Nordson Select Coat User manual

Select CoatrIn-Line Oven
Customer Product Manual
Part 108 183C
NORDSON CORPORATION DAMHERST, OHIO DUSA

1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12
Nordson Corporation welcomes requests for information, comments and inquiries about its products. General
information about Nordson can be found on the Internet using the following address: http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright. Original copyright date 1991. No part of
this document may be photocopied, reproduced, or translated to another language without the prior written consent
of Nordson Corporation. The information contained in this publication is subject to change without notice.
Trademarks
Blue Box, Can Works, Century, CleanSleeve, CleanSpray, Control Coat, Cross-Cut, Easy Coat, Econo-Coat, Excel
2000, Flow Sentry, FoamMix, Horizon, Hot Shot, Isocoil, Isocore, Iso-Flo, MEG, Nordson, the Nordson logo,
Package of Values, PowderGrid, Pro-Flo, PRX, RBX, Ready Coat, Rhino, SCF, Select Coat, Select Cure, Shur-Lok,
Smart-Coat, System Sentry, Tribomatic, Versa-Coat, Versa-Screen, and Versa-Spray
are registered trademarks of Nordson Corporation.
Accu-Jet, Auto-Flo, CanNeck, Clean Coat, CPX, EasyClean, Ink-Dot, OptiMix, PowderGrid, Pulse-Spray, Sure
Coat, Swirlcoat and Walcom are trademarks of Nordson Corporation.

Table of Contents
i
E1999 Nordson Corporation
All rights reserved 108 183C
Issued 7/99 Manual 12-12
Table of Contents
1. Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Qualified Personnel 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Intended Use 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Regulations and Approvals 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Personal Safety 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Pressure Fluids 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. Fire Safety 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogenated Hydrocarbon Solvent Hazards 1-5. . . . . . . . . . . . . . . .
7. Action in the Event of a Malfunction 1-5. . . . . . . . . . . . . . . . . . . . . . . . . .
8. Disposal 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Introduction 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Oven Components and Controls 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lamps and Reflector 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Front Panel User Controls and Displays 2-2. . . . . . . . . . . . . . . . . . . . . .
Inside Panel User Control 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AC Enclosure User Controls 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Theory of Operation 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Introduction 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Exhaust 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Power Cable 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Leveling/Alignment 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 1
Safety
Section 2
Description
Section 3
Installation

Table of Contents
ii
E1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12
1. System Startup 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Initial Setup 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Width Adjustment 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Speed Adjustment 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reciprocator Speed Adjustment 4-3. . . . . . . . . . . . . . . . . . . . . . . . . .
Focal Adjustment 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stroke Adjustment 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Focus Adjustment 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Focus Adjustment 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Focus Speed Adjustment 4-9. . . . . . . . . . . . . . . . . . . . . . . .
3. System Shutdown 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Daily 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Weekly 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Monthly 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Test Point Voltages 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Every Three Months 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Every Six Months 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Introduction 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Power Supply Fault Codes 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Troubleshooting Table 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Power Supply Connections and Test Points 6-9. . . . . . . . . . . . . . . . . . .
1. Blower/Irradiator Housing Removal/Replacement 7-1. . . . . . . . . . . . . .
Removal 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 7-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Ignitor Bulb Removal/Replacement 7-3. . . . . . . . . . . . . . . . . . . . . . . . . .
3. Air Pressure Switch Removal/Replacement 7-3. . . . . . . . . . . . . . . . . . .
4. Magnetron Removal/Replacement 7-4. . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Photoresistor Removal/Replacement 7-4. . . . . . . . . . . . . . . . . . . . . . . .
6. Blower Air Filter Removal/Replacement 7-4. . . . . . . . . . . . . . . . . . . . . .
Section 4
Operation
Section 5
Maintenance
Section 6
Troubleshooting
Section 7
Repair

Table of Contents
iii
E1999 Nordson Corporation
All rights reserved 108 183C
Issued 7/99 Manual 12-12
7. RF Screen Removal/Replacement 7-5. . . . . . . . . . . . . . . . . . . . . . . . . . .
8. Lamp Bulb Removal/Replacement 7-6. . . . . . . . . . . . . . . . . . . . . . . . . . .
9. Reflector Removal/Replacement 7-7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 7-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 7-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Introduction 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Illustrated Parts List 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Oven Parts List 8-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Panel and Curing Chamber 8-2. . . . . . . . . . . . . . . . . . . . . . . . .
Focal Adjustment 8-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reciprocator 8-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UV Lamp Enclosure 8-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Supply 8-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entry/Exit Conveyor 8-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reciprocator Linkage 8-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conveyor Motor Drive 8-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AC Cabinet 8-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Service Kits 8-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. System Requirements 9-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical 9-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air 9-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor Space 9-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Schematics 9-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 8
Parts
Section 9
Specifications

Table of Contents
iv
E1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12

E1998 Nordson Corporation
All rights reserved Issued 10/98 S1EN–03–[SF–LECAP]–7
Section 1
Safety

Safety
1-0
E1998 Nordson Corporation
All rights reserved
Issued 10/98
S1EN–03–[SF–LECAP]–7

Safety
1-1
E1998 Nordson Corporation
All rights reserved Issued 10/98 S1EN–03–[SF–LECAP]–7
Section 1
Safety
Read and follow these safety instructions. Task- and equipment-specific
warnings, cautions, and instructions are included in equipment
documentation where appropriate.
Make sure all equipment documentation, including these instructions, is
accessible to persons operating or servicing equipment.
Equipment owners are responsible for making sure that Nordson
equipment is installed, operated, and serviced by qualified personnel.
Qualified personnel are those employees or contractors who are trained
to safely perform their assigned tasks. They are familiar with all relevant
safety rules and regulations and are physically capable of performing
their assigned tasks.
Use of Nordson equipment in ways other than those described in the
documentation supplied with the equipment may result in injury to
persons or damage to property.
Some examples of unintended use of equipment include
Susing incompatible materials
Smaking unauthorized modifications
Sremoving or bypassing safety guards or interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum ratings
Make sure all equipment is rated and approved for the environment in
which it is used. Any approvals obtained for Nordson equipment will be
voided if instructions for installation, operation, and service are not
followed.
1. Introduction
2. Qualified Personnel
3. Intended Use
4. Regulations and
Approvals

Safety
1-2
E1998 Nordson Corporation
All rights reserved
Issued 10/98
S1EN–03–[SF–LECAP]–7
To prevent injury follow these instructions.
SDo not operate or service equipment unless you are qualified.
SDo not operate equipment unless safety guards, doors, or covers are
intact and automatic interlocks are operating properly. Do not bypass
or disarm any safety devices.
SKeep clear of moving equipment. Before adjusting or servicing
moving equipment, shut off the power supply and wait until the
equipment comes to a complete stop. Lock out power and secure the
equipment to prevent unexpected movement.
SRelieve (bleed off) hydraulic and pneumatic pressure before adjusting
or servicing pressurized systems or components. Disconnect, lock
out, and tag switches before servicing electrical equipment.
SWhile operating manual spray guns, make sure you are grounded.
Wear electrically conductive gloves or a grounding strap connected to
the gun handle or other true earth ground. Do not wear or carry
metallic objects such as jewelry or tools.
SIf you receive even a slight electrical shock, shut down all electrical or
electrostatic equipment immediately. Do not restart the equipment
until the problem has been identified and corrected.
SObtain and read Material Safety Data Sheets (MSDS) for all materials
used. Follow the manufacturer’s instructions for safe handling and
use of materials, and use recommended personal protection devices.
SMake sure the spray area is adequately ventilated.
STo prevent injury, be aware of less-obvious dangers in the workplace
that often cannot be completely eliminated, such as hot surfaces,
sharp edges, energized electrical circuits, and moving parts that
cannot be enclosed or otherwise guarded for practical reasons.
5. Personal Safety

Safety
1-3
E1998 Nordson Corporation
All rights reserved Issued 10/98 S1EN–03–[SF–LECAP]–7
High-pressure fluids, unless they are safely contained, are extremely
hazardous. Always relieve fluid pressure before adjusting or servicing
high pressure equipment. A jet of high-pressure fluid can cut like a knife
and cause serious bodily injury, amputation, or death. Fluids penetrating
the skin can also cause toxic poisoning.
If you suffer a fluid injection injury, seek medical care immediately. If
possible, provide a copy of the MSDS for the injected fluid to the health
care provider.
The National Spray Equipment Manufacturers Association has created a
wallet card that you should carry when you are operating high-pressure
spray equipment. These cards are supplied with your equipment. The
following is the text of this card:
WARNING: Any injury caused by high pressure liquid can be
serious. If you are injured or even suspect an injury:
SGo to an emergency room immediately.
STell the doctor that you suspect an injection injury.
SShow him this card.
STell him what kind of material you were spraying.
MEDICAL ALERT–AIRLESS SPRAY WOUNDS: NOTE TO PHYSICIAN
Injection in the skin is a serious traumatic injury. It is important to treat
the injury surgically as soon as possible. Do not delay treatment to
research toxicity. Toxicity is a concern with some exotic coatings injected
directly into the bloodstream.
Consultation with a plastic surgeon or a reconstructive hand surgeon may
be advisable.
The seriousness of the wound depends on where the injury is on the
body, whether the substance hit something on its way in and deflected
causing more damage, and many other variables including skin
microflora residing in the paint or gun which are blasted into the wound.
If the injected paint contains acrylic latex and titanium dioxide that
damage the tissue’s resistance to infection, bacterial growth will flourish.
The treatment that doctors recommend for an injection injury to the hand
includes immediate decompression of the closed vascular compartments
of the hand to release the underlying tissue distended by the injected
paint, judicious wound depravement, and immediate antibiotic treatment.
High-Pressure Fluids

Safety
1-4
E1998 Nordson Corporation
All rights reserved
Issued 10/98
S1EN–03–[SF–LECAP]–7
To avoid a fire or explosion, follow these instructions.
SGround all conductive equipment in the spray area. Use only
grounded air and fluid hoses. Check equipment and workpiece
grounding devices regularly. Resistance to ground must not exceed
one megohm.
SShut down all equipment immediately if you notice static sparking or
arcing. Do not restart the equipment until the cause has been
identified and corrected.
SDo not smoke, weld, grind, or use open flames where flammable
materials are being used or stored.
SDo not heat materials to temperatures above those recommended by
the manufacturer. Make sure heat monitoring and limiting devices are
working properly.
SProvide adequate ventilation to prevent dangerous concentrations of
volatile particles or vapors. Refer to local codes or your material
MSDS for guidance.
SDo not disconnect live electrical circuits while working with flammable
materials. Shut off power at a disconnect switch first to prevent
sparking.
SKnow where emergency stop buttons, shutoff valves, and fire
extinguishers are located. If a fire starts in a spray booth,
immediately shut off the spray system and exhaust fans.
SShut off electrostatic power and ground the charging system before
adjusting, cleaning, or repairing electrostatic equipment.
SClean, maintain, test, and repair equipment according to the
instructions in your equipment documentation.
SUse only replacement parts that are designed for use with original
equipment. Contact your Nordson representative for parts
information and advice.
6. Fire Safety

Safety
1-5
E1998 Nordson Corporation
All rights reserved Issued 10/98 S1EN–03–[SF–LECAP]–7
Do not use halogenated hydrocarbon solvents in a pressurized system
that contains aluminum components. Under pressure, these solvents
can react with aluminum and explode, causing injury, death, or property
damage. Halogenated hydrocarbon solvents contain one or more of the
following elements:
Element Symbol Prefix
Fluorine F “Fluoro-”
Chlorine Cl “Chloro-”
Bromine Br “Bromo-”
Iodine I “Iodo-”
Check your material MSDS or contact your material supplier for more
information. If you must use halogenated hydrocarbon solvents, contact
your Nordson representative for information about compatible Nordson
components.
If a system or any equipment in a system malfunctions, shut off the
system immediately and perform the following steps:
SDisconnect and lock out system electrical power. Close hydraulic and
pneumatic shutoff valves and relieve pressures.
SIdentify the reason for the malfunction and correct it before restarting
the system.
Dispose of equipment and materials used in operation and servicing
according to local codes.
Halogenated Hydrocarbon
Solvent Hazards
7. Action in the Event of a
Malfunction
8. Disposal

Safety
1-6
E1998 Nordson Corporation
All rights reserved
Issued 10/98
S1EN–03–[SF–LECAP]–7

E1999 Nordson Corporation
All rights reserved 108 183C
Issued 7/99 Manual 12-12
Section 2
Description

Description
2-0
E1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12

Description
2-1
E1999 Nordson Corporation
All rights reserved 108 183C
Issued 7/99 Manual 12-12
Section 2
Description
The Select Coat ultraviolet (UV) in-line oven cures ultraviolet
light-sensitive coating material using ultraviolet light. The oven is part of
the Select Coat in-line system.
See Figure 2-1 for a typical Select Coat ultraviolet in-line oven.
1212001A
1
2
3
4
6
5
Fig. 2-1 Typical Select Coat In-Line UV Oven
1. Control panel
2. Access door 3. Exit conveyor 4. Power supply location 5. AC enclosure 6. Entry conveyor
1. Introduction
2. Oven Components and
Controls

Description
2-2
E1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12
See Figure 2-2. The lamp module contains a 15-cm- (6-in.-) long bulb(1)
mounted at the focus of an elliptical reflector (2), and the magnetron
which energizes an ignitor bulb. The lamp/reflector assembly produces
an intense strip of light at the opposite focus of the reflector.
1212002A
1
2
Fig. 2-2 Lamp and Reflector
1.Bulb 2.Reflector
See Figure 2-3. Four user controls and displays are located on the front
panel:
SA manual override keyswitch (5) which allows qualified users to
bypass door interlock circuits. The oven can be powered up in the
manual override mode by pressing and holding the reset button for
three seconds
NOTE: The UV lamps will not light in the manual override mode.
SA remote reset switch (4) which resets the lamps when a system
interlock failure shuts down the system
Lamps and Reflector
3. Front Panel User
Controls and Displays

Description
2-3
E1999 Nordson Corporation
All rights reserved 108 183C
Issued 7/99 Manual 12-12
SA conveyor speed display (3)
SAn emergency stop (2) (E-stop) which allows the operator to turn off
all power to the oven and system in an emergency situation
See Figure 2-3. The inside panel contains a power focus switch (1)
which adjusts focal adjustment up or down for optimum curing.
A conveyor width adjustment handle (not shown) is located just inside the
front panel, near the lightshields.
1212003A
5
4
3
2
1
Fig. 2-3 Front and Inside Panel Controls and Displays
1. Power focus
2. Emergency stop
3. Conveyor speed indicator
4. Remote reset
5. Manual override keyswitch
Inside Panel User Control

Description
2-4
E1999 Nordson Corporation
All rights reserved
108 183C
Issued 7/99
Manual 12-12
See Figure 2-4. The following user controls are located in the ac
enclosure:
SPower focus speed adjustment knob (1)
SConveyor speed adjustment knob (2)
SReciprocator speed adjustment knob (3)
1212004A
1
2
3
Fig. 2-4 AC Enclosure User Controls
1. Power focus
2. Conveyor speed 3. Reciprocator speed
When the Select Coat System is powered up, power is supplied to the
UV oven through a relay in the Select Coat System workcell. The UV
oven powers up and checks all system interlocks. After reaching full
power and verifying that all system interlocks are operating properly, the
oven sends the system a NO OVEN FAULT signal and a LAMP ON
signal.
AC Enclosure User Controls
4. Theory of Operation
