Nortek Security & Control Gocontrol GC-TBZ48L Original operating instructions

MODE
FAN 74
Off
Auto
F
Model GC-TBZ48L
Battery Powered Z-Wave Plus
Thermostat
Installation & Operation Guide
PRINTER’S INSTRUCTIONS: INSTR,INSTL,GC-Z-TBZ48L - P/N: 10006936 C- INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 8.500” X 5.500” - TOL. +/- 0.125”- SCALE: 1-1
FOLDING: ALBUM FOLD: BINDING: SADDLE STITCH
NOTE: To take full advantage of this device's Z-Wave control capability you must purchase a compable
Z-Wave hub/controller. Remote control capability is provided via the hub/controller's remote control
app/soware.

Table of Contents
Typical Wiring for Standard Gas/Electric HVAC System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Typical Wiring for Heat Pump HVAC System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Thermostat Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
The C Wire. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
24VAC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Baery Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Z-Wave Operaon when Baery Powered. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Remove Exisng Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Wiring Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Install the Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Standard HVAC System Connecons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Single and Dual Transformer Systems (Split Systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Single Transformer System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Dual Transformer Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Heat Pump HVAC System Connecons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Mount the Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Baery Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Thermostat Setup Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Preset HVAC System sengs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Wait Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Minimum Run Time (MRT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Entering Menu Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Menu Mode Navigaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
System Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
System Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Fan Type (For Standard HVAC systems only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Changeover Type (For Heat Pump HVAC Systems Only) . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Z-Wave Plus Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Inclusion and Exclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Advanced Z-Wave® Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Support for Associaon Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Clock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Seng the Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
INFO Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Advanced System Sengs Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Thermostat Operaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Main Thermostat Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Backlight and Buon Operaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Staging Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Seng the System Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
System Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Special Heat Pump Mode: Emergency Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Seng the Heang or Cooling Temperature Setpoint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Automac Setpoint Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Seng the Fan Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Fan Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
User Customizaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
User preference sengs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Clock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Seng the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
INFO Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Z-Wave Configuraon Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Specificaons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Regulatory Informaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Industry Canada Noces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
What is Covered? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
How do I Obtain Warranty Service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Limitaons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Copyright ©2017 Nortek Security & Control LLC 1
GC-TBZ48L
BATTERY POWERED Z-WAVE PLUS THERMOSTAT
INSTALLATION INSTRUCTIONS
The Z-Wave Plus Thermostat (GC-TBZ48L) is a programmable, Z-Wave communicang
thermostat. It can be powered using 24VAC (if both “R”&”C”wires are available at the
thermostat), or using four (4) AA baeries. Using Z-Wave technology, end users have the ability
to use most compable Z-Wave hubs/controllers to operate and animate the thermostat,
configure programming sengs, as well as to display current condions in the home or office.
Figure 1. Z-Wave Thermostat Front View
MODE
FAN
Y
BATTERIES (4) PHILLIPS
SCREWS (2)
ANCHORS (2)
ADHESIVE WIRING LABELS SHEET
GC-TBZ48L THERMOSTAT
Features Include:
• A fixed format display with white backlight
• Heang and cooling setup display opons
• System mode (OFF, Heat, Cool, Auto,
E-Heat)
• Fan mode control and display (Auto, ON)
• Changeover type for Heat Pump (HP)
systems
• On-screen setup of HVAC type, Fan type
• F/C mode, and sensor calibraon
Compatible with 24 VAC gas, oil, or electric heating
and air conditioning systems; or gas millivolt heating
systems
DO NOT USE ON 120VAC SYSTEMS!
Standard Systems
• 1 Stage Heang and Cooling
• 2 Stage Heang and Cooling
Heat Pump Systems
• 1 Stage Heang and Cooling
• 2 Stage Heang and Cooling
• 2nd or 3rd Stage Aux Heang (Electric Heat
Strips
Box Contents
• 1─Z-Wave PlusThermostat
• 1─Sheet Adhesive Wiring Labels
• 2─Plasc Wall Anchors
• 4─AA Baeries
Installation Outline
• Step 1 Remove Exisng Thermostat
• Step 2 Install GC-TBZ48L Thermostat
• Step 3 Setup Thermostat to match System
Type
• Step 4 Install into Z-Wave Network

2Copyright ©2017 Nortek Security & Control
Typical Wiring for Standard Gas/Electric HVAC System
THERMOSTAT CONNECTION
C 24VAC COMMON
R 24VAC RETURN
W1 HEAT STAGE 1
W2 HEAT STAGE 2
G FAN
Y1 COMPRESSOR STAGE 1
Y2 COMPRESSOR STAGE 2
TYPICAL THERMOSTAT WIRING COLORS.
CAUTION: VERIFY THAT ORIGINAL WIRING
MATCHES. COLORS MAY BE DIFFERENT
STANDARD HVAC SYSTEM
BLUE
RED
WHITE
ORANGE
GREEN
YELLOW
BLACK/BROWN
THERMOSTAT BACK PANEL
INTERNAL RC=RH JUMPER
CWIRE IS NOT REQUIRED
FOR BATTERY OPERATION
CWIRE IS REQUIRED FOR
24VAC OPERATION
DEFAULT THERMOSTAT SETUP:
TYPE: STANDARD HVAC
FAN: GAS HEAT
1 STAGE HEATING
1 STAGE COOLING
NO SETUP CHANGE REQUIRED
FOR THIS CONFIGURATION
Y2 Y1 G RC CRH W1 W2
FOR SINGLE
TRANSFORMER SYSTEMS
CONNECT RWIRE TO
EITHER RC OR RH
TERMINAL
FOR SYSTEMS WITH SEPARATE
HEATING AND COOLING
TRANSFORMERS, CONNECT
HEATING RTO RH AND COOLING
RTO RC. NOTE! THE RC-RH
JUMPER MUST BE CUT
ON THE THERMOSTAT BOARD.

Copyright ©2017 Nortek Security & Control LLC 3
Typical Wiring for Heat Pump HVAC System
THERMOSTAT CONNECTION
C 24VAC COMMON
R 24VAC RETURN
W1 HEAT STAGE 1
O CHANGEOVER VALVE
G FAN
Y1 COMPRESSOR STAGE 1
Y2 COMPRESSOR STAGE 2
TYPICAL THERMOSTAT WIRING COLORS.
CAUTION: VERIFY THAT ORIGINAL WIRING
MATCHES. COLORS MAY BE DIFFERENT
HEAT PUMP HVAC SYSTEM
BLUE
RED
WHITE
ORANGE
GREEN
YELLOW
BLACK/BROWN
THERMOSTAT BACK PANEL
Y2 Y1 G R C RW1
O
INTERNAL R=R JUMPER
CWIRE IS NOT REQUIRED
FOR BATTERY OPERATION
BATTERIES ARE NOT
REQUIRED FOR 24VAC
POWERED SYSTEMS
CONNECT THE R WIRE TO
EITHER R TERMINAL.
R = R ARE JUMPERED
TOGETHER INTERNALLY
NOTE: IF HEATING IS OCCURING
WHEN COOOLING IS EXPECTED,
OR VICE-VERSA, CHANGE THE
CHANGEOVER TYPE TO THE
OPPOSITE SETTING.
O or B WIRE
NOTE! MOST HEAT PUMP
SYSTEMS DO HAVE THE C
WIRE AND THE
THERMOSTAT CAN BE
POWERED BY THE 24VAC
FROM THE HVAC SYSTEM

4Copyright ©2017 Nortek Security & Control
Thermostat Power
The thermostat can be powered by either 24VAC from the HVAC system or from four (4) type AA
internal baeries. DO NOT use this thermostat for line voltage controls (120/240VAC).
The C Wire
If the 24VAC common wire (usually blue) is present and is connected to 24VAC common at the HVAC
system end, the thermostat can be powered from the HVAC system and baeries are not required. If
there is no common wire, baeries are required.
24VAC Power
Powering the thermostat with 24VAC power requires both the 24VAC “C” common wire (typically a
blue wire) and the 24VAC ”R” return wire (typically a red wire).
BaƩery Power
Powering the thermostat from baeries does not require a “C” wire connecon.
DO NOT install baeries if the thermostat is powered by 24VAC. They are not required for backup.
If the thermostat is powered by baeries, the thermostat will operate for approximately (2) two
years on four (4) AA Alkaline baeries depending on the frequency of user operaons and backlight
operaon. Always use Alkaline baeries and replace in complete sets of four (4) at a me.
Z-Wave OperaƟon when BaƩery Powered
IMPORTANT: If the thermostat is installed on a Z-Wave network, while it is baƩery powered, it will
NOT work as a Z-Wave repeater.
CAUTION: Do not install baeries and temporarily power the thermostat from 24VAC to include onto
a Z-Wave network. Shortened baery life may occur when 24VAC power is removed.

Copyright ©2017 Nortek Security & Control LLC 5
Remove Existing Thermostat
• Turn offthe power to the thermostat. This is usually done at the heang/cooling system or
circuit breaker panel.
• Remove the cover of old thermostat to expose the wiring terminals.
• Take a picture of the wiring terminals and the wires before disconnecting them!
• Mark the exisng thermostat wires with the wiring labels included according to the terminal
markings. Some installaons may have addional wires not shown in this example illustraon.
Y1, Y2, W1, W2, O,B.
• Use the thermostat terminal “names/marking” (not the wiring color) to mark the wires.
• Remove the old thermostat base.
CAUTION: When removing thermostat, don’t let the wires slip into the wall and don’t let the wires
touch each other.
• If the old thermostat was a mercury style thermostat, dispose of it properly as described below.
Figure 2. Label Wire Terminals
NOTE: Taking a picture is critical if problems are encountered. This will allow reinstallation
of the old thermostat and will help with troubleshooting later if needed.
Terminal Typical Wire Color Function
Y YELLOW Cool
W WHITE Heat
G GREEN Fan
R RED 24VAC Return
CBLUE 24V Common (typically BLUE). When the wire is
present, the thermostat can be powered without
baeries. When the wire is absent, the thermostat
must be powered by baeries if 24VAC is present
across the R&C wires
Wiring Colors
While the thermostat terminal markings are intended to match the wire color, (R=RED, G=GREEN,
W=WHITE, Y=YELLOW) be sure to follow the terminal marking when marking the wires, even if the
wire color doesn’t match.
WARNING: If the exisƟng thermostat is a mercury-containing device, it must be disposed
of in compliance with federal, state, and local regulaƟons. Many states and /or local
agencies have collecƟon/exchange programs or hazardous waste collecƟon programs for
mercurycontainingdevices. For more informaƟon, see the U.S. Environmental ProtecƟon
Agencywebsite at:hƩp://www.epa.gov/osw/hazard/wastetypes/universal/mce.htm For Canada:
Environment Canada and Disposing of Mercury Products at: hƩps://www.ec.gc.ca/mercure-
mercury/default.asp?lang=En&n=F111AAC6-1.
C
R
G
W
Y
C
RG
W
Y
LABEL THE WIRES TO MATCH
THE OLD THERMOSTAT TERMINAL
MARKINGS
EXISTING THERMOSTAT TERMINALS
TAKE A PICTURE!

6Copyright ©2017 Nortek Security & Control
Install the Back Panel
Remove the back panel of the thermostat by pushing down the thumb tab on the boom of the body.
Figure 3. Removing back panel of thermostat.
Mount the thermostat back panel on the wall (See Figure 4).
1. Use the two (2) wall anchors and two (2) Phillips screws (provided) to mount the back panel.
2. Level as needed.
Figure 4. Mounting the Back Panel
BACK PANEL
BODY (WITH PCB)
PUSH ON THUMB TAB TO RELEASE
BACK PANEL
Y2 Y1 G RC C RH W1 W2 Standard
Y2 Y1 G R C R WI 0 Heat Pump
ANCHORS (2) PROVIDED
PHILLIPS SCREWS (2) PROVIDED

Copyright ©2017 Nortek Security & Control LLC 7
Standard HVAC System Connections
NOTE: For typical connecons to a Standard HVAC system, refer to the diagram on Page 2.
The terminals on the back panel have two sets of labels. The upper label shows the STANDARD HVAC
terminal connecons. The lower label shows HEAT PUMP HVAC terminal connecons.
Figure 5. Standard HVAC System Terminal Block Labeling
Figure 6. Standard HVAC Systems Terminal Block Connections
Single and Dual Transformer Systems (Split Systems)
HVAC systems may have one or two transformers. The “R” wire connects differently depending on
the system.
Single Transformer System
Most HVAC systems have a single 24VAC transformer. For these systems, there is only one “R”
wire and it can be connected to either the thermostat’s RC or RH terminal as these are internally
jumpered together.
If installing a Standard HVAC system, connect the wires from the HVAC system to the corresponding
terminals on the thermostat back terminal block. Use the table below as a guideline for connecng
the wires.
Wire Terminal
Y Connect to the Y1 terminal
G Connect to the G terminal
R Connect to either RC or RH terminals (Except for Dual Transformer Systems, See Next
Page)
C Connect to the C terminal. C wire (24VAC common) may not be present. If not present,
baeries MUST be installed.
W Connect to the W1 terminal
NOTES: Ensure that the appropriate wires are screwed into the terminal blocks firmly.
Gently pull on the wires to confirm the connecon.
Push all excess wiring back into the wall opening.
Y2 Y1 GRC CRH W1 W2
W
C
R
G
Y
STANDARD
Y2 Y1 GRCRW1 OHEAT PUMP
(STICKER LABELED WIRES)
REFERENCE
STANDARD
TERMINALS
CONNECT IF 2 STAGE SYSTEM CONNECT IF 2 STAGE SYSTEM
Y2 Y1 GRC C RH W1W2 Standard
Y2 Y1 GRCRW1 OHeat Pump
STANDARD HVAC
SYSTEM TERMINAL
WIRING

8Copyright ©2017 Nortek Security & Control
Dual Transformer Systems
For HVAC systems that have separate heang and cooling systems, each with their own 24VAC
transformers, there will be an “R” wire from the heang system and an “R” wire from the cooling
system.
For dual transformer systems, connect the “C” wire from the cooling system to the thermostat’s “C”
terminal. DO NOT CONNECT THE “C” WIRE FROM THE HEATING SYSTEM.
Figure 7. Dual Transformer HVAC System Thermostat Terminal Connections
Connect the wires from the HVAC system to the corresponding terminals on the thermostat back
terminal block. Use the table below as a guideline for connecng the wires.
Wire Terminal
Y2 Connect to the Y2 terminal (2-stage systems only)
Y or Y1 Connect to the Y1 terminal
G Connect to the G terminal
COOL Rc Connect to RC terminal
C Connect to C terminal (Cooling System C Wire, NOT Heang System C Wire)
HEAT Rh Connect to RH terminal
W or W1 Connect to W1 terminal
W2 Connect to W2 terminal (2-stage system only)
IMPORTANT! FOR SEPARATE RC/RH SYSTEMS, THE INTERNAL RC=RH JUMPER MUST BE
CUT ON THE BACK OF THE THERMOSTAT’S PRINTED CIRCUIT BOARD— (See Figure 8).
Figure 8. Internal RC=RH Jumper
RC=RH JUMPER
CUT JUMPER FOR
DUAL TRANSFORMER
SYSTEMS ONLY
Y2 Y1 GRC CRH W1 W2
W
C
G
STANDARD
Y2 Y1 GRCRW1 OHEAT PUMP
(STICKER LABELED WIRES)
REFERENCE
STANDARD
TERMINALS
Rc Rh
HEATING SYSTEM R WIRE
COOLING SYSTEM R WIRE
Y2 W2
Y
OR
Y1
RR
W1

Copyright ©2017 Nortek Security & Control LLC 9
Heat Pump HVAC System Connections
NOTE: For typical connecons to a Heat Pump HVAC system, refer to the diagram on Page 3.
The terminals on the back panel have two sets of labels. The lower label shows HEAT PUMP HVAC
terminal connecons. The upper label shows the STANDARD HVAC terminal connecons.
Figure 9. Heat Pump HVAC System Terminal Block Labeling
Figure 10. Heat Pump HVAC System Thermostat Terminal Block Connections
Connect the wires from the HVAC system to the corresponding terminals on the thermostat back
terminal block. Use the table below as a guideline for connecng the wires.
Wire Terminal
Y Connect to the Y1 terminal
G Connect to the G terminal
R Connect to either R terminal
C Connect to the C terminal. The C wire (24VAC common) Heat Pump systems typically
have the C wire connected to the thermostat. If there is no C wire, baeries MUST be
installed
W Connect to the W1 terminal
O or B Connect to the O terminal. Heat Pump setup must set changeover valve to correct O
or B seng (See page 13).
NOTES: Ensure that the appropriate wires are screwed into the terminal blocks firmly.
Gently pull on the wires to confirm the connecon.
Push all excess wiring back into the wall opening.
Y2 Y1 GRC C RH W1W2 Standard
Y2 Y1 GRCRW1 OHeat Pump HEAT PUMP SYSTEM
TERMINAL WIRING
Y2 Y1 GRC CRH W1 W2
O or B
W
C
G
Y
STANDARD
Y2 Y1 GRCRW1 OHEAT PUMP
(STICKER LABELED WIRES)
REFERENCE
HEAT PUMP
TERMINALS
R
CONNECT IF 2 STAGE SYSTEM

10 Copyright ©2017 Nortek Security & Control
Mount the Thermostat
Install the thermostat body/front panel onto the wall mounted base by firmly pressing in place unl
it snaps all around the edges. The GC-TBZ48L is now ready to program.
Figure 11. Attaching Front Panel to Back Panel
Battery Installation
If installing baeries, open the thermostat baery front panel, pry it offwith fingernail at indents on
boom of case (See Figure 12). Install the four (4) type AA baeries and assemble as shown in Fig.13.
Figure 12. Opening Battery Case/Cover
Figure 13. Battery Installation
MODE
MODE
FAN
FAN
BODY/FRONT PANEL
BACK PANEL (MOUNTED TO WALL)
HOOK ON CATCH IN
TOP OF BACK PANEL
SNAP ONTO CATCHES
AT BOTTOM OF BACK PANEL
FRONT PANEL
BACK
PANEL
MODE
FAN
BACK PANEL/BODY
(ATTACHED TO WALL)
FRONT PANEL
BATTERY
COMPARTMENT
HOOK ON CATCH IN
BACK
SNAP ONTO CATCHES
AT BOTTOM OF BACK PANEL
FRONT PANEL
BACK
PANEL
USE FINGER NAILS AT INDENTS
ON CASE BOTTOM
BACK PANEL/BODY ON WALL
FRONT PANEL TO BATTERY COMPARTMENT

Copyright ©2017 Nortek Security & Control LLC 11
Thermostat Setup Menus
The thermostat must be setup for the correct HVAC system type for proper operaon.
Preset HVAC System seƫngs
The thermostat is preset for the following typical HVAC system configuraon:
• HVAC system type: Standard gas/electric
• HVAC fan type: Gas heat
• HVAC heang stages: one
• HVAC cooling stages: one
If the thermostat is installed on this type HVAC system, the System Setup does not need to be
changed.
If installed on a Heat Pump HVAC system or any HVAC configuraon other than the preset sengs,
change the sengs in the SYSTEM setup menu to match the HVAC system.
NOTE: To conserve baery life, the thermostat backlight turns offaer a short me of no acvity.
The first press of any buon turns on the backlight (but does not iniate any acon). Press the buon
again to iniate the acon desired. If the backlight is already on, buon presses work with the first
press.
Wait Mode
The thermostat has a Minimum OffTime (MOT) delay aer any heang or cooling cycle ends. This
delay prevents rapid heang/cooling cycles and also provides “short cycle protecon” for the system
compressor. This delay may be noceable when you change a setpoint and it does not respond
immediately due to the MOT delay mer prevenng the system from restarng. The MOT delay me
can be adjusted in the Advanced Sengs menu of the thermostat but there is a minimum of five
minutes delay to assure compressor protecon.
Minimum Run Time (MRT)
The thermostat has a Minimum Run Time delay aer the start of any heang or cooling call. This
minimum run me assures even heang and cooling cycles. The MRT will keep the system on, even
if it reaches the setpoint room temperature, or you change the setpoint to a temperature that would
sasfy the call, unl the MRT expires. Changing the Mode to OFF will cancel the MRT and the system
will turn offimmediately. The MRT can be adjusted in the Advanced Sengs menu of the thermostat.
NOTE: The MRT delays are shown by flashing heat or cool icons on the display.

12 Copyright ©2017 Nortek Security & Control
Entering Menu Mode
To change the System setup, go to the thermostats Menu Mode and select SYSTEM. From there
select the correct HVAC sengs to match the installaon type.
Press and hold the FAN buon to enter the Menu Mode. SETUP is the first menu item displayed.
Press the buon to advance to the SYSTEM screen.
Figure 14. Menu Mode Setup
Menu Mode NavigaƟon
When the Thermostat Menu Mode screen is displayed, press the  buons to scroll through the
following menu items.
Figure 15. Menu Navigation
The following menu items are displayed in order.
• SETUP (user preference sengs)
• SYSTEM (HVAC system setup)
• Z-WAVE (install/uninstall from Z-Wave network)
• CLOCK (set me and day)
• INFO (firmware versions and Z-Wave network informaon)
MODE
FAN
Select
Done
Setup
PRESS DONE TO
EXIT BACK TO THE
MAIN THERMOSTAT
SCREEN
PRESS SELECT TO
ENTER THE DISPLAYED
MENU
MENU CHOICES ARE
DISPLAYED IN THE
STATUS DISPLAY LINE
USE THE 
BUTTONS TO CHANGE
TO THE DESIRED MENU
ITEM, THEN PRESS
SELECT
MODE
FAN 74
Off
Auto
TO SELECT THE
MENU MODE, PRESS
AND HOLD THE FA N
BUTTON UNTIL THE
SETUP SCREEN IS
DISPLAYED

Copyright ©2017 Nortek Security & Control LLC 13
System Menu
The SYSTEM menu is used to setup the thermostat for the correct HVAC system type. The following
setup opons will be displayed in the text line:
• HVAC System Type: Standard Gas/Electric or Heat Pump
• Fan Type: Gas Heang or Electric Heang
• Changeover Valve Type (for Heat Pump Systems): Changeover with Cooling or with Heang.
To select opons:
• Use the  buons to scroll to the desired seng.
• Press SELECT to change a seng. The current seng for that selecon will be flashing.
• Change the opon with the  buons.
• When the desired opon has been selected, Press SELECT again to save it.
• Then press DONE to exit.
System Type
• For Standard Gas/Electric systems, select STANDARD This is the default seng.
• For Heat Pump systems, press the  buons to change to HEAT PUMP
• Press SELECT to set.
• Press DONE to exit.
Fan Type (For Standard HVAC systems only)
Fan type depends on the heang system type.
• For Gas heat: select GAS. This is the default seng.
• For Electric heat: press the  buons to change to ELECTRIC.
• Press SELECT to set.
• Press DONE to exit.
Changeover Type (For Heat Pump HVAC Systems Only)
The changeover (or reversing) valve is used to change from heang to cooling operaon. The HVAC
system is either a Changeover with Cooling type (O) or Changeover with Heang type (B). Most are
changeover with cooling, which is the default seng.
• For Changeover with Cooling systems, select WITH COOL. This is the default seng.
• For Changeover with Heang systems, use the  buons to change to WITH HEAT.
• Press Select to set.
• Press Done to exit.
Not sure what type Changeover system? Check the exisng thermostat connecons to help
determine this. If the original system had an orange wire connected to an “O” terminal, then this is a
“changeover with cool” system. If there was a brown wire connected to a “B” terminal, then this is a
“change over with heat” system. Set the Changeover seng accordingly.
NOTE: If heating comes on when cooling is expected or vice versa, switch the “Changeover
Type” to the opposite setting.

14 Copyright ©2017 Nortek Security & Control
Z-Wave Plus InstallaƟon
Z-Wave controllers from various manufacturers may support the Z-Wave Thermostat General V2
Device class used by the GoControl Z-WAVE Thermostat. The following procedure will allow the
thermostat to be added to a Z-Wave network.
NOTE: Before adding the thermostat to a Z-Wave Network, check that it does not already belong to
one by viewing the Node ID (ZNID) located in the Thermostat Info screen. An uninstalled thermostat
should show zeros for the Node ID (000). Consult your controller’s user manual for details on
removing a device from a Z-Wave network.
Figure 16. Z-Wave Menu Setup
General Programming Procedure (for controllers supporng the thermostat device class):
1. Set your primary controller to Include, add or Install mode, to add the thermostat as a node on
your network (see your controller’s user manual for detailed instrucons).
2. Press any buon to take thermostat out of sleep mode.
3. Press and hold FAN buon for 5 seconds. SETUP will be displayed in the status display line.
4. Scroll to “Z-Wave” using  buons. Press SELECT.
5. When prompted by your Z-Wave controller, Press the YES buon in the Z-Wave Install screen.
6. Press SELECT (mode buon) to add thermostat to network.
7. Display line should flash WAIT then SUCCESS if Z-Wave connecon is made.
8. If Z-Wave does not connect to controller, WAIT, then FAIL will flash in status display line.
9. If thermostat fails to connect, repeat Steps three (3) thru (7) to re-try connecng.
Your controller will indicate the thermostat was successfully added to its network (see your
controller’s user manual for details). Also, you can check if the thermostat was successfully added
to the network by checking the ZHID (Home ID) and ZNID (Node ID) located in the Thermostat Info
screen.
For other specific tasks such as adding the thermostat to Scenes or Groups, or deleng the thermostat
from an exisng network, refer to the Z-Wave controller instrucons.
Inclusion and Exclusion
Inclusion or exclusion is started by pung the controller into add node or remove node state
and performing the General Programming Procedure outlined above. As part of the process, the
thermostat sends a node informaon frame at normal power. Low power inclusion or low power
exclusion is not possible.
CAUTION: Do not install baeries and temporarily power the thermostat from 24VAC to include onto
a Z-Wave network. Shortened baery life may occur when 24VAC power is removed.
MODE
FAN
Select
Done
z-wave
USE THE 
BUTTONS TO CHANGE
TO THE DESIRED MENU
ITEM, THEN PRESS
SELECT
MENU CHOICES
ARE DISPLAYED IN THE
STATUS DISPLAY LINE
PUSH AND HOLD
FOR 5 SECONDS
76

Copyright ©2017 Nortek Security & Control LLC 15
Advanced Z-Wave® Information
This document is for the advanced user who has knowledge of the Z-Wave™ Command Classes. The
GC-TBZ48 can operate as a FLiRS Device. If 24VAC is detected at the me of install the GC-TBZ48L will
be installed as a LISTENING node, otherwise it will be a NOT_LISTENING node if baery powered.
Support for AssociaƟon Groups
The GC-TBZ48L supports 3 groups and 5 associaons per group.
Group 1 Associaon is the default status report channel in Z-Wave+ lifeline requirements. Group 1
Alerts are to nofy an associated device of a thermostat generated change. Thermostat generated
changes are those changes that originate at or by the thermostat. The following Command Classes
can be sent to the lifeline:
• BATTERY_REPORT
• DEVICE_RESET_LOCALLY_NOTIFICATION
• SENSOR_MULTILEVEL_REPORT
• THERMOSTAT_SETPOINT_REPORT
• THERMOSTAT_SETPOINT_MODE
• THERMOSTAT_FANMODE_REPORT
• THERMOSTAT_FANSTATE_REPORT
• THERMOSTAT_OPERATINGSTATE_REPORT
• THERMOSTAT_CONFIGURATION_REPORT
Group 2 AssociaƟon Alerts will send a BASIC_SET 0xFF when a Cool Call starts and a BASIC_SET 0x00
when the Cool Call ends.
Group 3 AssociaƟon Alerts will send a BASIC_SET 0xFF when a Heat Call starts and a BASIC_SET 0x00
when the Heat Call ends.
Clock Menu
Use the clock menu to set thermostat’s internal clock.
Figure 17. Clock Setup
Seƫng the Clock
1. Press any buon to take thermostat out of sleep mode.
2. Press FAN buon for 5 seconds unl, SETUP appears in status display line.
3. Use  buons to select CLOCK in status display line.
4. Press SELECT, DAY will be displayed
5. Press buons, TIME will be displayed.
6. Use the  buons to select the current me.
7. Press SELECT, FAN (Done), FAN (Done).
MODE
FAN
Select
Done
CLOCK
USE THE 
BUTTONS TO CHANGE
TO THE DESIRED MENU
ITEM, THEN PRESS
SELECT
MENU CHOICES
ARE DISPLAYED IN THE
STATUS DISPLAY LINE
PUSH AND HOLD
FOR 5 SECONDS
76

16 Copyright ©2017 Nortek Security & Control
INFO Menu
The INFO menu displays informaon about the thermostat. Use the  buons to scroll through
the various items.
• MODEL GC-TBZ48L
• VERSION Thermostat firmware version.
• ZWAVE Z-Wave firmware version.
• NODE ID Z-Wave Node ID.
• HOME ID Z-Wave Home ID.
• SYSTEM TYPE displays current System Type seng.
• If System Type = Standard, FAN TYPE displays current Fan Type seng.
• If System Type = Heat Pump, CHANGEOVER TYPE displays current Change Over seng.

Copyright ©2017 Nortek Security & Control LLC 17
Advanced System Seƫngs Menu
The Advanced System Sengs Menu provides for addion system setup opons. These sengs can
affect system operaon and should only be changed by qualified HVAC installers.
To access the Advanced System Sengs menu, first press and hold the FAN buon to get into the
Setup menu. While in the Setup Menu, press and hold both the FAN and buons for 5 seconds.
• Use the  buons to scroll through the menu opons to the desired seng.
• Press SELECT (Mode) buon to change a seng. Once it begins to flash, use the  buons to
select the desired seng.
• Press the SELECT buon to accept the new seng (flashing will stop).
Feature Description Range Default
Setting
Test Mode Test mode shortens the system built-in delays (like
MOT and MRT)
Y = Test mode on. Reduces all delays to 10 seconds for
quicker system tesng
N = Test mode off. Normal system delays
Y or N N
Aux Heat
Enable (Heat
Pump Systems
only)
Enables the auxiliary heat operaon.
Typically the auxiliary heat will be heat-strips in a heat
pump system.
Y or N N
2nd Stage
Heat Enable
Enables the second stage heat operaon Y or N N
2nd Stage Cool
Enable
Enables the second stage cool operaon Y or N N
Minimum run
me
Sets the Minimum Run Time (MRT) delay before a
heang/cooling cycle can turn off.
Sets heang/cooling cycle me. Prevents rapid on/off
cycling.
1-9 3
Minimum Off
me
Sets the Minimum OffTime (MOT) delay before
another heang/cooling cycle can begin. Provides
compressor short cycle protecon. “Wait” is displayed
on screen when acve.
5-9 Minutes 5
Heat Setpoint
Max.
Sets the maximum heang setpoint value.
Will not ramp or accept setpoints higher than this
maximum
55F to 96F
(4C to 43C)
90F
(32C)
Cool Setpoint
Min.
Sets the maximum heang setpoint value 60F to 99F
(6C-45C)
60F
(15C)
Heat Blower
OffDelay
Sets the system blower delay offme aer a heat call
ends (fan purge)
0 to 9
seconds
0 (off)
Cool Blower
OffDelay
Sets the system blower delay offme aer a cool call
ends (fan purge)
0 to9
seconds
0 (off)

18 Copyright ©2017 Nortek Security & Control
Feature Description Range Default
Setting
Heat - Cool
Delta
Sets the minimum separaon between heang
and cooling setpoints. NOTE: Attempts to lower
cooling setpoint below the heating setpoint will
PUSH the heating setpoint down to maintain
this separation. The same applies to setting the
heating setpoint above the cooling setpoint, it
will PUSH the cooling setpoint up to maintain the
setpoint delta separation
3 to 15
degrees
3F (1C)
Heang Stage
1 on Threshold
Sets the delta from setpoint that stage 1 heang starts 1 to 6
degrees
1
Heang
Stage 1 Off
Threshold
Sets the delta from setpoint that stage 1 heang stops.
Stage 1 turns offat setpoint + Delta Stage 1.
0 to 5
degrees
0
Heang
Stage 2 On
Threshold
Sets the delta from setpoint that stage 2 heang starts 2 to 7
degrees
2
Heang
Stage 2 Off
Threshold
Sets the delay from setpoint that stage 2 heang stops.
Stage 2 turns offat setpoint + Delta Stage 2.
0 to 6
degrees
0
Aux Heat On
Threshold
Sets the delta from setpoint that stage 3 heang starts 3 to 8
degrees
3
Aux Heat Off
Threshold
Sets the delta from setpoint that stage 3 heang stops.
Stage 3 turns offat setpoint + Delta Stage 3
0 to 7
degrees
0
Cooling
Stage 1 On
Threshold
Sets the delta from setpoint that stage 1 cooling starts. 1 to 7
degrees
1
Cooling
Stage 1 Off
Threshold
Sets the delta from setpoint that stage 1 cooling stops.
Stage 1 turns offat setpoint - Delta Stage 1
0 to 6
degrees
0
Cooling
Stage 2 On
Threshold
Sets the delta from setpoint that stage 2 cooling starts. 2 to 8
degrees
2
Cooling
Stage 2 Off
Threshold
Sets the delta from setpoint that stage 2 cooling stops.
Stage 2 turns offat setpoint - Delta Stage 2.
0 to 7
degrees
0
Restore
Defaults
Restores all sengs to factory defaults.
Press Yes to restore defaults
Press No to exit and not restore defaults
Y or N N
