Norcold N260 User manual

PART NO. 619261
NORCOLD 01/04/2007
N260
N260.3
N260SERIES
PARTS LIST

PARTS LIST N260 SERIES Page 2
CABINET ASSEMBLY - FRONT VIEW - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
1 619232 BREAKER-CABINET/METAL X X
2 619237 SHELF-WIRE/TOP XX
3 619236 SHELF-WIRE/BOTTOM X X
4 619242 BIN-DOOR SHELF/SMALL X X
5 619233 DOOR GASKET XX
6 619234 DOOR ASSY XX
7 619235 BIN-DOOR SHELF/LARGE X X
8 61409622 CLIP-SHELF XX
9 61550722 HINGEPIN-BOTTOM X X
10 619222 HINGE-LOWER LH/UPPER RH X X
11 619238 NAMEPLATE XX
12 619221 HINGE-LOWER RH/UPPER LH X X
13 61114600 HINGEPIN-TOP XX

PARTS LIST N260 SERIES Page 3
CABINET ASSEMBLY - REAR VIEW - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
1 619272 CONTROL ASSEMBLY-ELECTRICAL/EG3 X
620203 CONTROL ASSEMBLY-ELECTRICAL/EG2 (USE619272 X
2 619271 CONTROL ASSEMBLY-GAS X X
3 61749122 MANUAL SHUT OFF VALVE X X
4 61749822 BRACKET-MANUAL SHUT OFF VALVE X X
5 619091 NSC SYSTEM PACK-COOLING UNIT X X
6 619068 BAFFLEASSY-REAR X X
7 61686823 FINS XX
NS 61728722 CLIP-FIN (NOT SHOWN) X X
8 61745322 HEATER-AC XX
9 61745422 HEATER-DC/EG3 X
NS 619188 BRACKET-MOUNTING/CONDENSER (NOT SHOWN) X X
NS 61754922 CAP-FLUEHEAT (NOT SHOWN) X X

PARTS LIST N260 SERIES Page 4
DOOR ASSEMBLY - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
1 619234 DOOR ASSY XX
2 61742022 HINGEBUSHING XX
3 619233 DOOR GASKET XX
4 619228 LATCH-DOOR XX

PARTS LIST N260 SERIES Page 5
BURNER ORIFICE AREA - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
1 618448 BRACKET-THERMOCOUPLE X X
2 618445 THERMOCOUPLE XX
3 621949 KIT-BURNER/ORIFICE ADAPTER ASSY X X
4 621077 PRESSURE TAP XX
4 621084 PRESSURE TEEASSY X X
61755322 PRESSURETAP (CONTACT NORCOLD) X X
5 61722922 ELECTRODE-SPARK X X
6 61721622 BURNER BOX-BOTTOM X X
7 620850 COVER ASSY-BURNER BOX/WITH DOOR/TOP X X

PARTS LIST N260 SERIES Page 6
CONTROL ASSEMBLY - GAS CONTROLS - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
619271 CONTROL ASSEMBLY-GAS X X
1 621053 BURNER TUBE XX
619256 BURNER TUBE (CONTACT NORCOLD) X X
2 61621622 BRASS ELBOW-UNION TUBE X X
3 622098 SAFETY VALVE XX
4 619278 BRASS ELBOW-90 DEGREE/1/8 NPTF X X
5 620418 GAS VALVE/THERMOSTAT X X
6 61546822 CONNECTOR-MALE XX
7 619257 INLET TUBE-GAS XX
8 619223 BRACKET-CONTROL/GAS X X
9 61645622 SPARK IGNITOR-MANUAL X X
10 619070 KNOB-TAUPE (SUBSTITUTE 629357 - WARM GRAY) X X
NS 620534 BY PASS SCREW-#8 (NOT SHOWN) X X
NS 621737 INTERRUPTER(NOT SHOWN) X X

PARTS LIST N260 SERIES Page 7
CONTROL ASSEMBLY - ELECTRIC CONTROLS - N260 SERIES
NO. PART # DESCRIPTION N260 N260.3
619272 CONTROL ASSEMBLY-ELECTRICAL/EG3 X
620203 CONTROL ASSEMBLY-ELECTRICAL/EG2 (USE619272 X
1 619168 SWITCH-SELECTOR/4 POSITION X X
2 61756322 COVER-TERMINAL BLOCK X X
3 61754722 TERMINAL BLOCK XX
4 61638722 FUSEHOLDER XX
5 61440522 FUSE-GLASS/20 AMP XX
6 61654622 FUSE-GLASS/3 AMP/32V OR LESS X X
7 619070 KNOB XX
8 619227 BRACKET-CONTROL/ELECTRIC X X
NS 617918 CORD-AC POWER (NOT SHOWN) X X
NS 619170 WIRE-11"/RED (NOT SHOWN) X X
NS 619172 WIRE-2"/BLUE(NOT SHOWN) X X
NS 619176 WIRE-2"/ORANGE (NOT SHOWN) X X
NS 619171 WIRE-2"/RED(NOT SHOWN) X X
NS 61752322 WIRE-4"/BLUE(NOT SHOWN) X X
NS 619169 WIRE-4"/ORANGE (NOT SHOWN) X X
NS 618557 WIRE-CONTROL/BLACK (NOT SHOWN) X
NS 618558 WIRE-CONTROL/RED (NOT SHOWN) X
