Norcold N640.3 - User manual

PART NO. 623423
NORCOLD 12/01/2010
PARTS LIST
N64/N84 SERIES
WRAPPED DOOR
STAINLESS STEEL
N641.3SS
N641IMSS
N641IMSSF
N641SS
N641SSF
N841.3SS
N841SS
N841SSF
N841IMSS
N841IMSSF
N842IMSS
N842IMSSF
N842SS
N842SSF
N843IMSS
N843IMSSF
PANEL DOOR
BROWN TRIM
N640.3
N640.3F
BLACK TRIM
N641
N641.3
N641.3F
N641F
N641IM
N641IMF
N841
N841.3
N841.3F
N841F
N841IM
N841IMF
N841IMV
N842
N842F
N842IM
N842IMF
N843IM
N843IMF
WRAPPED DOOR
BLACK
N641BK
N641IMBK
N841.3BK
N841BK
N841BKF
N841BKV
N841IMBK
N841IMBKF
WRAPPED DOOR
WHITE
N641WH
N641.3WH
N841.3WH
N841IMWH
NO
LONGER
PRODUCED

N6/N8 SERIES PARTS LIST - PAGE 2
UPPER DOOR (FREEZER) - PANEL TYPE - MODEL SERIES N64/N84
NO. PART # DESCRIPTION (SERIES) N640 N641 N841 N842 N843
1 623943 PANEL RETAINER-UPPER/BLACK/SDL (2 PER DOOR) N641 N841 N842 N843
624797 PANEL RETAINER-UPPER/BROWN/SDL (2 PER DOOR) N640
619558 PANEL RETAINER-UPPER/BLACK/WDL (2 PER DOOR) N641 N841 N842 N843
622906 PANEL RETAINER-UPPER/BROWN/WDL (2 PER DOOR) N640
2 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL N641 N841 N842 N843
622924 HINGE-DOOR SIDE/TOP RH/BTM LH/BROWN/WDL N640
3 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL (2 PER DOOR) ALL ALL ALL ALL
4 623945 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/SDL N641 N841 N842 N843
624813 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAME/SDL N640
619627 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/WDL N641 N841 N842 N843
622897 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAME/WDL N640
5 618160 CAP-HINGE PLUG/BLACK N641 N841 N842 N843
622989 CAP-HINGE PLUG/BROWN N640
6 621469 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BLACK N641 N841 N843
622916 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BROWN N640
621105 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/BLACK N842
619866 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/METAL/BLACK N641 N841 N843
622910 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/METAL/BROWN N640
7 619648 LATCH-STORAGE/DOOR/METAL HANDLE/WARM GRAY ALL ALL ALL ALL
622313 LATCH-STORAGE/DOOR/PLASTIC HANDLE/WARM GRAY N641 N841 N843
8 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK/WDL N641 N841 N842 N843
622923 HINGE-DOOR SIDE/TOP LH/BTM RH/BROWN/WDL N640
9 619006 BIN-DOOR SHELF/SMALL/CLEAR/WDL (1 PER DOOR) ALL ALL ALL ALL
624864 BIN-DOOR SHELF/CLEAR/SDL (1 PER DOOR) ALL ALL ALL ALL
10 619008 DIVIDER-DOOR BIN/CLEAR/WDL/SDL (1 PER DOOR SHELF BIN) ALL ALL ALL ALL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD (NOT SHOWN) ALL ALL ALL ALL
WDL = WAFFLE DOOR LINER SURFACE SDL = SMOOTH DOOR LINER SURFACE

N6/N8 SERIES PARTS LIST - PAGE 3
LOWER DOOR (FRESH FOOD) - PANEL TYPE - MODEL SERIES N64/N84
NO. PART # DESCRIPTION (SERIES) N640 N641 N841 N842 N843
1 623948 PANEL RETAINER-LOWER DOOR/6’/BLACK/SDL (2 PER DOOR) N641
624799 PANEL RETAINER-LOWER DOOR/6’/BROWN/SDL (2 PER DOOR) N640
623760 PANEL RETAINER-LOWER DOOR/8’/BLACK/SDL (2 PER DOOR) N841 N842 N843
619559 PANEL RETAINER-LOWER DOOR/6’/BLACK/WDL (2 PER DOOR) N641
622907 PANEL RETAINER-LOWER DOOR/6’/BROWN/WDL (2 PER DOOR) N640
619560 PANEL RETAINER-LOWER DOOR/8’/BLACK/WDL (2 PER DOOR) N841 N842 N843
2 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL N641 N841 N842 N843
622924 HINGE-DOOR SIDE/TOP RH/BTM LH/BROWN/WDL N640
3 619671 HINGE BUSHING-DOOR/WARM GRAY (2 PER DOOR) ALL ALL ALL ALL
4 623955 DOOR LINER ASSY-LOWER/6’/PANEL/BLACK FRAME/SDL N641
624812 DOOR LINER ASSY-LOWER/6’/PANEL/BROWN FRAME/SDL N640
623942 DOOR LINER ASSY-LOWER/8’/PANEL/BLACK FRAME/SDL N841 N842 N843
619629 DOOR LINER ASSY-LOWER/6’/PANEL/BLACK FRAME/WDL N641
622898 DOOR LINER ASSY-LOWER/6’/PANEL/BROWN FRAME/WDL N640
619631 DOOR LINER ASSY-LOWER/8’/PANEL/BLACK FRAME/WDL N841 N842 N843
5 621465 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/PLASTIC/BLACK N641 N841 N843
622915 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/PLASTIC/BROWN N640
621104 DOOR HANDLE ASSY-LOWER DOOR/RH SWING (N822/N842) N842
619865 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/METAL/BLACK N641 N841 N843
622909 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/METAL/BROWN N640
6 622313 LATCH-STORAGE/DOOR/PLASTIC HANDLE/WARM GRAY ALL ALL ALL
619648 LATCH-STORAGE/DOOR/METAL HANDLE/WARM GRAY ALL ALL ALL ALL
7 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK/WDL N641 N841 N842 N843
622923 HINGE-DOOR SIDE/TOP LH/BTM RH/BROWN/WDL N640
8 624864 BIN-DOOR SHELF/CLEAR/SDL 2 3 3 3
NS 624866 WIRE-BIN/SDL (NOT SHOWN) ALL ALL ALL ALL
619006 BIN-DOOR SHELF/SMALL/CLEAR/WDL 2 3 3 3
619005 BIN-DOOR SHELF/LARGE/CLEAR/WDL 1 1 1 1
9 619008 DIVIDER-DOOR BIN/CLEAR (1 PER DOOR SHELF BIN) ALL ALL ALL ALL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD (NOT SHOWN) ALL ALL ALL ALL
WDL = WAFFLE DOOR LINER SURFACE SDL = SMOOTH DOOR LINER SURFACE

N6/N8 SERIES PARTS LIST - PAGE 4
UPPER DOOR (FREEZER) - WRAP TYPE - MODEL SERIES N64/N84
NO. PART # DESCRIPTION N641 N841 N842 N843
1 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/SDL/WDL ALL ALL ALL ALL
2 619671 HINGE BUSHING-DOOR/WARM GRAY (2 PER DOOR) ALL ALL ALL ALL
3
624142 DOOR ASSY-UPPER/BLACK/VINYL COAT/WDL (SERIAL # 1315387 & BELOW) (USE 625874) BK
625874 DOOR ASSY-UPPER/BLACK/POWDER COAT/WDL (SERIAL# 1315388 & ABOVE) BK BK BK BK
627121 DOOR ASSY-UPPER/WRAP/BLACK/SDL (USE 632732) BK BK
632732 DOOR ASSY-UPPER/AT BLACK/SDL (FROM 07/10/08 THRU SERIAL # 12965198) BK BK
634605 DOOR ASSY-UPPER/ANCO BLACK/SDL (SERIAL # 12965199 & ABOVE) BK BK
627102 DOOR ASSY-UPPER/WRAP/AL-CLEAN STAINLESS/SDL (USE 630091) SS SS SS SS
630091 DOOR ASSY-UPPER/WRAP/VALSPAR STAINLESS/SDL SS SS SS SS
632731 DOOR ASSY-6’ UPPER/WRAP/AT STAINLESS/SDL (FROM 06/25/08 THRU S/N 12965541) SS
DOOR ASSY-8’ UPPER/WRAP/AT STAINLESS/SDL (FROM 06/25/08 THRU S/N 12985380) SS SS SS
634062 DOOR ASSY-6’ UPPER/WRAP/ANCO STAINLESS/SDL (SERIAL # 12965542 & ABOVE) SS
DOOR ASSY-8’ UPPER/WRAP/ANCO STAINLESS/SDL (SERIAL # 12985381 & ABOVE) SS SS SS
627120 DOOR ASSY-UPPER/WRAP/WHITE/SDL WH WH
624143 DOOR ASSY-UPPER/WRAP/WHITE/WDL WH WH WH WH
4 618160 CAP-HINGE PLUG/BLACK ALL ALL ALL ALL
5
621469 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BLACK ALL ALL ALL
621105 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/BLACK ALL
619866 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/METAL/BLACK ALL ALL ALL
6622313 LATCH-STORAGE/DOOR/PLASTIC HANDLE/WARM GRAY ALL ALL ALL
619648 LATCH-STORAGE/DOOR/METAL HANDLE/WARM GRAY ALL ALL ALL ALL
7 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK/SDL/WDL ALL ALL ALL ALL
8624864 BIN-DOOR SHELF/CLEAR/SDL (1 PER DOOR) ALL ALL ALL ALL
619006 BIN-DOOR SHELF/SMALL/CLEAR/WDL (1 PER DOOR) ALL ALL ALL ALL
9 619008 DIVIDER-DOOR BIN/CLEAR (1 PER DOOR SHELF BIN) ALL ALL ALL ALL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD (NOT SHOWN) ALL ALL ALL ALL
BK = BLACK WRAPPED DOORS SS = STAINLESS STEEL WRAPPED DOORS WH = WHITE WRAPPED DOORS
WDL = WAFFLE DOOR LINER SURFACE SDL = SMOOTH DOOR LINER SURFACE
PART IS NO LONGER AVAILABLE

N6/N8 SERIES PARTS LIST - PAGE 5
LOWER DOOR (FRESH FOOD) - WRAP TYPE - MODEL SERIES N64/N84
NO. PART # DESCRIPTION N641 N841 N842 N843
1 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK ALL ALL ALL ALL
2 619671 HINGE BUSHING-DOOR/WARM GRAY (2 PER DOOR) ALL ALL ALL ALL
3
625876 DOOR ASSY-LOWER/6’/WRAP/BLACK/POWDER COAT/WDL BK
627125 DOOR ASSY-LOWER/6’/WRAP/BLACK/SDL BK
632734 DOOR ASSY-LOWER/6’/WRAP/AT BLACK/SDL (FROM 07/10/08 THRU SERIAL # 12965198) (USE 634066) BK
634066 DOOR ASSY-LOWER/6’/WRAP/ANCO BLACK/SDL (SERIAL # 12965199 & ABOVE) BK
624144 DOOR ASSY-LOWER/8’/WRAP/BLACK/VINYL COAT/WDL (SERIAL # 1315387 & BELOW) (USE 625875) BK
625875 DOOR ASSY-LOWER/8’/WRAP/BLACK/WDL/POWDER COAT (SERIAL# 1315388 & ABOVE) BK
627129 DOOR ASSY-LOWER/8’/WRAP/BLACK/SDL (USE 634067) BK
632738 DOOR ASSY-LOWER/8’/WRAP/AT BLACK/SDL (07/10/08 THRU S/N 12965198) (USE 634067) BK
634067 DOOR ASSY-LOWER/8’/WRAP/ANCO BLACK/SDL (SERIAL # 12965199 & ABOVE) BK
624147 DOOR ASSY-LOWER/6’/WRAP/STAINLESS/WDL SS
627103 DOOR ASSY-LOWER/6’/WRAP/AL-CLEAN STAINLESS/SDL (USE 632733) SS
630092 DOOR ASSY-LOWER/6’/WRAP/VALSPAR STAINLESS/SDL (USE 623733) SS
632733 DOOR ASSY-LOWER/6’/WRAP/AT STAINLESS/SDL (FROM 06/25/08 THRU S/N 12965541) (USE 634063) SS
634063 DOOR ASSY-LOWER/6’/WRAP/ANCO STAINLESS/SDL (SERIAL # 12965542 & ABOVE) SS
623273 DOOR ASSY-LOWER/8’/WRAP/STAINLESS/WDL SS SS SS
627104 DOOR ASSY-LOWER/8’/WRAP/AL-CLEAN STAINLESS/SDL (USE 634064) SS SS SS
630093 DOOR ASSY-LOWER/8’/WRAP/VALSPAR STAINLESS/SDL (USE 634064) SS SS SS
632737 DOOR ASSY-LOWER/8’/WRAP/AT STAINLESS/SDL (FROM 06/25/08 THRU S/N 12985380) (USE 634064) SS SS SS
634064 DOOR ASSY-LOWER/8’/WRAP/ANCO STAINLESS/SDL (SERIAL # 12985381 & ABOVE) SS SS SS
624149 DOOR ASSY-LOWER/6’/WRAP/WHITE/WDL WH
627124 DOOR ASSY-LOWER/6’/WRAP/WHITE/SDL WH
624145 DOOR ASSY-LOWER/8’/WRAP/WHITE/WDL WH
627128 DOOR ASSY-LOWER/8’/WRAP/WHITE/SDL WH
4
621465 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/PLASTIC/BLACK ALL ALL ALL
621104 DOOR HANDLE ASSY-LOWER DOOR/RH SWING (N822/N842) ALL ALL
619865 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/METAL/BLACK ALL ALL ALL ALL
5 619648 LATCH-STORAGE/DOOR/METAL HANDLE/WARM GRAY ALL ALL ALL ALL
6 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK ALL ALL ALL ALL
7 624864 BIN-DOOR SHELF/CLEAR/SDL 3 4 4 4
NS
632458 WIRE-BIN/SDL (NOT SHOWN) 1 1 1 1
619006 BIN-DOOR SHELF/SMALL/CLEAR/WDL (2 PER N64 DOOR)(3 PER N84 DOOR) 2 3 3 3
619005 BIN-DOOR SHELF/LARGE/CLEAR/WDL (1 PER DOOR) 1 1 1 1
8 619008 DIVIDER-DOOR BIN/CLEAR (1 PER DOOR SHELF BIN) 3 4 4 4
NS 619569 BOLT-CAP SHOULDER/TORX HEAD (NOT SHOWN) ALL ALL ALL ALL
BK = BLACK WRAPPED DOORS SS = STAINLESS STEEL WRAPPED DOORS WH = WHITE WRAPPED DOORS
WDL = WAFFLE DOOR LINER SURFACE SDL = SMOOTH DOOR LINER SURFACE
PART IS NO LONGER AVAILABLE

N6/N8 SERIES PARTS LIST - PAGE 6
CABINET AREA (FRONT VIEW) - MODEL SERIES N64/N84

N6/N8 SERIES PARTS LIST - PAGE 7
CABINET AREA (FRONT VIEW) - MODEL SERIES N64/N84
NO. PART # DESCRIPTION (SERIES) N640
N641 N841 N842 N843
1 622319 TRIM PIECE ASSY-TOP/WITH INSERTS/BLACK N641 N841 N842 N843
622931 TRIM PIECE ASSY-TOP/WITH INSERTS/BROWN (USE 622926) N640
2 618170 HOLE PLUG-FOR TOP TRIM PIECE/BLACK (2 PER CABINET) N641 N841 N842 N843
622930 HOLE PLUG-FOR TOP TRIM PIECE/BROWN (2 PER CABINET) N640
3 624785 HINGE-3 POINT/TOP RH/BTM LH/WRAP/BLACK/SDL (2 PER CABINET) N641 N841 N842 N843
623771 HINGE-3 POINT/TOP RH/BTM LH/PANEL/BLACK/SDL (2 PER CABINET) N641 N841 N842 N843
624787 HINGE-3 POINT/TOP RH/BTM LH/PANEL/BROWN/SDL (2 PER CABINET) N640
619335 HINGE-3 POINT/TOP RH/BTM LH/PANEL/BLACK/WDL (2 PER CABINET) N641 N841 N842 N843
622885 HINGE-3 POINT/TOP RH/BTM LH/PANEL/BROWN/WDL (2 PER CABINET) N640
4 624786 HINGE-3 POINT/TOP LH/BTM RH/WRAP/BLACK/SDL (2 PER CABINET) N641 N841 N842 N843
623772 HINGE-3 POINT/TOP LH/BTM RH/PANEL/BLACK/SDL (2 PER CABINET) N641 N841 N842 N843
624789 HINGE-3 POINT/TOP LH/BTM RH/PANEL/BLACK/SDL (2 PER CABINET) N640
619336 HINGE-3 POINT/TOP LH/BTM RH/PANEL/BLACK/WDL (2 PER CABINET) N641 N841 N842 N843
622886 HINGE-3 POINT/TOP LH/BTM RH/PANEL/BLACK/WDL (2 PER CABINET) N640
5 622295 TRIM PIECE FOAM TAPE ASSY-SIDE/6’/BLACK (2 PER CABINET) N641
623516 TRIM PIECE FOAM TAPE ASSY-SIDE/6’/BROWN (2 PER CABINET) N640
622296 TRIM PIECE FOAM TAPE ASSY-SIDE/8’/BLACK (2 PER CABINET) N841 N842 N843
6 61630422 ICE CUBE TRAY-(NON ICE MAKER MODELS ONLY)(2 PER CABINET) ALL ALL ALL
7 620249 SHELF-WIRE/FREEZER (ICE MAKER MODELS) ALL ALL ALL ALL
620250 SHELF-WIRE/FREEZER (NON ICEMAKER MODELS) ALL ALL ALL
8 628976 CONTROL ASSY-OPTICAL/BLACK (SERIAL# EG2=9044284 & ABOVE - EG3=8938728 &
ABOVE) N641 N841 N842 N843
629794 CONTROL ASSY-OPTICAL/BROWN (SERIAL# EG2=9044284 & ABOVE - EG3=8938728 &
ABOVE) N640
619665 CONTROL ASSY-OPTICAL/BLACK (LIMITED AVAILABILITY) (SERIAL# EG2=9044283 &
BELOW - EG3=8938727 & BELOW) N641 N841 N842 N843
633287 KIT-CONTROLS ADAPTER-BLACK/EG2 (SERIAL# = 9044283 & BELOW) N641 N841 N842 N843
633280 KIT-CONTROLS ADAPTER-BLACK/EG3 (SERIAL# = 8938727 & BELOW) N641 N841
633207 KIT-CONTROLS ADAPTER-BROWN/EG3 (SERIAL# = 8938727 & BELOW) N640
9 619282 FRONT BOX-BLACK N641 N841 N842 N843
622896 FRONT BOX-LIGHT BROWN N640
10 623250 DRIP TRAY-INSIDE (ONE PIECE DRIP TRAY & LOUVER) ALL ALL ALL ALL
11 620269 SHELF-WIRE/SHORT ALL ALL ALL ALL
12 620270 SHELF-WIRE/FULL 1 1 2 2
13 617756 TRAY-SHELF/WHITE/CUT OUT ALL ALL ALL ALL
14 620268 SHELF-WIRE/CUT OUT ALL ALL ALL ALL
15 618158 CRISPER COVER-GLASS SHELF ALL ALL ALL ALL
16 619007 BIN-ICE/CRISPER/CLEAR (2 PER MODEL)(3 PER ICE MAKER MODEL) ALL ALL ALL ALL
17 618145 HINGE PIN-DOOR/BLACK (4 PER)/WDL PANEL/SDL WRAP) N641 N841 N842 N843
622925 HINGE PIN-DOOR/PANEL/BROWN (4 PER REFRIGERATOR) N640
623899 HINGE PIN-UPPER/LOWER/BLACK/SDL PANEL N641 N841 N842 N843
61550722 HINGE PIN-BOTTOM/WDL/SDL N641 N841 N842 N843
18 619671 HINGE BUSHING-DOOR/WARM GRAY (4 PER REFRIGERATOR) ALL ALL ALL ALL
19 619301 COVER-HINGE HOLE/WHITE/3 POINT (2 PER CABINET) ALL ALL ALL ALL
20 622323 TRIM PIECE FOAM TAPE ASSY-CABINET/BOTTOM/BLACK N641 N841 N842 N843
622927 TRIM PIECE FOAM TAPE ASSY-CABINET/BOTTOM/BROWN (USE 622926) N640
21 618181 RETAINER-SHELF (SERIAL # 926963 AND BELOW) N641 ALL ALL ALL
622033 RETAINER-SHELF (SERIAL # 926964 AND ABOVE) ALL ALL ALL ALL
22 61586722 BRACE-CABINET/BACK ALL ALL ALL ALL
23 619561 HOLE PLUG-DIVIDER/WHITE (MODELS PRODUCED PRIOR TO 07/21/98) N641 N841
620282 HOLE PLUG-DIVIDER/WHITE (MODELS PRODUCED AFTER 07/20/98) ALL ALL ALL ALL
24 618167 STRIKE PLATE-BLACK N641 N841 N842 N843
619673 STRIKE PLATE-WARM GRAY N640
NS 622325 KIT-INSTALLATION/BLACK (TRIM PIECES/SCREWS/PLUGS)(NOT SHOWN) N641 N841 N842 N843
NS 622926 KIT-INSTALLATION/BROWN (TRIM PIECES/SCREWS/PLUGS)(NOT SHOWN) N640
WDL = WAFFLE DOOR LINER SURFACE SDL = SMOOTH DOOR LINER SURFACE
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE REPLACED WITH A
NEW KIT-CONTROL ADAPTER.

N6/N8 SERIES PARTS LIST - PAGE 8
CABINET AREA (REAR VIEW/COOLING UNIT) - MODEL SERIES N64/N84
NO. PART # DESCRIPTION (SERIES) N640
N641 N841 N842 N843
1 632307 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X
632314 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X X X
2M0802 THERMAL SWITCH/BRACKET ASSY (SEE NOTE) X X X X
NS 618111 BAFFLE/WIRE ASSY (NOT SHOWN) X X X X
2 622390 DRAIN HOSE ASSY X
622391 DRAIN HOSE ASSY X X X
622857 KIT-DRAIN HOSE REPAIR X X X X
3 622546 DRIP CUP-REAR/PLASTIC X X X X
4 61712637 COVER ASSY-BURNER BOX X X X X
5 61695322 BASE-BURNER BOX X X X X
6 621702 HEATER-AC (COOLING UNIT SERIAL# 11231023 & BELOW) X
HEATER-AC (COOLING UNIT SERIAL# 11232007 & BELOW) X X X
630811 HEATER-AC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) X
HEATER-AC/BACKER (COOLING UNIT SERIAL# 11232008 & ABOVE) X X X
7 626832 HEATER-DC (COOLING UNIT SERIAL# 11231023 & BELOW) EG3
HEATER-DC (COOLING UNIT SERIAL# 11232007 & BELOW) EG3 EG3 EG3
630812 HEATER-DC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) EG3
HEATER-DC/BACKER (COOLING UNIT SERIAL# 11232008 & ABOVE) EG3 EG3 EG3
8 61695022 CAP-HEAT DEFLECTOR X X X X
9 61586722 BRACE-CABINET/BACK X X X X
10 61686823 FINS X X X X
NOTE: FOR COOLING UNITS WITH A THERMAL SWITCH.

N6/N8 SERIES PARTS LIST - PAGE 9
CONTROLS (REAR VIEW) - MODEL SERIES N640.3, N641, N841, N842, N843
NOTE: FOR MODELS PRODUCED WITHOUT A SEPARATE MANUAL SHUT OFF VALVE (SERIAL # 656980 & AFTER)
NO. PART # DESCRIPTION (SERIES) N640
N641 N841 N842 N843
1 618186 BASE-POWER BOARD (SERIAL# - EG2=9044283 & BELOW)(EG3=8938727 & BELOW) ALL ALL ALL ALL
628674 BASE-POWER BOARD/EG2 (SERIAL# - 9044284 & ABOVE) N641 ALL ALL ALL
628675 BASE-POWER BOARD/EG3 (SERIAL# - 8938728 & ABOVE EXCEPT N640.3) N641 ALL
2 621269001 KIT-POWER BOARD/EG2 (SERIAL# - 9044283 & BELOW) N641 ALL ALL ALL
621270001 KIT-POWER BOARD/EG3 (SERIAL# - 8938727 & BELOW EXCEPT N640.3) N641 ALL
628661 POWER BOARD (SERIAL# - EG2=9044284 & ABOVE; EG3=8938728 & ABOVE EXCEPT
N640.3) N641 ALL ALL ALL
628669 DC BOARD-EG3(SERIAL# 89387287 & ABOVE EXCEPT N640.3) N641 ALL
3 618185 COVER-POWER SUPPLY (SERIAL# - EG2=9044283 & BELOW; EG3=8938727 & BELOW
EXCEPT N640.3) N641 ALL ALL ALL
628677 COVER-POWER BOARD/EG2 (SERIAL# 9044284 & ABOVE) N641 ALL ALL ALL
628678 COVER-POWER BOARD/EG3 (SERIAL# 8938728 & ABOVE EXCEPT N640.3) N641 ALL
4 621448 WIRE-WHITE/9”/GAS VALVE (2 PER ASSEMBLY) ALL ALL ALL ALL
5 624681 BRACKET-MOUNTING/GAS VALVE (9185698 & BELOW) ALL ALL ALL ALL
628993 BRACKET-MOUNTING/GAS VALVE (9185699 & ABOVE) ALL ALL ALL ALL
6 621334 KIT-GAS VALVE/BRACKET/WIRES (9185698 & BELOW) ALL ALL ALL ALL
633726 GAS VALVE-COMBINATION (9185699 & ABOVE) ALL ALL ALL ALL
7 624682 BURNER TUBE-N8/N6 SERIES ALL ALL ALL ALL
8 621957 KIT-BURNER/ORIFICE ADAPTER ASSY - ORIFICE AND/OR BURNER ALL ALL ALL ALL
9 61554422 CORD-AC POWER/BLACK ALL ALL ALL ALL
618406 CORD-AC POWER/IM ALL ALL ALL
NS 621755 CORD-POWER/ICE MAKER/WHITE (NOT SHOWN) ALL
10 61712637 COVER ASSY-BURNER BOX ALL ALL ALL ALL
11 61695322 BASE-BURNER BOX ALL ALL ALL ALL
12 61692222 ELECTRODE-SPARK/SENSE/SINGLE ELECTRODE/0.25” ALL ALL ALL ALL
13 632307 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) ALL
632314 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) ALL ALL ALL
14 61586722 BRACE-CABINET/BACK ALL ALL ALL ALL
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE REPLACED WITH
A NEW KIT-CONTROL ADAPTER.

N6/N8 SERIES PARTS LIST - PAGE 10
CONTROLS (REAR VIEW) - MODEL SERIES N641/ N841
NOTE: FOR MODELS WITH A SEPARATE MANUAL SHUT OFF VALVE (SERIAL # 656979 & BELOW).
NO. PART # DESCRIPTION (SERIES) N641 N841
1 618186 BASE-POWER BOARD ALL ALL
2 621269001 KIT-POWER BOARD -EG2 ALL ALL
621270001 KIT-POWER BOARD -EG3 ALL ALL
3 618185 COVER-POWER SUPPLY ALL ALL
4 621448 WIRE-WHITE/9”/GAS VALVE (2 PER ASSEMBLY) ALL ALL
5 61694022 BRACKET-MOUNTING/GAS VALVE ALL ALL
6 61594422 PRESSURE TAP ALL ALL
61445322 PLUG-1/8”/FOR PRESSURE TAP ALL ALL
7 621334 KIT-GAS VALVE/BRACKET/WIRES ALL ALL
8 61694622 UNION TUBE ALL ALL
9 61694922 MANUAL SHUT OFF VALVE ASSY (USE 621444) ALL ALL
10 61546822 CONNECTOR-MALE ALL ALL
11 618252 BURNER TUBE ALL ALL
12 621957 KIT-BURNER/ORIFICE ADAPTER ASSY ALL ALL
13 61554422 CORD-AC POWER/BLACK (NON ICEMAKER MODELS ONLY) ALL ALL
618406 CORD-AC POWER/IM/BLACK (ICE MAKER MODELS) ALL ALL
14 61712637 COVER ASSY-BURNER BOX ALL ALL
15 61695322 BASE-BURNER BOX ALL ALL
16 61692222 ELECTRODE-SPARK/SENSE/SINGLE ELECTRODE/0.25” ALL ALL
17 632307 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) ALL
632314 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) ALL
18 61586722 BRACE-CABINET/BACK ALL ALL
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE REPLACED WITH A
NEW KIT-CONTROL ADAPTER.

N6/N8 SERIES PARTS LIST - PAGE 11
ICE MAKER AREA - MODEL SERIES N64/N84 (ICE MAKER MODELS)
NO. PART # DESCRIPTION (SERIES) N641IM N841IM N842IM N843IM
1 61656822 COVER-FRONT/ICE MAKER N641IM N841IM N842IM N843IM
2 633324 KIT-ICE MAKER N641IM N841IM N842IM N843IM
3 61690822 CLAMP-TUBING/IM N641IM N841IM N842IM N843IM
4 617869 TUBE-WATER FEED/IM/68” (USE 621429) N641IM N841IM N842IM N843IM
5 61346822 BUSHING-SNAP N641IM N841IM N842IM N843IM
6 620659 FITTING-WATER TUBE N641IM N841IM N842IM N843IM
7 618407 WIRING HARNESS-IM N641IM N841IM N842IM N843IM
8 617831 BRACKET-MOUNTING/ICE MAKER (ENDING 09/26/99) N641IM N841IM
620889 BRACKET-MOUNTING/ICE MAKER (STARTING 09/27/99) N641IM N841IM N842IM N843IM
9 633325 KIT-WATER VALVE/SINGLE PORT N641IM N841IM N842IM N843IM
10 618169 SPACER-WATER VALVE/NYLON N641IM N841IM N842IM N843IM
11 61679622 GARDEN HOSE ADAPTER-STRAIGHT/IM N641IM N841IM N842IM N843IM
12 622991 NUT-COMPRESSION/WATER VALVE FITTING/IM/PLASTIC N641IM N841IM N842IM N843IM
622846 NUT-COMPRESSION/WATER VALVE FITTING/IM/BRASS N641IM N841IM N842IM N843IM
13 61656922 SHUT OFF ARM/IM N641IM N841IM N842IM N843IM
14 619007 BIN-ICE/CRISPER/CLEAR N641IM N841IM N842IM N843IM
15 632445 SHELF-WIRE/FREEZER/N84/N64 (620249 OLDER MODELS) N641IM N841IM N842IM N843IM
NS 621429 WATER TUBE/HEATER ASSY/FOR ICE MAKER N641IM N841IM N842IM N843IM
NS 623182 KIT-OEM WATER TUBE FITTINGS/IM X X X X
NS - NOT SHOWN

N6/N8 SERIES PARTS LIST - PAGE 12
INTERIOR LIGHT AND THERMISTER ASSY - MODEL SERIES N64/N84
NO. PART # DESCRIPTION (SERIES) N640 N641 N841 N842 N843
1 61629722 LAMP BRACKET ASSY ALL ALL ALL ALL
2 632545 LAMP-DC LIGHT BULB ALL ALL ALL ALL
3 621827 COVER-LAMP BRACKET ALL ALL ALL ALL
4 633734 CLIP-THERMISTER MOUNTING/FIN ALL ALL ALL ALL
5 618548 LAMP THERMISTER WIRE ASSY ALL ALL ALL ALL

N6/N8 SERIES PARTS LIST - PAGE 13
FAN MODEL COMPONENTS - MODELS SERIES N64/N84
NOTE: LOWER FAN POSITION - MODELS WITH SERIAL # BELOW 9056492
PART # DESCRIPTION
WITHOUT ICE
MAKER
WITH ICE
MAKER
HIGH
VELOCITY
WITHOUT
ICE MAKER
HIGH
VELOCITY
WITH
ICE MAKER
618857 BRACKET-DC FAN 1 1 1 1
619016 BRACKET-FAN SUPPORT 1 1 1 1
61417922 CABLE TIE-NYLON 3 4 3 4
618856 FAN-EXTERNAL DC 1 1
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1 1 1
618950 WIRE MOUNT-ADHESIVE 2 2 2 2
621943 WIRE-60” (FAN MODELS) 1 1 1 1
621431 WIRE-AUXILLARY/BLACK/POSITIVE (+) 1 1
621430 WIRE-AUXILLARY/RED/NEGATIVE (-) 1 1
618700 WIRE-BLACK/24”/18 GA 1 1 1 1
619017 WIRE-BLACK/6”/18 GA 1 1
618978 WIRE-FAN/RED/6”/18 GA/12V 1 1
618701 WIRE-RED/36”/18 GA 1 1 1 1
NOTE: LOWER FAN POSITION - MODELS WITH SERIAL # 9056492 TO 10087057
PART # DESCRIPTION
WITHOUT ICE
MAKER
WITH ICE
MAKER
HIGH
VELOCITY
WITHOUT
ICE MAKER
HIGH
VELOCITY
WITH
ICE MAKER
618857 BRACKET-DC FAN 1 1 1 1
619016 BRACKET-FAN SUPPORT 1 1 1 1
61417922 CABLE TIE-NYLON 3 4 3 4
618856 FAN-EXTERNAL DC 1 1
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1 1 1
618950 WIRE MOUNT-ADHESIVE 2 2 2 2
621943 WIRE-60” (FAN MODELS) 1 1 1 1
628758 WIRE-AUXILLARY/OUTPUT/BLACK 1 1
628759 WIRE-AUXILLARY/OUTPUT/RED 1 1
619017 WIRE-BLACK/6”/18 GA 1 1
628999 WIRE-NEGATIVE/AUXILLARY TO Y CONNECTION 1 1 1 1
618978 WIRE-RED/6”/18 GA/12V 1 1
618701 WIRE-RED/36”/18 GA 1 1 1 1
NOTE: UPPER FAN POSITION - MODELS WITH SERIAL # ABOVE 10087057
PART # DESCRIPTION
WITHOUT ICE
MAKER
WITH ICE
MAKER
HIGH
VELOCITY
WITHOUT
ICE MAKER
HIGH
VELOCITY
WITH
ICE MAKER
628747 BRACKET-DC FAN 1 1 1 1
61417922 CABLE TIE-NYLON 3 4 3 4
628685 FAN-EXTERNAL DC 1 1
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1 1 1
629883 WIRE ASSY 1 1 1 1
629882 WIRE ASSY 1 1 1 1
618950 WIRE MOUNT-ADHESIVE 2 2 2 2
621943 WIRE-60” (FAN MODELS) 1 1 1 1
628758 WIRE-AUXILLARY/OUTPUT/BLACK 1 1 1 1
628759 WIRE-AUXILLARY/OUTPUT/RED 1 1 1 1
619017 WIRE-BLACK/6”/18 GA 1 1
618978 WIRE-FAN/RED/6”/18 GA/12V 1 1
