Northwestern Bell Phones Excursion 36247 User manual

36247 Canadian I/B version 12229C-1
OWNER S MANUAL#36247 VER. 12229C-1
PAGE: 0English version
Excursion® 36247
Congratulations on your selection of the Excursion®
36247 from Northwestern Bell Phones. This quality
2.4GHz cordless telephone with Caller ID and Call
Waiting, like all Genuine BELL® products, has been
designed to give you many years of continuous service
and represents the best value for your money. It
requires little maintenance and is easy to setup and
operate.

36247 Canadian I/B version 12229C-1
112229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 1English version
IMPORTANT SERVICE INFORMATION
Read this manual before attempting to setup or use this instrument. It contains
important information regarding safe installation and use. Keep this manual for
future reference. Also save the carton, packing and proof of purchase to simplify and
accelerate any needed action. If you need assistance or service in Canada, call
Sonigem Products Inc. at [phone] or [phone] between 8:30 a.m. and
5:00 p.m. Eastern Standard Time, Monday through Friday. You can also visit our
web site at http://www.nwbphones.com for technical support and information on our
other products.
WARNING
To prevent fire or shock hazard, do not expose this product to rain or any type of
excess moisture. If accidentally dropped into water, the adapter should
immediately be unplugged from the wall along with the telephone line cord.
THIS SYMBOL IS INTENDED TO ALERT THE USER OF THE PRESENCE OF
IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS
IN THE OWNER'S MANUAL.

36240 Canadian I/B version 12229C-1
12229C-1 2
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 2English version
CARTON CONTENTS
SAVE THESE INSTRUCTIONS
HANDSET BASE UNIT
RECHARGEABLE Ni-Cd
BATTERY PACK
ADAPTER
(9VDC, 300mA)
TELEPHONE
LINE CORD
(Short & Long)
WALL MOUNT
BRACKET BELT CLIP
USER’ S MANUAL
WARRANTY CARD
ACCESSORY
ORDER FORM
Ｍｏｄｅｌ Ｎｏ：
Ｓｅｒｉａｌ
Ｎｏ：
Ｍｏｄｅｌ Ｎｏ：
Ｓｅｒｉａｌ
Ｎｏ：
Excursion
®
36247

36247 Canadian I/B version 12229C-1
312229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 3English version
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons, including the
following:
1. Readandunderstandallinstructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet basement or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
6. Slots and openings in the cabinet at the back or bottom are provided for
ventilation, to protect it from overheating. These openings should never be
blocked or covered. The openings should never be blocked by placing the
product on the bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register. This product should not
be placed in a built-in installation unless proper ventilation is provided.
7. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be abused by persons walking on it.
9. Do not overload wall outlets and extension cords as this can result in the risk of
fire or electric shock.
10. Never push objects of any kind into this product through cabinet slots as they
maytouchdangerous voltage points or short out parts that could result in a risk
of fire or electric shock. Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this product, but take it
to a qualified servicecontractor when some service or repair work is required.
Opening or removing covers may expose you to dangerous voltages or other
risks. Incorrect reassembly can cause electric shock when the appliance is
subsequently used.
12. Unplugthisproductfromthe wall outlet and refer servicing to qualified service
personnel under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions. Improper adjustments of other controls may result in damage
and will often require extensive work by a qualified technician to restore
the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinctive change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm.

36240 Canadian I/B version 12229C-1
12229C-1 4
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 4English version
There may be a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
BATTERY SAFETY INSTRUCTION
CAUTION: To reduce the risk of fire or injury to persons, read and follow these
instructions:
1. Use only the following type and size of handset battery pack:
Cordless Telephone Battery Pack
DC3.6V, 850mAh, Ni-CdBatteryPack
Manufacturer:MaxPowerElectronicsLtd.
Model No.: 10312F0
2. Do not dispose of the battery in a fire. The cell may explode. Check with local
codes for possible special disposal instructions.
3. Do not open or mutilate the battery. Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling the battery in order not to short the battery with
conducting material such as rings, bracelets and keys. The battery or conductor
mayoverheatandcauseburns.
5. Recharge only the battery provided with or identified for use with this product.
The battery may leak corrosive electrolyte or explode if it is not the correct type.
6. Do not attempt to rejuvenate the battery provided with or identified for use with
this product by heating them. Sudden release of the battery electrolyte may
occur causing burns or irritation to eyes or skin.
7. When inserting the batteries into this product, the proper polarity or direction
mustbeobserved.Reverseinsertionofbatteriescancausechargingthatmay
result in leakage or explosion.
8. Remove the batteries from this product if the product will not be used fora long
period of time (several months or more) since during this time the battery could
leakin theproduct.
9. Discard “dead” batteries as soon as possible since “dead” batteries are more
likely to leak in a product.
10. Do not store this product, or the battery provided with or identified for use with
this product, in high-temperature areas. Batteries that are stored in a freezer or
refrigerator for the purpose of extending shelf life should be stabilized at room
temperature prior to use after cold storage.
11. Disconnect telephone lines before installing batteries.
SAVE THESE INSTRUCTIONS
INSTALLATION PRECAUTIONS

36247 Canadian I/B version 12229C-1
512229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 5English version
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
3. Never touch uninsulated telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
4. Usecautionwhen installing or modifying telephone lines.
INDUSTRY CANADA CERTIFIED
RINGER EQUIVALENCE NUMBER
NOTICE: The ringer equivalence number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be connected
to a telephone interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the sum of the ringer
equivalence numbers of all the devices does not exceed 5.
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label identifies certified equipment. This certification
means that the equipment meets certain telecommunications network protective,
operational and safety requirements. The Department does not guarantee the
equipment will operate to the operator's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company.
The equipment must also be installed using an approved method of connection. The
customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian
maintenance facility designated by the supplier. Any repairs or alterations made by
the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.
Users should ensure for their own protection that the electrical ground connections
of the power utility, telephone lines and internal metallic water pipe system, if
present, are connected together. This precaution may be particularly important in
rural areas.
CAUTION: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection authority, or

36240 Canadian I/B version 12229C-1
12229C-1 6
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 6English version
electrician, as appropriate.
This device complies with Part 15 of the FCC Rules. Operation issubject to the
following two conditions: (1) This device may not cause harmful interference,
and, (2) his device must accept any interference received, including interference
that may cause desired operation. Privacy of communications may not be
ensured when using this phone.
Changes or modifications not expressly approved in writing by Northwestern Bell
Phones may void the user's authority to operate this equipment.
Some cordless phones operate at frequencies that may cause interference to
nearby TVs and VCRs; to minimize or prevent such interference, the base of the
cordless phone should not be placed near or on top of a TV or VCR; and, if
interference is experienced, moving the cordless telephone farther away from
the TV or VCR will often reduce or eliminate the interference.
ADAPTER:
Use only with Class 2 Transformer 9VDC output 300 mA.
TABLE OF CONTENTS

36247 Canadian I/B version 12229C-1
712229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 7English version
IMPORTANT SERVICE INFORMATION………………………………………1
CARTON CONTENTS ………………………………………………………..…2
IMPORTANT SAFETY INSTRUCTIONS………………………………………3
BATTERY SAFETY INSTRUCTION……………………………………………4
ISTALLATION PRECAUTIONS…………………………………………………5
INDUSTRY CANADA CERTIFIED
CAUTIONFCC
TABLE OF CONTENTS
GETTING TO KNOW YOUR NEW PHONE
INTRODUCTION TO CALLER ID AND CALL WAITING ID
EXCURSION® 36247CONTROLS DIAGRAM
DESCRIPTION
CONTROL'S’LOCATIONANDFUNCTION
HANDSET CONTROLS
BASE UNIT CONTROLS
MOUNTING POSITION
DESKTOP USE
WALL USE
BELT CLIP INSTRUCTION
CONNECTING THE HEADSET
POWER INSTALLATION
INITIALSETUP
SETTING THE TONE / PULSE MODE
SETTING THE HANDSET RINGER ON / OFF
SETTING THE LANGUAGE
SETTING USER'S AREA CODE AND NEIGHBORING AREA CODE
INPORTANT INFORMATION FOR THE CALL BACK FEATURE AND
AREACODESET-UP IN CANADA
TELEPHONE OPERATION
TO PLACE A CALL IN TALK MODE
TO PLACE A CALL IN STANDBY MODE (PREDIAL MODE)
TO RECEIVE A CALL
LAST NUMBER REDIAL
STORING TELEPHONE NUMBERS INTO MEMORY DIALING
DIRECTORY
DELETING STORED TELEPHONE NUMBERS
DIALING FROM THE MEMORY DIALING DIRECTORY
EDITING STORED TELEPHONE NUMBERS
MIXED MODE DIALING
PAUSEFUNCTION
FLASHFUNCTION
CHANNEL SELECTION (40 Channels)
OUT OF RANGE WARNING
LOW BATTERY WARNING
PAGING FUNCTION
CALLER ID OPERATION
RECEIVING NEW CALL
VIEWING CALL RECORDS AND NEW CALL RECORDS
SAVING CALL RECORDS

36240 Canadian I/B version 12229C-1
12229C-1 8
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 8English version
DELETING CALL RECORDS
CALLBACK FROM CALL RECORDS
PROGRAMMING MODE
SUMMARY OF FUNCTION MODE
HOW TO CHANGE THE LANGUAGE
HOW TO SET CIDCW ON / OFF
HOW TO SET USER AND NEIGHBORING AREA CODE
HOW TO SET CALLBACK NUMBER
HOW TO SET RINGER ON / OFF
HOW TO SET TIME
HOW TO ADJUST THE CONTRAST OF LCD DISPLAY
NEW CALL / MESSAGE INDICATOR
TALKING TIME AND CHANNEL DISPLAY
CALL WAITING ID OPERATION
LCD DISPLAY SYMBOLS AND MESSAGES
IMPROVING CORDLESS RECEPTION
MAXIMIZING BATTERY LIFE
MAINTENANCE
TROUBLESHOOTING
TECHNICAL INFORMATION
GLOSSARY
GETTING TO KNOW YOUR NEW PHONE
IMPORTANT:Subscription to Caller ID (CID) / Call Waiting ID services from your
local phone company is required for using the Caller ID / Call Waiting ID features of
the Excursion® 36247.
Your new Excursion® 36247 telephone gives you the ultimate in cordless telephone
sound quality with the luxury of Caller ID and Call Waiting ID.
If this is your first cordless telephone, you will soon discover that your cordless is
similar to regular telephones, except without the cord. If you have owned a cordless
in the past, you will discover that the Excursion®36247 telephone is the most
powerfulandfull-functioned Call Waiting ID cordless telephone on the market,
some key features are:
•40 name and number Caller ID / Call Waiting ID memory
•20 name and number programmable memory
•Hearing -aid compatibility
•Automatic or manual selection of the clearest of 40 channels
Unlike regular telephones, your cordless does not work during power failures. We
do not recommend you to use a cordless telephone as the only phone inyour
residence.
INTRODUCTION TO CALLER ID AND CALL WAITING ID
The Excursion®36247 Caller ID / Call Waiting ID devices allow you to take

36247 Canadian I/B version 12229C-1
912229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 9English version
advantage of the Caller Identification delivery service offered by your local telephone
company. Should you have any questions about the operation of your Caller ID,
please call Sonigem Products Inc. at [phone] between 8:30 a.m. and 5:00
p.m. Eastern Standard Time, Monday through Friday, or you can refer to the
following Question and Answer table:
QUESTIONS ANSWERS
What is Caller ID? ACallerIDisa device that identifies the calling party
before you answer a call. This device can be used to
screen unwanted calls and eliminate harassment
from annoying calls.
What is Call Waiting ID? A Call Waiting ID is a device that can also identifies
the call waiting party before you answer a call.
How does Caller ID and
Call Waiting ID work? When used with Caller ID / Call Waiting ID service, the Caller ID / Call Waiting ID device displays the
name (if available), and the telephone number (if
available) of the person calling before you answer
yourtelephone.
Who provides Caller ID
service? Your local telephone company. However, not all local telephonecompaniesprovide Caller ID service.
Please call you local phone company to confirm that
the service is available before you install the device.
How can I activate my
Caller ID? For your Caller ID unit to function, you must first arrange with your local telephone company to have
Caller ID / Call Waiting ID service installed on your
line.Thereisanextrachargeaddedtoyourmonthly
telephone bill for this service. Before using this unit,
please read this instruction manual carefully.
For further definition of terms, refer to the Glossary section.
EXCURSION®36247 CONTROLS DIAGRAM

36240 Canadian I/B version 12229C-1
12229C-1 10
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 10 English version
Receiver
NEW CALL
LED Indicator
TALK Button
/ # Button
C.BACK
Button
VOL /

Button
Microphone
Microphone
RE/PA Button
-Button
+Button
FLASH/DEL
Button
TONE(*)Button
MEMO Button
LCD Display
INUSE/CHARGE
LED Indicator
NEWCALLLED
Indicator
PAGE
Button
Charge
Terminals
Retainer
Tab
BASE UNIT (Rear View)
DC Adapter
Jack
Tel Line
Jack
BASE UNIT (Bottom View)
T/P (Tone/ Pulse)
Switch

36247 Canadian I/B version 12229C-1
11 12229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 11 English version
DESCRIPTION
CONTROLS' LOCATION AND FUNCTION
(Figure1)
HANDSET CONTROLS
1. LCDDisplay:Shows the phone status, Caller ID Call Record information and
function menus.
2. TALKButton: Press to answer an incoming call, place a call or end a call.
3. MEMO (Memory) Button: Used for storing / retrieving phone numbers to / from
the 20 Memory Dialing Directory.
4. TONE ( * ) Button: Used to temporarily change the dialing mode from pulse to
tone for rotary service user. Provides tone function to access specialservices
such as phone banking services.
5. FLASH / DEL (Delete) Button: In talk mode, it allows you to momentarily
hangs up the phone to regain dial tone or access custom calling features such
as Call Waiting or Three-Way Calling provided by your local phone company.
In standby mode, it allows you to scroll the Call Record list and also to remove
one or all records from the Call Record list or Memory Dialing Directory.
6. (+)Button: Allows you to enter to your Caller Record list. It is also used to
scroll up in Call Record list, memory and program mode.
7. (-) Button: Allows you to enter to your Call Record list. It is also used to scroll
down in Call Record list, memory and program mode.
8. RE / PA (Redial / Pause) Button: Automaticallydialsthelastphonenumber
dialed up to 31 digits. Also used to insert 4-second delay between dialed
numbers in PABX systems or long distance services.
9. Charge Contacts: Used for charging the handset battery.
10. Microphone:Used for speaking with callers.
11. VOL (Volume) / (Shift Left ) Button: In talk mode, it allows you to adjust
12
13
17
16
15
14
11
10
9
8
7
6
5
4
2
1
3

36240 Canadian I/B version 12229C-1
12229C-1 12
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 12 English version
the handset to either high, medium or low. In program, memory and predial
mode, it is used for changing mode and moving the cursor to the left during edit
mode.
12. C. BACK (Call Back) Button:Allows you to callback the phone number in Call
Record list, memory and predial mode.
13. # / (Shift Right) Button : In program, memory and predial mode, it is
used for changing mode and moving the cursor to the right during edit mode.
14. Headset Jack: For headset connection at hands free conversation.
15. SCAN / PRG (Program) Button: In talk mode, it allows you to change
channels if the current channel is noisy or having interference from other
sources. In standby mode, it allows you to enter and store program function.
16. NEW CALL LED Indicator: Flashes if the system has new callmessage(s) and
have message(s) in your voice mailbox (if you subscribe to your telephone
company's voice mail service).
17. Receiver: Allows you to hear calls.
(Figure 2)
BASE UNIT CONTROLS
1. 9VDC Adapter Jack: Ajack located on the rear side of the base unit used for
connecting the adapter to the base unit.
2. TEL LINE Jack: Accepts line cord to make connection with modular type
telephoneoutlet.
3. T / P (TONE / PULSE) Switch: Allows you to select the appropriate dialing
service. TONE for tone dialing or PULSE for rotary service.
4. IN USE / CHARGE LED Indicator: Lights up steadily when the phone is in talk
mode and when the handset is being charged on the base. Turns off when the
handset is not in use and when the handset is removed from its cradle. Flashes
when paging the handset.
5. Charge Terminals: Used for charging the handset battery.
6. NEW CALL LED Indicator: Flashes if the system has new call message and
have message(s) in your voice mailbox (if you subscribe to your telephone
company's voice mail service).
Rear View
1
2
Bottom View
346
7
5
8

36247 Canadian I/B version 12229C-1
13 12229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 13 English version
7. Page Button: Allows you to locate the handset when it is not on the base.
8. RetainerTab: Allows the handset to hang on the base unit in the wallmount
position.
MOUNTING POSITION
DESKTOPUSE:
Connect the telephone line cord to the TEL
LINE jack on the rear of the base unit and
connect the opposite end to the telephone
modular jack. (Figure 3)
WALL USE :
A. WITH A STANDARD AT&T OR GTE MODULAR WALL JACK
1. Install the wall mount bracket at the position as shown in Figure 4.
2. Connect the short telephone line cord to the TEL LINE jack on rear of the base
unit.
3. Connect the opposite end of the telephone line cord to the modular wall jack.
4. Align the wall mounting slots with the studs located on the modular wall plate
and slide the base down to lock in place.
(Figure 4)
NOTE: If you do not have a standard modular wall jack, find a qualified technician to
mount one on the wall.
B. WALL MOUNTING (No Standard Wall Jack)
Base Unit
(Side view)
Wall Mount
Bracket
Wall Mouting
Solts
Telehone
Modular Wall
Jack
Studs

36240 Canadian I/B version 12229C-1
12229C-1 14
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 14 English version
Drill two holes with a vertical distance between the two
marked positions of 315/16” (100 mm) as shown in Figure 5.
1. Drive a screw into each of the holes. Tighten them to the
end of the screw line, only leaving the smooth part of the
screw head outside the wall.
2. Hang the unit onto the screws, then slide it down firmly to
fasten the base securely. (Figure 5)
BELT CLIP INSTRUCTION
•Clamp the belt clip at the back of the handset as shown in Figure 6.
(Figure 6)
CONNECTING THE HEADSET
For hands free conversation, a headset (not included) is connected to the headset
jack as shown in Figure 7. The handset receiver and microphone are disabled when
the headset is connected.
(Figure7)
Press the TALK button to answer or place a call using the headset. Refer to the
manufacturer's headset manual for more details.
HeadsetJack
Headset Plug
(2.5mm)

36247 Canadian I/B version 12229C-1
15 12229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 15 English version
POWER INSTALLATION
BASE UNITPOWERCONNECTION
CAUTION:
You must use a Class II, 120 VAC Input / 9VDC Output adapter that delivers at
least 300 milliampere. The plug should correctly fit the base unit's adapter jack.
1. Plug the adapter into a standard AC outlet.
2. Insert the small plug into the adapter jack on the rear of shown in the base as in
Figure 8.
(Figure 8)
HANDSET BATTERY INSTALLATION
CAUTION:
Useonly the Nickel Cadmium (Ni-Cd) battery type included with this
unit. Use of other battery types may cause injuries or damage.
1. Remove the battery compartment cover of the handset.
2. Connect the rechargeable Ni-CdbatteryasshownonFigure9.
(Figure9)
3. Insert the Ni-Cd battery into the battery compartment of the handset.
4. Slide the battery compartment cover firmly in its closed position.
INITIAL SETUP
Beforeyoucanuseyourcordlesstelephone,thehandsetmustbechargedforat
least 20 hours. Seecharging instruction in the MAXIMIZING BATTERY LIFE section
9VDC
Adapter
Jack
Line
Cord
Telephone
ModularJack AC Wall Outlet
9VDCAdapter
DC Plug
Inset the End
of the Battery
PackWire
BLACK WIRE
Handset
Battery
Compartment
RED WIRE

36240 Canadian I/B version 12229C-1
12229C-1 16
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 16 English version
on this manual.
SETTING THE TONE / PULSE MODE
Select the appropriate dialing service by moving the T / P
TONE / PULSE switch at the bottom side of the base unit:
•TONE for Tone service, or
•PULSE for Rotary service. (Figure 10)
SETTING THE HANDSET RINGER ON / OFF
The handset ringer must be set to ring ON position inorder to ring when receiving an
incoming call. See PROGRAMMMING MODE section on page 26.
SETTING THE LANGUAGE
There are three language modes (English / Spanish / French) available in this unit.
You can change and select a different language mode. See PROGRAMMMING
MODE section on page 25.
NOTE:The default language mode is English.
SETTINGUSER'S AREA CODE AND NEIGHBORING AREA CODE
In order to use callback function, the user's area code and neighboring area code
must be programmed. Neighbor area code is optional.
IMPORTANT INFORMATION FOR THE CALLBACK FEATURE AND
AREA CODE SET-UP IN CANADA.
The Excursion® 36247 Callback feature will automatically redial any number from the
Caller ID records. Most telephone service providers in major metropolitan areas in
Canada send the caller ID information in a format which the Excursion® 36247
Callback feature can automatically redial any number (including long distance / toll
numbers) without any changes to the stored number.
The Excursion® 36247 can automatically detect this type of Caller ID information
format. In this situation, there is no need to set the Area Code(s) in the user setup.
Simply review the incoming calls, if the phone numbers in the Call records list
appear exactly as you would dial them, without any changes, then you do not need
to setup the area code for the Callbackfeature.
In rare cases in Canada where the local telephone provider does not send the Caller
ID information in a format which the Callback feature can automatically redial any
number, without any changes to the stored number, the Area Code(s) must be setin
the user setup.
IMPORTANT: Please note that most Canadian phone subscribers will not need to
perform the area code setup!
AREA CODE SETUP (If Needed)
If you don't live in an area where the local phone provider sends Caller ID
information in a format which can automatically redial any number (including long
distance / toll numbers) without any changes to the stored number, up to 3 different
Area Codes can be programmed into the Excursion® 36247.
T/P

36247 Canadian I/B version 12229C-1
17 12229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 17 English version
If you don't live in large metropolitan area where 10 digits dialing may be required
into certain area codes, then it may only be necessary to set 1 area code in the
Excursion® 36247 area code setup as indicated below.
Single Area Code Setup
Do this method if you only need to dial 7 or 11 digits numbers. Your User's (Home)
area code is set and all calls dialed using the Callback feature that are called into
your User's (Home) area code, will be dialed as 7 digits. All other calls from outside
area codes will automatically dial as 11 digits (1 + Area Code + Local Number).
Please refer to PROGRAMMING MODE section to set single area code on page 26.
NOTE: If you need to dial calls to your User's (Home) area code and that call being
a toll call (as required in some areas) then the 1 + Area Code can be added back to
the 7 digits number. Please refer to CALLBACK OPTION 2 on page 25.
Multiple Area Code Setup
In some large metropolitan areas, 10 digits dialing may be required into certain
neighboring area codes. In these situations, the phone company will take an existing
area code and split the area code into 2 or 3 area codes. One area code is the
original "User's (Home)" area code and the new "Neighboring" area code(s) are
assigned new area code numbers.
In some cases a new area code is overlayed into the old area and only the new
phone subscribers will be assigned the new neighboring area code number. In either
case, the Excursion® 36247 can automatically dial these numbers using the Callback
feature correctly, even if your local phone number service provider doesn't send ID
information in a format which can automatically redial 7, 10, or 11 digits.
NOTE: If you are not sure how to dial your User's (Home) or adjoining Neighboring
area code, please contact your local phone service provider first before attempting
the area codes setup.
2 Area Code Setup
Your User's (Home) area code can be programmed as 7 or 10 digits Callback. If
your situation was due to an area code split, then the 7 digits dialing is usually
required for local calls. If your situation was due to an area code overlay, then 10
digits dialing is likely required into your User's (Home) area code. In either case
dialing into the new area code (Neighboring area code) created by the split or
overlay may require 10 digits dialing into the Neighboring area code. Please refer to
the PROGRAMMING MODE section to set 2 area code on page 26.
NOTE: If your User's (Home) area code requires 10 digits dialing for the Callback
feature, set Callback Number. Please refer to the PROGRAMMING MODE section
to set CALLBACK NUMBER on page 26. The default setting for the Callback
Number of digits is 7. In many split area codes, 7 digits dialing is required in the
User's (Home) area code and 10 digits dialing is required in the Neighboring area
code.
All other area codes not affected by the split will dial as 11 digits (1 + Area Code +
Local 7 Digits Number).
All area codes that are received by the Excursion® 36247 that are not programmed
into the Area Code setup will automatically dial out 11 digits.

36240 Canadian I/B version 12229C-1
12229C-1 18
OWNER＿＿S MANUAL#36240 VER. 12229C-1
PAGE: 18 English version
In most overlay area codes, 10 digits dialing is required in both the User's (Home)
and Neighboring area codes.
NOTE: If you need to dial calls to your User's (Home)
area code and that call requires 11 digits due to that call
being a toll call (as required in some areas), then the 1
+ Area Code can be added back to the 7 digits number. Please refer to CALLBACK
OPTION2onpage25.
3 Area Code Setup
Your User's (Home) area code can be programmed as 7 or 10 digits Callback. If you
have 2 new area codes that require 10 digits dialing because of a 3 way area code
split or overlay, then use this procedure to set your Excursion® 36247 Area Code
setup.
If your situation was due to an area code split, then 7 digits dialing is usually
required for local calls from your User's (Home) area code and calls placed into the
new Neighboring area codes may require 10 digits dialing.
If your situation was due to an area code overlay, then 10 digits dialing is likely
required into your User's (Home) area code. In either case, dialing into the new
Neighboring area codes created by the split or overlay may require 10 digits dialing
into those new area codes. Please refer to the PROGRAMMING MODE section to
set 3 area code on page 26.
NOTE: If your User's (Home) area code requires 10 digits dialing for the Callback
feature, set Callback Number. Please refer to the PROGRAMMING MODE section
to set CALLBACK NUMBER on page 26. The default setting for the Callback
Number of digits is 7. In many split area codes, 7 digits dialing is required in the
User's (Home) area code and 10 digits dialing is required in the Neighboring area
code.
All other area codes not affected by the split will dial as 11 digits (1 + Area Code +
Local 7 digits number).
All area codes that are received by the Excursion® 36247 that are not programmed
into the Area Code setup will automatically dial out 11 digits.
In most overlay area codes, 10 digits dialing is required in both the User's (Home)
and Neighboring area codes.
NOTE: If you need to dial calls to your User's (Home) area code and that call
requires 11 digits due to that call being a toll call (as required in some areas), then
the 1 + Area Code can be added back to the 7 digits number. Please refer to
CALLBACK OPTION 2 on page 25.
TELEPHONE OPERATION
TO PLACE A CALL IN TALK MODE

36247 Canadian I/B version 12229C-1
19 12229C-1
OWNER＿＿S MANUAL#36247 VER.12229C-1
PAGE: 19 English version
1. Press the TALK button on the handset. The LCD Display will show "TALK" and
the symbol will flash while the unit auto-scans and will light
steadily when it finds a clear channel. (Figure
11)
2. Listen for a dial tone.
3. Dialthe telephone number. The phone numbers appear on the LCD Display as
you enter the number.
4. When finished with your call, press the TALK button or place the handset on the
base unit. The base IN USE LED indicator will turn off.
TO PLACE A CALL IN STANDBYMODE (PREDIAL MODE)
1. Ensure that the unit is in standby mode. The handset and base unit IN USE
LEDindicator isoff.
2. Dial the telephone number or press RE / PA button. If you make a mistake,
press
button to delete the character on the left ofthe cursor.
3. Press C. BACK button.
4. When finished with your call, press the TALK button or place the handset on the
base unit. The base IN USE LED indicator will turn off.
TO RECEIVE A CALL
NOTE: If you are expecting incoming calls, the handset must be programmed to
RING ON mode. See PROGRAMMING MODE section on 26.
A. IF THE HANDSET IS ON THE BASE UNIT
1. Since the Excursion® 36247 features “Auto-Answer”, simply pick up the handset
from the base cradle when the phone rings. The LCD Display will show " TALK"
and the symbol will light steadily.
2. Start your conversation.
3. To end your conversation, either press the TALK button or place the handset
on the base unit. The base IN USE LED indicator will turn off.
B. IF THE HANDSET IS OUT OF THE BASE UNIT
1. When the phone rings, press the TALK button on the handset. The LCD Display
will show "TALK" and thesymbol will light steadily.
2. Start your conversation.
3. To end your conversation, either press the TALK button or place the handset
on the base unit. The base IN USE LED indicator will turn off.
LAST NUMBER REDIAL
A. AFTER HEARING A BUSY TONE WHEN PLACING A CALL
1. If you get a busy tone, press handset TALK button to hang up.
2. Press the handset TALK button again and listen for a dial tone.
3. Press the handset RE / PA button. This will automatically
redial the last telephone number you called (Up to 31 digits).
B. WHEN THE HANDSET IS OFF THE BASE UNIT AND IN STANDBY MODE
1. Press the TALK button on the handset and listen for a dial tone.
2. Press the RE / PA button. This will automatically redial the last telephone
number you called (Up to 31 digits).
STORING TELEPHONE NUMBERS INTO MEMORY DIALING DIRECTORY
