Nordmende WD515IX User manual

SAVE THESE INSTRUCTIONS CAREFULLY
To avoid the risk of accidents or damage to
the appliance it is essential to read these
instructions before it is installed and used for
the first time.
BUILT-IN WARMING DRAWER
WD515IX
USER MANUAL

Table of Contents
ã=
Warning and Safety Instructions
This appliance complies with all relevant safety
requirements. However inappropriate use can, lead
to personal injury and damage to property.
To avoid the risk of accidents and damage to the
appliance, please read these instructions carefully
before installation and before using it for the first
time. They contain important notes on installation,
safety, use and maintenance.
Keep these instructions in a safe place and ensure
that new users are familiar with the content. Pass
them on to any future owner.
Warning and Safety Instructions
Correct Application
► The appliance is not designed for commercial use. It is intended for use in domestic
households and similar working and residential environments. Warranty is void if it is used in a
commercial environment.
► The appliance is not intended for outdoor use.
► It is intended for domestic use only as described in these operating and installation instructions.
Any other usage is not supported by the manufacturer and could be dangerous.
► The appliance can only be used by people with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, if they are supervised whilst using
it, or have been shown how to use it in a safe way and understand the hazards involved.
Safety with Children
► Children under 8 years of age must be kept away from the appliance unless they are constantly
supervised.
► Children 8 years and older may only use the appliance if they have been shown how to use it in
a safe way and understand the hazards involved.
► Children must not be allowed to clean the appliance unsupervised.
2
Warning and safety instructions ............ 2
Caring for the environment .................... 4
Before using for the first time ................. 5
Guide to the appliance ........................... 5
Control panel ......................................... 6
Operation ............................................... 6
Function settings ................................... 6
Temperature settings ............................ 8
Duration ................................................. 8
Capacity ................................................. 8
Keeping food warm ................................ 9
Low temperature cooking ...................... 10
Other uses ............................................. 16
Cleaning and care .................................. 17
Problem solving guide ........................... 19
Safety instructions for installation .......... 21
Built-in dimensions ................................. 22
Technical data ....................................... 23
Environmental protection ....................... 23

► This appliance is not a toy! To avoid the risk of injury, do not let children play with the
appliance or its controls.
► The appliance gets hot when in use and remains hot for quite a while after being switched off.
Keep children well away from the appliance until it has cooled down and there is no danger of
burning.
► Packaging, e.g. cling film, polystyrene and plastic wrappings, must be kept out of the reach of
babies and children. Danger of suffocation. Dispose of or recycle all safely as soon as possible.
Technical Safety
► Installation, maintenance and repair work may only be carried out by a suitably qualified and
competent person in strict accordance with national and local safety regulations.
Installation, maintenance and repairs by unqualified persons could be dangerous.
► A damaged appliance can be dangerous. Before installation, check the appliance for visible
signs of damage. Do not use a damaged appliance.
► The electrical safety of this appliance can only be guaranteed when correctly earthed. It is
most important that this basic safety requirements are observed and regularly tested and where
there is any doubt, the household wiring system should be inspected by a qualified electrician.
► To avoid the risk of damage to the appliance, make sure that the connection data (frequency
and voltage) on the data plate corresponds to the household supply, before connecting the
appliance to the mains supply. Consult a qualified electrician if in any doubt.
► Do not connect the appliance to the mains electricity supply by a multi-socket adapter or
an extension lead. These do not guarantee the required safety of the appliance (e.g. danger of
overheating).
► For safety reasons, this appliance may only be used when it has been built-in. This appliance
must not be used in a non-stationary location (e.g. on a ship).
► Do not open the casing of the appliance. Tampering with electrical connections or
components and mechanical parts is highly dangerous to the user and can cause operational
faults.
► While the appliance is under guarantee, repairs should only be undertaken by a NordMende
service technician. Otherwise the guarantee is invalidated.
► The manufacturer can only guarantee the safety of the appliance when replacement parts
are used. Faulty components must only be replaced by genuine NordMende original spare parts.
► If the plug is removed from the connection cable or if the appliance is supplied without a plug,
the appliance must be connected to the electrical supply by a suitably qualified electrician.
► The appliance must be disconnected from the mains electricity supply during installation,
maintenance and repair work. Ensure that power is not supplied to the appliance until after it
has been installed or until any maintenance or repair work has been carried out.
3

4
► THE DRAWER IS DESIGNED TO KEEP HOT FOOD WARM AND NOT TO WARM FOOD
UP. ENSURE FOOD IS ALREADY REALLY HOT WHEN PLACED
► You could burn yourself on the hot drawer or crockery. Protect your hands with heat-resistant
pot holders or gloves when using the appliance. Do not let them get wet or damp, as this causes
heat to transfer through the material more quickly with the risk of scalding or burning yourself.
► Do not store any plastic containers or flammable objects in the warming drawer. They could
melt or catch fire when the appliance is switched on, causing a fire hazard.
► Due to the high temperatures radiated, objects left near the appliance when it is in use could
catch fire. Do not use the appliance to heat up the room.
► Never place paper kitchen towels or similar in the base of the appliance.
► If you overload the drawer, or sit or lean on it, the telescopic runners will be damaged. The
telescopic runners can support a maximum load of 25kg.
► If the appliance is installed behind a kitchen furniture door, it may only be used with the
furniture door open. Only close the door if the appliance is switched off.
► Do not heat up unopened tins or jars of food in the drawer, as pressure will build up in the tin
or jar causing it to explode. This could result in injury and scalding or damage.
► The underside of the drawer gets hot when switched on. Be careful not to touch it when the
drawer is open.
► Do not use plastic or aluminum containers. These melt at high temperatures and could catch
fire. Use only heat-resistant crockery made of glass, porcelain, etc.
► Take care when opening and closing the loaded drawer, that liquids do not spill over and get
through the vents. This can cause the appliance to short circuit.
► Bacteria can develop on the food if the temperature is too low. Make sure that you set a high
enough temperature to keep food warm.
Correct Use
► In areas which may be subject to an infestation by vermon, pay attention to keeping the
appliance and its surroundings in a clean condition at all times. Any damage which may be
caused vermin will not be covered by the guarantee.
► If the supply cord is damaged, it must be replaced by the manufacturer, its' service agent or
similarly qualified persons in order to avoid a hazard.
► The power cord can only be routed through the hole in the bottom of the cabinet to avoid
touching the back shell of the oven.

Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Please ensure that it presents
no danger to children while being
stored for disposal.
Caring for the Environment
5
,PSRUWDQWIQIRUPDWLRQ
5IFBQQMJBODFJTEFTJHOFEUPCFQFSNBOFOUMZJOTUBMMFEXJUIB UISFFQJOQPXFSDPSEBOENBZPOMZCFDPOOFDUFECZBMJDFOTFE
FYQFSUJOBDDPSEBODFXJUIUIFDPOOFDUJPOEJBHSBN
0OMZBRVBMJGJFEFMFDUSJDJBOXIPUBLFTUIFSFMFWBOUSFHVMBUJPOTJOUP BDDPVOUNBZSFQMBDFUIFQPXFSDPSE
%P OPU VTF NVMUJQMF QMVHT QPXFS TUSJQT PS FYUFOTJPOT 0WFSMPBEJOH DBVTFTBSJTLPGGJSF
*GUIFDPOOFDUJPOJTOPMPOHFSBDDFTTJCMFGPMMPXJOHJOTUBMMBUJPOBO BMMQJO JTPMBUJOH TXJUDI XJUI B DPOUBDU HBQ PG BU MFBTU  NN NVTU CF
QSPWJEFE
&RQQHFW WKH ZLUHV RI WKH PDLQV SRZHU FRUG LQ DFFRUGDQFH ZLWK WKHIROORZLQJFRORXUFRGLQJ
(SFFOBOE
ZFMMPX
&BSUIXJSF <&
#MVF /FVUSBMXJSF/
#SPXO -JWF-
► Danger of injury. Do not use a steam cleaners to clean this appliance. The steam could
reach electrical components and cause it to short circuit.
► Do not immerse the appliance in water or other liquid when cleaning.
Cleaning and Care
Disposal of the Packing Material
The transport and protective packing has been selected
from materials which are environmentally friendly for
disposal, and should be recycled.
Ensure that any plastic wrappings, bags, etc. are
disposed of safely and kept out of the reach of
babies and young children. Danger of suffocation.
Disposal of your old Appliance
Electrical and electronic appliances often contain
materials which, if handled or disposed of incorrectly,
could be potentially hazardous to human health and
to the environment. They are, however, essential for
the correct functioning of your appliance.

^Close the drawer.
The warming drawer is fitted with a softclose self-closing
mechanism.
It also has a contact switch, which ensures that the
heating element and fan in the appliance only work when
the drawer is closed.
Metal components have a protective coating which may
give off a slight smell when heated up for the first time.
The smell and any vapours will dissipate after a short time,
and do not indicate a faulty connection or appliance.
Ensure that the kitchen is well ventilated whilst the
appliance is being heated up for the first time.
Guide to the Appliance
1. Control panel
To Open: Press the middle of the drawer to open or close it.
When opening, the drawer pops out slightly. You can then pull it out towards you.
Before Using for the First Time
A display test is carried out for 10 seconds after the
appliance has been installed and after a power cut. The fan
comes on at the same time. The appliance cannot be used
during this time.
Cleaning and Heating up for the First Time
^Remove any protective foil and sticky labels.
^The rack from the drawer, and sponge both with warm
water and a little washing-up liquid. Dry using a soft cloth.
^Wipe the appliance inside and out with a damp cloth only,
and then dry with a soft cloth.
^Then heat the empty drawer for at least two hours.
^Switch the appliance on by touching the sensor.
^
^
^Touch the sensor repeatedly until 2h lights up.
Touch the sensor repeatedly until the LED light.
sensor repeatedly until the LED on the far
Touch the
right lights up.
6
Please stick the extra data plate for the appliance supplied with
this documentation in the space provided below -

Control Panel
For warming cups and glasses For
Warming plates and dishes For
Keeping food warm
For setting the temperature For
Setting the duration
For adjusting temperature and time
Cancel Button
Start Button
The appliance can be used to keep food warm
at the same time as warming plates and
dishes. But the food must be covered properly
Wipe off any residual condensation that may be
present in the cooled drawer after use.
Take care. The plates and dishes will take
longer to warm up, but can get very
hot on this function.
Operation
(1)In waiting state,press " " key to start the function
of warming cups and glasses with 40 .
°C
(2)" 40 " will dislpay.
(3) Touch " " or " " to adjust the tem[perature.
°C
(4)Touch " " and then touch " " or " " to
.
(5)Touch " " to save the temperature and time.
(5)Close the door and there will be a beep.Then the
Note:
(1)During parameters setting,you can press other
function keys to change the function among " ",
" " and " ".
(2)Before closing the door,you can touch " " to
appliance will start working.
cancel the setting.And the appliance will go back
to waiting state.
Function Settings
he warming timeadjust t
Specifications
(1) When the appliance is electrified, open the door. The
buzzer will ring once and the appliance will enter to
waiting state. " 0 " will display.
(2) In the process of clock setting, if there is no operation
within 3 minutes, the oven will go back to the waiting state.
(3) The buzzer sounds once by efficient press.
(4) The buzzer will sound thrice to remind you when
cooking is finished.
(3) During the process of working, open the door
to enter to the parameters adjusting mode. And
then press " " or " " to adjust the temperature.
You can press the " " or " " to change the parameter
which you want to adjust.And then press " " to save the
setting.
(4) After saving the setting as above, you can press " "
to enter to the waiting state, or close the door to start
working.
7

Temperature °C*
40 60 60
45 65 65
50 70 70
55 75 75
60 80 80
* Approximate temperature values, measured in the middle
of the drawer when empty
Duration
The appliance is set for continuous operation mode.
duration can be selected by touching the
touch for 1 hour (1h), two touches
A limited
sensor. One
for 2 hours (2h) etc
Capacity
The quantity that can be loaded will depend to a great
your own crockery. Do not overload the drawer. The maximum load bearing
the drawer is 25 kg. Under the maximum load bearing capacity, the drawer
The loading examples shown here are
–
6 dinner plates C26 cm
6 dessert dishes C
C
1 medium serving bowl 16cm
1 small serving bowl C
1 oval platter
1 3 cm
cm
extent on the size and weight of
capacity of
nly
.
o
suggestions
.
6 soup plates C 2 3 cm
1 9 cm
32
preheat :dinnerware for pe pleo
should be opened or closed slightly.
8
Operation
Temperature Settings
Each function has its own temperature range. The factory-set
recommended temperatures are printed in bold. The
temperature can be altered in 5° steps by touching the
sensor. The last temperature selected is automatically
activated the next time the drawer is switched on and this is
shown in the display.

Settings
Food Cover the
container? Temperature for the
setting
Steak (rare) yes
Bake/gratin yes
Roast meat yes
Casserole yes
Fish fingers no
Meat in a sauce yes
Vegetables in a
sauce
yes
Goulash yes
Mashed potato yes
Plated meal yes
Baked potatoes /
New potatoes
yes
Breaded escalope no
Pancakes/
potato pancakes
no
Pizza no
Boiled potatoes yes
Gravy yes
Strudel no
To warm bread no
To warm rolls no
Keeping Food Warm
80
75
80
80
80
80
80
65
80
80
80
75
80
75
80
80
65
65
80
* Depending on model
* The containers depend on the quantity, or food, or type of recipe
9

How to use it
1.Preheat the warming drawer for 15 min to 70°C.
2.Cover the meat properly with cling wrap.
3.The cooking duration depends on the size of the individual pieces of meat (check
table).
4.Put the covered meat on a plate and use a chronometer to calculate the time.
5.Sear the meat to give flavour (check the table).
10
What is it?
I t is any cooking procedure where the cooking temperature is at or close to the
desired final core temp. In traditional cooking, the cooking temperature always
exceeds the desired ready-to-eat temperatures. With low temperature cooking
meat cooks at a low temperature over a long period of time. Using this method,
meat loses less liquid (less molecule breaking), maintain organoleptic
characteristic (vitamins, proteins and so on) keeping freshness, flavor and
juiciness intact.
This cooking method is particularly suitable for large and tender pieces of meat.
For precision we recommend using a proprietary food thermometer to monitor
the core temperature.
Core temperature
Food can be cooked to a core temperature of up to 70°C in the food warming
drawer. Meat which needs to be cooked to a core temperature higher than
70°C is not suitable for cooking in the food warming drawer.
The core temperature reading gives information about the degree of cooking in
the middle of a piece of meat. The lower the core temperature, the less cooked
the meat is in the middle:
45-50 °C = rare
55-60 °C = medium
65 °C = well done
Low Temperature Cooking

Cooking Table
Part Thickness Doneness Time Searing time and indications
Whole Fillet
50 mm
Rare 1h 35min 90 seconds for outer side with full power of the
stove
Medium 2h 35min
3 min. for outer side with medium-high power of the
stove
Well done 3h 30min
60 mm
Rare 1h 45min 90 seconds for outer side with full power of the
stove
Medium 2h 50min
3 min. for outer side with medium-high power of the
stove
Well done 4h
70 mm
Rare 2h 90 seconds for outer side with full power of the
stove
Medium 3h
3 min. for outer side with medium-high power of the
stove
Well done 4h 40min
Medallions
Rib ye
T-bone
Rump Steak
20 mm
Rare 50 min 90 seconds for side with full power of the stove
Medium 1h 30min
Well done 2h 3 min. for side with medium-high power of
the stove
30 mm
Rare 1h 5min 90 seconds for side with full power of the stove
Medium 1h 50min
Well done 2h 20min 3 min. for side with medium-high power of the stove
40 mm
Rare 1h 20min 2 min for side with full power of the stove
Medium 2h 10min
Well done 3h 4 min. for side with medium-high power of the stove
Roast Beef
60 mm
Rare 1h 45min 4 min. for outer side with medium-high power of the
stove
Medium 2h 50min
Well done 4h 6 min. for outer side with medium power of the
stove
70 mm
Rare
2h 4 min. for outer side with medium-high power of the
stove
Medium 3h
Well done 4h 40min 6 min. for outer side with medium power of the
stove
80 mm
Rare 2h 20min 4 min. for outer side with medium-high power of the
stove
Medium 3h 30min
Well done 5h 40min 6 min. for outer side with medium power of the
stove
Sirloin jJoint
Beef &&&and Veal
11
Low Temperature Cooking

Pork
Part
Thickness
Doneness
Time
Searing time and indications
Whole filet
40mm
Medium
2h 20min
90 secondsfor outer side with full power of the
stove
Well done
3h 10min
3 min. for outer sidewith medium-high power of the
stove
50mm
Medium
2h 35min
90 seconds for outer side with full power of the
stove
Well done
3h 25min
3 min. for outer sidewith medium -high power of the
stove
60mm
Medium
3h 90 seconds for outer side with full power of the
stove
Well done
4h 5min 3 min. for outer sidewith medium -high power of the
stove
Boned gammon
Roulades
Roast pork
Whole pork loin
30mm
Medium
1h 50min 2 min. for outer side with high power of the stove
Well done
2h 40min 3 min. for outer side with medium -high power of the
stove
40mm
Medium
2h 20min 2 min. for outer side with high power of the stove
Well done
3h 10min
3 min. for outer side with medium -high power of the
stove
50mm
Medium
2h 35min
4 min. for outer sidewith medium -high power of the
stove
Well done
3h 25min
6 min. for outer sidewith medium power of the
stove
60mm
Medium
3h
4 min. for outer side with medium-high power of the
stove
Well done
4h 5min
6 min. for outer sidewith medium power of the
stove
70mm
Medium
3h 20min
4 min. for outer sidewith medium -high power of the
stove
Well done
4h 45min
6 min. for outer sidewith medium power of the
stove
80mm
Medium
3h 40min
4 min. for outer sidewith medium -high power of the
stove
Well done
5h 30min
6 min. for outer sidewith medium power of the
stove
Chop loin
10mm
Medium
1h 10min
60 seconds for side with full power of the stove
Well done
1h 30min
2 min. for side with full power of the stove
20mm
Medium
1h 30min
90 seconds for side with full power of the stove
Well done
2h 10min 3 min. for side with high power of the stove
12
Low Temperature Cooking

Poultry
Part Thickness Doneness Time Searing time and indications
Chicken breast
25mm Medium 1h 30min 60 seconds for side with full power of the stove
Well done 2h 90 seconds for side with full power of the stove
35mm Medium 1h 45min 60 seconds for side with full power of the stove
Well done 2h 20min 90 seconds for side with high power of the stove
Duck breast
35mm
Rare 1h 4 min. for the skin side with medium-high power of
the stove
Medium 1h 30min 4 min. for the skin side with medium -high power of
the stove
Well done 2h 4 min. for the skin side with medium-high power of
the stove
40mm
Rare 1h 45min 4 min. for the skin side with medium-high power of
the stove
Medium 2h 20min 4 min. for the skin side with medium -high power of
the stove
Well done 3h
Turkey breast
40mm Medium 3h 90 seconds for side with full power of the stove
Well done 4h 3 min. for side with high power of the stove
50mm Medium 3h 50min 90 seconds for side with full power of the stove
Well done 5h 3 min. for side with high power of the stove
Foie Medallion
(Duck or Goose liver)
10mm Medium 30min 60 seconds for side with full power of the stove
20mm Medium 40min 60 seconds for side with full power of the stove
30mm Medium 50min 60 seconds for side with full power of the stove
Whole Foie
(Duck or Goose liver)
35mm Medium 48min 90 seconds for outer side with full power of the
stove
45mm Medium 1h 90 seconds for outer side
with full power of the
stove
55mm Medium 1h 15min 90 seconds for outer side
with full power of the
stove
4 min. for the skin side with medium-high power of
the stove
13
Low Temperature Cooking

Lamb
Part Thickness Doneness Time/Temp. Searing time and indications
Rack of lamb
40 mm
Rare 1h 20min 90 seconds for outer side with full power of the
stove.
Medium 2h 10min
Well done 3h 3 min. for outer side with medium-high power of
the stove.
50 mm
Rare 1h 35min 90 seconds for outer side with full power of the
stove.
Medium 2h 35min
Well done 3h 30min 3 min. for outer side with medium-high power of
the stove.
60 mm
Rare 1h 45min 90 seconds for outer side with full power of the
stove.
Medium 2h 50min
Well done 4h 3 min. for outer side with medium-high power of
the stove.
Saddle of Lamb
60 mm
Rare 1h 45min 3 min for outer side with full power of the stove.
Medium 2h 50min 4 min. for outer side with medium-high power of
the stove.
Well done 4h
70 mm
Rare 2h 3 min for outer side with full power of the stove.
Medium 3h 4 min. for outer side with medium-high power of
the stove.
Well done 4h 40min
80 mm
Rare 2h 20min 3 min for outer side with full power of the stove.
Medium 3h 30min 4 min. for outer side with medium-high power of
the stove.
Well done 5h 40min
Boned leg of lamb
Gigot
60 mm
Rare 1h 45min 2 min for outer side with full power of the stove.
Medium 2h 50min 3 min. for outer side with medium-high power of
the stove.
Well done 4h
70 mm
Rare 2h 2 min for outer side with full power of the stove.
Medium 3h 3 min. for outer side with medium-high power of
the stove.
Well done 4h 40min
80 mm
Rare 2h 20min 2 min for outer side with full power of the stove.
Medium 3h 30min 3 min. for outer side with medium-high power of
the stove.
Well done 5h 40min
Lamb chops
10 mm
Rare
Medium
Well done
35min
1h 10min
2h
60 seconds for side with full power of the stove.
90 seconds for side with full power of the stove.
20 mm
Rare
Medium
Well done
50min
1h 30min
2h 30min
60 seconds for side with full power of the stove.
90 seconds for side with full power of the stove.
14
Low Temperature Cooking

Eggs
Size Weight Time Remarks
Very Large 73g and over
2h 20min
2h 30min
3h 10min
Large 63g<
2h 11min
2h 31min
3h 1min
Medium
2h 5min
2h 25min
2h 55min
Small 53 and under
2h
2h 20min
2h 50min
53g<
73g
63g
15
Low Temperature Cooking

*Depending on model
Type of
food
Container
Cover the
container
Temperature of
the setting
Duration in hours
Defrosting
berries Plate no 65℃1 hour
Defrosting
Frozen
Vegetables
Plate no 65℃1 hour
Proving dough Bowl yes 45℃1/2 hour
Making yoghurt Yoghurt jars with
lids yes 45℃6 hours
Melt chocolate Bowl no 50℃1 hour
Infusion oil Bowl covered with
cling wrap yes 75℃4 hours
Infusion w ater Bowl covered with
cling wrap yes 65℃4 hours
Dry tomatoes Plate with baking
paper no 60℃20 hours
Dry Vegetable Plate no 60℃12 hours
Dry sliced fruits Plate no 60℃12 hours
Dry herbs Plate no 70℃4 hours
Dry bread for
bread crumbs Plate no 80℃4 hours
Confited
Fish in oil
Tupperware
Microwaveable
cover and
open the vent 50℃Depends on size between 1 to 2h.
White Melba
toast Plate no 80℃2 hours
Slow cooking
stew Pyrex container yes 80℃Between 1 to 12 hours
16
Other Uses

,Danger of injury.
Do not use a steam cleaning appliance to clean this
appliance. The steam could reach electrical components
and cause a short circuit.
Danger of damage.
Unsuitable cleaning agents can damage the surfaces of
the appliance. Only use domestic washing-up liquid to
clean the appliance.
Clean and dry the entire appliance after each use. Allow the
appliance to cool down to a safe temperature before
cleaning.
Remove any soiling immediately.
If this is not done, it might become impossible to remove
and could cause the surfaces to alter or discolour.
Clean all surfaces with a clean sponge and a solution of hot
water and washing-up liquid. Then dry with a soft cloth.
A clean, damp microfibre E-cloth without cleaning agent can
also be used.
All surfaces are susceptible to scratching. Scratches on
glass surfaces could even cause a breakage.
Contact with unsuitable cleaning agents can alter or
discolour the surfaces.
17
Cleaning Care
Appliance Front and Interior

To avoid damaging the surfaces of your appliance, do not
use:
– cleaning agents containing soda, ammonia, acids or
chlorides.
– cleaning agents containing descaling agents.
– abrasive cleaning agents, e.g. powder cleaners and cream
cleaners.
– solvent-based cleaning agents.
– stainless steel cleaning agents.
– dishwasher cleaner.
– oven sprays.
– glass cleaning agents.
– hard, abrasive sponges and brushes, e.g. pot scourers.
– sharp metal scrapers.
Cleaning and Care
18

With the help of the following guide minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be put right
without contacting the Service Department.
,Installation work and repairs to electrical appliances must only be carried
out by a suitably qualified person in strict accordance with current local and
national safety regulations. Repairs and other work by unqualified persons
could be dangerous.
Problem Possible cause Remedy
The appliance does not
heat up.
The appliance is not correctly
plugged in and switched on at
the mains socket.
Insert the plug and switch on at the
socket.
The mains fuse has tripped. Reset the trip switch in the mains fuse
box (minimum fuse rating - see data
plate).
If, after resetting the trip switch in the
mains fuse box and switching the
appliance back on, the appliance will
still not heat up, contact a qualified
electrician.
The food is not hot
enough.
The function for keeping food
warm is not selected.
Select the correct function.
The temperature setting is too
low.
Select a higher temperature.
The vents are covered. Ensure that the air can circulate freely.
The food is too hot. The function for keeping food
warm is not selected.
Select the correct function.
The temperature setting is too
high.
Select a lower temperature.
The crockery is not warm
enough.
The function for warming
plates and dishes is not
selected.
Select the correct function.
The temperature setting is too
low.
Select a higher temperature.
The vents are covered. Ensure that the air can circulate freely.
The crockery has not been
allowed to heat up for a
sufficiently long time.
Various factors will affect how long the
crockery will take to heat up (see
"Warming crockery").
19
Problem Solving Guide

Problem Possible cause Remedy
The crockery is too hot. The function for warming
plates and dishes or
warming cups and glasses
is not selected.
Select the correct function.
The temperature setting is too
high.
Select a lower temperature.
A noise can be heard
when the drawer is being
used.
The noise is caused by the fan
which distributes the heat
evenly through the drawer.
The fan operates at intervals
when the functions for keeping
food warm and low
temperature cooking are
being used.
This is not a fault.
20
Problem Solving Guide
