VC50/75A ASSEMBLY
VC50/75AASSEMBLY PROCEDURES
Tools Required: Knife or Scissors, Hammer, 7/16” (11 mm) wrench/ratchet or an adjustable wrench,
Step 1: Unpack carton
Use the knife or scissors to cut the strapping on the package then lift off the cardboard cap.
Remove the cardboard sleeve by lifting it straight over top of the barbecue. Check the 4 enclosed
parts kits, 3 boxes outside the grill, and 1 box inside, against the parts list (Appendix A) to ensure
that no parts are missing.
Page 1
Philips or Robertson screwdriver.
Box
#
1
Box
#
2
Box
#
4
Box
#
3

VC50/75A ASSEMBLY
Step 2: Assemble Legs
Required: The Main Grill Unit, (2) Right Legs,
(2) Left Legs, (8) 1/4” x 1-3/4” Hex Head Bolts.
Carefully remove the grill unit from the carton bottom,
and lay it on its back (use the flattened carton cap as a
protective surface). This is best performed with 2
people (use of gloves is recommended). Ensure the
front lid does not fall open while moving the unit.
Allow the lid to rest partially open once the unit is on
its back.
Remove and discard the 2 shipping brackets and bolts
from the bottom of the unit by removing the 4 bolts
holding them to the base. Also remove and discard the
4 bolts above these (fig 2A).Attach the two right legs
(with the large hole at the bottom end) to the right side
of the base using (4) 1/4” x 1-3/4” bolts. Ensure that the
sides with the 2 small holes, about 6 inches from each
end, are facing inwards. Tighten the bolts only finger tight
(Fig 2B). Repeat for the left legs.
Page 2
Fig. 2A
Fig. 2B
Shipping
Brackets
VERMONT
C
astings
Remove
Bolts
VERMONT
C
astings

VC50/75A ASSEMBLY
Step 3: Assemble Bottom
Required: Bottom Pan, (4) 1/4” x 1-3/4” Hex Head Bolts, (4) 1/4 ” Hex Nuts, (4) 1/4” Washers, (for pro-
pane models only – the Lower Tank Bracket, (2) 1/2” self tap screws, (2) 1/4” Washers only.
Assemble the Bottom Pan to the legs with 4 bolts and nuts as shown. Ensure the side with 5 holes at the
edge is facing up towards the front of the grill (Fig 3A). For propane models, also attach the lower tank
bracket to the right end, no washers are required (Fig 3B). Assemble the top flange of the lower tank
bracket to the bottom pan with (2) self tap screws. Tighten the fasteners.
Page 3
Fig. 3A Fig. 3B
VERMONTVERMONT
C
astings

VC50/75A ASSEMBLY
Step 4: Assemble casters, wheels and upper door support
Required: (2) Caster Inserts, (2) Casters, (2) Wheels, Axle, (2) Axle Caps, Upper Door Support, (2) 1/2” self
tap screws.
Place a caster insert into the bottom of each left leg, and lightly tap into place with a hammer. Snap the
casters into the inserts (Fig 4A).
Tap an axle cap onto 1 end of the axle. Slide a wheel onto the axle flush against the cap. Insert the end of the
axle down through the large holes at the bottom of the right legs. Lift the bottom of the legs up enough to
place the other wheel onto the axle (Fig 4B).
Install the upper door support to the front corners of the grill base with 2 self-tapping screws (Fig 4C).
Carefully lift the grill assembly off its back onto the wheels and casters (2 people). Tap the other axle cap
onto the axle.
Page 4
Fig. 4A Fig. 4B
Fig. 4C
Cap
Wheel
Axle
Caster
Insert
Self Tap Screw
Self Tap
Screw

VC50/75A ASSEMBLY
Page 5
Fig. 5
Step 5: Assemble Shelf Supports
Required: (2) Left Shelf Supports, (2) Right Shelf Supports.
Attach a right and left shelf support to the right side by loosening the 4 leg bolts (2 to 3 turns only) so that
the supports can be slid over the bolt heads. Push the supports down fully, ensuring undersides of supports
are resting on top of the legs, then tighten the bolts. Repeat for left side (Fig 5).
.

VC50/75A ASSEMBLY
VC50/75 ASSEMBLY
Step 6: Install Front Panels and Door
Required: Front door, (2) leg panels, (8) self tap screws, (2) shoulder screws, (1) nylon insert nut.
Fasten the two leg panels to the bottom pan (from behind the panels) with 2 screws each, then to the upper
door support with (2) screws each (fig 6A).
Snap the nylon insert nut into the square hole at the left side of the bottom pan opening. Assemble the door
by inserting the top hinge pin at the left side of the upper door support into the hole in the top door flange,
then attach the bottom left flange of the door to the insert nut in bottom pan with the shoulder screw (Fig
6B). The door should swing freely. Screw 2 nd Shoulder screw into base panel to act as a door stop (locate
at right side of door).
Page 6
Fig. 6A
Fig. 6B
VERMONT
Castings

VC50/75A ASSEMBLY
Step 7: Install grease pan and cup
Required: grease pan, grease cup, grease cup holder.
Assemble the grease pan into position at the bottom
of the grill base from the left side. The base has a
guide track so the pan can easily slide in and out.
Start the narrow end of the pan into the track, and
slide in half way.
Insert a grease cup into the cup holder, then hook
the holder onto the slots at the end of the pan.
Slide the pan in fully (Fig 7).
Step 8: Assemble Base Side Panels
Required: (2) Base side Panels, Rear Panel, (4/8*) shoulder screws, (10/6*) self tap screws. *Natural models
Screw (2) shoulder screws into the inside face of each left leg. Attach the base panel to the left side by
hooking the four slots in the edges of the panel over the shoulder screws, and pushing the panel downwards
(Fig 8A). Repeat for the right side if the grill is a natural gas model. If the grill is an LP model, assemble the
concave right base panel to the right legs with (4) self-tapping screws (Fig 8B). Ensure the propane regula-
tor is outside the panel, with the hose in the notch at the upper left corner of the panel. This panel is not
removable like the left panel (Fig. 8C).
Insert the bottom panels of the cabinet by placing the lips of the panels on the front and rear leg brace. For
Propane Models, the panel with the holes is to be placed on the right and secured with four self-tapping
screws.
VC50/75 ASSEMBLY
Page 7
Fig. 7
Fig. 8A Fig. 8B
Hand Hold
(Lift Up and Pull Out)
2
1
Shoulder
Screws
Fig. 8C
Shoulder
Screws
Grease
Pan
Grease
Cup Holder
Grease Cup

VC50/75A ASSEMBLY
Step 9: Attach Side Shelves and Front Tool Holders
Required: (2) Side Shelves, (2) front tool holders, (8) # 10 x 1/2” bolts, (8) # 10 locknuts, (4) nylon insert
nuts, (4) self tap screws.
Assemble the side shelves to the shelf supports by positioning them up from below the supports. Ensure that
the long edge with 2 small holes face towards the grill. Once aligned, attach with (4) bolts and (4) locknuts
each (Fig 9A).
Insert (4) nylon insert nuts into the square holes in the front of the shelf supports. Hook the left and right
toolholders over the corresponding shelf supports, and attach with (2) self-tap screws each (Fig 9B).
Page 8
Step 10: Attach Handles
Required: front door handle and screws, Handle grip (top and Bottom), (2) # 4 x3/4” screws.
Assemble the door handle with (2) screws provided (Fig 10A).
Install lid handle grips to the handle by snapping them together around the handle, then securing
them with (2) screws (fig 10B).
.
Fig. 9A Fig. 9B
Fig. 10A
VERMONT
Castings
Fig. 10B

VC50/75A ASSEMBLY
Page 9
Step 11: Install Sear Plates, Cooking Grates, Warming Rack
Required: (2) sear plates, (3) cooking grates, warming rack.
Place the sear plates into the grill base ensuring their
edges are facing downward. The sides with the narrower
edges face should be in the center (if the plates have
arrows stamped in them, they should point to each other).
Position the three cooking grates in the base with the
finger holes towards the front. Slip the rear lip of the
warming rack into the two supports extending up at
the rear of the base (rotisserie burner housing model
VC75). Tilt it down to rest in a level position (Fig 11)
Step 12: Propane Models- Assemble Cylinder Brackets
Required: Upper tank bracket, tank clip, (2) # 10 x 1/2” bolts, (2) # 10 locknuts, (1) carriage bolt, (1) wing nut.
Attach the upper tank bracket to the lower right end
of the grill base with (2) nuts and bolts. For model
VC75, be careful not to pinch the rotisserie electrode
wire behind this bracket.
Loosely attach the tank clip to the upper bracket
with the carriage bolt and wing nut (Fig 12)
Fig. 12
Sear
Plates (2)
Cooking
Grates (3)
Finger
Hole
Warming
Rack (1)
Fig. 11

VC50/75A ASSEMBLY
Page 10
Step 13: Propane Models- Assemble Gas Cylinder
Required: Cylinder (not supplied).
Hook bottom cylinder ring over lower tank bracket, swing cylinder up and slide tank clip down over
cylinder top handle. Tighten tank clip wing nut. Ensure cylinder valve is facing towards the front (Fig 13).
Fig. 13

VC50/75A ASSEMBLY
Page 11
APPENDIXA
Box 1:
Cooking Grates (3)
Bottom Pan (1)
Side Shelf (2)
Base Panel –Side (2)* (1)**
Base Panel RH (0)* (1)**
Door -50 Black (1)
Leg Panel (2)
Bracket Tank Lower (1)**
Bracket Tank Upper (1)**
Clip Tank (1)**
Hardware Bag L.P.**
* Natural Models
** LP Models
Box 2:
Grease Pan (1)
Caster (2)
Caster Insert (2)
Wheel (2)
Axle (1)
Grease Cup Holder (1)
Grease Cup (2)
Warming Rack (1)
Hardware Bag (1)
Handle –Door (1)
Handle Grip Bottom (1)
Handle Grip Top (1)
Box 3:
Leg Left (2)
Leg Right (2)
Door Support Assembly (1)
Box 4:
Heat Plate (2)
Angle Brace Leg R (2)
Angle Brace Leg L (2)
Front Tool Rack Left (1)
Front Tool Rack Right (1)
Hardware Bag: (All Models)
(2) Axle Caps
(10) #8-18
Shoulder Screws
(18) #8-18
Self Tapping Screws
(8) #10-24 Lock Nuts
(2) #4 x 3/4 Screws
(8) #10-24 x 1/2” Bolts
(4) #10-24 Hex Nuts
(12) 1/4-20 x 1-3/4”
Hex Head Bolts
(Parts not available separately)
(5) Insert nuts
(4) 1/4” Washers
(6) #8-18
Self Tapping Screws
(2) #10-24 Lock Nuts
(2) #10-24 x 1/2’ Bolts
Hardware Bag: (L.P. Models)
(1) 5/16 x 3/4”
Carriage Bolt
(1) 5/16 - 18 Wing Nut

VC50/75A ASSEMBLY
Page 12
VC50/75AASSEMBLY DRAWING
58
57 56
55
54 53 52
51
50
49
48
47
46
44
43
42
41
40
39
38
37
36 35
34
33
32
31
30
29
28
27
26
25
23
22
21
20
19
18
17
16
15
14
13
12
10
9
7
6
5
4 3
2
1
11

VC50/75A ASSEMBLY
Page 13
ITEM QTY QTY PART NO. DESCRIPTION
1 1 1 50000899 BASE ASSEMBLY
2 2 2 50000079 LEG, LEFT
3 2 2 50000084 LEG, RIGHT
4 1 1 50000494 PANEL, BOTTOM
5 1 1* 50000495 BRACKET, TANK LOWER
6 2 2 50000493 ANGLE BRACE LEG LEFT
7 2 2 50000492 ANGLE BRACE LEG RIGHT
9a Opt Opt VCSB2AP SIDE BURNER 50/75 –LP
9b Opt Opt VCSB2AN SIDE BURNER 50/75 – NG
10 2 2 50000498 SHELF SIDE CHARCOAL
11 4 4 50000402 BRACKET LEG BOLT
12 1 1 50000024 HEAT SHIELD CONSOLE
13 1 1 50000043 FLASH TUBE
14 1 1 50000487 GREASE PAN ALZ’D
15a - 1 50000542 CONSOLE 75 BLK
15b 1 - 50000486 CONSOLE 50 BLK
16 2 2 50000038 BURNER MAIN ASSEMBLY
17 1 1 50000093 AXLE
18 1 1 50000360 WHEEL (2)
19a - 1 50000562 VALVE/MANIFOLD 75 LP
19b - 1 50000917 VALVE/MANIFOLD 75 NG
19c 1 - 50000551 VALVE/MANIFOLD 50 LP
19d 1 - 50000916 VALVE/MANIFOLD 50 NG
20 1 1 50000297 END STOP
21 1 1 50000556 DOOR SUPPORTASSEMBLY 50
22 2 2 50000028 PLATE HEAT
23a 3 3 50000294 STEEL COOK GRATE
23b Opt Opt VCCG1A CAST IRON COOK GRATES SET
25 1 1 50000359 CASTER INSERT SET
26 1 1 50000359 CASTER SET
27 2 2 50000520 LEG PANEL 50
28 2 (1*) 2 (1*) 50000517 BASE PANEL SIDE 50
29 1* 1* 50000496 BRACKET TANK UPPER
30 1* 1* 50000497 CLIP TANK
31 1 1 50000927 FRONT EDGE BASE 50
32 1* 1* 50000521 BASE PANEL RIGHT LP
33 1 1 50000474 LID ASSEMBLY REAR BLACK
34 1 1 50000365 LID BUMPERS (6)
35 1 1 50000554 TOOL RACK FRONT RIGHT
36 1 1 50000587 DOOR BLACK 50
37a 1 1 50000478 LID ASSEMBLY FRONT BLACK 50
37b 1 1 50000505 LID ASSEMBLY FRONT GREEN50
38 1 1 50000967 GAUGE TEMP
39 1 1 50000007 LOGO
40 1 1 50000355 PIVOT BOLT SET
41a 1 1 50000434 HOUSING ROTISSERIE
41b 1 - 50000298 PLATE-ROTISS COVER
42 1 1 50000261 WARMING RACK
43 2 2 50000499 GASKET MAIN BURNER
44a 1 1 50000358 IGNITOR ROTARY 3 TERM KIT
44b - 1 50000367 IGNITOR ROTARY 2 TERM KIT
46 1 2 50000073 WIRE GROUND
47 1 1 50000361 GREASE CUP HOLDER & CUPS (2)
48a 1 1 50000524 HANDLE GRIP BOTTOM
48b 1 1 50000525 HANDLE GRIP TOP (WITH LOGO)
49 1 1 50000488 PANEL REAR UPPER (50)
50 1 1 50000553 TOOL RACK FRONT LEFT
51 2 3 50000076 KNOB CONTROL
52 - 1 50000436 SCREEN ROTISSERIE
53 - 1 50000437 DEFLECTOR REAR ROTISSERIE
54 - 1 50000528 FACE PLATE ASSEMBLY
55 - 1 50000047 BURNER ROTISSERIE ASSEMBLY
56a - 1 50000543 TUBE/TIP ASSEMBLY 75 ROTISS 1.15
56b 50000568 TUBE /TIP ASSEMBLY 75 ROTISS #51
57 - 1 50000075 ELECTRODE ROTISSERIE
58 2 2 50000071 ELECTRODE MAIN SHORT
1 1 50000552 REGULATOR QD ASSEMBLY
1 1 50000198 HOSE 12’ BBQ NAT GAS
1 1 50000915 CONNECTOR HOSE Q.D ASSEM
1 1 50000135 HANDLE DOOR
1 1 50000501 HARDWARE BAG – COMMON
1 1 50000491 HARDWARE BAG – LP
1 - 50000305 DECAL CONSOLE VC 50
1 - 50000563 DECAL CONSOLE VC 75
* LP Models only
VC50 VC75 VC50/75A PARTS LIST
1ROTISSERIE SMOKER SET
50000747
1
PARTS NOT SHOWN

VC50/75A ASSEMBLY
50000928
Rev. 1 0402
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.vermontcastings.com
Vermont Castings, Majestic Products
