Nordco M2 User manual

Model M2
Ballast Regulator and Snow Clearing
(BR/SC) Machine
OPERATION AND
MAINTENANCE MANUAL
October 2000
Re-Order: 49458501

This manual is a guide for the operation and routine maintenance of a NORDCO Railroad Maintenance
Machine. It covers product technical information, basic operating and maintenance procedures, and
safety information and is provided for use by the qualified personnel who will supervise, operate or service
the equipment described herein.
Measurements in this manual are given in both metric and customary U.S. unit equivalents.
Personnel responsible for the operation and maintenance of this equipment should thoroughly study the
manual before commencing operation or maintenance procedures.
This manual should be considered a permanent part of your machine and should
remain with the machine at all times.
Additional copies of this manual are available either as a part (Operation Manual
only) or a whole (operation and parts manual), at a nominal cost, through our Part
Sales Department. Additional service information, parts, and application information
is available through these Nordco product support resources:
NORDCO Sales: Milwaukee, Wisconsin
[phone]
[email protected]
NORDCO Parts: Milwaukee, Wisconsin
1-800-647-1724
[email protected]
Oshawa, Ontario, Canada
[phone], Ext. 224
[email protected]
NORDCO Service: 1-800-445-9258
[email protected]
We ask that if you have any comments or suggestions about this manual, let us hear from you. We are
here to be of service to you, our customers. Direct your comments and inquiries to:
Technical Documentation Department
NORDCO Inc.
245 W. Forest Hill Avenue
Oak Creek, WI 53154

HAZARDOUS MATERIAL DATA
In an effort to provide information necessary for your employee safety training program and to meet the
requirements of OSHA Hazard Communication Standard 1910.1200, we have OSHA Form 20 Safety Data
Sheets available that cover the material contained in this machine.
If you are interested in receiving this information, please refer to the Name, model, and Serial Number of
your machine when calling or writing, and direct your inquiries to:
Vice-President of Operations
NORDCO Inc.
245 W. Forest Hill Avenue
Oak Creek, WI 53154
Fax: [phone]
Phone: [phone]

Model M2 BR/SC Machine CONTENTS
10/00 (4945-8500) i Contents
TABLE OF CONTENTS
SAFETY ........................................................................................................................................................1
Understanding Key Safety Alert Words...................................................................................................1
Follow Safety Instructions .......................................................................................................................1
General Safety Tips.................................................................................................................................1
Safety Alerts............................................................................................................................................4
Lockout/Tagout Procedures....................................................................................................................7
GENERAL INFORMATION.........................................................................................................................10
About this Manual..................................................................................................................................10
Optional Equipment...............................................................................................................................10
Machine Specifications..........................................................................................................................11
Parts Ordering Information....................................................................................................................13
OPERATION
BEFORE OPERATION................................................................................................................................15
Front Ballast Plow .................................................................................................................................15
Ballast Wing..........................................................................................................................................16
Broom....................................................................................................................................................16
Stone Deflector......................................................................................................................................16
Cab Controls .........................................................................................................................................18
Control Console ............................................................................................................................18
Engine and Pump Controls...........................................................................................................21
Left Valve Bank – Ballast Regulator..............................................................................................24
Left Valve Bank – Snow Wings.....................................................................................................27
Right Valve Bank – Ballast Regulator...........................................................................................29
Broom Valve Bank ........................................................................................................................31
Hydraulic Pressure Gauges..........................................................................................................32
Remote Controls...........................................................................................................................33
Engine Operation ..................................................................................................................................34
START-UP CHECKS...................................................................................................................................35
Preparing the Machine for Work ...........................................................................................................36
Pre-Operational Checklist .....................................................................................................................36
Lock-Up Devices...................................................................................................................................37
PROPELLING AND BRAKING (TRAVEL).................................................................................................38
MACHINE SET-UP......................................................................................................................................41
Height Adjustments ............................................................................................................................41
MACHINE OPERATION..............................................................................................................................43
Front Ballast and High Speed Plows.....................................................................................................43
Multi-Position Plows ..............................................................................................................................44
Ballast Wings ........................................................................................................................................44
Broom....................................................................................................................................................44
Snow Screw & Blower...........................................................................................................................45
EMERGENCY STOPPING..........................................................................................................................45
AFTER OPERATION...................................................................................................................................46
Parking or Locating Machine.................................................................................................................46
Rotating Machine ..................................................................................................................................46
Towing...................................................................................................................................................47
- Continued on Next Page -

Model M2 BR/SC Machine CONTENTS
10/00 (4945-8500) ii Contents
MAINTENANCE AND SERVICE
GENERAL ...................................................................................................................................................49
LUBRICATION AND MAINTENANCE CHART ..........................................................................................51
LUBRICATION AND MAINTENANCE BY DAY/WEEK/MONTH/ETC.......................................................52
Daily Instructions...................................................................................................................................56
Weekly Instructions...............................................................................................................................60
Monthly Instructions ..............................................................................................................................61
Quarterly Instructions ............................................................................................................................62
Yearly Instructions.................................................................................................................................63
RECOMMENDED SPARE PARTS ..................................................................................... See Appendix A
TROUBLESHOOTING
GENERAL ...................................................................................................................................................65
ENGINE TROUBLESHOOTING .................................................................................................................66
ELECTRICAL TROUBLESHOOTING ........................................................................................................67
HYDRAULIC SYSTEM TROUBLESHOOTING..........................................................................................71
MECHANICAL TROUBLESHOOTING.......................................................................................................75
APPENDICES
APPENDIX A - SUGGESTED SPARE PARTS
APPENDIX B – OPTIONAL JOYSTICK CONTROLS
APPENDIX C – SNOW MACHINE CONVERSION

Model M2 BR/SC Machine CONTENTS
10/00 (4945-8500) iii Contents
MECHANICAL PARTS SHEETS
FIGURE ASSEMBLY
FIGURE 1. CAB ASSEMBLY (OPERATOR STATION)
1-1 Seats....................................................................................................................................E-30270
1-2 Defroster ............................................................................................................................................
1-3 Air Conditioner ....................................................................................................................D-38200
1-4 Heater ................................................................................................................................................
1-5 Steps, Right Hand................................................................................................................C-33040
1-6 Steps, Left Hand ..................................................................................................................C-33041
1-7 Upper Control Console..........................................................................................................D-33533
1-8 Lower Control Console
1-8-1 Lower Control Console (Standard)............................................................................E-32077
1-8-2 Lower Control Console (Optional w/ECD Pump - ZF Transmission) ........................D-32321
1-9 Joystick Controllers (Optional)......................................................................................Not Available
1-10 Front Wipers .......................................................................................................................A-32235
1-11 Rear Wipers........................................................................................................................A-32236
1-12 Sliding Window Assembly (Heavy Duty).............................................................................C-38345
1-13 Heated Mirrors ....................................................................................................................C-38151
1-20 Miscellaneous Cab Accessories............................................................................................ Varies
FIGURE 2. AXLES AND SUSPENSION
2-1 Axles (Insulated) ..................................................................................................................E-16450
2-2 Axles Gear Housing.............................................................................................................E-16450
2-3 Suspension (Without Lockup)...............................................................................................D-32790
2-4 Suspension (With Lockup)....................................................................................................D-38405
2-5 Shock Absorbers (Cab End).................................................................................................C-33241
2-6 Shock Absorbers (Engine End).............................................................................................C-33240
FIGURE 3. BRAKES
3-1 Dual Shoe Brakes (Dual Canister)........................................................................................D-33261
3-2 Dual Shoe Brakes (Single Canister) .....................................................................................D-33580
3-3 Single Shoe Brakes (Single Canister).................................................................................D-25405?
FIGURE 5. DRIVE SYSTEM
5-1 Drive Line Assembly .............................................................................................................E-33336
5-2 Torque Arm Assembly (Engine End) ....................................................................................C-32678
5-3 Torque Arm Assembly (Cab End).........................................................................................C-27237
5-4 Drive Shaft Assembly (Cab End) ..........................................................................................A-32661
5-5 Drive Shaft Assembly (Engine End)......................................................................................A-32662
FIGURE 6. FRAME ACCESSORIES
6-1 Batteries................................................................................................................................D-38130
6-2 Tow Pin Assembly.................................................................................................................B-38241
6-3 Rail Sweep............................................................................................................................C-25400
FIGURE 7. ENGINES AND PUMPS
7-1 Cummins Diesel (M11-C300)...............................................................................................E-33301
7-1-1 Engine Shroud...........................................................................................................D-32740
7-1-1-1 Shroud Insulation (Optional).......................................................................C-32739
7-1-2 Engine Block Heaters................................................................................................C-38253
7-1-3 Cold Ether Start.........................................................................................................C-38038
7-1-4 Radiator Assembly.....................................................................................................D-32760
7-1-4-1 Radiator Seal Kit.................................................................................................C-33310
7-1-5 Intake/Exhaust Assembly..........................................................................................D-32730
7-1-6 Engine Air Intake Pre-Cleaner (Optional)..................................................................A-38026
7-1-7 Engine Coolant Heater ..............................................................................................D-38059
7-1-8 Engine Oil Remote Drain...........................................................................................B-32736
7-5 Pump Drives
7-5-1 Pump Drive w/Clutch (For Cummins Engines)..........................................................B-38297
7-5-2 Pump Drive w/Clutch (For Cummins Engines).............................................B-38299/800115
7-5-3 Pump Drive w/o Clutch (For Cummins Engines)..........................................B-38377/800111
7-5-4 Pump Drive w/o Clutch (For Cummins Engines)..........................................E-33301/800116

Model M2 BR/SC Machine CONTENTS
10/00 (4945-8500) iv Contents
FIGURE 8. HYDRAULIC TANKS
8-1 Hydraulic Tank ......................................................................................................................D-32240
8-1-1 Hydraulic Tank Heater...............................................................................................C-38007
FIGURE 10. FUEL TANKS
10-1 Primary Fuel Tank...............................................................................................................D-33271
10-1-1 Tank Drain Assembly ..............................................................................................A-38219
10-2 Secondary Fuel Tank (Optional).........................................................................................D-38211
10-3 Dual Tank Level Sending Unit Kit .......................................................................................D-38393
FIGURE 13. FRONT PLOWS
13-1 Two-Way Plow (Ballast or Snow)........................................................................................D-25111
13-1-1 Plow Blade...............................................................................................................B-25121
13-2 Versatile Plow .....................................................................................................................D-27600
13-3 Front V-Plow ......................................................................................................................E-29130
FIGURE 14. SIDE WINGS
14-1 Ballast Wing........................................................................................................................E-25710
14-1-1 Inner Door Cylinder (Optional)................................................................................C-38287
14-2 Snow Wing (Left Hand).......................................................................................................E-32300
14-2-1 Lower Curl (Left hand) (Optional)............................................................................D-33220
14-3 Snow Wing (Right Hand) ....................................................................................................E-32301
14-3-1 Lower Curl (Right Hand) (Optional).........................................................................D-33221
FIGURE 15. BROOM & DEFLECTOR
15-1 Standard Broom..................................................................................................................E-33260
15-1-1 Broom Liner.............................................................................................................C-38264
15-2 Clamp Style Broom Shaft....................................................................................................D-27730
15-3 Stone Deflector ...................................................................................................................D-27680
FIGURE 16. SNOW SCREW & BLOWER
16-1 Snow Screw and Blower (9-Feet) .......................................................................................D-27709
16-2 Snow Screw and Blower .....................................................................................................E-27187
FIGURE 22. TURNTABLE................................................................................................................D-33030
HYDRAULIC PARTS SHEETS
PIPING ASSEMBLIES
60 Main Machine......................................................................................................................D-33393
60-1 Ballast Wing...............................................................................................................C-32275
60-2 Snow Wing.................................................................................................................D-32277
60-3 Snow Blower..............................................................................................................D-33398
60-4 Transmission .............................................................................................................B-32283
60-5 Emergency Hydraulic Pump ......................................................................................D-38233
60-6 2nd Fuel Tank .............................................................................................................D-38211
60-7 Air Conditioning..........................................................................................................C-32718
Suspension w/Lockups .........................................................................See Mechanical, Figure 2-4
Heater ...................................................................................................See Mechanical, Figure 1-4
Inner Door Cylinder - Ballast Wing (Optional)................................. See Mechanical, Figure 14-1-1
FUNCTIONAL SCHEMATICS
65 Main Machine......................................................................................................................D-33394
65-1.....................................................................................................................................C-32396
65-2.....................................................................................................................................B-32282
65-3.....................................................................................................................................B-32276
MANIFOLDS
68 Main ....................................................................................................................................D-33292

Model M2 BR/SC Machine CONTENTS
10/00 (4945-8500) v Contents
PNEUMATIC PARTS SHEETS
FIGURE ASSEMBLY
BASE MACHINE
80 Main Machine........................................................................................................................D-32650
80-1 T-2000 Air Dryer (Optional)........................................................................................C-38385
80-2 Air System Quick Disconnect ....................................................................................A-38053
80-3 Air System Drain........................................................................................................B-38043
80-4 Brake Pressure..........................................................................................................B-38081
80-5 Parking Brake ............................................................................................................C-38249
SAFETY LOCKS
81-1 Safety Locks.......................................................................................................................C-38116
81-2 Safety Locks - Front Plow..................................................................................................C-33358
81-3 Safety Locks - Turntable....................................................................................................D-32401
81-4 Safety Locks - Broom..........................................................................................................C33359
ELECTRICAL PARTS SHEETS
FIGURE ASSEMBLY
70 Main Machine (Up to S/N 9914, excluding 9815)........................................................................E-33060
70A Main Machine (S/N 9915 and Above, S/N M20100 and Above)...............................................E-33530
70-1 Upper Control Console (Up to S/N 9914, excluding 9815) ..............................................C-32330
70-1A Upper Control Console (S/N 9915 and Above, S/N M20100 and Above) .......................D-33531
70-2 Cab and Engine Shroud Emergency Shutdown..................................................................C-38085
70-3 Ammeter .............................................................................................................................C-38429
70-4 Air Conditioning...................................................................................................................B-33105
70-5 Upper Control Console........................................................................................................D-33531
70-6 Power Circuit and Gear Shift Lever (Up to S/N 9914, excluding 9815) .............................C-32333
70-6A Power Circuit and Gear Shift Lever (S/N 9915 and Above, S/N M20100 and Above) ....C-33532
70-7 Emergency Hydraulic Pump...............................................................................................B-33254
70-8 Illuminated Speedometer (Up to S/N 9914, excluding 9815).............................................D-38359
70-8A Illuminated Speedometer (S/N 9915 and Above, S/N M20100 and Above).....................D-38395
70-9 Work Lights........................................................................................................................C-38281
70-10 Beacon..............................................................................................................................C-38155
MISCELLANEOUS ELECTRICAL SCHEMATICS (ELSEWHERE IN MANUAL)
Air Dryer, T-2000 (Optional).........................................................................See Pneumatic, Figure 80-1
Batteries........................................................................................................See Mechanical, Figure 6-1
Brake Pressure Gauge.................................................................................See Pneumatic, Figure 80-4
Defroster........................................................................................................See Mechanical, Figure 1-3
Engine Sump and Block Heater................................................................ See Mechanical, Figure 7-1-2
Ether Start (Optional) ................................................................................ See Mechanical, Figure 7-1-3
Fuel Level Senders .....................................................................................See Mechanical, Figure 10-3
Heater............................................................................................................See Mechanical, Figure 1-4
Oil Tank Heater......................................................................................... See Mechanical, Figure 8-1-1
Parking Brake Warning Light .......................................................................See Pneumatic, Figure 80-5
Suspension w/Lockup ...................................................................................See Mechanical, Figure 2-4

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 1
SAFETY
Please read and comply with all of the safety precautions in this manual BEFORE
operating this machine.
GENERAL
DO NOT use this machine for machine operations other than for which it was
intended.
NORDCO is not responsible for any modifications made without authorization or
written approval. Replace all NORDCO and OEM parts with genuine NORDCO
or OEM parts. Use of non-OEM parts could compromise the safety of your
machine.
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this manual. Learn how to operate the
machine and how to use controls properly. Do not let anyone operate this
machine without instruction.
SAFETY ALERT SYMBOLS!
These are the safety-alert symbols. These symbols
means pay attention! Your safety is at risk!
SYMBOL MEANING
DANGER typically defines the most serious
hazards. DANGER usually means that
improper use could result in severe bodily
harm or even death.
WARNING means that improper use could
result in bodily harm and/or extensive
machine damage.
CAUTION means that improper use could
result in machine damage.

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 2
GENERAL SAFETY TIPS
Only trained and authorized personnel should be allowed to operate this machine.
In addition, all personnel should be aware of the safety concerns and their
individual responsibilities prior to working this machine. General guidelines
include:
1. Handle fuel safely. It is highly flammable and prolonged breathing of
fumes may cause bodily harm.
2. Prepare for emergencies. Keep a first aid kit and fire extinguisher handy.
3. Wear good-fitting pants and shirt, no baggy or loose clothing.
4. Safety glasses, safety boots, hearing protection, and a hard hat should
be worn at all times.
SAFETY DURING WORK
NORDCO recommends the use of a Command position. This means that the
machine is never running unless someone is at or near the main control panel or
remote control boxes. To prevent injury to personnel or damage to the machine,
it is highly recommended to:
1. Make certain that no one is in the path of this machine. Before moving this
machine, whether in work or travel mode, make certain that all personnel
have left the area before moving this machine.
2. Slow down the work cycle and use slower travel speeds in congested or
populated areas. Use a commonly understood signal so that others can warn
the operator to slow or halt work in a possible hazardous situation.
3. Strong rains, fog, and extremely dusty and blowing conditions can obscure
visibility in your work area. Wait for weather to improve before continuing
work.
4. Anyone standing near the machine is at risk of being injured. Make certain
they keep away from any moving assembly during working operations.
5. There are standard guards in place on this machine. These are to be
removed only when service or maintenance is being performed in that area.
Reinstall guards after work has been completed.
6. Check and service the fire extinguisher (if so provided) at regular intervals.
Make certain all personnel are trained in its use. Note - Non-use of fire
extinguisher still requires that it be recharged at the interval stated on its last
inspection notice.
7. There are lockups on this machine that are used for both work and travel.
These should be kept clear and free of debris, grease, etc. See Lockup
section for instructions on their use.
8. Inspect safety decals and replace when they become unreadable or are
damaged. (See “Safety Decals” at the end of this Safety section).
9. Keep steps, walkways, and the top of the turntable clear and free of oil, ice,
mud, ballast, tools and other loose objects.
10. When mounting and dismounting the machine, use the handrails and steps
provided. Do not climb onto the machine in any other manner.

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 3
11. Only the number of riders for which seats are available are allowed on this
machine during work or travel operations. DO NOT ALLOW RIDERS ON
THIS MACHINE IF SEATS ARE NOT AVAILABLE.
12. Never change the direction of work travel without first bringing the machine to
a complete stop.
SAFETY DURING TRAVEL
Traveling in this machine requires all steps listed above, in addition:
1. Always make certain that lockups provided on this machine are free of debris
or grease and are in place prior to travel.
2. Operate the machine carefully when bad weather conditions exist. Maintain a
distance between machines that will allow you room to stop.
3. Strong rains, fog, and extremely dusty and blowing conditions can obscure
visibility in your area. Wait for weather situation to improve before continuing
travel.
4. Anyone standing near the machine is at risk of being injured. Make certain
they keep away from the machine during travel operations.
5. Never change direction of travel without bringing the machine to a complete
stop.
SAFETY DURING MAINTENANCE
Alert others in the area that service or maintenance is being performed on this
machine. Become familiar with, and use, your company’s lockout/tagout
procedures when performing maintenance on this machine. See
LOCKOUT/TAGOUT REQUIREMENTS later in this Safety Section for a chart on
energy sources located on this machine.
Do not start the engine if repairs or work is being performed alone. You should
always have at least two people working together if the engine must be run during
service. One person needs to remain in the command position (at the controls),
ready to stop the machine and shut off engine if the need arises.

Model M2 BR/SC Machine SAFETY
10/00(4945-8501) Safety, Page 4
MACHINE SAFETY ALERTS
DANGER ALERTS
Improper use of this machine for any type of operation can cause serious injury or
death.
To avoid serious injury or death, make certain that the area around and under the
machine is clear of all personnel and obstructions BEFORE travelling or working.
Serious injury or death can result from reaching into working components while
machine is running. Make all observations from a distance and SHUT OFF machine
while making adjustments.
Shut off engine when checking battery electrolyte level. Do not check or fill battery in
presence of open flame, sparks, or when smoking. Battery fumes are flammable and/or
explosive and if ignited will result in severe bodily injury or death.
Do not ride on tow bar between the machine and the towing vehicle. Falling from a
moving vehicle may cause serious injury or death.

Model M2 BR/SC Machine SAFETY
10/00(4945-8501) Safety, Page 5
MACHINE SAFETY ALERTS
WARNING ALERTS
Failure to engage all lockup devices before propelling at travel speed can result in
injury to personnel and/or extensive damage to the machine.
Tighten fittings only when system is not pressurized. High pressure leaks can cause
personal injury.
Always turn off machine when performing maintenance, making adjustments, or
whenever unintended movement of machine could occur; unless directed otherwise.
Failure to comply could result in personal injury and/or damage to the machine.
Exhaust emissions caused by the use of the engine on this machine may cause cancer,
birth defects, or other reproductive harm if inhaled.
Disconnect the battery before servicing this machine. Failure to do so could result in
personal injury from accidental engine startup.
You must always use the air treadle or parking brake to stop this machine while in the
Travel Mode. Failure to do so may cause personal injury or machine damage.

Model M2 BR/SC Machine SAFETY
10/00(4945-8501) Safety, Page 6
MACHINE SAFETY ALERTS
CAUTION ALERTS
Before starting a new or overhauled engine that has been in storage, consult the
engine manufacturer’s manual for initial start instructions. Failure to follow those
instructions can result in serious engine damage.
Never shut off battery disconnect switch with the engine running. This could cause
damage to the voltage regulator, alternator, and/or electrical system.

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 7
LOCKOUT AND/OR TAGOUT PROCEDURES
It is your company’s responsibility to develop Lockout/Tagout Procedures, train you in their proper and safe
use, and to periodically inspect your work area to verify that you are complying with the procedures.
Lockout/Tagout Procedures must be followed!
This machine is completely locked out when the ignition switch and battery disconnect switch have
been turned to the “OFF” position and their respective covers closed and locked. HOWEVER, some
energy is stored in the hydraulic components of this machine; and these must be relieved of
pressure prior to service and maintenance.
NORDCO has provided the means to lockout this machine. NORDCO cannot be held responsible for injury
caused by failure to comply with your company’s Lockout/Tagout Procedures.
ENERGY SOURCES
The list on the following pages provides information on energy sources located on this machine and
instructions for inserting manual lockups, if applicable. It is your company’s responsibility to incorporate
these instructions into their Lockout/Tagout Procedures.
IMPORTANT NOTICE!
This machine may have been equipped with both Manual and Power Lockup devices.
Read the energy source information closely and DO NOT ASSUME ALL LOCKUPS ARE
POWERED.

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 8
LOCKOUT/TAGOUT – PROCEDURES
When servicing
or performing
maintenance on:
Energy
Source to
be locked
out:
Use this procedure:
Electrical System
(Work and Travel
Boxes, Battery,
Wiring
Harnesses,
Junction and
Control Boxes)
Electrical 1) Turn the ignition switch to the OFF position.
2) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off electrical power supply to the machine.
Engine Electrical
1) Turn the ignition switch to the OFF position.
2) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off electrical power supply to the machine and
prevent accidental startup of engine while servicing.
Propulsion
System
Hydraulic
1) Turn the ignition switch to the OFF position.
2) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Ballast Plow Hydraulic
Gravity
1) Lower plow until it rests on solid ground.
2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Ballast Wings Hydraulic
Gravity
1) Lower wing(s) until it (they) rests on solid ground.
2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Broom Hydraulic
Gravity 1) Raise Broom. Depending on options on the machine, either insert lock pins at Up/Down Cylinder, or lock the broom in the
UP position by pressing the lock valve button on the control
panel.
2) Tilt broom back and lock in place with lock chains.
3) Turn the ignition switch to the OFF position.
4) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components.

Model M2 BR/SC Machine SAFETY
10/00 (4945-8501) Safety, Page 9
When servicing
or performing
maintenance on:
Energy
Source to
be locked
out:
Use this procedure:
High Speed V-
Plow Hydraulic Gravity 1) Lower plow until it rests on solid ground. 2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
High Speed One-
WayPlow
Hydraulic
Gravity 1) Lower plow until it rests on solid ground. 2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Multi-Position
Plow
Hydraulic
Gravity 1) Lower plow until it rests on solid ground. 2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Side Wing (Long
Reach)
Hydraulic
Gravity 1) Lower wing until it rests on solid ground. 2) Turn the ignition switch to the OFF position.
3) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components of
the machine.
Snow Screw and
Blower
Hydraulic
Gravity 1) Raise Unit. Depending on options on the machine, either insert lock pins at Up/Down Cylinder, or lock in the UP position by
pressing the lock valve button on the control panel.
2) Tilt unit back and lock in place with lock chains.
3) Turn the ignition switch to the OFF position.
4) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components.
Stone Deflector Hydraulic
Gravity 1) Raise Unit. Depending on options on the machine, either insert lock pins at Up/Down Cylinder, or lock in the UP position by
pressing the lock valve button on the control panel.
2) Tilt unit back and lock in place with lock chains.
3) Turn the ignition switch to the OFF position.
4) Turn the battery disconnect switch to the OFF position and close
and lock the disconnect switch box.
This will cut off hydraulic pressure to hydraulic components.

Model M2 BR/SC Machine GENERAL
10/00 (4945-8501) General, Page 10
GENERAL
This manual contains information for the Model M2 Ballast Regulator machine manufactured by NORDCO
INC., Oshawa, Ontario. Information is provided in this manual for operation and maintenance of the
machine. Information regarding operation and maintenance of OEM parts not of NORDCO manufacture
can be found at the back of this manual, behind the tab marked “Component Data”.
Become familiar with all safety instructions, controls and instruments before operating this machine. Follow
all instructions carefully.
ABOUT THIS MANUAL
This manual has been broken down into sections which have been separated by index tabs. Contents of
these sections are as follows:
TAB CONTAINS
Operation Includes all information necessary to set up and operate the machine.
Maintenance Includes lubrication, maintenance, and mechanical adjustment
instructions.
Troubleshooting Includes basic troubleshooting for all components on the machine, as
well as functional hydraulics, electrical schematics, and cabling
locations.
Appendices Contains information that is subject to periodic updating or has been pre-
printed. Refer to the Table of Contents for appendices included in this
manual.
Mechanical Includes individual parts breakdown drawings and lists for each
assembly
Hydraulic Includes all piping and functional drawings for a standard machine; for
optional equipment that requires additional drawings, see tab “Customer
Options”.
Electrical Includes all electrical schematics, electrical boxes, remote control boxes,
cables and cabling layout drawings for the machine
Component Data Includes parts breakdowns and service instructions for components
installed on the machine that are not of NORDCO’s manufacture.
Customer Options Includes parts breakdowns, lists, and drawings for all equipment on the
machine that is optional.
OPTIONAL EQUIPMENT
The specifications that following include Customer Selectable Features such as the engine. This means
that an engine is required to run the machine, but the customer has a choice as to what type of engine they
want to have installed. This differs from Optional Equipment such as a remote engine drain system.
Optional equipment are those items that are not considered a vital operating part to the machine, but the
customer wants them installed. Sheets for the Optional Equipment have been included behind the tab
Customer Options. It is recommended that you know what options you have on your machine.
