Serial-to-Ethernet Device Servers
The NPort® IA5150 and IA5250 device servers each have two Ethernet
ports that can be used as Ethernet switch ports. One port connects
directly to the network or server, and the other port can be connected
NPort®IA5000 Series
1 and 2-port serial device servers for industrial automation
NPort® IA device servers provide easy and reliable serial-to-Ethernet
connectivity for industrial automation applications. The device servers
can connect any serial device to an Ethernet network, and to ensure
compatibility with network software, they support a variety of port
operation modes, including TCP Server, TCP Client, and UDP. The
rock-solid reliability of the NPort® IA device servers makes them
an ideal choice for establishing network access to RS-232/422/485
serial devices such as PLCs, sensors, meters, motors, drives, barcode
readers, and operator displays. All models are housed in a compact,
rugged housing that is DIN-rail mountable.
to another NPort® IA device server or another Ethernet device. The
dual Ethernet ports help reduce wiring costs by eliminating the need to
connect each device to a separate Ethernet switch.
Cascading Ethernet Ports Make Wiring Easy (10/100BaseTX models only)
Overview
›Versatile socket operation modes, including TCP Server, TCP
Client, UDP
›Patented ADDC® (automatic data direction control) for 2-wire
and 4-wire RS-485
›Cascading Ethernet ports for easy wiring (applies only to RJ45
connectors)
›Redundant DC power inputs
›Warning by relay output and e-mail
›10/100BaseTX (RJ45) or 100BaseFX (single mode or multi-mode
with SC connector)
›IP30-rated housing
See also NPort IA5000A, p. 8-45

2www.moxa.com [email protected]
Serial-to-Ethernet Device Servers
The NPort® IA5000 device servers have two power inputs that can
be connected simultaneously to live DC power sources. If one power
source fails, the other source takes over automatically. Redundant
power inputs help assure that your device server will operate non-stop.
The built-in relay output can be used to alert administrators of
problems with the Ethernet links or power inputs, or when there is a
change in the DCD or DSR serial signals. The web console indicates
The NPort® IA5000 series includes 100BaseFX fiber models that
support transmission distances up to 2 km for multi-mode models,
and up to 40 km for single-mode models. Optical fiber is well-suited
for industrial applications because it is immune to electromagnetic
To ensure safe and reliable operation in industrial environments,
the NPort® IA5000 device servers have obtained various industrial
certifications, including an IP30 rating for mechanical protection,
UL508 safety certification for industrial control equipment, and
noise and interference. For environments that experience high ground
loop voltages, fiber provides the best isolation protection, and because
there is no danger of sparking, optical fiber is safer than copper wire to
use in hazardous environments.
explosion-safe certifications for hazardous locations.
Certifications include UL/cUL Class 1 Division 2 Groups A,
B, C, D, and ATEX Class 1 Zone 2.
which Ethernet link or power input has failed, or which serial signal
has changed. An e-mail warning can also be issued when an exception
is detected. These functions are valuable tools that enable maintenance
engineers to react promptly to emergency situations.
Appearance
Redundant Power Inputs
Industrial-grade Certification
Relay Output Warning and E-mail Alerts
Optical Fiber for Ethernet Communication
Reset
NPort IA5250
NPort IA5150
NPort IA5150I
NPort IA5150-S-SC
NPort IA5150-M-SC
NPort IA5150I-S-SC
NPort IA5150I-M-SC
Copper
Ethernet
LED
Indicators
Fiber optic
Ethernet
Reset Dual Power Inputand
Relay Output
RS-232
RS-232/422/485
RS-422/485
Dual Power Inputs
Power Failure Alarm

3www.moxa.com [email protected]
Serial-to-Ethernet Device Servers
PIN RS-232 RS-422/RS-485-4w RS-485-2W
1 DCD TxD-(A) –
2 RXD TxD+(B) –
3 TXD RxD+(B) Data+(B)
4 DTR RxD-(A) Data-(A)
5 GND GND GND
6 DSR – –
7RTS – –
8 CTS – –
PIN RS-422/RS-485-4w RS-485-2w
1 TxD+(B) –
2 TxD-(A) –
3 RxD+(B) Data+(B)
4 RxD-(A) Data-(A)
5 GND GND
5 4 3 2 1
RS-232/422/485
DB9 male port
RS-422/485 Terminal
Block Wiring
Pin Assignment
1 2 3 4 5
6 7 8 9
Specifications
Ethernet Interface (NPort IA5150/5150I/5250)
Number of Ports: 2
Speed: 10/100 Mbps, auto MDI/MDIX
Connector: 8-pin RJ45
Magnetic Isolation Protection: 1.5 KV built-in
Optical Fiber Interface (-M-SC and -S-SC models)
100BaseFX
Multi-mode Single-mode
Wavelength 1300 nm 1310 nm
Max. TX -14 dBm 0 dBm
Min. TX -20 dBm -5 dBm
RX Sensitivity -32 dBm -34 dBm
Link Budget 12 dB 29 dB
Typical Distance 5 km a
4 km b40 km c
Saturation -6 dBm -3 dBm
a. 50/125 μm, 800 MHz*km fiber optic cable
b. 62.5/125 μm, 500 MHz*km fiber optic cable
c. 9/125 μm, 3.5 PS/(nm*km) fiber optic cable
Serial Interface
Number of Ports:
NPort IA5150: 1
NPort IA5250: 2
Serial Standards: RS-232/422/485
Connector:
NPort IA5150: DB9 male for RS-232, terminal block for RS-422/485
NPort IA5250: DB9 male for RS-232/422/485
Serial Line Protection:
15 KV ESD protection for all signals
2 KV isolation protection (NPort IA5150I, NPort 5150I-M-SC, NPort
5150I-S-SC)
RS-485 Data Direction Control: ADDC® (automatic data direction
control)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
Baudrate: 110 bps to 230.4 Kbps
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS-485-2w: Data+, Data-, GND
Software
Network Protocols: ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet,
Rtelnet, DNS, SNMP V1, HTTP, SMTP, SNTP
Configuration Options: Web Console, Serial Console, Telnet Console,
Windows Utility
Windows Real COM Drivers: Windows 95/98/ME/NT/2000, Windows
XP/2003/Vista/2008/7 x86/x64, Embedded CE 5.0/6.0, XP Embedded
Fixed TTY Drivers: SCO Unix, SCO OpenServer, UnixWare 7, UnixWare
2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX
11i
Linux Real TTY Drivers: Linux kernel 2.4.x, 2.6.x
Physical Characteristics
Housing: Plastic, IP30 protection
Weight:
NPort IA5150: 360 g
NPort IA5250: 380 g
Dimensions: 29 x 89.2 x 118.5 mm (0.82 x 3.51 x 4.57 in)
Environmental Limits
Operating Temperature:
Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Power Requirements
Input Voltage: 12 to 48 VDC
Power Consumption:
NPort IA5150: 360 mA @ 12 V, 195 mA @ 24 V
NPort IA5150I: 420 mA @ 12 V, 215 mA @ 24 V
NPort IA5250: 440 mA @ 12 V, 200 mA @ 24 V
NPort IA5150-S-SC: 470 mA @ 12 V, 210 mA @ 24 V
NPort IA5150I-S-SC: 490 mA @ 12 V, 250 mA @ 24 V
NPort IA5150-M-SC: 500 mA @ 12 V, 250 mA @ 24 V
NPort IA5150I-M-SC: 510 mA @ 12 V, 260 mA @ 24 V
Standards and Certifications
Safety: UL 508, UL 60950-1, EN 60950-1
Hazardous Location: UL/cUL Class I Division 2 Groups A/B/C/D, ATEX
Zone 2
EMC: CE, FCC
EMI: EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS:
EN 55024,
EN 61000-4-2 (ESD) Level 3,
EN 61000-4-3 (RS) Level 3,
EN 61000-4-4 (EFT) Level 4,
EN 61000-4-5 (Surge) Level 3,
EN 61000-4-6 (CS) Level 3,
EN 61000-4-8,
EN 61000-4-11
Marine: DNV
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Reliability
Water and Dust Proof: IP30
Alert Tools: Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures):
NPort IA5150 Series: 183,747 hrs
NPort IA5150I Series: 195,614 hrs
NPort IA5250 Series: 194,765 hrs
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty

4
Serial-to-Ethernet Device Servers
© Moxa Inc. All Rights Reserved. Updated Oct. 19, 2011. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Ordering Information
Available Models
NPort IA5150: 1-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP), 0 to 55°C operating temperature
NPort IA5150I: 1-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP) and 2 KV optical isolation, 0 to 55°C
operating temperature
NPort IA5150-M-SC: 1-port RS-232/422/485 device server with 1 100BaseF(X) multi-mode fiber port (SC connectors), 0 to 55°C operating
temperature
NPort IA5150I-M-SC: 1-port RS-232/422/485 device server with 1 100BaseF(X) multi-mode fiber port (SC connectors) and 2 KV optical isolation, 0 to
55°C operating temperature
NPort IA5150-S-SC: 1-port RS-232/422/485 device server with 1 100BaseF(X) single-mode fiber port (SC connectors), 0 to 55°C operating
temperature
NPort IA5150I-S-SC: 1-port RS-232/422/485 device server with 1 100BaseF(X) single-mode fiber port (SC connectors) and 2 KV optical isolation, 0 to
55°C operating temperature
NPort IA5250: 2-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP), 0 to 55°C operating temperature
NPort IA5150-T: 1-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP), -40 to 75°C operating temperature
NPort IA5150I-T: 1-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP) and 2 KV optical isolation, -40 to
75°C operating temperature
NPort IA5150-M-SC-T: 1-port RS-232/422/485 device server with 1 100BaseF(X) multi-mode fiber port (SC connectors), -40 to 75°C operating
temperature
NPort IA5150I-M-SC-T: 1-port RS-232/422/485 device server with 1 100BaseF(X) multi-mode fiber port (SC connectors) and 2 KV optical isolation,
-40 to 75°C operating temperature
NPort IA5150-S-SC-T: 1-port RS-232/422/485 device server with 1 100BaseF(X) single-mode fiber port (SC connectors), -40 to 75°C operating
temperature
NPort IA5150I-S-SC-T: 1-port RS-232/422/485 device server with 1 100BaseF(X) single-mode fiber port (SC connectors) and 2 KV optical isolation,
-40 to 75°C operating temperature
NPort IA5250-T: 2-port RS-232/422/485 device server with 2 10/100BaseT(X) ports (RJ45 connectors, single IP), -40 to 75°C operating temperature
Optional Accessories (can be purchased separately)
Din-Rail Power Supply: See page A-8
SC male to ST female duplex adaptors: See page A-11
Package Checklist
• NPort IA5000 series device server
• Documentation and software CD
• Quick installation guide (printed)
• Warranty card
Dimensions
Unit: mm (inch)
20
(0.79)
69.5 (2.74)
25.9 (1.02) 35 (1.38) 25.9 (1.02) 35 (1.38)
20.6
(0.81)
29.91
(1.18)
11.5
(0.45)
124.5 (4.9)
118.5 (4.67)
89.2 (3.51)
14.5
(0.57)
66.6 (2.62)
79.5 (3.13)
92.4 (3.64)
29 (1.14)
29 (1.14)
14.5
(0.57)
14.5
(0.57)
NPort IA5150
NPort IA5150 I
NPort IA5150-S-SC
NPort IA5150-M-SC
NPort IA5150 I-S-SC
NPort IA5150 I-M-SC
NPort IA5150
NPort IA5150I
NPort IA5250
NPort IA5150I-S-SC
NPort IA5150I-M-SC
NPort IA5150-S-SC
NPort IA5150-M-SC
NPort IA5250
