Dacor IWD24 Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 2.8
24”, 27”, 30”, 36” Wide,
Warming Drawers
EWD, IWD, MWDV, MWDH, MRWD, PWD
Warming Drawers
1/2
Revised
06/03/08
Warming Drawer
Cooktop
1 1/2" (38 mm)
Typical counter top
3/4” Min.*
(19 mm)
120 Vac
electrical
receptacle
A
36" Typ.
(914 mm)
B
C
A
Warming Drawer
Warming Drawer
B
3/4" Min.*
(19 mm)
D
3/4" Min.*
(19 mm)
120 Vac
electrical
receptacle
36" Typ.
(914 mm)
C
C
27"/30"/36"
Dacor
single oven
Warming Drawer
Warming Drawer
Toe Kick
D
C
D
C
120 Vac
Elect.
120 Vac
Elect.
A
3/4" Min.*
(19 mm)
Model “A” Cutout Width “B” Min. Width to Adjacent
Doors/Drawers “C” Cutout Height “D” Min. Vertical Gap Between Cutouts
IWD24 22 1/2” (572mm) 24 1/4”*
(616mm)
9 1/8” (232mm) 1 1/16”*
(27mm)
EWD24
EWD27
25 1/2” (648mm) 27 1/4”*
(692mm)
IWD27
MWDH27
MWDV27
MRWD27
PWD27
EWD30
28 1/2” (724mm) 30 1/4”*
(768mm)
IWD30
MWDH30
MWDV30
MRWD30
PWD30
EWD36 34 1/4” (870mm) 36 1/4”
(921mm)
CUTOUTS DIMENSIONS
CUTOUT DEPTH: 24” MIN. (610mm)
* EWD36 cannot be stacked. Bare minimum spacing shown allows extra space to avoid scrapping and allow for
ventilation. On IWD series models, additional space may be required if an oversized drawer front is used. Use the
drawer face dimensions for the corresponding EWD series model for reference.

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 2.9
24”, 27”, 30”, 36” Wide,
Warming Drawers
2/2
23 3/8"
(594 mm)
Chassis
Drawer open
5/64"
(2mm)
23 13/16
(605 mm)
B
C
OVERALL DIMENSIONS
TOP VIEW
(EWD SERIES SHOWN)
10 1/8"
(257 mm)
A
DRAWER FACE DIMENSIONS
(MW SERIES SHOWN)
3 5/16"
(84mm)
1"
(25mm)
EWO
1"
(25mm)
1 5/16"
(33mm)
MWO
1"
(25mm)
2 3/16"
(56mm)
PWO
3 7/16"
(87mm)
EW
3 1/4"
(83mm)
PW
2 1/4"
(57mm)
MW
1"
(25mm)
1 5/32"
(29mm)
1 1/8"
(29mm)
3 7/16"
(87 mm)
EWD
3 1/4"
(83 mm)
MRWD MWDH/V
1"
(25mm)
1"
(25mm)
PWD
2 1/4"
(57 mm)
1"
(25mm)
1"
(25mm)
HANDLE DIMENSIONS
CHASSIS DIMENSIONS
10"
(254 mm)
9"
(229 mm)
1/2"
(13 mm)
1/2"
(13 mm)
Chassis without
drawer inserted
Mounting
Hole 9 Places
40" (1016 mm)
3 prong
120 Vac power cord
WARMING DRAWER OVERALL DIMENSIONS
Model “A” Drawer Face Width “B” Chassis Face Width “C” Chassis Width
EWD24 24” (610mm) 23 5/8” (600mm) 22 1/4” (565mm)
EWD27
27” (686mm) 26 5/8” (676mm) 25 1/4” (641mm)
MRWD27
MWDH27
MWDV27
PWD27
EWD30
30” (762mm) 29 5/8” (752mm) 28 1/4” (718mm)
MRWD30
MWDH30
MWDV30
PWD30
EWD36 36” (914mm) 35 5/8” (905mm) 34 1/4” (870mm)
Revised
06/03/08
EWD, IWD, MRWD, MWDV, MWDH, PWD
Warming Drawers
