Numark Drake SS-K-733B User manual

1
Questions, problems, missing parts with this product? Do not return to your
retailer,please call our customer service department 9:00 a.m. to 5:00 p.m.
Eastern Standard Time Monday through Friday Phone # [phone]
or contact us at www.numarkcustomerservice.com
Drake 5 piece high dining set
ASSEMBLY INSTRUCTIONS
SS-K-733B/5(2018)

2
Parts
Hardware
Screw Metal washer
Bolt Allen wrench
Glass bumper
Ie x 2
Ib x 2 Ic x 80
Ia x 80 + 2 spare
A
B
C
D1
D2
E
F
G
H
chair back
chair seat
front panel
left connection Bar
right connection Bar
metal leg
table support bar
bottom crossbar
glass top
4
4
4
4
4
2
2
1
1
Id x 1 spare
G
E
E
F
F
H
A
B
C
D1
D2
Assembly instruction
1
Do not tighten completely.
Repeat procedure for the other side.
Ia x 7
Bolt
Ic x 7
Metal Washer
A
B
Ia
Ic
Ia
Ic

3
Assembly instruction
3
2
Do not tighten completely.
Repeat procedure for the other side.
Ia x 5
Bolt
Ic x 5
Metal Washer
A
B
C
Ic
Ia
Ia
Ic
Trun over the chair and securely tighten all bolts.
Ia x 6
Bolt
Ic x 6
Metal Washer
Repeat procedure for the other chair.
D1
D2
C
A
D1
Ic
Ia
Ia
Ic
Ia
Ic
A
C
D2

4
Assembly instruction
4
Ia x 8
Bolt
Ic x 8
Metal Washer
Do not tighten completely.
Repeat procedure for the other three side.
E
F
F
Ic
Ia
E
5
Repeat procedure for the other side.
Ib x 2
Screw
Note:The arrow points upside when assembling
E
G
F
G
E
Ib
6
Securely tighten all bolts, put the glass onto the assembled frame.
H
