NUTRICHEF PKNESPRESO60 User manual

EspressoMachine
PKNESPRESO60
Automatic Capsule Espresso Maker
(Works with Nespresso Coffee Capsule Pods)

www.NutrichefKitchen.com 2
PLEASE READ THIS INSTRUCTION MANUAL
AND SAFETY INSTRUCTIONS BEFORE OPERATING THE APPLIANCE!
Content
Safety precautions
Notes on this operating manual
Unpacking
Starting up
• Before using for the first time
• Capsule type can be used
• Overview of machine parts and controls
• Filling/refilling the water tank
• Flushing out the machine/internal piping
Brewing coee
• Refill hydraulic circuit when water tank is out of water during brewing
• Programming coee volume.
Energy saving mode
Cleaning
• Emptying the Capsule container/drip tray
• Clean the coee machine
Decalcification
Factory reset
Steaming out/storage/transportation
Troubleshooting
Technical data

www.NutrichefKitchen.com
3
Safety Precautions
Please take time to read these
safety precautions carefully
before connecting your machine
to the power supply. It is essential
to follow them and the operating
instructions.
• First read this entire operating
manual.
• Danger of electric shock! Never
immerse the machine in water or
any other liquid.
• Connect only to a properly
grounded power point.
• To make sure that the machine is
switched o, remove the plug
from the power point.
• Always pull out the power plug
before:
* Relocating the machine.
* Cleaning or maintenance.
* Long periods of disuse.
• Never clamp or run the power
cable over sharp corners or edges.
• Danger of electric shock!
Damaged power cables may only
be replaced at the customer
service centre.
• Danger of electric shock! Never
touch the power plug/socket/
cable or the machine with damp
or wet hands. Never unplug by
pulling out the power cable;
always remove the plug.
• If you need an extension cable,
make sure it is suitable for your
machine (3-pole grounded,
1.5 mm2 conductor cross -
section), and lay the cable to
avoid tripping.
• Danger of scalding! Never move
the machine during operation!
• Never operate the machine
without water
• Always make sure there is water
in water tank not less than
minimum level.
• Danger of burning! Never touch
very hot parts of the machine
(e.g. brew unit during operations).
• Danger of scalding! Do not touch
the steam or water jets.
• Danger of scalding! Do not move
the operating lever when the
machine is still under pressure
making Coee .
• Do not use the machine in case of:
*Faulty operation
*Damaged power cable.
*After falling or other damage.
*In such cases immediately have
the machine checked and
repaired if necessary at the
customer service centre.
•The machine location must meet
the following requirements:
* Choose a dry, stable and level
support surface not immediately
underneath the power point.
at least 60 cm away from the
washbasin and taps.
*Never place on flammable/
fusible surfaces or equipment.
* Never place the machine or
power cable on or nearer than

www.NutrichefKitchen.com 4
Notes
This operating manual cannot cover all possible circumstances. For further
information or in case of problems not adequately covered in this operating
manual, please contact the service and sales centre.
Please keep this operating manual safe and pass it on to the next user.
Unpacking
• Remove your espresso Capsule coee machine from its packaging.
• After unpacking, please check that the following parts are included:
1. Water tank
2. Coee machine
3. Manual
50 cm to hot surfaces or open
flames.
* Never cover the machine during
operation.
• Keep children away from the
machine during operation.
• Only use the machine in dry
rooms.
• Danger of tripping! Do not let the
power cable hang down.
• This machine is only intended for
household use.
• Pull out the power plug and allow
the machine to cool down
completely before cleaning and
or Maintenance.
• To prevent damage, never use
replacement parts or accessories
not recommended by the
manufacturer
• This appliance is not intended for
use by young children or inform
persons unless they have been
adequately supervised by a
responsible person to ensure that
they can use the appliance safely,
Young children should be
supervised to ensure that they
don’t play with the appliance .
• If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in
order to avoid hazard.
This appliance is intended to be
used in household and similar
applications such as:
*Sta kitchen areas in shops,
oces and other working
environments;
*Farm houses;
*By clients in hotels, motels and
other residential type
environments;
*Bed and breakfast type
environments.

www.NutrichefKitchen.com
5
Note:
• Check that your home power supply voltage is the same as marked on
the machine rating plate
• Destroy all the plastic bags to prevent danger to children!
Tip: Keep the packaging for transporting the machine (e.g. for removals,
servicing, etc.)
Note:
You may find little water remaining in the machine.
In order to ensure that this machine works perfectly, it was tested with
water before leaving the factory.
• DANGER OF FROST
Starting up
Before using for the first time
Caution: Improper handling of electrical equipment is dangerous and can
be lethal. Please pay attention to the safety precautions in this manual, in
particular the following:
• Danger of scalding: beware of hot water!
• Do not operate the machine with an empty water tank or water is less
than MINIMUM level.
• Do not open the handle when the machine is brewing.
• Always pull out the power plug before cleaning the machine.
• Only use the machine in a dry room.
• Thoroughly rinse out the water tank with fresh water before using for the
first time. Clean the Capsule coee machine using a damp cloth only.

www.NutrichefKitchen.com 6
Machine Parts and Controls Overview
No. name
A handle
B buons
C Dispenser
D Drip tray set
E
ll
E wa
ll
F Water tank
G water tank
(removable)
H Power cord
I Main switch
J Used capsule
container
K Drip tray cover
L drip tray
(removable)
Short espresso button
A
Lungo
Espresso
button
B
C
Normal
espresso
button
C
DE
J
D
J
K
L
Adjustable dispenser
spout (2 positions）

www.NutrichefKitchen.com
7
Definition of Lighting
name status funcon acon
indicator
First use. 
machine and internal
circuit”
Light steady/Water tank
is empty.
Fill up water tank, open
handle, then press any
btl th i t l
b
u

on
t
o
l
th
e
i
n
t
erna
l
circuit.
Light steady Stand-by
 Blinking when
warming up.
Wait for ready.
light steady ready
Each  blinks
circularly.
In energy saving mode.
Light in
used
capsule
container
light steady when
handle is open.
Check if the used capsule
container is full or not.

www.NutrichefKitchen.com 8
Fill / Refill Water Tank
• Slide the water tank slowly on water tank base. When the water tank
outlet is inserted in the inlet receptacle, push firmly on the water grip
as shown in direction 2 to lock the water tank.
Flushing out the machine and internal piping/first use
There are two ways to fill the water tank:
Directly into the machine, by using for example a jug, or
by removing the water tank.
Filling without removing the tank
• Raise the water tank lid
• Fill the tank up to the “MAX” mark with cold fresh
water (the maximum capacity is 0.8 litre), or at least
the “Min” mark .
• low down the lid
Filling by removing the water tank
• Hold the water grip at tilting angle as
shown in direction 1 to remove the water
tank from the machine.
• Fill the tank up to the “MAX” mark with
cold fresh water (the maximum capacity is
0.8 litre). or at least the“Min” mark .
Before using for the first time or after long pauses
(e.g. holidays) the machine must be flushed out.
This short procedure can flush out and cleans the internal
piping thoroughly.
• Fill water tank to maximum level.
• Plug in the appliance and turn it on.

www.NutrichefKitchen.com
9
Press any button to start pump, once water is detected entering the internal
circuit, the red indicators becomes blue. The machine starts to heat up
automatically when detected water in circuit with 3 buttons blinking.
The lights on the control buttons are blinking, blue lights in
used-capsule container is lighted in blue which goes o after
1 minute
Tips: You can check easier if the used container is full
or not when the blue light is ON. The indicator will
blink in red for first use, meaning the internal circuit is
empty. Please fill up water tank and open the handle.
The lights on buttons become steady when the
machine is heated up, heating up time is 40 seconds
approximately
Press the lungo coee button, before pressing the
button, make sure that:
• The handle is closed without capsule inside.
• The water tank is full.
• The water tank is firmly in place, otherwise water may
leak.
• The drip tray with the used capsule container is
completely inserted (never operate the machine
without drip tray set (part D shown in “Overview of
machine parts and controls”), or hot water will run
out when opening handle.).
• A large bowl ( 250ml size or above) is placed under
the dispenser.
• Press the middle button to start flush out.
• Open the handle when the flush out process stopped
automatically.
• Empty the cup.
• Flush out cycle is finished

www.NutrichefKitchen.com 10
Brewing Coee
3. Insert capsule to fall straight into the compartment correctly.
4. Close the handle firmly to load the capsule .
5. Press the desired coee button only once
6. The selected button will blink and the machine is brewing coee,
dispensing will stop automatically when reaching the default brewing
volume (30ml for short espresso, 60ml for normal espresso, 110ml for
lungo espresso), default setting can be programmed, please refer to “how
to program volume”.
7. Raise the handle to eject the used capsule into the container.
8. Close the handle.
Tips:
• If the machine is cold (for example, using the machine in the morning or
idle time longer than 1 hour), it is suggested to brew water first in order to
remove the residual taste of the last cup.
• When brewing is finished , a small amount of water will be dicharged to
the water tank ,it is clean water and still drinkable.
Refill internal circuit when water tank is out of water during brewing.
• It is strongly suggested to be sure there is enough water in the tank
before making coee,minimum level at least.
In case water is running out during coee brewing, you can stop it by
pressing the selected button which is blinking.
Open the handle to eject the used capsule.
CAUTION: Beware of hot steam: danger of scalding! Fill up water tank
and press one of the buttons to start pumping water, once the circuit is
refilled, the indicator light turns from red to blue.
*Make sure the water tank is in place before brewing.
Because there is hot cleaning water come out during
heating up.
CAUTION HOT WATER RISK OF SCALDING
1. Place an empty cup under the dispenser.
For small cups, low down the dispensing spout.
2. Move the handle back completely

www.NutrichefKitchen.com
11
Programming the coee volume.
1. Place an empty cup under the dispenser. For small cups, low down the
dispensing spout.
2. Raise the handle back completely
3. Insert capsule into the compartment gently.
4. Close the handle firmly to load the capsule.
5. Press the desired button and keep it pressed down, once the desired
volume has been reached, release the button, now the button is
reprogrammed.
6. After the programming, the size will be recorded in memory for next use,
by clicking the button normally (ie, press once.)
Do the same for other buttons if required.
Volume range: 25ml ~150ml based on Nespresso“Ristretto” capsule &
“lungo” capsule), default size is 25ml (short espresso), 40ml (normal
espresso), and 110ml (Lungo espresso).
Tips: when programming process is finished, leave the machine for 30
seconds for cool down prior to open handle. The blinking frequence is 1
second 1 blink, hence, you can counter the blinking to know the brewing
time.
Be sure there is enough water in the tank before
programming coee volume. Make sure the water tank
is in place before brewing. Because there is hot clean-
ing water come out during heating up.
CAUTION HOT WATER RISK OF SCALDING

www.NutrichefKitchen.com 12
Energy saving mode.
The machine enters energy saving model automatically once the machine is
idle for 15 minutes. The 3 buttons will flash cyclically in energy saving mode.
To access quiet energy saving mode, please press any button, appliance will
start warming up with lights blinking, when the buttons are lit steadily, the
machine is ready to brew coee.
Cleaning
Emptying the capsule container and drip tray. The capsule container holds
around 10 used capsules. We recommend emptying the used capsule
container and the drip tray every day, you can see if the used capsule
container is full or not while the blue light is on in the used capsule
container.
1. Raise the handle to ensure there is no capsule inside the
brewing compartment.
2. Raise the dispensing spout up if it is in low position.
3. Hold the drip tray firmly and pull it out by lifting gently.
4. Dispose of used capsules and drip tray.
5. The used capsule container can be detached,
if necessary, from the lower drip tray (snaplock).
6. Resin out the drip tray set with fresh water.
7. Remove the water from the appliance, resin out the
water tank with fresh water.
8. After emptying/cleaning, reassemble the parts in reverse
order and insert them back to machine in place.
Important:
The plastic parts of the machine are not dishwasher safe
Coee Machine
•Always pull out the power plug before cleaning the
machine
•Never immerse the machine in water or clean it under
running water
•Clean the machine with a dry cloth
•Never use abrasive cleaning agents or materials (use e.g.
dry rags or kitchen paper)

www.NutrichefKitchen.com
13
Decalcification
Decalcification / Maintenance
Drinking water varies according to region. The lime particles in hard
drinking water are deposited as residues in the machine and can block the
piping and cause damage. To prevent this, be sure to decalcify the machine
at the very least after making 300 to 400 cups of coee or in any case if the
output falls significantly or after one or two months. Decalcification must be
done correctly to prevent damage.
So it is essential to follow these instructions.
Important:
•Never clean the machine with vinegar.
This causes damage and makes your coee taste bad.
•Damage caused by incorrect decalcification or failure to decalcify is not
covered by the guarantee.
•Caution: HOT WATER!
1. Recommendations: Purchase commercially available decalcifier
(decalcifying liquid), diluted according to the manufacturer‘s instructions;
pour the mixture in the water tank.
2. Make sure there is without Capsule inside the machine.
3. Place a large bowl under the dispensing head to collect the decalcification
diluted and lime residues.

www.NutrichefKitchen.com 14
4. Fill the water tank with water to maximum level mixed with decalcifying
solution, make sure the solution is dissolved completely.
5. Press the small button to run decalcifying water as you brew coee
normally, repeat for several times to run out the entire tank water.
6. Repeat the process to run another tanks of water mixed with decalcifying
solution.
7. Repeat the process to Flush out the intern circuit with a tank of fresh
water (without the decalcifying solution) to clean the internal circuit
completely.
Factory Reset
Tips:
Make the reset when machine is warmed up so that you can see flash signal
easier.
In case you want to have the default setting of the
machine, please follow below instruction
a. Turn o the machine.
b. Press the lungo button and keep the button pressed,
then switch ON the machine simultaneously, release the
button after 3 seconds or when you see the buttons
flash. if the machine is warming up after reset, the
machine will flash more than twice).
c. After above operation, the machine is reset to factory
default setting- the following parameters are reset:
1. Coee brewing volume
• 25ml (Short Espresso)
• 40ml (Normal Espresso)
• 110ml ( Lungo)
2. After the reset, machine can start to work when the
lights are steady.

www.NutrichefKitchen.com
15
Steaming out / Storage / Transport
Steaming Out
•Prior to long periods of disuse or for storage or transport at temperatures
below 41°F, it is essential to steam out the machine.
This removes water from the system to prevent internal frost damage.
•Turn ON the machine
•Empty the water tank and place it in its position.
•Put an empty cup under the coee dispensing spout.
•Press “lungo” button to start brewing.
•Steaming out now commences.
After the pump stops automatically, the steaming out process is
completed.
•turn OFF the machine and unplug.
CAUTION:
•CAUTION HOT WATER RISK OF SCALDING

www.NutrichefKitchen.com 16
TROUBLESHOOTING
Capsule droped down directly
to used capsule container.
 The water tank is empty.
-The Cold cups / mugs.
- Scale build-up in machine.
- Cold machine.
Fill water in the water tank.
Preheat cup / mug.
- Descale.
- For cold machine, brewing a cup of
water to warm up the circuit.
Empty the used capsule container.

the handle and open it once again.
- Leave a few seconds to let the residual
pressure to escape.
-Occasional drops are normal, it is
not a defect
-The used capsule container
is full.
-The capsule is deformed

- Opened the handle too

-Capsule deformed
-the heater is keeping warm.

Capsule can’t drop down
steam when handle opened.
Water on table
Occasional drops drip out of
the dispensing head
Handle can not close
-Water tank is leaking.
-Drip tray is full of water.

opened the brewing chamber
without drip tray set in place.
-Water tank is out of its place

-Check if the valve on water tank is
stuck.
- Empty the drip tray.
- Make sure the drip tray set is in place.
- Make sure the water tank is in place.
1)Change the Capsules.

align with the Capsule chamber.

-Use a new Capsule
-Capsule is not placed well in
brewing chamber.

www.NutrichefKitchen.com
17
PKNESPRESO60
Espresso Machine
Automatic Capsule Espresso Maker
(Works with Nespresso Coee Capsule Pods)
Features:
• Countertop Espresso Maker
• Brew Size Selectable: Short, Normal or Lungo Espresso Cups
• Compatible with Nespresso Coee Capsule Pods
• Simple Electric Plug-in Design
• Quick Heat Ability, Warms in Seconds
• Sleek, Modern Kitchen Style
• Integrated (10) Capsule Pod Storage Tray
• LED Indicator Lights
• Stain-Resistant & Easy-to-Clean
• Integrated Rellable Water Tank
• Energy Ecient Auto Power-O Feature
• Removable Parts for Hassle-Free Clean-Up
• Safe for Placement on Any Kitchen Table or Countertop!
What’s in the Box:
• Espresso Maker
• Drip Tray
Technical Specs:
• Power Rating: 1260 Watt
• Capsule Pod Holder Capacity: 10 Capsule Pods
• Brew Sizes: Short 25ml, Normal 40ml, Lungo 110ml
• Coee Spout Height: 4.3’’ -inches
• Water Tank Capacity: 27 oz.
• Heating Time: Up to 15 Seconds
• Pump Pressure: 19Bar
• Stand by Time: 15 Minutes
• Construction Material: Engineered ABS
• Power Cord Length: 3.2’ ft.
• Power: 110V
• Dimensions (L x W x H): 14.2” x 4.6” x 9.8” -inches
