Nova gear NG-53A User manual

NG-53A
12V IMPACT DRIVER
INSTRUCTION MANUAL
PRODUCT CODE: 40043
CAUTION: Read the operating
instructions to reduce the risk of inquiry
Battery and charger sold separately

2
ELECTRICAL SAFETY
This manual contains important
safety and operating instructions
for your battery charger (sold
separately).
› Before using the charger, read all
instructions and cautionary markings
on charger, battery pack and product
using the battery pack.
› The charger is not intended for
any uses other than charging
rechargeable batteries. Any other
use may result in risk of fire, electric
shock or electrocution.
› Do not place any object on top of the
charger or place the charger on a soft
surface that may result in excessive
internal heat. Place the charger in a
position away from any heat source.
› To reduce risk of damage to the
electric plug and cord, pull by the
plug rather than the cord when
disconnecting the charger.
› Make sure cord is located so that it
will not be stepped on, tripped over, or
otherwise subjected to damage or
stress.
› An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in the risk of fire, electric shock or
electrocution.
› Do not operate charger if it has
received a sharp blow, been dropped
or otherwise damaged in any way. Have
it checked by an electrician or power
tool repairer.
› Do not disassemble charger. Take it to
an electrician or power tool repairer
when service or repair is required.
Incorrect reassembling may result in
a risk of electric shock, electrocution
or fire.
› To reduce risk of electric shock,
unplug charger from the outlet before
attempting any cleaning. Removing the
battery pack will not reduce this risk.
› Never attempt to connect 2 chargers
together.
SAFETY
CAUTION: Read the operating
instructions to reduce the risk
of inquiry.
DOUBLE INSULATED
This tool is double insulated
in accordance with AS/NZS
60335-1; therefore no earth wire
is required.
DANGER! If the battery case is
cracked or damaged, do not insert
into charger. There is a danger of
electric shock or electrocution.
Warning: Do not allow any liquid to
get inside charger. Electric shock
may result. To facilitate cooling of
the battery pack after use, avoid
placing the charger or battery pack
in a warm environment such as in
a metal shed, or an uninsulated
trailer.
!
!

3
GENERAL SAFETY
› DO NOT store or use the tool and
battery pack in locations where the
temperature may reach or exceed
40ºC (such as outside sheds or metal
buildings in summer).
› The charger is designed to operate
on standard household electrical
power (240 volts). Do not attempt
to use it on any other voltage! The
battery pack is not fully charged out
of the carton. First read the safety
instructions and then follow the
charging notes and procedures.
› The longest life and best
performance can be obtained if the
battery pack is charged when the air
temperature is between 18 - 24ºC.
Do not charge the battery pack in
an air temperature below 10ºC or
above 40ºC. This is important and will
prevent damage to the battery pack.
› Do not incinerate the battery pack
even if it is seriously damaged or is
completely worn out. The battery can
explode in a fire.
› Never attempt to open the battery
pack for any reason. If the plastic
housing of the battery pack breaks or
cracks, immediately discontinue use
and do not recharge.
Save these instructions and other
documents supplied with this tool for
future reference.
1) WORK AREA SAFETY
a) Keep work area clean and well
lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in
explosive atmospheres, such as in
the presence of flammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match
the outlet. Never modify the plug
in any way. Do not use any adapter
plugs with earthed (grounded)
power tools. Unmodified plugs and
matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed
or grounded surfaces, such as
pipes, radiators ,ranges and
refrigerators. There is an increased
risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain
or wet conditions. Water entering a
power tool will increase the risk of
Warning: Read all safety warnings
and all instructions. Failure to
follow the warnings and
instructions may result in electric
shock, fire and/or serious injury.
!

4
electric shock.
d) Do not abuse the cord. Never
use the cord for carrying, pulling
or unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of
electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a
damp location is unavoidable, use
a residual current device (RCD)
protected supply. Use of an RCD
reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired
or under the influence of drugs,
alcohol or medication. A moment
of inattention while operating power
tools may result in serious personal
injury.
b) Use personal protective
equipment. Always wear eye
protection. Protective equipment
such as dust mask, non-skid safety
shoes, hard hat, or hearing protection
used for appropriate conditions will
reduce personal injuries.
Prevent unintentional starting.
Ensure the switch is in the off-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying
power tools with your finger on the
switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or
wrench before turning the power
tool on. A wrench or a key left
attached to a rotating part of the
power tool may result in personal
injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear
loose clothing or jewellery. Keep
your hair, clothing and gloves away
from moving parts. Loose clothes,
jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these
are connected and properly used.
Use of dust collection can reduce
dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the

5
rate for which it was designed.
b) Do not use the power tool if
the switch does not turn it on
and off. Any power tool that cannot
be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the
power source and/or the battery
pack from the power tool before
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures
reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained
users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and
clean. Properly maintained cutting
tools with sharp cutting edges are
less likely to bind and are easier to
control.
g) Use the power tool, accessories
and tool bits etc. in accordance with
these instructions, taking into
account the working conditions and
the work to be performed. Use of the
power tool for operations different
from those intended could result in a
hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with
specifically designated battery. Use
of any other battery packs may create
a risk of injury and fire.
c) When the battery is not in
use,keep it away from other metal
objects, like paper clips, coins, keys,
nails, screws or other small metal
objects, that can make a connection
from one terminal to another.
Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions,
liquid may be ejected from the
battery; avoid contact. If contact
accidentally occurs, flush with
water. If liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery may
cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by

6
ADDITIONAL SAFETY RULES
FOR IMPACT DRIVERS
a) Hold power tool by insulated
gripping surfaces, when performing
an operation where the fastening
may contact hidden wiring or its
own cord. Fasteners contacting a
“live” wire may make exposed metal
parts of the power tool “live” and
could give the operator an electric
shock.
b) Do not use the tool in wet or damp
conditions.
c) Wear ear protectors when impact
driving. Exposure to noise can cause
hearing loss.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
Children should be supervised to
ensure that they don’t play with the
appliance.
Recommendations for the use of a
residual current device with a rated
residual current of 30mA or less:
› Wear a hard hat (safety helmet),
safety glasses and/or face shield. It
is also highly recommended that you
wear a dust mask, ear protection and
padded gloves.
› Secure the work piece. A work piece
clamped with clamping devices or
in a vice, is held more secure than
by hand.
› One-handed operation can be
hazardous. It is recommended you
hold the unit firmly with both hands
when operating the tool.
› After installing the driver bit, pull
lightly on the bit to make sure that it
does not come loose. If the bit is not
installed properly, it can come loose
during use, which can be dangerous.
› Use a bit that matches the screw.
› Tighten the screw with the impact
driver lined straight with the screw to
prevent the screw head from being
damaged and to ensure the proper
force is delivered.
› Hold the power tool with a firm grip.
High reaction torque can briefly occur
while tightening and loosening nuts
and bolts.
› Check that any bit to be used is not
cracked or broken. Broken or cracked
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power
tool is maintained.
b) If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.

7
LITHIUM-ION BATTERY &
CHARGER SAFETY
OVER CHARGING PROTECTION
This feature ensures that the battery is
never overcharged. When the battery
has reached its full charge capacity
the charger will shut off protecting the
internal components of the battery
from being damaged.
OVER DISCHARGE PROTECTION
An internal component of the battery
pack is an over discharge protector.
This feature will stop the battery from
discharging beyond the recommended
lowest safety voltage.
OVER HEAT PROTECTION
The battery has an internal Thermister
cut off sensor which will cease the
charging cycle if the battery becomes
hot during the charging process. This
Thermister sensor will also stop the
battery from operating should the
battery become too hot during the
operation of the tool. This can happen
when the tool is overloaded or being
used for extended periods of time.
Up to 30min in cooling time may
be required depending on ambient
temperature and operation being
performed.
OVER CURRENT PROTECTION
Should the battery be overloaded
and the maximum current draw be
exceeded the battery will temporarily
stop working to protect the internal
components. The battery will resume
to normal operation once the excessive
current draw has returned to normal
safe level. This may take a few seconds.
sockets are dangerous.
› If the ring securing the bit is
damaged, the socket may come off
during use causing personal injury.
› The torque delivered by the impact
driver depends on how long it is
applied, the size of bit and other
factors such as the state of the battery
charge.
› Use a torque wrench to check that
the bolt has been tightened to the
appropriate level of torque.
› Stop the impact driver before
changing the direction of rotation.
Always release the trigger switch
and wait for the impact driver to stop
before switching the direction of
rotation.
› Never touch the bit whilst it is
turning. Do not let the turning bit get
near your hands or any other part of
your body. You could be cut or caught
up in the socket.
› Do not touch the bit after it has been
in use for an extended period. It could
be hot and burn you.
SHORT CIRCUIT PROTECTION
If the battery pack was to short circuit
the short circuit protector would
immediately stop the battery pack

8
INTENDED USE
The cordless impact driver is designed
to drive and remove screws and to
tighten and loosen nuts and bolts
quickly and efficiently.
This tool is to be used only for its
prescribed purpose. Any other use
is deemed to be a case of misuse.
The user / operator and not the
manufacturer will be liable for any
damage or injuries of any kind caused
as a result of this.
TECHNICAL SPECIFICATIONS
SPECIFICATIONS NG-53A IMPACT DRIVER
Product code 40043
Warranty 3 years
Voltage 12V
Battery type Li-ion 2000mAh
Torque 90N.m
Impact rate 0-3000 BPM
Chuck Quick release hex
No-load speed 0-2200 RPM
Screw size 4 - 8mm
Battery charge time 30 mins
from operating. This will ensure that
no further internal components of the
battery or the tools are damaged.

9
PRODUCT OVERVIEW
IDENTIFICATION
BATTERY AND CHARGER
This tool is compatible with the
NG-6020 battery and NG-61 charger.
1
3
6
42
5
1. Quick release chuck
2. Forward / reverse selector
3. On / off trigger
4. LED light
5. Battery level indicator
6. Battery release button
(battery not included)

10
INSTALLING AND REMOVING
THE BATTERY
Always switch off the impact driver
before insertion or removal of the
battery.
INSTALLING THE BATTERY
1. Hold the impact driver upright and pick
up the battery in your opposite hand.
Place two fingers over the battery release
buttons and insert the battery until it
clicks into place (Fig. 1).
2. Do not use excessive force when
inserting the battery. If the battery does
not slide in easily, it is not being inserted
correctly. It is also possible that there
could be damage to the battery, battery
terminals or the impact driver.
REMOVING THE BATTERY
Press both the battery release buttons on
either side and gently pull the battery out
of the driver.
BATTERY LIFE
The length of service from each charging
cycle will depend on the type of work you
are doing. To obtain the longest possible
battery life, we suggest the following:
› Store and charge your battery in a cool
area. Temperatures above or below normal
room temperature will shorten battery life.
› Never store batteries in an uncharged
condition. Recharge them immediately
after they are uncharged.
Fig.1

11
ASSEMBLY
› All batteries gradually lose their charge.
The higher the temperature the quicker
they lose their charge. If you store your
impact driver for long periods of time
without using it, recharge the batteries
every month or two. This practice will
prolong battery life.
INSTALLING A DRIVER BIT OR SOCKET
1. Pull the quick release chuck forward
(Fig. 2) and insert the hex shank of the
appropriate driver bit or socket into
the quick release chuck.
2. Release the quick release chuck
and slowly pull the driving bit / socket
forward until you feel the ring engage
with the groove in the bit / socket
indicating that the bit / socket is
locked in position (Fig. 3).
3. Check if the bit / socket is correctly
fitted by pulling on it to see if it can be
removed. If it cannot be extracted out
of the quick release chuck, the bit /
socket has been inserted correctly.
4. Select the correct socket for the nut
or bolt you which to tighten or loosen.
A socket that is too large will result in
Warning: Always ensure the
forward / reverse switch is in
the lock position and remove
the battery from the tool before
inserting or removing a bit or
socket or when making any
adjustments to your tool.
!
Quick release
chuck Fig.2
Fig.3
*Bit not included

12
REMOVING A DRIVER BIT
Pull the quick release chuck forward
and remove the driving bit.
slippage or inaccurate and
inconsistent torque, or damage to
the nut or head of the bolt. Insert the
square end of the socket bit into the
socket adaptor.
Warning: If the driving bit is not
properly secured it may be ejected
unexpectedly during operation. This
could potentially cause serious
personal injury or injury to others.
Always ensure the driving bit is
secured properly before beginning
operation.
!
OPERATION
ON / OFF TRIGGER
1. Turn the impact driver ON by pressing
the on / off trigger (Fig. 4).
2. To turn the impact driver OFF release
the on / off trigger.
VARIABLE SPEED
You can vary the speed of the impact
driver by controlling the amount of
pressure applied to the on / off trigger.
The tool reaches its max speed when the
on / off trigger is fully pressed.
Fig.4
On / off trigger

13
Warning: Do not change direction
of rotation unless the tool has
come to a complete stop.
!
Forward / reverse
selector Fig.5
LED LIGHT
› The impact driver has one LED Light
built into the unit (Fig. 6).
› The LED light turns on automatically
when you press the on / off trigger.
› The LED light illuminates dark areas in
tight corners to assist with driving. This
helps achieve a more accurate result in
your work piece.
Fig.6
LED light
CHANGING THE ROTATION DIRECTION
1. The direction of rotation can be
changed with the forward / reverse
selector. This is located above the
on / off trigger (Fig. 5).
2. To select the forward position, push
the forward / reverse selector. To select
the reverse driving position, push the
forward / reverse selector again.
3. The on / off trigger can be locked
off by pushing the forward / reverse
selector into the middle of both the
forward and reverse positions.
4. Do not change the direction of rotation
while the keyless chuck is in motion.

14
USING THE TOOL
1. Insert the correct driving bit or
socket bit (with socket adaptor).
2. Before starting your job, always
perform a test operation in a similar
application using scrap material.
3. When fastening screws sized M8
or smaller, take particular care to
use light pressure on the on / off
trigger switch for fear of damaging
the fixture.
4. Hold the tool pointing straight in line
with the fastener and apply sufficient
forward pressure to stop the bit
from slipping off the fastener.
5. Apply slight pressure to the on /
off trigger to turn on the tool then
increase the speed according to
the circumstances.
6. Do not apply torque for too long
when tightening a screw or nut or it
may become damaged.
MAINTENANCE
› When not in use, the impact driver
should be stored in a dry, frost free
location, out of reach of children.
› Keep ventilation slots of the tool
clean at all times and prevent any
foreign matter from entering.
› After each use, blow air through the
tool housing to ensure it is free from
all dust particles which may build up.
Build up of dust particles may cause
the tool to overheat and fail.
› If the enclosure of the tool requires
cleaning do not use solvents but
a moist soft cloth only. Never let
any liquid get inside the tool; never
immerse any part of the tool into a
liquid.
NOTE: Nova Gear will not be
responsible for any damage or
injuries caused by repair of the
impact driver by an unauthorised
person or by mishandling of the
impact driver.
WASTE DISPOSAL
& RECYCLING
SERVICING
Do not dispose of this product
in household waste!
Please recycle this product
responsibly in accordance with
local and national law.
For information on servicing
and repairs please contact
Spot-on on 1300 658 338 or
visit www.spoton.com.au.

15
WARRANTY
The NG-53A Impact Driver comes with
a 3 year manufacturers warranty.
Our goods come with guarantees that
cannot be excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major
failure and for compensation for any
other reasonably foreseeable loss or
damage. You are also entitled to have
the goods repaired or replaced if the
goods fail to be of acceptable quality
and the failure does not amount to a
major failure.
Separate to the above Australia
Consumer Law, Spot-on offers a global
warranty.
The warranty period commences on
the date of purchase, which can be
verified on your receipt or invoice. We
cannot offer a warranty for damages
and defects on appliances or their
parts caused by improper use or
treatment. Damage caused by failure
to comply with the operating manual
will be excluded from the warranty.
In the event that an unauthorised
persons has modified the appliance,
the warranty will be rendered void.
Damages that are caused by improper
handling are excluded from the
guarantee.
If you have any concerns or wish to
make a warranty claim please contact
your retailer or Spot-on Laser and Tool
Company on 1300 658 338.
Spot-on Laser and Tool Company PTY LTD
10-12 Dowsett Street,
South Geelong, VIC 3220
Australia

Spot-on Laser and Tool Company | 1300 658 338 | www.spoton.com.au
