Norelco Norelco T760 User manual

Beard and
Moustache
Trimmer
with
ACU•CONTROL
SYSTEM
SP
T760
Rechargeable
Cordless

IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic safety precautions should
always be followed,including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for aTrimmer that has fallen into water. Unplug
immediately.
2. Do not use while bathing or in a shower.
3. Do not place or storeTrimmer where it can fall or be pulled
into a tub or sink.Do not place in or drop into water or other
liquid.
4. Always unplug thisTrimmer from the electrical outlet
immediately after using,except whenTrimmer is (re)charging.
5. UnplugTrimmer before cleaning.
6. When discardingTrimmer,unplugTrimmer to remove
rechargeable battery.See Battery Removal instruction sheet.
WARNING
To reduce the risk of burns,fire, electic shock, or injury to
persons:
1. Close supervision is necessary when this appliance is used by,
on,or near children or invalids.
2. Use thisTrimmer for its intended household use as described in
this manual.Do not use attachments not recommended by
ENGLISH

ENGLISH
Philips Electronics NorthAmerica Corporation.
3. Never operate thisTrimmer if it has a damaged cord or plug,if
it is not working properly,if it has been dropped, damaged,or
dropped into water.Return theTrimmer to anAuthorized
Norelco Service Location for examination and repair.
4. Keep theTrimmer and Cord away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug inTrimmer outdoors or where aerosol
(spray) products are being used or where oxygen is being
administered.
7. Do not use thisTrimmer with a damaged or broken cutter, as
facial injury may occur.
8. Always attach plug toTrimmer first, then into outlet.To
disconnect,turn ON/OFF switch to“OFF” position (switch is
down),then remove plug from outlet.
9. To prevent possible damage to the cord,do not wrap cord
around theTrimmer.
10.Never putTrimmer in direct sunlight or store in a pouch at a
temperature above 140˚F.
11.ThisTrimmer is for use on human facial hair only. Do not use
thisTrimmer for any other purpose.
SAVETHESE
INSTRUCTIONS
IMPORTANT: YOURTRIMMER CONTAINS A NICKEL
CADMIUM RECHARGEABLE BATTERY.
See Battery Removal instruction sheet.

ENGLISH
Name
Address
City
State Zip
Telephone No.( )
REASON FOR RETURNING:
60-DAY MONEY-BACK
GUARANTEE
If you are not fully satisfied with your Norelco Beard and Moustache
Trimmer,send the product back and we’ll refund you the full purchase price.
TheTrimmer must be shipped prepaid by insured mail, insurance
prepaid,and have the sales receipt,indicating purchase price and
the date of purchase, enclosed.TheTrimmer must be postmarked no
later than 60 days after the date of purchase. Norelco reserves the
right to verify the purchase price of theTrimmer and limit refunds
not to exceed suggested retail price.
Send dated sales receipt,your complete name and address as indicated
below, and theTrimmer,prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics
North America Corporation
450 North Medinah Road, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check.(Please Print)
AREA CODE

Table of Contents
Features........................................................2–3
To Charge / Recharge...............................4–5
CordlessTrimming.........................................5
Put ItToTheTest.............................................6
Acu•Control System......................................6
Trimming...........................................................7
TrimmingWithAcu•Control
Guide Comb....................................................7
Trimming For "Stubble" Look......................8
TrimmingWithoutAcu•Control
Guide Comb....................................................9
Replacing Guide Comb
Attachment OnTrimmer...........................10
Cleaning ...................................................11-12
ReplacingThe
Cutting Unit ..................................................12
Assistance.......................................................13
Battery Removal...........................................13
Spanish Instructions.....................................14
Warranty.......................................Back Cover
1
ENGLISH

Features
A. UniqueAcu•Control System with
Removable Guide CombAttachment
B. Selected Hair Length SettingWindow
C. Unique,Patented Zoom Ring
with 9 Pre-select Settings:
.06,.1,.16,.22,.3,.38,.48,.6,.72 in./
1.5,2.5,4,5.5,7.5,9.5,12,15,18mm
D. 3-Dimensional Rounded Chromium
Steel Cutter Blades
E. On/Off Switch
F. Charging Indicator Light onAdaptor
G. Cleaning Brush
H. FullTwo-YearWarranty
I. 60-Day Money-Back Guarantee
2ENGLISH

T760
A
D
C
E
B
G
3
ENGLISH

To Charge / Recharge
◗(Re)charging requires 10 hours.
◗Use only the cord provided.
◗Battery performance is best if you recharge
only when the battery is (almost) completely
empty.
◗Charging or recharging at temperatures below
40°F or higher than 95°F adversely affects
lifetime of battery.
◗Continuously recharging will reduce life of
battery.
CBe certainTrimmer is OFF.
CConnect cord toTrimmer. Plug into any
120VAC outlet. Use only the
cord provided.
Do not chargeTrimmer in a pouch or
for more than 24 hours.
CGreen Charging Indicator Light on the
adaptor will go on to indicate theTrimmer
is charging.It will take approximately
10 hours to fully charge the battery.
Disconnect the cord and unplug from
electrical outlet.
4
3
2
1
4ENGLISH
CHARGE

Optimize the working life
of the battery
◗AfterTrimmer has been charged for the first
time,do not rechargeTrimmer between
trimming sessions. Continue using it until the
battery is completely empty.
◗Discharge the battery completely twice a
year by letting the motor run until it stops.
◗Do not charge for more than 24 hours.
◗Do not keep cord permanently plugged in.
◗If Trimmer hasn’t been used for a long period of
time,Trimmer must be recharged for 10 hours.
CordlessTrimming
Charge according to directions. Unplug
Trimmer from outlet.
Slide ON/OFF switch ON to begin
trimming.
If the battery is empty and you want to
trim your beard,charge theTrimmer for at
least 1.5 hours and you will have enough
power for one use.
3
2
1
5
ENGLISH

Put ItToTheTest
Like many new products,your NorelcoTrimmer
may take a little getting used to. If you are using
an electricTrimmer for the first time,or if you’ve
been using a different brand,take the time to
acquaint yourself with your newTrimmer.
YourTrimmer features the unique
ACU•CONTROL SYSTEM combined with
an adjustable Zoom Ring to make trimming
facial hairs goof proof.
Throw your scissors away and put your new
Trimmer to the test.We guarantee precise,
professional results or Norelco will refund you
the full purchase price, guaranteed!
Acu•Control System
The unique Norelco ACU•CONTROL SYSTEM
puts you in complete control while trimming
your facial hairs with no prior experience
needed. The flexing Guide Comb adjusts
automatically to hug the contours of your face
for a trim that is both even and accurate.And, it’s
easy to maneuver over those hard-to-reach areas
such as the throat and chin.The patented Zoom
Ring Hair Length Selector allows you to choose
among 9 preset hair lengths and locks into
position so you can control the exact hair length
you desire or vary the length of your facial hair.
The Norelco ACU•CONTROL SYSTEM with
Patented Zoom Ring Hair Length Selector for
professional,goof-proof results every time or
your money back.
6ENGLISH

7
ENGLISH
Trimming
◗Use thisTrimmer for its intended household
use as described in this manual.
◗ Always comb the beard and/or moustache with
a fine comb before you start trimming.
If you are trimming for the first time,be careful.
Do not move theTrimmer too fast. Make
smooth and gentle movements.
Trimming withACU•CONTROL
Guide CombAttachment
◗Guide Comb Attachment must be onTrimmer
in order to use Zoom Ring.
CTurn the Zoom Ring to the desired
trimming length setting (see table).The
setting will appear in the window below
the Zoom Ring.
◗If you are trimming for the first time,start by
using the maximum trimming length setting #9
to prevent accidentally trimming hairs too
short.As you become familiar with the settings,
adjust Zoom Ring to desired trimming length.
Zoom Ring will“click” into position at each
setting.
Switch theTrimmer ON.
CTo trim in the most effective way,move
theTrimmer against the direction of hair
growth.Make sure the surface of the
Guide Comb always stays in contact
with the skin.
3
2
1
99

NOTE: Since all hairs do not grow in the same
direction,you may want to try different trimming
positions (i.e.,upwards,downwards,or across).
Practice is best for optimum results.
CIf a lot of hair has accumulated in the Guide
Comb,remove the CombAttachment and
blow and/or shake the hair out of the comb.
The selected trimming length setting will
not change when you do this.
Trimming Length SettingsTable
Trimming For“Stubble” Look
CBe certain Guide Comb is onTrimmer and
use setting #1 to result in a“stubble”look.
1
4
8ENGLISH
#1 Stubble Length or Closely Cropped .06 in./1.5 mm
#2 Short .1 in./2.5 mm
#3 .16 in./4 mm
#4 .22 in./5.5 mm
#5 Medium .3 in./7.5 mm
#6 .38 in./9.5 mm
#7 .48 in./12 mm
#8 .6 in./15 mm
#9 Long .72 in./18 mm
1

9
ENGLISH
TrimmingWithout Guide Comb
Attachment
Remove Guide Comb Attachment if you are:
◗Defining hair lines
◗Trimming nape of neck
◗Removing single,unwanted hairs
Be certainTrimmer is in the OFF position.
CRemove the Guide CombAttachment by
pulling it off theTrimmer.
Never pull off the Guide CombAttachment by
grasping the flexible top portion.Always pull off
by the bottom part of attachment.
Switch theTrimmer on.
CMake well-controlled movements. Touch
the hair lightly with theTrimmer.
4
3
2
1

10 ENGLISH
Replacing Guide CombAttachment
OnTrimmer
Be certainTrimmer is in OFF position.
Replace Guide CombAttachment until it
“clicks”into position.The Guide Comb
Attachment can be placed onTrimmer only
one way. If it does not fit properly,reverse it.
NOTE: The Zoom Ring can be on any setting
when removing or replacingAttachment.
2
1

11
ENGLISH
Cleaning
◗ Always switchTrimmer OFF before cleaning.
◗ Do not use abrasives,scourers or liquids such
as alcohol,benzene, bleach or acetone to clean
theTrimmer.
◗ Never clean,remove or replace Guide Comb
Attachment with motor ON.
◗ Do not apply pressure to cutters.
◗ Do not touch cutters with hard objects as this
may damage them.
◗ Do not use while bathing,showering or
immerse theTrimmer in water or other liquids
as damage toTrimmer may occur.
During Use:
◗ If cut hairs have accumulated in the Guide Comb
area,turnTrimmer off,pull Guide Comb
Attachment offTrimmer and remove hairs by
shaking and/or blowing.
OnceAWeek:
Make sure theTrimmer is switched OFF
and disconnected from the electrical
outlet.
Remove the Guide CombAttachment.
COpen the cutting unit.
3
2
1

CClean the cutting unit and the inside of the
Trimmer with the brush supplied.
CClose the cutting unit by pushing it back
into place on theTrimmer until you hear
a click.
ReplacingThe Cutting Unit
If your cutters become damaged or worn,
do not continue using theTrimmer.
Replace cutters immediately.
Open the cutting unit.
CRemove the old cutting unit by pulling
it upwards.
CPlace the two notches of the new cutting
unit into the guiding slots.
Push the cutting unit back onto the
Trimmer until you hear a click.
ThisTrimmer has no otherr user-serviceable
parts. Any other service should be performed
by anAuthorized Norelco Service Location.
4
3
2
1
5
4
12 ENGLISH

13
ENGLISH
Assistance
For assistance or the Authorized Norelco Service
Location nearest you,call toll free:
1-800-243-3050
or visit our website:www.norelco.com
Authorized Norelco Service Location
information is available 24 hours a day,
7 days a week.
Battery Removal
◗ This NorelcoTrimmer contains rechargeable
Nickel-Cadmium batteries, which must be
disposed of properly.
◗ Batteries should only be removed when
Trimmer is to be discarded.
◗ Refer to Battery Removal instruction sheet for
directions on removing the rechargeable
batteries.

INSTRUCCIONES
DE SEGURIDAD
IMPORTANTES
Siempre que utilice un aparato eléctrico usted debe respetar ciertas
precauciones básicas,incluyendo las indicadas a continuación:
Lea todas las instrucciones antes de utilizar este aparato.
PELIGRO
Para reducir el riesgo de descarga eléctrica:
1. No intente recuperar una afeitadora que se haya caído al agua.
Desenchúfela inmediatamente.
2. No la utilice mientras se baña o se ducha.
3. No coloque ni guarde la máquina en un sitio donde pueda caerse
o ser empujada a una bañera o un lavabo.
No la coloque ni deje que se caiga al agua u otro líquido.
4. Siempre desenchufe la máquina inmediatamente después de
utilizarla,excepto cuando se estárecargando.
5. Desenchufe la máquina antes de limpiarla.
6. Cuando deseche la máquina,desenchúfela para quitarle
la batería recargable.CONSULTE LA HOJA DE
INSTRUCCIONES SOBRE RETIRO DE LA BATERÍA.
ADVERTENCIA
Para reducir el riesgo de quemaduras,incendio o lesiones a
las personas:
1. Es necesario un estrecho control cuando esta máquina es
utilizada,por o en,personas discapacitadas,o cerca de ellas.
2. Utilice esta máquina para el uso doméstico previsto,tal como se
describe en este manual.No utilice accesorios no
recomendados por Philips Electronics NorthAmerica
Corporation.
ESPAÑOL

ESPAÑOL
3. No utilice nunca esta afeitadora si el cordón o el enchufe están
dañados,si no funciona correctamente,si ha sufrido una caída o
se ha dañado o si se ha caído al agua.Lleve la afeitadora a un
centro de servicio autorizado de Norelco para que sea
examinada y reparada.
4. Mantenga la máquina y el cordón alejados de las superficies
calientes.
5. Nunca deje caer ni inserte objeto alguno en ninguna de las
aberturas.
6. No cargue ni enchufe la máquina mientras estáal aire libre,ni
donde se estén utilizando productos en aerosol (pulverizadores)
o donde se estéadministrando oxígeno.
7. No utilice esta máquina con una cuchilla dañada o rota ya que
puede provocar lesiones faciales.
8. Ponga siempre el cordón en el enchufe de la máquina primero y
luego en la toma de corriente.Para desconectarla,deslice el
botón de encendido y apagado a la posición de apagado OFF (el
botón estaráhacia abajo),luego desconecte el enchufe del
tomacorriente.
9. Para evitar posibles daños al cordón,no lo enrolle alrededor de
la máquina.
10.Nunca exponga la máquina a la luz directa del sol ni la guarde en
una bolsa a temperaturas superiores a 140ºF (60°C).
11. Esta máquina es para vello facial humano únicamente.No utilice
esta afeitadora para ningún otro propósito.
GUARDE ESTAS
INSTRUCCIONES
IMPORTANTE: SU MÁQUINA CONTIENE UNA
BATERÍA DE NICKEL CADMIO RECARGABLE.
Consulte las instrucciones de retiro de las baterías.

GARANTÍA DE DEVOLUCIÓN
DEL IMPORTE DE 60 DÍAS
Si usted no estáplenamente satisfecho con la afeitadora para barba y big-
ote de Norelco, devuelva el producto y le reembolsaremos el precio total
de compra.
La máquina debe enviarse por correo franqueado y asegurado, con el
seguro pagado, el recibo de compra incluido, con indicación del pre-
cio y la fecha de compra. El matasellos no debe ser posterior a 60
días de la fecha de compra. Norelco se reserva el derecho de verificar
el precio de compra del producto y limitar los reembolsos de manera
que no excedan el precio de venta sugerido.
Envíe el recibo de compra fechado, su nombre completo y dirección como
se indica más abajo, y el producto franqueado a:
Norelco Consumer Products Company
A Division of Philips Electronics
North America Corporation
450 North Medinah Road, Dock 16
Roselle, IL 60172-2329
El envío del cheque se demora de 4 a 6 semanas.
(Escriba sus datos en letra de imprenta).
Nombre
Dirección
Ciudad
Estado Código postal
Número de teléfono
.( )
MOTIVO DE LA DEVOLUCIÓN:
CÓDIGO DEL ÁREA
