULSS
SDU I SW FANSDU1-RET
SDU II SW FANSDU2-RET
W SDU fan
SDU III SP 3010
X Transformer See table below
SDU I and SDU 2 SP 5105
Y Fuse inside SDU SDU 3 SP 5106
Z Drain pump SK302 to SK360 SP G4101

SK300 Humidifie
r
User Manual
36
Model Voltage D
Heater element R Transformer S Contactor X SDU Transformer
240V/1SW 5932 SP 3310 SP 3029 SP 3312
208V/1SW 5933 SP 3308 SP 3029 SP 3305
480V/1SW 5934 SP 3321 SP 3029 SP 3329
SK302
600V/1SW 5935 SP 3341 SP 3029 SP 3349
240V/1SW 5937 SP 3310 SP 3029 SP 3312
208V/1SW 5940 SP3308 SP 3029 SP 3305
208V/3SW 5924 SP3308 SP 3080 SP 3305
480V/1SW 5941 SP 3321 SP 3029 SP 3329
480V/3SW 5923 SP 3321 SP 3080 SP 3329
600V/1SW 5942 SP 3341 SP 3029 SP 3349
SK304
600V/3SW 5925 SP 3341 SP 3080 SP 3349
240V/1SW 5938 SP 3310 SP 3100 SP 3312
208V/1SW 5943 SP3308 SP 3220 SP 3305
208V/3SW 5933 SP3308 SP 3080 SP 3305
480V/1SW 5944 SP 3321 SP 3029 SP 3329
480V/3SW 5934 SP 3321 SP 3080 SP 3329
600V/1SW 5945 SP 3341 SP 3029 SP 3349
SK306
600V/3SW 5935 SP 3341 SP 3080 SP 3349
208V/3SW 5959 SP 3308 SP 3220 SP 3305
480V/3SW 5958 SP 3321 SP 3080 SP 3329
SK310
600V/3SW 5957 SP 3341 SP 3080 SP 3349
208V/3SW 5946 SP 3308 SP 3027 SP 3305
480V/3SW 5947 SP 3321 SP 3080 SP 3329
SK314
600V/3SW 5948 SP 3341 SP 3080 SP 3349
208V/3***-
480V/3SW 5950 SP 3321 SP 3100 SP 3352
SK320
600V/3SW 5951 SP 3341 SP 3080 SP 3353
480V/3SW 5952 SP 3321 SP 3027 SP 3352
SK330 600V/3SW 5939 SP 3341 SP 3220 SP 3353
208V/3***-
480V/3SW 5950 SP 3321 SP 3220 (2x) -
SK340
600V/3SW 5951 SP 3341 SP 3027 -
480V/3SW 5952 SP 3321 SP 3027 (2x) -
SK360 600V/3SW 5939 SP 3341 SP 3220 (2x) -
*Available, please consult factory.
