NuForce S3-BT User manual

w
u
L
0
lL
J
[
lf1
Q)
.r:::
D..
0
D
::l
CD
r-
~
co~
Q)
I
~
(Y)
~
(J) ]
ca
>-
~
Q)
D
4-
_c
Ql
:r:

FCC Compliance Statement
Fe
Hereby,NuForce Inc.declares that this deviceisIn compliance with the
limits for aClass 8 digital device, pursuant to part 15 of the FCC Rules.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment uses and
can radiate radio frequency energy.
If not installed and operated in accordance with the
instructions, it may interfere with radio communications.
There is no guarantee that interference will not occur in a particular installation. If this
equipment does interfere
with radio or television reception, the user may be able to correct
the problem by one or more of the following measures:
D Reorient or relocate the receiving antenna.
D Increase separation between equipment and receiver.
D Connect the equipment into an outleton acircuit different from that towhich the receiver
is connected.
D Consultthe dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the
FCC class B limits may be attached to this
equipment.
Changes
or modifications made to this equipment. not expressly approved by us or parties
authorized
by us could void the user's authority to operate the equipment. This device
complies
with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Notice
for customers: The following information is only applicable to equipment sold in
countries applying EU Directives.
EU Declaration of Conformity
(€
Hereby,NuForce Inc.declares that this device is in compliance with the
essential requirements and other relevant provisions of Directive
2004/108/EC.
The manufacturer
of this product is NuForce. 382 South Abbott Ave, Milpitas, CA 95035, USA.
The Authorized Representative for EMC and product safety is NuForce. 382 South Abbott Ave,
Milpitas, CA 95035. USA.
For any service or guarantee matters please refer to the addresses given in separate service
or guarantee documents.
For customers in Europe
)t
Disposal of Old Electrical & Electronic Equipment (Applicable in the
European Union and other European countries with separate
collection systems)
This symbol on the product or on its packaging indicates thatthis productshall not be treated
as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health. which could otherwise be caused by inappropriate waste handling of this
product. The recycling
of materials will help to conserve natural resources. For more detailed
information about recycling of this product, please contact your local Civic Office, your
household waste disposal service orthe shop where you purchased the product.
SAFETY
IN STRUCTIONS
There are
two categories of Safety Instructions included in this manual:
D Product Warnings. (i.e
.. what must never be done to assure avoiding those hazards that
could cause bodily injury or property damage)
D User Directions (i.e .. what must always be done to assure the safe use of your device).
The Safety Instructions contained in this manual have been categorized in accordance with
the seriousness of the potential hazardsthrough the use ofSignal Words. Those Signal Words.
and their intended meanings. are
as follows:
DANGER : Indicates that failing to observe the Safety Instructions could result in death or
catastrophic bodily injury.
WARNING: Indicates that failing to
to observe the Safety Instructions could result in serious
bodily injury.
CAUTION: Indicates
thatfailing to observethe Safety Instructions could result in minor bodily
injury or property damage.
NOTE : Designates important information that relates to activities and/or conditions that
might result in loss of data and/or damage to your device.
Safe Use and Operation of Your Device
This equipment emits stray RF energy and will interfere with the reception of signals by
airborne electronic navigational devices or medical devices.
Do not operate this equipment
near any sensitive medical devices.
WARNING: Use only grounded AC power cords.
Always immediately disconnect the power to the equipment in the event the device emits an
unusual odor or sound or generates smoke.
WARNING : Never attempt to disassemble, repair or make any modification to your device.
Disassembly. modification or any attempt at repair could cause bodily injury or property
damage,
as well as damage to the device itself.
WARNING :Your device is not a toy. Never allow children to play with your device. Misuse.
rough
or improperhandling of your device by children could result in serious bodily injury for
any
of the enumerated safety warnings in this manual. In addition. always keep all accessories
and components
out of the reach of small children as small parts might present a choking
hazard. Seek immediate medical attention
if choking occurs or if any small part has been
swallowed.
CAUTION : Never raise the sound volume level
too high when using your device with
earphones.
An excessive sound volume level could cause damage to your hearing.
WARNING:
To reduce the risk of fire or electric shock. do not expose the unit to moisture or
water.
Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture. or a
foreign object gets into the enclosure, immediately disconnect the power cord from the wall.
Take the unit to a qualified service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual
so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the product itself.
Follow all operating instructions.
Do
not use this unit near water.
Allow for a minimum 10
em or 4 inches of unobstructed clearance around the unit. Do not
place the unit on a bed. sofa. rug. or similar surface capable of blocking ventilation openings.
Ifthe
unit is placed in abookcase orcabinet. allow for proper ventilation. Keep thecomponent
away from radiators. heat registers, stoves,
or any other appliance that produces heat.
If the unit requires a power supply:
D It must
be connected to a power supply only of the typeand voltage specified on the rear
panel.
D Connectthe component to the power
outlet only with the supplied power supply cable or
an exact equivalent. Do not modify the supplied cable.
D
Do not route the power cord where it will be crushed, pinched, bent. exposed to heat. or
damaged in any way.
Pay particular attention to the power cord at the plug and where
the cord exits the back
of the unit.
D The power cord should be unplugged from the wall outlet during a lightning storm or if
the unit is to be left unused for a long period of time.
Immediately stop using the component and have
it inspected and/or serviced by a qualified
service agency if :
D The power supply cord
or plug has been damaged.
D Objects have fallen
or liquid has been spilled into the unit.
D The unit has been exposed to rain.
D The unit shows signs of improper operation.
D The unit has been dropped
or damaged in any way.
1

Introduction
The NuForce 53-BT is an active loudspeaker featuring high-fidelity (apt-X and
AAC)
8/uetooth
wire-
less connectivity. It's designed
to
fit
your
modern lifestyle and decor while also delivering a level
of
audiophile-quality
that
many dedicated enthusiasts have longed for-wirelessly.
8/uetooth (BT)-enabled devices are
now
commonplace,
but
most have always had one weakness -
mediocre sound quality. While many
BT
speakers
work
well for basic applications, they really aren't
able
to
deliverhigh quality
sound-at
least
not
by
NuForce standards.That's becausethey
emp
l
oy
the
old and
inferior
"SBC"
codec
.l
ncontrast.
the
NuForce
S3
-
BT
is based on the latest"apt-X" codec, which
was developed
to
enable
the
kind
of
crystalline sound
that
NuForce customers have come
to
expect.
Regardless
of
how
the signal
is
delivered
to
it, every speaker
is
still a speaker
at
its core, so sound
quality always dependends on the fundamental principles
of
speaker design, including
the
materials
used.
We
kept this in mind when designing the
S3-BT,
which we
built
upon a platform
of
advanced
design and superior components. The woofer is constructed using a proprietary "anti-resonance"
cone technique and powerful magnet assembly, while the
tweeter
is a custom soft-dome design
known among audiophiles
for
offering the lowest distortion and smoothest natural response.
In its "standard mode," out-of-the-box
form
, the
S3-BT
with
apt-X codec offers exceptional
8/uetooth
performance.
Even
so,
for
those hardcoreaudiophiles
who
demand the highestlevel
of
wireless fidel-
ity, we've made the
S3-BT
upgradeable by including an additional set
of
analog inputs in the design.
This allows
the
user
to
bypass the standard 8/uetooth connection in favor
of
using NuForce's
own
Air
DAC
wireless system,
or
even a wired connection.
The advantage
to
using the NuForce Air
DAC
is
that
it
was designed
to
achieve a level
of
true
16-bit
performance
that
simply isn't possible
with
the
8/uetooth
standard.
As
good
as
8/uetooth w
it
h apt-X
is,the
S3-BT
mated
with
the
NuForce Air
DAC
sounds even better.
Whetheryou choose
to
use the
S3-BT's
"standard mode"8/uetooth wireless,
or
upgradeits sound
with
the Air
DAC
system,
the
S3-BT
offers a much needed, audiophile-grade alternative
to
mediocre wire-
less sound. Don't settle
for
less than
the
best any longer: get
the
clarity, detail and power all NuForce
products are known for, with the NuForce
S3-BT.
Packaging
Content
S3-BT
BookshelfSpeakers
3.5mm stereo
to
RCA
Cable
InterconnectSpeaker Cable
2 pes
1pc
1
pc
AC
Power Adapter
User Manual
Quick start guide
1pc
1
pc
1pc
2

D
c::.
/
0 Bluetooth
0 Line~ in
G~
(o
volume
~=~
--..,
8
8
••I)
o)
/
Top View
Speaker binding posts
Bluetooth
LED
Source selector button
Line-in LED
Play/Pause
Next track
Previous track
Volume control
3

ON
OFF
nur=orcE
S3- BT
Bluetooth powered ac tive speakers
Designed by NuForce in Milpitas,
CA
FCC 1D : A3HS3-B T
apt~ · CE: C A
-@
@
~ I
5V :-.:: 1A
~
[00 ------+--+----
C- to LEFT SPEAKER
DC IN:
18V :-.:: 2A
@ @
~ ----+---+----
+ 6-Ce--4)
L
Rear View (right channel unit)
Audio input (Line-in)
Bass reflex port
USP.. charging port for mobiledevices
Power
on/off switch
DC input jack for power supply
Speaker binding posts
4

Connect to your sourcedevices
NuForce53-BT can connect
to your devices
wirelesslyand/orwired.
8/uetooth WirelessConnection
0 Turn on the AC powerswitch on the back of the unit.
8 The Bluetooth LED will first light up in blue, then
pairing will initiate in about 2 seconds. with the
8/uetooth LED blinking alternatively in red and blue
colors. Note
that 8/uetooth connection is the default
source selection.
8 Select "NuForce S3-BT" from the
8/uetooth device
list
of your 8/uetooth device. Your 8/uetooth device
indicates when pairing is complete. The
8/uetooth
LED on S3·BT blinks slowly in blue when pairing is
complete. (Please consult the user manual of your
8/uetooth source devices for instructions on how to
pair them with other 8/uetooth devices)
0 To change to another 8/uetooth source device, turn
off the
8/uetooth connection on the current device,
then press and hold the Play/Pause button on the
top control panel
for a few seconds, this will restart
the pairing process.
0 If pairing is not completed in 2 minutes, S3-BT will go
into power-saving mode, with the 8/uetooth LED
blinking inred. Press and holdthePlay/Pause button
for afew seconds to re-start pairing.
Wired Connection
0 Connect the analog output of your TV or other
source devices
to S3-BT's Audio Input RCA jacks with
the included
RCA interconnectcable.
8 Press the "Source" button on the control panel to
select "Line-in" as the source; The Line-in LED will
lightup.
Volume
control and other operations
0 Press the "Source" button to select between Blue-
tooth and Line In as the input source. Note that you
may need
to go through the pairing process again
when you switch back
from Line-in to8/uetooth_
8 Press the volume button to increase or decrease the
volume.
8
You can use the "Previous track/Next track" button
to jump to the previous or next track on your
8/uetooth device. Note that this function works only
with
8/uetooth devices supporting AVRCP profile
(this includes devices running
iOS 4.1 or later,
Android
1.5 or later. and Windows Mobile 5.0 or later).
0 The USB charging port allows you to charge your
mobile devices via a USB cable. Please refer to the
user manual
of your mobiledevices for instructions.
Specifications
Speakers
1" soft dome tweeter x 2
3.5'" composite paper cone wooferx 2
Amplifier
Maximum power output: 18 Watt x 2 RMS
Harmonic distortion:<0.5% 1W 1kHz
Frequency response :
50 Hz - 20 kHz
Signal/Noise ratio:>75 dB
Separation :>45 dB
Input/Output
Speaker output on right channel unit: Five-way binding posts
Speaker input on left channel unit: Five·way binding posts
Analog
Input : RCA jacks
USB Charger Port: Sv . 1A output (strictly for charging mobile
devices only,
no audio/data transmitting)
8/uetooth wireless connection : 8/uetooth coreversion 4.0 with
aptX. SBC, AAC codecs; A2DP and AVRCP profiles
(C) 2 01 2, Nuforce, Inc. All rights reserved.
• The
aptx• software iscopyri ght CS Rpic or it sgroupcompanies. All rights reserved.The
aptX• markand
the aptX logoare trade marks of CSR pic or one of its group companies
and maybe registered
in one or morejurisdictions.
•• The 8/uetooth• word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any user of such marks by Nuforce, Inc. is under license. Nuforce, the
Nuforce logo and
S3·BT are trademarks or registered trademarks of Nuforce, Inc. USA.
All othertrademarks are theproperty of their respective owners.
5
