NOVELLO KYS-367AP User manual

1/ 9
BBQ-ELC-STAND-GREY
Model No: KYS-367AP
INSTRUCTION MANUAL

2/ 9
Before use
Dear customer,
Congratulations and thank you for purchasing this high quality product. Please read the instruction
manual carefully so that you will be able to make the best possible use of the appliance. This manual
includes all the necessary instructions and advice for using, cleaning and maintaining the appliance. If
you follow these instructions you will be guaranteed of an excellent result, it saves you time and will
avoid problems. We hope you will have a great deal of pleasure from using this appliance.
For outdoor use only.
SAFETY INSTRUCTIONS
1. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by children unless they
are older than 8 years and supervised.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
5. Regarding the instructions for cleaning the surfaces which come in contact
with food, please refer to the paragraph “cleaning and maintenance” of the
manual.
6. Only the appropriate connector must be used.
7. The appliance is only for outdoor use.
8. The supply cord should be regularly examined for signs of damage, and if
the cord is damaged, the appliance must not be used.

3/ 9
9. The appliance must be supplied through a residual current device (RCD)
having a rated residual operating current not exceeding 30mA.
10. The appliance is to be connected to a socket-outlet having an earthing
contact (for class I appliances).
11. Keep the appliance and its cord out of reach of children less than 8 years.
12. WARNING!!
Please do not touch surface while in use. The temperature of
accessible surface may be high when the appliance is
operating.
13. Incorrect operation and improper use can damage the appliance and
cause injury to the user.
14. The appliance may be used only for its intended purpose. No
responsibility can be taken for any possible damage caused through
incorrect or improper handling.
15. Before connecting the appliance to the power source, check that the
current and power match those given on the rating plate.
16. Do not put the appliance or the plug in water or any other liquid. However
if the appliance accidently fall into water, unplug the appliance immediately
and have it checked by a qualified person before using it again.
Non-observance could cause a fatal electric shock!
17. Never attempt to open the housing yourself.
18. Do not place any kind of object into the inside of the housing.
19. Do not use the appliance with wet hands, on a damp floor or when the
appliance itself is wet.

4/ 9
20. Do not touch the plug with wet or damp hands.
21. Check the cord and the plug regularly for any possible damage.
22. Do not use the appliance if it is dropped or otherwise damaged or if the
cord or plug is damaged. In the case of damage, take the appliance to an
electrical repair shop for examination and repair if necessary.
23. Never attempt to repair the appliance by yourself. This could cause an
electric shock.
24. Do not allow the cord to hang over sharp edges and keep it well away
from hot objects and naked flames. Remove the plug from the socket only by
holding the plug.
25. Make sure that there is no danger that the cord or extension cord may
inadvertently be pulled or cause anyone to trip when in use.
26. If an extension cord is used it must be suited to the power consumption of
the appliance, otherwise overheating of the extension cord and/or plug may
occur.
27. This unit is not suitable for professional operation.
28. Never leave the appliance unattended while it is in use.
29. Children cannot recognize the dangers involved in the incorrect use of
electrical appliances. Therefore never allow children to use household
appliances without supervision.
30. Always remove the plug from the socket when the appliance is not in use
and each time before it is cleaned.
31. Danger! Nominal voltage is still present in the appliance as long as the
appliance is connected to the mains socket.

5/ 9
32. Switch off the appliance before disconnect from the mains.
33. Never use the cord to carry the appliance.
34. The machine should not be operated by means of an external
timer-switch or by means of a separate system with remote control.
35. The appliance can be operated outdoors in fine weather. But it must
never become wet.
36. Before use, the appliance must be placed on a firm, flat surface and at
least 50 cm away from the nearest wall or any flammable objects.
37. Attention! The appliance is become very hot! It must cool down
completely, before its surface can be touched. Removing and cleaning of the
barbecue grill, the control
unit and the drip tray may only be done after the appliance has cooled down
completely.
38. Charcoal or other combustibles may not be used with this appliance.
39. The appliance must not be stored outdoors.
40. During first use, a small amount of smoke and faint smell might occur.
41. Burn hazard! Be careful when handling hot oil and fat. Beware of spitting
oil and hot steam!
42. Do not move the appliance during use.

6/ 9
ELECTRIC BBQ
MODEL: BBQ-ELC-STAND-GREY (KYS-367AP)
VOLTAGE: 220-240V
FREQUENCY: 50-60Hz
POWER: 1400-1600W
Description
1 Metal grill hood
2 Handle of hood
3 Grill Plate
4 Fat collecting bowl
5 Base of appliance
6 Condiment tray
7 Upper stand tube
8 Decoration
9 Nether stand tube
10AStand foot
10B Stand base
11 Handle of base
12 Opening for appliance socket
13 Detachable temperature
Regulator with cable
14 Temperature indicator lamp
15 Appliance socket
16 Washer
17 Screw
Installation instructions
Install the stand feet
(10A) into the stand
base (10B) properly.
That will be a “click”
sound when the stand
foot is fixed
completely.
Place the washer (16)
onto the stand base.
And then install the
screws (17) into the
washer to fix the stand
feet and stand base
firmly.
Install half of the
threaded rod (a) in the
nether tube (9). Put the
decoration (8) on the
nether tube (9) and
assemble both tubes
together; ensure that
they are fixed well.
Connect the grill stand
base (10) and the
nether tube (9)
together to form the
complete grill stand.
(The grill can be used
with or without this
stand).

7/ 9
Install the screw (b)
into upper tube (7),
and then put the
condiment tray on the
upper tube (Making
sure that the tray is
fixed well)
Place the bowl-shaped
base of the appliance
(5) onto the grill stand.
(Making sure that the
grill stand is placed on
a dry flat, stable
surface).
Put the fat collecting
bowl (4) into the
bracket supplied for it
in the base of the
appliance; buckle the
hole of fat collecting
bowl onto the screw to
fix it well. (The flat
collecting bowl can be
filled with little water to
make it easier to
clean).
Place the grill plate (3)
on the base of the
appliance (5). First of
all insert the appliance
socket (15) into the
opening intended for it
(12), then set the grill
plate horizontally on
the appliance base.
Install the handle (2) to
the metal hood with
the screw (d) and hook
(c). Then place the
hood on the grill plate.
Push the detachable
temperature regulator
(13) as far as it will go
into the grill’s
appliance socket
The metal hood (2)
can be opened and
placed on the side by
being hooked up on
the edge of grill plate

8/ 9
Before using the appliance for the first time
Remove all the packaging materials
Please remove the 4 plastic mats before use. (Plastic mat)
And wash the grill plate (3), fat collecting bowl (4) and metal grill hood (1) thoroughly.
Important: Dry all the different parts thoroughly. This applies especially to the appliance socket
(15) .Never immerse the detachable temperature regulator (13) in water.
Heat the grill to its maximum setting for about 3-5 minutes, with the metal grill hood closed and
without putting any food on it.
The appliance may emit some smoke and a characteristic smell when you switch it on for the
first time. This is normal and will stop soon.
Operating the appliance
Connect the appliance to the mains electricity supply.
Set the temperature regulator (13) to the required temperature level (it usually takes about 3 minutes
to heat up).
The temperature indicator lamp (14) will go out as soon as the required temperature has been
reached.
Place the food to be grilled on the grill plate (3)
Cooking times
The following are recommended cooking times for reference only. Different times will be required for
different weights and sizes of foods to be grilled, and depending on whether you are grilling with or
without the metal grill hood.
Food to be grilled
Temperature grade setting
Cooking time
Steak/beef
5
15-20 mins
Lamb
5
12-18 mins
Chicken drumsticks
5
25-30 mins
Chops
5
20-25 mins
Chicken wings
5
15-20 mins
Fillet of pork
4-5
9-10 mins
Whole fish
5
12-15 mins
Kebabs
3-4
10-12 mins
Various sausages
3-4
12-15 mins

9/ 9
Tips for grilling
Your meat will be tendered if you marinade it overnight before cooking (the marinade is always made
of oil (to and moistness), vinegar (to tenderize) and a mixture of seasonings).
Always use tongs or some form of scoop to turn the grilled food (using a fork to turn the food will dry it
out and damage the non-stick coating).
Only turn meat and fish once during grilling. You do not need to turn it more than once and too much
turning dries food out.
Never cook meat for too long. Even pork is better if it is served when it is still somewhat pink and
juicy.
If cooked food sticks to the grill plate, rub the plate with a piece of kitchen paper soaked in oil from
time to time.
Cleaning and looking after the appliance
Disconnect the appliance from the mains electricity supply.
Allow the grill to cool completely.
Take the detachable temperature regulator (13) out of the appliance socket.
Clean the grill plate (3) and grease collecting bowl (4) with warm washing-up water and damp
cloth. Do not use steel wool pads, brush or abrasives to avoid any damages to the coating of
grill.
Wipe the base of the appliance (5) with a damp cloth. Fat splashes can be removed with a mild
cleaning agent.
Note:The grill plate has a non-stick coating. Do not scratch this coating during either the
grilling or the cleaning stages.
Tip: Protect the appliance from dust and dirt if it is not to be used for a prolonged length of time (wrap it
in a plastic bag). Store it in a dry place.
Disposal
Disable unserviceable appliances immediately. Remove the mains plug and cut up the mains
connection cable. If possible, bring unserviceable appliances to an official waste collection point. Most
local authorities provide removal services for bulky refuse at least once a year.
