Novus WS10 User manual

NOVUS AUTOMATION 1/33
Web Server – WS10
INSTRUCTIONS MANUAL V2.0x B 5000702
INDEX
Index........................................................................................................................................................................................................ 1
Basic Functions ....................................................................................................................................................................................... 2
Electrical Connections............................................................................................................................................................................. 4
WS10 configuration ................................................................................................................................................................................. 6
Local inputs and outputs configurations..................................................................................................................................................
Modbus RTU network configuration – WS10 as master ....................................................................................................................... 12
Alarms supervision configuration .......................................................................................................................................................... 14
Data logger configuration ...................................................................................................................................................................... 15
HTML Page server configuration........................................................................................................................................................... 17
Periodical data transmission configuration............................................................................................................................................ 20
E-mail configuration............................................................................................................................................................................... 22
Modbus RTU Network configuration – WS10 as slave ......................................................................................................................... 24
Modbus TCP network configuration – WS10 as server or gateway...................................................................................................... 25
Configuring the modem to start a data call – PPP client....................................................................................................................... 27
Configuring the modem to receive a data call – PPP Server ................................................................................................................ 2
DNS Configuration................................................................................................................................................................................. 30
Secutity issues on the WS10................................................................................................................................................................. 31
Specifications ........................................................................................................................................................................................ 32
Appendix A ............................................................................................................................................................................................ 33

Web Server – WS10
NOVUS AUTOMATION 2/33
BASIC FUNCTIONS
The WS10 Web Server by Novus is an equipment capable of acquiring and delivering data using the internet technologies. Local and remote
systems supervision, alarm notification and data logging are easy to configure and operate, with no dedicated software.
DATA ACQUISITION
The WS10 gets data from the system or process through:
•4 built-in signal inputs
•RS232 or RS485 serial communication interface
Data acquisition over the RS485 communication interface uses the Modbus RTU protocol. The WS10 acts as a master, polling the Modbus network
nodes to get the specified data to its memory.
All the data acquired from its local inputs and from external Modbus devices are stored on the WS10 memory. The user can assign identifiers for
each memory position. On the configurations of the data access functions, all registers are referenced by their names.
R GIST RS
Registers are memory locations in the WS10 that contain:
•Instantaneous input or output values read or written to the WS10 built-in signal inputs.
•Instantaneous values, read from or written to, the equipments connected to the Modbus RTU network.;
•Instantaneous memory values, used to control WS10´s functions, not directly connected to the physical inputs or outputs;
•The instantaneous values corresponding to the current alarms situation.
Each register has an identifier composed by a Device Name and a Tag Name. This identifier is used as a reference to the register when configuring
the WS10 functions:
Device
N
ame
/Tag
Regist
er
For registers access using ModbusTCP and ModbusRTU-Slave, numerical addresses must be assigned to the registers. These addresses may be
defined in file MAP.CFG, described on chapter ModbusTCP.
DATA LOGGING
The WS10 can be configures to periodically log the values of a group of registers on its Flash memory. This historical logging can be sent out by e-
mail or directly to a computer. This function allows the WS10 to act as a Data Logger for the variables read from the equipments in the Modbus
network or from its built-in signal inputs. On a remote supervision system, this function enables the WS10 to monitor the process and send the
acquired data periodically or when the communication link is established.
R MOT DATA ACC SS
The instantaneous and historical values acquired from the system or process can be accessed by different physical ways:
•Ethernet interface;
•RS232, RS485 serial interface or Modem (conventional or mobile).
The WS10 offers five basic applications for remote data access of its registers.
•WebServer;
•Modbus TCP or Modbus RTU;
•Alarm conditions supervision;
•E-mail transmission;
•Periodical data transmission.
The WS10´s multi-task operating system allows for the simultaneous utilization of all these applications
HTML PAG S RV R APPLICATION
In this application, the WS10 presents the acquired data of the process in dynamic user-created HTML pages, that can be visualized by any
computer using a Internet browser (Netscape, Internet Explorer, etc).
The WS10, connected to the company’s intranet by its Ethernet interface, shares the information (application data) to any computer connected to
the intranet, allowing both readings and writings of data, with or without password authorization.
In a remote application, a WS10 connected to a conventional or mobile modem can answer a "dial-up" call connection and present a supervision
page to the internet browser of the computer that originated the call, allowing the supervision of remote units.
MODBUS TCP
The WS10 can be configured as a ModbusTCP server and gateway, enabling integration to SCADA supervisory systems. As a server, WS10
accepts connections from multiple SCADA clients, allowing read and write access to its internal registers. This registers are associated to WS10’s
local I/O, memory positions or external ModbusRTU devices. As a gateway, WS10 forwards messages between ModbusTCP and ModbusRTU
networks, acting as a protocol converter. Both modes may be used simultaneously, while all other WS10 functions remain fully functional.
ModbusTCP communication can be used over Ethernet or phone line (fixed or mobile).

Web Server – WS10
NOVUS AUTOMATION 3/33
ALARM SUP RVISION
In this application, the WS10 continuously compares the content of its registers against user programmed limits. The result of this comparison is
assigned to a new register that can be used to trigger a local output, write in a remote equipment through the Modbus RTU, send an e-mail or send
information to a remote server.
TRANSMISSION OF -MAIL OR MOBIL PHON M SSAG S
The WS10 can be configured to send e-mails automatically to an address list. The transmission can be periodical or by exception, based on
register values. The e-mails are sent through the Ethernet or Modem and have a dynamic content, sending process data to the recipient. The
message sending to cell phones can be done by email (depending on the routing service offered by the mobile phone operator) or directly to a
GSM modem connected to the WS10. The e-mail may include, as an attached file, the historical data stored in its memory.
P RIODICAL DATA TRANSMISSION
The data acquired by the WS10 can be sent periodically to any accessible computer in the Ethernet or Internet (using a conventional or mobile
Modem), being received by a TCP server application and stored in a place and format defined by the user. Both instantaneous and historical
register values can be sent to the remote server.
APPLICATION TOPOLOGY
LOCAL OP RATION
Connected to a local network, WS10 can bridge a ModbusRTU network to existing SCADA using Ethernet, expanding data accessibility to virtually
all networked computers using internet browser. WS10 can also log historical data, monitor alarm conditions and send e-mail messages in
periodical or exception basis. WS10 is an alternative to SCADA in small applications. When the network connection to the internet is properly
configured, WS10 data can be accessed from external locations, both by SCADA systems and browsers. The following figure shows WS10 in local
application.
R MOT OP RATION
Installed on a remote site, WS10 can connect trough a modem to a fixed (optional internal modem) or cellular phone line. Using this connection,
WS10 can access internet and send e-mail messages on abnormal conditions or periodically. WS10 can also transfer historical data to a networked
computer. Its ability to answer data calls allows dial-up access using SCADA or browser. Remotely installed, WS10 allows additions functionalities
when compared to conventional remote units that can only transfer data periodically. The following figure shows WS10 in a remote application.
CONFIGURATION
The WS10 configuration is accomplished with usual Internet tools available in most computers: Telnet and FTP (File Transfer Protocol). Telnet is
used for IP address configuration, and FTP it is used for transferring the configuration files to the WS10.
The various functions of the WS10 are enabled by the presence of the correspondent configuration files, containing the parameters required for
configuring an application.

Web Server – WS10
NOVUS AUTOMATION 4/33
ELECTRICAL CONNECTIONS
POW R SUPPLY
Terminals 17 and 18 are the power supply inputs of the WS10, accepting any voltage input between 100 and 240 Vac. A few seconds after power-
on the STATUS indicator blinks, indicating the WS10 is running.
The mains power should be one proper for instrumentation or computers.
INPUTS
The built-in WS10 inputs can be used to measure the following types of signals:
•Analog voltage between 0 to 5 V
•Analog current between 0 to 20 mA (or 4 to 20 mA with 20 % resolution loss)
•Digital logic level: Level 0 for signals between 0 and 1V, Level 1 for signals between 4 and 5 V.
•Dry contact digital signal.
The connections are done on terminals 1 to 8, observing voltage limits and polarities. Sensor cables should run separately from power signals, in
grounded conduits.
The selection between digital and analog inputs, as well as the setting of the ranges for these inputs, are described in the section Configuration of
local inputs. For current type inputs, it is required to change internal jumpers in the WS10.
For the digital inputs, it is possible to associate a function for pulse integration, useful with flow transducers with pulse output. For more information,
refer to Configuration of local inputs and outputs.
HARDWAR CONFIGURATION FOR CURR NT INPUT
For the mA inputs, it is necessary to short circuit internal jumpers in the WS10. There is a separate jumper for each input.
Attention: The following actions require the work of a skilled hardware technician. Use appropriate soldering iron and solder.
1. Open the WS10 back cover.
2. Find the locations of jumpers J1, J2, J3 e J4. The jumpers are identified as follows.
Jumper Input Opened Closed
J2 Input 1
J3 Input 2
J4 Input 3
J1 Input 4
Voltage or switch Current
3. Using solder, close or open the jumper that corresponds to the desired input and function.
4. Re-install the WS10 back cover.
OUTPUTS
The WS10 has 2 relay outputs with SPST contacts: Output 1 (terminals 10 and 12) and Output 2 (terminals 13 and 15). Wiring and loads must
comprise the specification.
Noise suppressors (RC filters) should be installed in parallel to contactors and solenoids coils driven by the WS10 or placed close to it.
S RIAL INT RFAC S
The WS10 provides up to 2 serial communication interfaces. The label placed in the WS10 lateral side identifies the installed serial interfaces.
The SERIAL 1 interface is used to communicate with remote equipment using the master Modbus RTU protocol. It is usually an RS485 interface.
The SERIAL 2 interface is intended for communicating with Modems, either internal (provided as an optional) or external. This interface can be
configured to allow access to the WS10 configuration functions. In the standard WS10 configuration, SERIAL 2 is a RS232 interface.
The figure below shows the RJ12 terminal assignments for the SERIAL 1 and SERIAL 2 interfaces.
Terminal RS232 RS485 Modem interno
1 +5 V / 20 mA Output +5V / 20 mA Output -
2 Signal GND Signal GND -
3 CTS - Telephone lime
4 RxD - Telephone lime
5 TxD D1 (or D) -
Internal connector view 6 RTS D0 (or D\) -

Web Server – WS10
NOVUS AUTOMATION 5/33
USING TH RS232 WITH RS232/RS485 CONV RT RS
The WS10 is ready to accept an external RS232 / 485 converter on its SERIAL 2 (RS232) communication port. Converters like the Novus ISO485-1
and ISO485-2, in the RTS mode, can be used. The DTR signal is kept fixed in +5V and used to power the RS232 side of the converter. The CTS
signal is also kept fixed in +5 V to enable the WS10 for transmitting. The RJ12 to DB or DB25 cable adaptor is described in the table below. It is
necessary to wire all the signals as shown.
RJ12 Male DB9 Male DB25 Description
1 4 20 DTR – Fixed in +5 V
2 5 7 Comum
3 4 20 CTS – Fixed in +5 V
4 2 3 RXD
5 3 2 TXD
6 7 4 RTS
USING TH RS232 WITH AN XT RNAL MOD M
External Modems can be connected to the RS232 serial port of the WS10. A cable connecting the RJ12 to the DB and DB25 connectors needs to
be assembled, following the descriptions of the table below. The configuration shown implements the RTS/CTS flow control.
RJ12 Male DB9 Male DB25 Description
1 4 20 DTR – Fixed in +5 V
2 5 7 Comum
3 8 5 CTS
4 2 3 RXD
5 3 2 TXD
6 7 4 RTS
TH RN T
The Ethernet connection follows the RJ45 Standard. It is recommended to use category 5 cables. For direct connection of the WS10 to a
computer, use cross wiring. When a hub or switch is used, use conventional wiring.

Web Server – WS10
NOVUS AUTOMATION 6/33
WS10 CONFIGURATION
Installing and configuring the WS10 require networking e pertise. Consult your company’s network administrator.
G N RAL INFORMATION
The WS10 configuration is accomplished through the Ethernet interface making use of ordinary network programs: FTP (File Transfer Protocol – for
transferring files to/from the WS10) and Telnet (to access the configuration console). The FTP is normally provided with the Internet navigators
(Internet Explorer or Netscape); other FTP programs can also be used. The Telnet application is available in the operating system of your
computer, although other Telnet client applications can be used.
In order to configure the WS10, it must be powered and connected to the Ethernet though a hub or switch, or directly to the Ethernet interface of a
computer (in this case a cross cable must be used). The WS10 IP address must be known to get FTP or Telnet access to the WS10.
The WS10 factory settings are:
IP = 192.168.200.200
NetMask = 255.255.255.0
Gateway = 192.168.200.1
DHCP disabled
The computer used to access the WS10 must be on the same sub-network of the WS10. To access the WS10 with the factory settings, the IP
addressing configuration of the computer must be:
IP = 1 2.168.200.xxx (where xxx can be any value except 200, already assigned to the WS10)
NetMask = 255.255.255.0
T LN T CONFIGURATION
To change IP configurations, it is necessary to establish a Telnet connection with the WS10 to get access to configuration console. Run your
preferred Telnet application and connect your computer to the WS10 IP address, using the Telnet standard port. When the WS10 is found, the
message “Novus WS10 Telnet Session” is presented. The WS10 prompts for Username and password. The factory values are:
Username: telnet
Password: telnet
Once connected, the message “ ser logged in” is showed indicating the connection success. With the Telnet application running, the WS10 gives
access to commands similar to the ones of the DOS operating system. The commands are executed when the Enter key is pressed
Through the Telnet console, a user can modify important configurations in the WS10. Only capable users should use this
feature. Use only the commands listed on this section.
The following commands are related to the configuration of the WS10 IP address and may be needed in the configuration process.
IPCFG: Shows current IP address.
IP aaa.bbb.ccc.ddd: Defines a new IP address for the WS10.
N TMASK aaa.bbb.ccc.ddd: Defines a new subnet mask for the WS10.
GAT WAY aaa.bbb.ccc.ddd: Defines the gateway address.
DHCP n: n = 0 disables the dynamic addressing through DHCP; n = 1 enables dynamic addressing.
R BOOT: forces the WS10 reboot. A new IP address is effective only after the reboot. Following the reboot, the Telnet connection is lost. To
re-establish the connection, use the new IP address. In the case of the new IP address falls in another subnet, it will be necessary to change
the address of the computer used in the configuration to this same subnet.
WS10 –v: Shows the Web Server software version.
The same console commands may be available on the SERIAL 2 communication port, provided it is RS232 and is not being used as a PPP client
or Server. Factory settings for the communication parameters are: Baud Rate 1 200 bps, no parity, 8 bits, 1 stop bit. Use a RS232 cable and PC
serial communication program to communicate over this port. This feature may be factory disabled depending on the WS10 version and hardware
options.
FIL TRANSF R USING FTP
The configuration of the WS10 is defined by text files stored in its memory. These files can be transferred to a computer, modified, and copied back
into the WS10. The new configurations will be effective when the WS10 is rebooted. The WS10 incorporates a FTP Server compatible to the
majority of the FTP clients available, like the ones provided with the navigators Internet Explorer and Netscape. The Windows Explorer can also be
used for this purpose.
To establish a FTP connection with the WS10, write the WS10 IP address in the navigator address bar, as shown below:
If prompted, inform username and password. The FTP factory settings are:
Username: ftp
Password: ftp
The WS10 factory settings allow anonymous FTP connection also.
The WS10 internal files and directories are shown. It is possible to drag the files and directories from the WS10 to any other local directory or
network location, and the other way around.
Configuration files that require modification can be copied to a computer temporary directory, edited, saved and stored back in the WS10. The
modifications performed on the configuration files will become effective in the next boot.
In some navigators, the FTP access may refuse connection even with the correct password. The way around is to inform username and password
along with the IP address. The example below illustrates this procedure for username user and password pass:
ftp://user:[email protected]

Web Server – WS10
NOVUS AUTOMATION 7/33
If the error persists, not allowing the FTP connection, perform a WS10 reboot and try again using the username and password in the address line
as suggested above.
To solve further FTP connection errors, we recommend the usage of dedicated FTP client software. There are many shareware and freeware
options available for download on the Internet. In the WS10 CD are included some of these FTP softwares.
CONFIGURATION OF TH IP ADDR SS
The IP address is used in every communication with the WS10. The IP address must be known and properly kept.
The WS10 with an unknown IP address is useless. Novus provides a low level IP detection program to scan the network
looking for a WS10 with unknown IP address.
Once in the Ethernet, the WS10 can only be accessed by computers in the same subnet. So, the computer used to access the WS10 must have its
address in the same subnet address range of the WS10. If not, the computer must be temporarily addressed to the same WS10 subnet, returning
to its original configuration after the configuration is completed.
PROC DUR S FOR GIVING TH WS10 A FIX D IP ADDR SS
The following steps are required to assign a new IP address to the WS10:
•Get from the network administrator a IP address for the WS10 and the configurations for the Gateway and subnet mask.
•Establish a Telnet connection with the WS10 using its current IP address. The computer must belong to the same WS10 subnet.
•Disable the WS10 DHCP client typing: DHCP 0 and Enter.
•Type a new IP address and Enter. Example: IP 10.1.1.80
•Configure the subnet mask typing NETMASK followed by the mask and Enter. Example: NETMASK 255.255.255.0
•Configure the gateway address by typing GATEWAY followed by the address. Example: GATEWAY 10.1.1.1
•Re-initialize the WS10 by typing REBOOT followed by Enter.
•Upon reboot, the WS10 will assume the new network configuration, and will only be reached by computers in the same subnet.
PROC DUR FOR DYNAMIC IP ADDR SSING
The WS10 incorporates a DHCP client for automatic network parameters assignment (IP, gateway and subnet mask). This feature requires that:
•A DHCP Server is available in the same WS10 subnet. Check this condition with your network administrator.
•The DHCP client must be enabled in the WS10. The factory setting for this function is disabled.
To enable the DHCP client in the WS10, follow the steps below:
•Connect the Ethernet to the WS10
•Power-on the WS10
•Open a Telnet session with the WS10 using the current IP address (probably the factory setting address). The computer must be in the
same WS10 subnet.
•Enable the DHCP client in the WS10, typing: DHCP 1 and Enter.
•Type REBOOT followed by the Enter.
•After reboot, the WS10 will request a IP address to the network DHCP Server. This address is obtained from your network DHCP
Server. Ask your network administrator.
The address assigned to the WS10 is retained even if it is powered off, as long as it comes back to the network before the expiration date
configured in the DHCP Server, typically a few weeks. If the WS10 is kept away from the network beyond the IP expiration date, then it will probably
get a new IP address when it returns to operation. To avoid this possibility of having a new IP address assigned to the WS10, the DHCP Server can
be configured to keep a permanent IP address for the WS10, based on its MAC address. Consult your network administrator.
CONFIGURATION FIL S
All WS10 configurations are based on text files which contain the parameters that control all of the WS10 functions.
CFG FIL S
The configuration of the WS10 functionalities is defined in text files stored in the disk A root. The configuration files carry the extension CFG, and, in
order to be modified, they must be transferred using FTP to a computer, edited with a text editor with no formatting (as Windows Notepad) and
transferred back to the WS10. The new configurations will be effective in the next WS10 boot. These configuration files have a rigid syntax, and the
rules for editing the files must be followed strictly to assure success in the configuration.
These files are separated by sections (names between [ ]), sub-sections (names between < >) and parameters, as the following example:
[DEVICES] Section name: DEVICES
<TT101> Sub-section name: TT101
ADDRESS=1 Assigns 1 to the ADDRESS parameter.
When a Section has sub-sections, these must be placed in the end of the section, after all the parameters that are not related to sub-sections. No
distinction is made between capital and low case characters. It is not recommended to use accentuated characters in the configuration files. When
defining the tag names, make sure not to repeat names in the same device, as no warning will be generated and only the first defined tag will be
accessed.
To define a comment line on a CFG configuration file, start the line with the # character.
It is recommended to keep in a computer a complete copy of all the WS10 files. Always edit the configuration files and
HTML pages in this same computer. This way a backup copy with the full WS10 contents is saved, protecting the
application against accidental file corruption.
Observe the correct spelling for the file names. If a file with the wrong name is included in the WS10, the corresponding
function will not be installed.
Parameter names inside all CFG files must be written e actly as specified in this manual.

Web Server – WS10
NOVUS AUTOMATION 8/33
The WS10 configuration files are:
MODBUS.CFG
Data acquisition configuration for the ModbusRTU network (WS10 as the network master)
LOCALIO.CFG
Configuration and calibration of local inputs
WEBS.CFG
Configuration of the HTML page server
PPP.CFG
Modem configuration for originating data calls (PPP client)
MODBUS2.CFG
Configuration of the WS10 as a slave in a ModbusRTU network
CLITCP.CFG
Configuration for the periodic send of data to a Server.
DATALOG.CFG
Configuration of the WS10 for the historical logging in internal Flash memory
ALARMS.CFG
Configuration of the alarm condition supervision or exceptions
MAIL.CFG
WS10 configuration for e-mail transmission
MODBTCP.CFG
ModbusTCP configuration
MAP.CFG
Registers memory map definition for ModbusTCP or ModbusRTU-Slave access
DNS.CFG
Addresses for DNS servers.
CHIP.INI FIL
The CHIP.INI file belongs to the WS10 operating system and shall not be altered, e cept in particular situations, listed
below. Tampering on this file may result on WS10 failure.
Only in the cases listed below should the CHIP.INI file be modified:
•Change of the security level and passwords for the Telnet console access.
•Change in the security level and passwords of the FTP server.
•Configuration of the WS10 for receiving a data phone call (PPP Server).
Further details can be obtained in the sections that deal with security and modem configuration for data transfer.

Web Server – WS10
NOVUS AUTOMATION 9/33
LOCAL INPUTS AND OUTPUTS CONFIGURATIONS
The built-in inputs and outputs are configured on the LOCALIO.CFG file. Only the selection between voltage and current input is accomplished in
hardware. All other configurations are done on this file, exemplified below.
[General]
AChannels=1
DecimalSeparator=.
[Input1]
Tag=LIN1
Logic=1
PullUp=2
Debounce=1
CalLow=0
CalHigh=1023
[Input2]
Tag=LIN2
Logic=1
PullUp=1
Debounce=0
CalLow=0
CalHigh=1023
<Flow>
TotTag=TOT2
Interval=10 [Input3]
...
[Input4]
...
[Output1]
Tag=OUT1
[Output2]
Tag=OUT2
[Memory]
MEM01=0
MEM02=”NOVUS”
[Memory-Hold]
MEM03=50
[Aliases]
PRES1=_INTERNAL_/LIN1
LEVEL=TT101/PV,0,0,1000,3000,1
On [General] section are defined the number of analog input channels (the remaining channels are
digital inputs) and the character to be used as decimal separator in numbers calculated by the
WS10. In the example, one input is defined as analog, and the decimal separator is a dot.
All parameters for each of the 4 inputs are defined on sections [Input1], [Input2], [Input3] and
[Input4]. On the end of each of this sections can be defined a sub-section named <Flow>, that
activates flow measurement for this input. The instantaneous flow is defined as the number of
pulses on the defined Interval. The total flow is also calculated and identified by a separate tag
named on the parameter TotTag.
On sections [Output1] and [Output2] tag names are assigned to both outputs.
On [Memory] section the user can define tag names for memory registers. This memory registers
are not associated to any input or output, and may be used to store values used as email triggers,
historical log control and any other function that require volatile storage of values. A name and initial
value is defined for each memory register. Changes to the content of a memory register will be lost
when the WS10 is powered-down. On power-up the defined initial value will be assigned to each
memory register. To assign text to a memory register, set the initial value as a quoted string
(maximum 200 characters).
On section [Memory-Hold] the user can define tag names for non-volatile memory registers. The
initial value of these registers can be changed by a write operation to the register using an HTML
page, for example. They can also hold text values when defined with a quoted string as initial value
(maximum 200 characters). These register can be used, for example, to hold setpoints for the
alarms of the WS10.
On the [Aliases] section, new registers can be defined from the value of an existing register. It can
be used to create a new register, calculated as a linear transformation of an existing register. It is
useful to convert the numerical range of a register. In the example, register LEVEL (in the range 0 to
300.0) is calculated from register TT101/PV, which range is 0 to 1000.
The input, output and memory registers belong to the _INTERNAL_ device.
Local inputs are automatically read by the WS10 at 100ms interval. If the configuration file
MODBUS.CFG exists, the local inputs scan will be done on the same Scanrate of the Modbus
network.

Web Server – WS10
NOVUS AUTOMATION 10/33
Section Parameter Values Description
General AChannels 0, 1, 2 or 4
Number os analog channels.
0: All 4 channels are digital inputs
1: Input 1 is analog
2: Input 1 and 2 are analog
4: All 4 channels are analog inputs
Tag Up to 6 characters or digits Name for the input channel
Logic 0 or 1
For digital inputs, define the active state of the input. Has no effect on analog
channels.
0: Input state is active (1) when the input is in low level.
1: Input state is inactive (0) when the input is in low level.
PullUp 0, 1 or 2
Define the type of internal bias resistor (10K) for the input. Select 2 for analog
inputs.
0: Bias resistor tied to ground (PullDown)
1: Bias resistor tied to +5V (PullUp)
2: No bias resistor. Use this setting for analog channels
Debounce 0 or 1
Enable (1) or disable (0) the digital input filter. Enable the debounce filter to
debounce contact signals. This parameter has no effect on analog channels. Filter
time is 200ms.
CalLow Low value for calibration of the analog channel.
CalHigh
See section Local Inputs
Calibration High value for calibration of the analog channel.
Flow Sub-section
TotTag Up to 6 characters or digits Define a tag name for the flow total, if the flow function is used. Remove the Flow
sub-section if pulse flow measurement is not necessary.
Input1
Flow Sub-section
Interval 1 to 30000 Time in seconds for the flow measurement. The register identified by the input tag
will contain the number of pulses counted on each Interval.
Input2
Input3
Input4
The same parameters described for Input1 are repeated under the sections for the 3 other inputs.
Output1 Tag Up to 6 characters or digits Output channel name.
Output2 The same parameters described for Output1 are repeated under the section for the second output
Memory
Name for the
register with up to 6
characters or digits
Initial value for the memory
register. Numbers up to 32
bits and text up to 200
characters
Names and initial values for a list of volatile memory registers. To define a text
register, set the initial value as a quoted text string.
Memory-Hold
Name for the
register with up to 6
characters or digits
Initial value for the memory
register. Numbers up to 32
bits and text up to 200
characters
Names and initial values for a list of non-volatile memory register. To define a text
register, set the initial value as a quoted text string. The initial value can be
changed by a write operation to the register.
Aliases
Name for the new
register with up to 6
characters or digits
RegB,A
L
,B
L
,A
H
,B
H
,P
where:
RegB: Name for the
register with up to 6
characters
A
L
,A
H
,B
L
,B
H
: numbers in
the range –2147483647
to 2147483648
P: 0 to
In section Aliases new registers can be defined. The value of the new register will be
calculated using a linear transformation of the value of an existing register. In this
section multiple new registers can be defined, one in each line of the section. Sintax:
RegB=RegA,A
L
,B
L
,A
H
,B
H
,P
RegB: Name for the new register, with up to 6 characters.
RegA: Name of an existing register.
A
L
: Minimum Value of RegA.
A
H
: Maximum value of RegA.
B
L
: Minimum value for RegB.
B
H
: Maximum value for RegB.
P: Number of decimal places in the calculated RegB value.
(B
H
-B
L
).(A
H
-A
L
) must be in the range –2147483648 to [phone]
RegB value will be continuously calculated using the following formula:
( )
L
B
L
ARegA
L
A
H
A
L
B
H
B
RegB +−⋅
−
−
=









Web Server – WS10
NOVUS AUTOMATION 11/33
LOCAL INPUTS CALIBRATION
Before using a local input as analog input, it must be calibrated. The local inputs have a 10 bits resolution and a measurement range from 0 to 5V
or 0 to 20mA. The calibration procedure allows configuration of the measured value range, to achieve the desired result in engineering units.
Calibration is configured in 2 parameters for each channel on the LOCALIO.CFG file: CalLow and CalHigh. During calibration the values of these
parameters need to be changed using the described FTP procedures. Remember to reboot the WS10 after the transfer of a new configuration file.
The measurement result of each channel can be viewed using the browser to display the default HTML file installed on the WS10.
The goal of the calibration procedure is to get the minimum and maximum desired values when the minimum and maximum signals are applied to
each input. On the following procedure, this indication limits are identified as ResultLow and ResultHigh.
The calibration procedure shoul be executed to each analog input, following the next steps.
•Configure the J1 to J5 jumpers according to the type of signal – V or mA.
•Edit the LOCALIO.CFG file to set the initial values for the calibration parameters: CalLow = 0 and CalHigh = 1023. Transfer the file to
the WS10 and reboot.
•Apply the lowest signal value to the input (for example, 0V for a 0-5V signal or 4mA for a 4-20mA signal).
•Check the measurement of the input – This value is the ADLow.
•Apply the highest signal value to the input (for example, 5V for a 0-5V signal or 20mA for a 4-20mA signal).
•Check the measurement of the input – This value is the ADHigh
•Calculate the first calibration parameter of the channel – CalLow:
(
)
(
)
( )
sultLowResultHighRe sultLowReADHighsultHighReADLow
CalLow −
×
−
×
=
•Calculate the second calibration parameter of the channel – CalHigh:
(
)
sultHighRe ADHighsultHighReCalLow
CalHigh
×
+
−
×
=10231023
•Edit the calibration parameters CalLow and CalHigh on the calibrated channel section of the LOCALIO.CFG. Transfer the file to the
WS10 and reboot.
•Check the calibration result on the extreme input values and at least one intermediate value.
•Repeat the above procedure for each analog input.
If CalLow or CalHigh values result out of the –32768 to +32767 range, the desired calibration is not achievable. Try different values for ResultLow
and ResultHigh.
PR D FIN D TAGS OF TH WS10
In addition to the user defined tags, the WS10 has a set of predefined tags, listed on the following table.
Internal Tag name Description
_VER Integer value containing the firmware version of the WS10. Read only.
_BOOT WS10 reboot. Write 1 to this tag to force the reboot. Write only.
_DAY Day value of the internal real time clock. Read/Write.
_MONTH Month value of the internal real time clock. Read/Write.
_YEAR Year value of the internal real time clock. Read/Write.
_HOUR Hour value of the internal real time clock. Read/Write.
_MIN Minutes value of the internal real time clock. Read/Write.
_SEC Seconds value of the internal real time clock. Read/Write.
_LOG Identify the content of the data logger function. Used on the configuration of the email or of the data delivery functions, to
enable transmission of the data logger memory content. Read only
_LOG_E Identify the content of the data logger function. Used on the configuration of the email or of the data delivery functions, to
enable transmission of the data logger memory content, followed by an automatic log erase. Read only
R F R NC TO TH _INT RNAL_ D VIC TAGS
The _INTERNAL_ device contains all internal tags of the WS10:
•Predefined tags
•Tags assigned to the local inputs and outputs
•Tags assigned to memory registers
To reference internal tags on the creation of HTML files and other configurations, use the syntax exemplified below:
_INT RNAL_/_day _INT RNAL_/MyOUT

Web Server – WS10
NOVUS AUTOMATION 12/33
MODBUS RTU NETWORK CONFIGURATION – WS10 AS MASTER
The WS10 can be configured as a Modbus master, and can read or write on memory locations of other Modbus devices on the same network.
If the MODBUS.CFG file exists on the WS10, this function is enabled and the WS10 starts scanning the network according to the configuration of
devices and registers. Values read from the external devices are stored on the WS10 memory and are identified by a device/tag name.
Follows an example of content of the MODBUS.CFG file:
[Config]
Scanrate=50
Serial=1
Flowctrl=2
De485=1
Baudrate=19200
Parity=0
Wordlen=8
Stopbits=1
Responsedelay=100
Bytetimeout=80
FrameDelay=10
Retries=2
[Devices]
<TT101>
Address=1
PV=5
OUT=24,1
<TT201>
Address=2
TVALS=0,3,8
INVALS=32,4,16
On section [Config] the communication parameters and data acquisition interval are defined.
On section [Devices] the external Modbus devices are identified. A new sub-section is defined and named
for each Modbus device. The Address parameter defines the slave address and a list of tags and register
addresses define the registers of interest on the device.
In this example there are two Modbus devices: TT101 (slave address 1) and TT201 (slave address 2).
On the TT101 device, two registers are defined. The register identified as PV is a Modbus holding register
located at address 6 of the device. The register identified as OUT is a Modbus coil status register located at
address 24 of the device, and is read using Modbus command 1 (Read Coil Status).
On the TT201 device, two block registers are defined. Register TVALS are read from the Modbus slave
using command 3 (Read Holding Register), and 8 registers starting at address 0 are read. Registers
INVALS are read using command 4 (Read Input Register), and 16 registers are read starting at address 32.
If the Modbus command is not specified, it defaults to the Read Holding Register (3) for read operation and
Preset Single Register for write operation. If the number of registers is not specified, a single Modbus
register is read.
Valid Modbus commands on a tag definition are: 1, 2, 3 or 4. If a write operation is issued on a tag defined
with commands 1 or 3, the WS10 executes the write operation using command 5 or 6. The WS10 can’t
issue block write commands to the Modbus network.
Section Sub-Section Parameter Values Description
Scanrate 1 to 30000 Data acquisition interval, in 100ms units. The same interval will be used
for acquisition from local inputs.
Serial 1 or 2 Number of the serial port assigned to the Modbus RTU function.
Factory setting is 1.
Flowctrl 0 or 2
Serial port flow control configuration:
0: Now flow control
2: RTS/CTS flow control (typical whenRS485 or RS232 with external
RS232/485 converter. Factory setting)
De485 0, 1 or 2
RS485 mode configuration.
0: RS232 with external RS232/485 converter.
1: RS485(factory setting)
2: RS232
Baudrate
300, 600, 1200,
2400, 4800, 600,
1 200, 38400
Serial port baud rate. Factory setting is 600.
Parity 0, 1 or 2 Serial port parity.
0: No parity (factory setting); 1: Even; 2: Odd.
Wordlen 7 or 8 Number of bits per byte. Factory setting is 8.
Stopbits 1 or 2 Number of stop bits. Factory setting is 1.
Responsedelay 1 to 30000 Maximum response wait time, in ms. Factory setting is 100.
Bytetimeout 1 to 30000 Maximum interval between bytes of the received frame, in ms. Factory
setting is 80.
FrameDelay 0 a 30000 Time in ms between the reception of an answer frame and transmission
of a new request frame. Typical value is 10.
Config
Retries 0 to 100 Number of communication retries in case of error. Factory setting is 2.
Address 1 to 247 Address of the slave device named on this section.
Devices
Device name
with up to 10
characters
(1 sub-section for
each device)
Tag name with
up to 6
characters or
digits
Addr,Cmd,Num
Addr: 0 to
Cmd: 1 to 4
Num: 1 to 125
Tag name, first Modbus address (Addr), Modbus read command (Cmd)
and number of registers for each variable of interest on the device of this
sub-section.
Specifying the Modbus command (Cmd) is optional, and defaults to
command 3 (Read Holding Register). Valid commands are 1 to 4.
Specifying the number of registers (Num) is optional, and defaults to a
single register. When the number of registers is specified, the Modbus
command (Cmd) must be specified. Registers with Num greater than 1
are called Block Registers.
Multiples Modbus devices can be defined, one in each sub-section.
Multiple registers can be defined for each Modbus device.

Web Server – WS10
NOVUS AUTOMATION 13/33
R F R NC TO TH MODBUS ACQUIR D TAGS
Reference to the WS10 registers associated to external Modbus RTU devices are done through the device and tag name defined at the
MODBUS.CFG file, using one of the syntax options bellow. Only registers read with commands 3 (default command) and 1 accepts write operation.
Reference to the value of a single register
DeviceName/TagName
TT101/PV
TT101/PV.Val Same result as above. “.Val” means the tag value and can be
omitted.
Reference to a member of a Block Register
DeviceName/TagName[n]
TT201/TVALS[0] 1
st
position of the block register
TT201/INVALS[5] 6
th
position of the block register
Reference to the status of the last read operation on a Modbus
register
DeviceName/TagName.Sts
TT101/PV.Err Register error status
TT201/TVALS[0].Err Block Register error status. The status is the same for all members
of the block
Reference to the error counter of the read operations on a
Modbus register
DeviceName/TagName.Sts
TT101/PV.ErrCnt Number of reading errors of the register
TT201/TVALS[0].ErrCnt Number of reading errors of the block. The number is the same
for all members of the block
The values read by the WS10 from the external Modbus slaves are stored on the WS10 memory with additional status information to allow
validation of the last Modbus network operation. An communication error counter is also stored for each register.
The communication status of the last reading (. rr) is read-only and can contain the following values:
0: The current value was read with no error on the last scan interval.
1: The current value is out-dated due to a Invalid Operation error on the last scan interval.
2: The current value is out-dated due to a CRC error on the last scan interval.
3: The current value is out-dated due to a time-out error on the last scan interval.
The error counter (.ErrCnt) is a read-write value that contains the accumulated number of communication errors detected for the associated register
or block register.
The error and error counter values are not updated on write operations to the Modbus network. The WS10 doesn’t offer any function to validate the
success of a write operation into a Modbus slave.

Web Server – WS10
NOVUS AUTOMATION 14/33
ALARMS SUPERVISION CONFIGURATION
The WS10 can compare the value of any register against limits defined as constants or other registers. The result of the comparison is assigned to
a new alarm register. Based on the result of the alarm, registers can be written to, allowing the WS10 to take actions based on the detected alarm
condition. Some examples of actions that can be executed by the WS10 when an alarm condition is detected:
•Write to a local output register, allowing local signaling of the alarm condition.
•Write to registers of external Modbus devices, taking alarm actions on other parts of the system.
•Enable the WS10 data logger function to start logging critical values of the system under abnormal conditions.
•Trigger email messages containing process information and informing the start or end of an alarm condition.
The alarm function is enabled when the ALARMS.CFG file is installed on the WS10. Follows an example of the ALARMS.CFG file:
[Alarm1]
Condition=TT101/PV > 200
Hysteresis=2
<SetList>
_INTERNAL_/OUT1=1
TT101/RUN=0
<ResetList>
_INTERNAL_/OUT1=0
[Emerg1]
Condition=TT201/TVALS[3]<=_INTERNAL_/MEM01
Hysteresis=1
<SetList>
_INTERNAL_/OUT2=1
<ResetList>
_INTERNAL_/OUT2=0
Each section defines a new alarm, and the name of the section defines a
tag name on the _ALARMS_ device. This read-only tag contains alarm
status.
Under each alarm section, an alarm condition is defined from the
comparison of a register value and a constant value or from the comparison
of 2 registers values. Many comparison operators can be used.
At the <SetList> sub-section of each alarm a list of write operations can be
defined. These write operations will be executed when the alarm condition
starts.
At the <ResetList> sub-section of each alarm a list of write operations can
de defined. These write operations will be executed when the alarm
condition ends.
Multiple alarm sections can be defined.
Section Sub-section Parameter Values Description
Condition
Device/Tag
Operator
Device/Tag
or
Device/Tag
Operator
Numerical constant
Defines the alarm activation condition. The alarm is activated when
the condition results true. The comparison may be between 2 tag
values or one tag and one constant value. The allowed comparison
operators are: >, <, >=, <=, = e <>.
In a typical application, an local input register is compared against a
memory register. The value of this memory register is programmed by
the operator through an HTML page on the browser screen.
Hysteresis 0 to 30000
Hysteresis for the end of the alarm condition. Example. If the alarm is
activated above 200 and the hysteresis is 2, then the alarm will be
deactivated below 1 8.
SetList Device/Tag Value for the register List of register identifications and values. The values will be written to
the registers when the alarm condition begins.
Alarm Name
With up to 6
characters or
digits
ResetList Device/Tag Value for the register List of register identifications and values. The values will be written to
the registers when the alarm condition ends.
Multiple alarms can be defined, one in each section as the one described above.
When the ALARMS.CFG file is installed, a new device named _ALARMS_ is created on the WS10. This device contains tags with the same names
of the alarm sections on the file. The values of these alarm registers correspond to the status of each alarm, with value zero for an inactive alarm
and one for an active alarm condition. Typically these alarm registers are used to trigger email messages and displayed on the browser screen.
R F R NC TO TH WS10 ALARM TAGS
To reference the alarm status tags under the _ALARMS_ device, use the syntax of the example below:
_ALARMS_/HiPres
Alarm registers are read only. A value of 0 indicates an inactive alarm, and a value of 1 indicates an active alarm condition.

Web Server – WS10
NOVUS AUTOMATION 15/33
DATA LOGGER CONFIGURATION
The WS10 can be programmed to periodically save a set of register values and time stamps on its flash memory as a file. This file can be
transferred to the PC using FTP or can be automatically sent as an email attachment.
Attention: The data logger is stopped during the transmission of the data.
The data logger function is enabled when the DATALOG.CFG is installed on the WS10. Follows an example of the DATALOG.CFG file:
[General]
ID=LOGGER1
File=A:\LOG\DATALOG.TXT
Interval=600
ReserveDisk=10000
WrapAround=0
FileMode=TXT
DateFormat=DMY
LogEnable=_INTERNAL_/IN3
LogClear=_INTERNAL_/MEM1
[DatalogServer]
Enable=0
Port=2001
[VarList]
N1100/PV
N1100/PV.Err=PVStatus
_ALARMS_/AL01
At the [General] section all log control parameters are defined.
At the [VarList] section all registers that will be logged are identified. An alternative name (alias) can be
defined for each register. The register names or alias are printed on the first line of the log file. The following
lines contains the time-stamps and values of each register.
Section [DatalogServer] is necessary only when a Java application supplied by Novus is used to plot the
content of the data logger into an HTML page. If this function is not being used, omit this section.
Section Parameter Values Description
ID Log identification, with
up to 10 characters
Name for the Log, to allow the recipient of the log file to identify its origin. The ID is printed on the
first line of the log file. Maximum 10 characters.
File Name and path to the
log file
Name of the log file. Must start with the drive letter (A: for internal flash, B: for external flash or
compact flash card), a folder name and a file name. To allow browser access to the log file, store
at the A:\WEB folder. If browser access to the log file is not necessary, store on a separate folder.
Interval 1 to 65535
Interval between logs in 100ms units. At each interval a new line is appended to the log file,
containing a time stamp and values of the listed registers. Avoid setting interval to values bellow
100 (10 second), to avoid premature failure of the Flash memory and the WS10 to fail.
WrapAround 0 or 1
Action to be executed when no more memory is available for the log file. If 0, the data logger is
stopped. If 1 the log continues on the beginning of the file, replacing the older lines with the newer
lines.
ReserveDisk 5000 to 2000000 Number of bytes to be reserved on the flash memory. The data logger will not use the specified
amount of memory for storage of the log file.
FileMode TXT Type of the log file. At the present WS10 version only the text format TXT is available.
DateFormat DMY, MDY or YMD Date format of the time-stamp logged on each line of the log file. Define the sequence of day (D),
month (M) and year (Y). The separator is /.
LogEnable Device/Tag
Register that enable or disable the data logger. If the register value is 0, the data logger is
suspended. If the register value is different from 0, the data logger is enabled. To keep the data
logger always running, omit this parameter line.
General
LogClear Device/Tag
Register that clear the data logger file. When the register value changes from 0 to a non 0 value,
the log file is erased. After the erase completion, the WS10 write 0 to this register. To disable the
erase of the log file under register control, omit this parameter line.
If the register value is 0, the data logger is suspended. If the register value is different from 0, the
data logger is enabled. To keep the data logger always running, omit this parameter line.
Enable 0 or 1 Enable TCP communication with an external application for reading the data logger file content.
Port 1 to 65535 TCP por used to communicate with an external application for reading the data logger file content.
Value above 1024 should be used.
DatalogServer
Section DatalogServer should only be created if the Java application supplied by Novus is being used to display a plot of the data logger content
into an HTML page. If this function is not being used, omit this section.
VarList
Device/Tag of
the registers
to be logged
Alternative name for the
register, with up to 24
characters.
List of registers to be included on the log file. The device and tag names or the alternative name
will be printed at the first line of the file. The registers values will be printed on every line of the log
file.

Web Server – WS10
NOVUS AUTOMATION 16/33
DATA LOGG R FIL FORMAT
A new line is appended to the log file at each interval. The first line contains the identifiers, and all following lines contain the values of the listed
registers.
The first 2 columns of a log line contain the date and time, and the following columns contain the values for each register. Columns are separated
by the comma character.
File layout:
Log ID Empty field Identifier 1 Identifier 2 ... Identifier n
If Interval ≥ 10 (1s) MM/DD/YY HH:MM:SS Value 1 Value 2 ... Value n
If Interval < 10 (1s) MM/DD/YY HH:MM:SS.S Value 1 Value 2 ... Value n
File example:
OvenRoom,,Oven1Temp,Oven2Temp,AmbientTemp,TT101/PV,
12/24/04,10:10:10,180,200,28,121,
12/25/04,11:11:11,182,245,28,121,
12/26/04,22:22:22,182,286,30,120,
When data wrap around is enabled (WrapAround=1), one or more of the file lines may contain the character ^, indicating that this line has no data
and can be discarded. These lines are automatically excluded when the log file is sent as an email attachment.
PLOTTING TH DATA LOGG R CONT NT INTO AN HTML PAG
Novus offers a Java application that can read the content of the data logger file from the WS10 flash memory and plot its data in an HTML page,
with zoom and print capability. The Java application must be installed in all PCs that will display this plot. These PCs must also have installed the
Java Virtual Machine from Sun – JRE.
To enable communication between the Java application and the WS10, the following parameters must be programmed in section [DatalogServer]
of the DATALOG.CFG file:
[DatalogServer]
Enable=1
Port=2001
The TCP port 2001 is the default for this function. The same port must be programmed for the WS10 and in the Java application configuration.
The Java application, documentation and examples are included in the WS10 CD.
R F R NC TO TH LOG R LAT D TAGS
To integrate the data logger to the email and periodical data transmission functions of the WS10, two tags are defined on the _INTERNAL_ device
of the WS10 to identify the data logger content. If one of these tags is included on the list of tags for delivering, the content of the log file will be
attached to the email message or sent to the specified server. The two log related tags are:
_INT RNAL_/_LOG Send the log content and don’t erase the log file
_INT RNAL_/_LOG_ Send the log content and erase the log file
During the log delivery, the data logger is suspended. Use the _LOG_E tag with caution, since the is no guarantee of the email delivery and data
can be lost.
To get access to the log file through the browser, add a FTP link to the log file on the HTML page, or address directly the file path at the browser
address line (the log file must be located at the WEB folder to allow http access to it).

Web Server – WS10
NOVUS AUTOMATION 17/33
HTML PAGE SERVER CONFIGURATION
The WS10 can store and serve HTML files. All files accessed through http must be stored in the WEB folder or in its sub-folders. Use FTP to
include and exclude files. It is not necessary to reboot the WS10 when new or updated files are transferred to the WS10. The new page version will
be displayed on the next browser refresh.
The default page of the WS10 is named MAIN.HTM. If a page with this name is stored in the WS10, it will be exhibited on the browser when only
the WS10 IP address is typed at the address line. All web server files must be located at the WEB folder or in its subfolders.
The WEBS.CFG configuration file define some parameters to the web server of the WS10. Follows an example:
[Auth]
PostPage=procform
User=Novus
Pass=suvoN
[PagesList]
forno1.htm
forno2.htm
At section [Auth] are defined the user name and password to log on all HTML files served by the WS10.
The CGI script name is also defined at this section.
At section [PagesList] all HTML files containing dynamic data must be listed. Dynamic pages are HTML
files that contain tag names of WS10 registers, which will be replaced by the corresponding values when
the page is served by the WS10. Them MAIN.HTM page can not contain dynamic data.
Section Parameter Values Description
PostPage CGI script name Name of the CGI script executed by the WS10 when the method POST is invoked on an HTML
formulary. Must match to the name assigned to the ACTION attribute of the formulary.
User User name
Name of the user that can access the pages served by the WS10. If this parameter is defined, the
browser will prompt for a user name and password before presenting the HTML files. Omit this
parameter to disable password on each page served by the WS10.
Auth
Pass User password Password assigned to the user. Omit this parameter to disable passwords.
PagesList HTML file
names
List of dynamic HTML files. Dynamic pages are HTML files that contain tag names of WS10 registers,
which will be replaced by the corresponding values when the page is served by the WS10.
Attention: Type the name of the files exactly the same way here and at the browser address
line. The web server differentiates lower case and upper case characters, and a mistyped file
name will display with the tag names instead of the tag values.
CR ATING HTML FIL S
There are no special restrictions on the design of pages hosted by the WS10. All the usual techniques such as frames, tables, Java script, images,
animation, etc. can be used, limited only by the available memory.
Pages that should present dynamic information must include a special marker at the dynamic data position. This marker identifies the device and
tag name of the value to be displayed, and should be enclosed between 2 percent characters, as exemplified below:
%DeviceName/TagName%
Attention:
Only pages listed at the [PagesList] section of the WEBS.CFG file will be served by the WS10 with the tag names
substituted by the tag values. When invoking these pages from the browser address line, the same name and
capitalization defined at the WEBS.CFG file must be used.
The WS10 can not handle references to internal registers in the main page – MAIN.HTM. Register names will not be
replaced with the respective values for this page.
To include the percent (%) character at the page, type it doubled – %%.
The ma imum size for HTML and associated files (images, flash, etc) is 64K for each file.
If a register name is unknown, it will be substituted by the string “N/A” when the page is served.
The page at Example 1 presents the content of 3 registers in a table. The register identifications are highlighted. When serving this page, the WS10
will replace the tag names with the corresponding values stored on its memory.
<html>
<head>
<title>Monitor</title>
<META HTTP-EQUIV="Refresh" CONTENT="10">
</head>
<body>
<font face="Arial" color="navy" size=+1><p align="center"><b>
<table border=1>
<tr>
<td colspan=2 align=center> Heat Exchanger 1 </td>
</tr><tr>
<td> Input </td><td> %TT101/PV% </td>
</tr><tr>
<td> Output </td><td> %TT201/INVALS[0]% </td>
</tr><tr>
<td> Flow </td><td> %_internal_/FT101% </td>
</tr>
</table>
</b></p></font>
</body>
</html>
Example 1 – Dynamic HTML file with table

Web Server – WS10
NOVUS AUTOMATION 18/33
The MAIN.HTM page can not display register values. To display dynamic data in the start page, define frames inside MAIN.HTM and include
register references in separate HTML files. The MAIN.HTM page can also switch automatically to the page which actually displays the register
values. See example of redirection to DATA.HTM below:
<html>
<head>
<meta http-equiv="REFRESH" content="0;URL=data.htm">
</head>
</html>
The example page 2 uses Java Script to format date and time information from the WS10 real time clock, and to execute mathematical operations
before presenting the data. This is an important feature, since sometimes the data measured or acquired by the WS10 is not in the desired
engineering unit for exhibition. The usage of Java scripts allows formatting of the data before presenting the page. In this example a link to other
page is also created.
<html>
<head>
<title>Monitor</title>
<META HTTP-EQUIV="Refresh" CONTENT="3">
</head>
<body>
<center><font face="Arial" color="navy" size=+1><b>
<script language="JavaScript" type="text/JavaScript">
<!--
var month = new Array('jan', 'feb', 'mar', 'apr', 'may', 'jun', 'jul', 'aug', 'sep', 'oct', 'nov', 'dec');
function cMonth(x)
{
if (x > 0 && x < 13)
return month[x - 1];
else
return '';
}
function cNum(x)
{
if (x >= 0 && x < 10)
return '0' + x;
else
return '' + x;
}
document.write(cMonth(%_INTERNAL_/_MONTH%)+', %_INTERNAL_/_DAY%, '+ cNum(%_INTERNAL_/_YEAR%)+'<br>');
document.write(cNum(%_INTERNAL_/_HOUR%)+':'+cNum(%_INTERNAL_/_MIN%)+':'+cNum(%_INTERNAL_/_SEC%));
document.write('<br><br>FT1: '+%_INTERNAL_/FT1%/9+'<br>');
document.write('FT1 Total: '+Math.round(%_INTERNAL_/FT1TOT%/10)+'<br>');
//-->
</script>
</b></font>
<br>
<br>
<a href=modif.htm>Modify</a></center>
</body>
</html>
Example 2 – Usage of Java Script for formatting and math operations on tag values

Web Server – WS10
NOVUS AUTOMATION 19/33
USAG OF CGI TO S ND VALU S TO TH WS10
An HTML formulary can write to a WS10 register using the POST method. The WS10 built in CGI script associate the formulary values to the WS10
registers. The example 3 show the use of the POST method to write on the WS10 real time clock registers and on 3 other registers.
The CGI script name defined at the [Auth] section of the WEBS.CFG file must match to the name used at the page Forms. The default name
procform is used on the example and shown below:
<FORM ACTION=procform METHOD=POST>
The name of the page to be presented after the form post can be defined. This definition is optional, and the same form page will be reloaded if not
defined. At example 3, the following hidden field is used to define the next page to be presented:
<INPUT TYPE=HIDDEN NAME=nextpage VALUE=data.htm>
It is important to examine the following field definition extracted from example 3:
<INPUT TYPE=TEXT NAME=_INTERNAL_/FT1TOT SIZE=7 VALUE=%_INTERNAL_/FT1TOT%>
In this field, the first usage of the tag _INTERNAL_/FT1TOT is not enclosed by the percent characters, since we don’t want the WS10 to
replace the name by the corresponding value. The tag name must remain untouched to inform to the WS10 CGI script the name of the destination
register for the written data. The second usage of the same tag is enclosed by the percent characters to allow the WS10 to replace the tag name
with the corresponding value, which will be used as the initial value for the form field.
Date/Time<br><br>
<script language="JavaScript" type="text/JavaScript">
<!--
function goback()
{
document.location='data.htm';
return false;
}
function cNum(x)
{
if (x >= 0 && x < 10)
return '0' + x;
else
return '' + x;
}
document.write('<FORM ACTION=procform METHOD=POST>\
<INPUT TYPE=HIDDEN NAME=nextpage VALUE=data.htm>\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_MONTH SIZE=1 VALUE='+cNum(%_INTERNAL_/_MONTH%)+'>/\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_DAY SIZE=1 VALUE='+cNum(%_INTERNAL_/_DAY%)+'>/\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_YEAR SIZE=1 VALUE='+cNum(%_INTERNAL_/_YEAR%)+'><br>\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_HOUR SIZE=1 VALUE='+cNum(%_INTERNAL_/_HOUR%)+'>:\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_MIN SIZE=1 VALUE='+cNum(%_INTERNAL_/_MIN%)+'>:\
<INPUT TYPE=TEXT NAME=_INTERNAL_/_SEC SIZE=1 VALUE='+cNum(%_INTERNAL_/_SEC%)+'><br><br>\
<INPUT TYPE=SUBMIT NAME=button VALUE="Set Date/Time" ></FORM>');
//-->
</script>
<FORM ACTION=procform METHOD=POST>
<INPUT TYPE=HIDDEN NAME=nextpage VALUE=data.htm>
FT1 Totalization: <INPUT TYPE=TEXT NAME=_INTERNAL_/FT1TOT SIZE=7 VALUE=%_INTERNAL_/FT1TOT%>
<INPUT TYPE=SUBMIT NAME=button VALUE="Apply">
</FORM>
<FORM ACTION=procform METHOD=POST>
<INPUT TYPE=HIDDEN NAME=nextpage VALUE=data.htm>
OUT1: <INPUT TYPE=TEXT NAME=_INTERNAL_/OUT1 SIZE=1 VALUE=%_INTERNAL_/OUT1%>
<INPUT TYPE=SUBMIT NAME=button VALUE="Apply"><br>
</FORM>
<FORM ACTION=procform METHOD=POST>
<INPUT TYPE=SUBMIT NAME=button VALUE="Back" onClick='return goback();'>
</FORM>
</b></center></font>
</body>
</html>
Example 3 – Write to the WS10 using formula with the POST method
The WS10 memory registers are useful to control some internal functions using HTML pages. Pages can write to memory registers used for:
•Enable, disable or clear the data logger file
•Trigger an email
•Define alarms setpoints
•Activate an alarm
Screenshots of the 3 examples are presented at the appendix A.

Web Server – WS10
NOVUS AUTOMATION 20/33
PERIODICAL DATA TRANSMISSION CONFIGURATION
The WS10 can be configured to periodically send data to a host computer. This host computer must run a dedicated application that accepts a
socket connection requested by the WS10 and receive and store the sent data on files or database. The periodical data transmission function of the
WS10 is enabled by the inclusion of the CLITCP.CFG file at the WS10.
There are 2 output paths for the TCP data: Ethernet or PPP (modem). The Ethernet interface is used when the host computer is on the same
network or can be reached through the network gateway. PPP connection is used when the WS10 is installed on a remote location without
available Ethernet connection. The WS10 can dial to a internet service provider and reach the host IP address through the internet, or can dial
directly to the host.
Before using PPP and modem, read the section: “Configuring the modem to start a data call”. ”. To use a domain name instead of a IP address for
the server, refer to section “DNS Configuration”.
After the establishment of the socket connection between WS10 and host, the data transfer is started as bellow:
WS10 Host Comment
ID WS10Name<LF>  WS10 presents itself to the server, using the name defined in CLITCP.CFG
 02<LF> Server acknowledges. <LF> is the Line Feed character
{Data Block}  WS10 transfers data. Details bellow.
 03<LF> Server acknowledges reception and storage of data.
The data block sent by the WS10 to the host computer is pure text with the following layout:
{S;N;IdData1;IdData2;...;IdDataN;ddmmyyhhmmss;ValData1;ValData2;...;ValDataN;}
or
{L;N;IdData1;IdData2;...;IdDataN;ddmmyyhhmmss;ValData1;ValData2;...;ValDataN;ddmmyyhhmmss;ValData1;ValData2;...;}
where:
S or L Data type identifier. S for a single value for each register
L for the whole content of data logger file.
N Number of registers on the data block. In case of data logger file content, is the number of registers values stored on
each log file line.
IdData0...N Identifier of the Nth register sent. Register name or alias defined at the CLITCP.CFG file.
ddmmyyhhmmss Day, month, year, hour, minute, second when the data was acquired by the WS10.
ValData0...N Value of the Nth register.
{ } Block delimiter
; Field separator
Example of the CLITCP.CFG file:
[General]
Address=192.168.200.10
Port=2001
SendRate=60
KeepAlive=1
LinkType=ETH
ID=Oven1
[VarList]
N1100/PV
TT201/INVALS[3]
[TriggerList]
_INTERNAL_/MEM5
_ALARMS_/AL22
In [General] section the connection parameters are defined.
In [VarList] section all registers that will be sent are identified. An alternative name (alias) can be defined
for each register.
In [TriggerList] section a list of tags can be included. When any of these tags change from a zero to a non-
zero value, transmission of data is started.
