Norelco HP6328/82 User manual

4203 000 52921
1 2
3 4
56
78
OIL
9
Body Select
Wet/Dry
rechargeable razor
HP6328
ENGLISH
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric appliance, basic precautions
should always be followed, including the following.
Read these instructions for use carefully
before using the appliance and save them for
future reference.
DANGER
To reduce the risk of electric shock:
◗Never use an extension cord with this
appliance.Always plug the charging base
directly into the outlet.
◗Do not plug in the charging base while bathing
or taking a shower.
◗Do not place or store the charging base where
it can fall or be pulled into a bathtub or sink.
◗Do not place or drop the charging base in
water or any other liquid.
◗Always unplug the appliance immediately after
use, except when you are charging the
appliance.
◗Unplug the appliance from the charging base
before cleaning.
◗When discarding the appliance, remove it from
the charging base and make sure the appliance
is in the Off ("O") position.Then remove the
rechargeable battery.
WARNING
To reduce the risk of burns, fire, electric
shock, or injury to persons:
◗Close supervision is necessary when this
product is used by, on, or near children or
invalids.
◗This appliance is intended for household use
only, as described in this manual.
◗Only use attachments that are recommended
by Philips Electronics North America
Corporation.
◗Never use the appliance/charging base if the
plug is damaged, if the appliance/charging base
is not working properly, if the appliance/charging
base has been dropped and appears to be
damaged, or if the appliance/charging base has
been dropped into water.Always return the
appliance/charging base to an authorized
Norelco Service Location for examination and
repair.
◗Never drop or insert any objects into any
opening of the appliance.
◗Do not charge or operate the appliance
outdoors, in places where aerosol (spray)
products are being used or where oxygen is
being administered.
◗Always check the foil before using the
appliance. Do not use the appliance if the
foil of the trimmer is damaged, as injury
may occur.
◗Never store the appliance in direct sunlight in
the pouch or at temperatures above 140ºF.
◗The appliance is water-resistant and can be
used in the bathtub or shower. Do not
submerge the appliance in water for an
extended period of time.
SAVE THESE
INSTRUCTIONS
IMPORTANT
This appliance contains a RECHARGEABLE NICKEL-
CADMIUM BATTERY. See Battery Removal
Instruction Sheet.
PUT IT TO THE TEST & SHAVING TIPS
Like many new products, your Norelco Ladyshave
Razor may take a little getting used to. If you are
using a rechargeable Razor for the first time, or if
you've been using a different brand, your skin may
need time to adapt to the Body Select Shaving
System. Give yourself a little time to practice and
determine the best stroking motions for the best
shave.
Use it exclusively for 3 weeks, or a bit longer
for sensitive skin. If you alternate shaving or
other hair removal methods during this
adjustment period, it may become more
difficult to adapt to the Norelco shaving
system.
Since your Ladyshave Razor features the Body Select
Shaving System, you'll be able to customize hair
removal for the area you are shaving. However, at
first you may not get as close a shave as you expect,
or your skin may become slightly irritated.This is
normal as your skin adjusts. After this adjustment
period, you'll find that you can remove hair without
irritating your skin, for a close, smooth shave.
The Norelco Ladyshave Razor, with Body Select
Shaving System.....the choice for close, smooth
shaving results. If you're not convinced after 21 days,
Norelco will refund you the full purchase price,
guaranteed.
BEFORE USINGYOUR NEW NORELCO RAZOR
BThis appliance is intended for household use only, as
described in this manual.
BBefore using, check foil for wear or damage. If the
60-Day Money-Back Guarantee
If you are not fully satisfied with your Norelco Ladyshave
Razor, Norelco will refund you the full purchase price. The
razor must be shipped prepaid by insured mail, insur-
ance prepaid, have the sales slip indicating purchase
price and date of purchase enclosed. The razor must be
postmarked no later than 60 days after the date of purchase.
Norelco reserves the right to verify the purchase price of
the razor and limit refunds not to exceed suggested retail
price.
Send dated sales receipt, your complete name and address as
indicated below, and the razor, prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
450 North Medinah Road, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_______________________________________________________
Address_____________________________________________________
City________________________________________________________
State_________________Zip___________________________________
Day timeTelephone No.(______)_______________________________
E-mail Address________________________________________________
REASON FOR RETURNING:
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________

foil shows signs of wear or damage, do not use the
Razor as injury may occur. Do not use it until the
foil has been replaced.
BFor wet shaving, you may wish to prepare your skin
with soap or shaving cream before shaving.
BFor dry shaving, be certain that your skin is clean. If
you have sensitive skin, you may wish to apply
talcum powder before and/or after shaving.
BWhen shaving your legs, underarms, or bikini line, it
is not necessary to press hard to get a close shave.
Pressing too hard may cause skin irritation, and the
Razor will not function properly. In addition, do not
use deodorant or alcohol-based lotions immediately
before or after shaving.You may, however, want to
use talcum powder.
BClean the Razor regularly, for instructions see
chapter 'Cleaning'.
BOnly the Razor, not the charging base, can be
submerged in water; however, do not submerge the
Razor for extended periods of time.
BYou may wish to store the Razor with the charging
base connected to the outlet, so that the Razor is
kept fully charged. However, remember to allow the
battery to totally deplete charge every 4 weeks
(see chapter TO CHARGE/RECHARGE).
BODY SELECT SHAVING SYSTEM
Your new Ladyshave Razor features the Body Select
Shaving System. Each section of the shaving foil was
specifically designed to meet your personal shaving
needs, so you can choose the best selection of the
foil for the area you are shaving.
1Simply slide the Body Select switch on the side
of the Razor head to the appropriate position
for the body area you wish to shave.
◗Slide the switch up for shaving underarms.
(fig. 1)
◗Slide the switch to the middle position for
shaving bikini line or sensitive areas. (fig. 2)
◗Slide the switch down for shaving legs. (fig. 3)
TO CHARGE/RECHARGE
◗Charging and recharging your Razor requires a
full 16 hours.
◗Charge the Razor only with the charging base
provided.
◗Be certain hands and Razor are dry before
charging.
◗Recharge at temperatures between 40ºF and
90ºF. Charging at lower or higher temperatures
adversely affects the lifetime of the battery.
◗Do not charge the Razor in the pouch.
1Be certain the Razor is in the Off position.
2Put the Razor onto the charging unit.. The pilot
light goes on to indicate that the battery is being
charged(fig. 4)
3Plug the charging base into any 120V AC outlet.
Use only the charging base provided.
◗An adaptor plug and converter may be necessary
for the use of the charging base plug in some for-
eign countries. Use an attachment plug adaptor of
the proper configuration for the power outlet.
4Charging requires 16 hours.This Razor model,
HP6328, is for cordless shaving only.
5Razor may be continuously charged with
charging base connected to electrical outlet for
a maximum of 4 weeks.At the end of 4 weeks,
you must allow the battery to totally deplete
charge before recharging.
- To deplete charge, shave in usual manner;
however, do not recharge Razor between shaves.
Continue to use Razor until battery is totally
depleted.
6You may then keep Razor continuously
charging for another 4-week period before you
must once again allow Razor to totally deplete
charge.
IMPORTANT:
Before connecting Razor to charging base, be cer-
tain Razor is in Off (“O”) position.While Razor is
charging, the recharge light will light with Razor in
either the On or Off position, however, your Razor
will only recharge if Razor is turned off.
SHAVING LEGS
1Prepare legs for wet or dry shaving (see
BEFORE USINGYOUR NEW
NORELCO RAZOR).
2To shave legs, slide the Body Select Switch
down to the position for the silver foil area.
(fig. 5)
3Turn the Razor on. (fig. 6)
4Hold the Razor so that Shaving Head is in full
contact with your skin. Shave with smooth,
steady strokes, against the direction of hair
growth.
- Pressing too hard may cause skin irritation.
- Practice is best for optimum results.
- Make sure both trimmers and shaving foil are in
complete contact with skin.
5Turn the Razor Off.
SHAVING UNDERARMS
1Prepare underarms for wet or dry shaving (see
BEFORE USINGYOUR NEW
NORELCO RAZOR).
2To shave underarms slide Body Select Switch
up to the position for the golden foil area.
(fig. 1)
3Turn Razor on.
4Lift your arm until skin under arm stretches
slightly.
5Hold Razor so that Shaving Head is in full
contact with the skin. Shave with gentle
strokes, using light pressure.
BPressing too hard may cause skin irritation, and
Razor will not function properly.
6Do not use deodorant or alcohol-based lotions
immediately before or after shaving.You may,
however, want to use talcum powder.
7Turn Razor Off.
SHAVING BIKINI LINE
1Prepare bikini line or other sensitive areas for
wet or dry shaving (see BEFORE USING
YOUR NEW NORELCO RAZOR).
2To shave bikini line or other sensitive areas,
slide Body Select Switch to the position for the
golden striped foil area. (fig. 2)
3Turn Razor on.
4Stretch skin taut with your fingers.
5Hold Razor so that shaving head is in full
contact with the skin and shave using gentle
strokes.
6Turn razor off.
CLEANING
◗Regular cleaning guarantees better shaving
results.
◗It is recommended that you replace your
shaving foil once a year.
◗Always switch Razor Off and remove Charging
base from outlet before cleaning.
◗Never clean, remove, or replace Shaving Head
while motor is on.
◗Do not apply pressure or touch Shaving Head
with hard objects as this may dent or damage
foil or trimmers. If damage occurs, replace foil.
BCheck foil regularly.
BNever use a razor with a damaged or broken foil.
AFTER EACH USE
After each use, Razor should be quickly cleaned by
rinsing under running water or dipping and shaking
gently in water.
IMPORTANT: DO NOT keep Razor submerged
in water for a long period of time.
ONCE A MONTH - CLEANING SHAVING
HEAD
IMPORTANT: DO NOT apply pressure to
Shaving Foil.
1Remove the Shaving Head (fig. 7)
BHold Shaving Head by plastic housing only -
Shaving Foil is very delicate and should not be
handled. If foil becomes worn or damaged, replace it.
2Hairs can be removed from Shaving Head
housing and cutter block by using a soft brush
or by lightly blowing out hairs. Be sure you
also brush hairs away from under the trimmers.
(fig. 8)
BNOTE: Avoid using brush on Shaving Foil, as this
may cause damage.
◗Body of Razor and Shaving Head, including
Shaving Foil, may also be rinsed under running
water to remove hairs.
◗Do not use or clean razor with water hotter
than shower temperature.
3Be sure all parts are dry before reassembling.
BDo not use cloth or towel to dry Shaving Foil or
cutter block; allow to air dry.
4Replace Shaving Head by gently pressing back
into position on Razor body.
- Hold Razor Head by plastic housing only.
- Always replace Protective Cap on shaving head
to prevent damage to foil.
BNOTE: Use cold or lukewarm water. Never use
cleaners such as alcohol, nail polish remover,
corrosive detergents or scouring pads.
◗For best shaving performance, it is suggested to
lightly oil Shaving Head twice a year by
spreading a drop of mineral oil over the foil
and trimmers. (fig. 9)
If this does not improve the performance of your
razor, it may be time to replace the foil.
◗Never immerse Charging base in water or
other liquid.You may clean by wiping with a
damp cloth.
◗This razor has no other user-serviceable parts.
Any other service should be performed by an
Authorized Norelco Service Location.
ASSISTANCE
BFor assistance or the Authorized Norelco Service
Location nearest you, call toll free:
1-800-243-3050 or visit our Norelco website:
www.norelco.com
BAuthorized Norelco Service Location information is
available 24 hours a day, 7 days a week.
BATTERY REMOVAL
THIS NORELCO RAZOR CONTAINS A
NICKEL-CADMIUM RECHARGEABLE
BATTERY WHICH MUST BE DISPOSED
OF PROPERLY.
◗Battery should only be removed when
razor is to be discarded.
◗Refer to Battery Removal instruction sheet for
directions on removing the rechargeable
battery.
ACCESSORIES
For maximum performance, replace your Norelco
Ladyshave foil and cutter block once a year
- Model HP6120 Philips replacement foil
- Model HP2909 Philips cutter block
Razor accessories may be purchased at a store near
you, an authorized Norelco Service Location on our
website www.norelco.com or by using the handy
order form enclosed.
FULL TWO-YEAR WARRANTY
Philips Electronics North America Corporation warrants each new Norelco
Product, Model HP6328 (except foil and trimmers), against defects in materials
or workmanship for a period of two years from the date of purchase, and
agrees to repair or replace any defective product without charge.
IMPORTANT:This warranty does not cover damage resulting from accident,
misuse or abuse, lack of reasonable care, the affixing of any attachment not
provided with the product or loss of parts or subjecting the product to any but
the specified voltage.* Use of unauthorized replacement parts will void this
warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION
WILL NOT PAY FOR WARRANTY SERVICE PERFORMED BY A
NON-AUTHORIZED REPAIR SERVICE AND WILL NOT
REIMBURSETHE CONSUMER FOR DAMAGE RESULTING
FROM WARRANTY SERVICE PERFORMED BY A NON-
AUTHORIZED REPAIR SERVICE. NO RESPONSIBILITY IS
ASSUMED FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
In order to obtain warranty ser vice, simply take or ship the product postage
prepaid to the nearest Authorized Norelco Service Location. It is suggested
that for your protection you return shipments of product by insured mail,
insurance prepaid. Damage occurring during shipment is not covered by this
warranty.
NOTE: No other warranty, written or oral, is authorized by Philips Electronics
North America Corporation.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above exclusion and
limitations may not apply to you.
*Read enclosed instructions carefully.
Manufactured for:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd., Stamford, CT 06912-0015
RAZOR MADE IN AUSTRIA.
CHARGING BASE MADE IN CHINA.
Ladyshave & Design and Norelco are RegisteredTrademarks of Philips
Electronics North America Corporation.
Ladyshave and Body Select are RegisteredTrademarks of Koninklijke Philips
Electronics N.V.
PHILIPS and Philips Shield are Registered Trademarks of Koninklijke Philips
Electronics N.V.
z2003 Philips Electronics North America Corporation. All Rights Reserved.
This symbol on the product’s nameplate means it is
listed by Underwriters’ Laboratories, Inc.
®
LISTED
