Nuvo NV-M3 User manual

ENGLISH
Danger
Exposuretoextremelyhighnoiselevelsmaycause apermanent
hearingloss.Individualsvaryconsiderably tonoiseinducedhearing
lossbutnearlyeveryonewilllosesome hearingifexposedtosufficiently
intensenoiseforasufficienttime.TheU.S.Government's
OccupationalSafetyandHealthAdministration(OSHA) hasspecified
thefollowingpermissiblenoiselevelexposures:
AccordingtoOSHA,anyexposurein theabove permissiblelimits could
resultinsomehearingloss. Earplugs orprotectors inthe earcanal orover
theearsmustbewornwhenoperating thisamplification systemin orderto
preventapermanenthearingloss. Ifexposure inexcess ofthe limitsas
putforthabove,toinsureagainst potentiallyharmful exposureto high
soundpressurelevels,it isrecommended thatall personsexposed to
equipmentcapableofinducinghigh soundpressure levels,such asthis
amplificationsystem,be protectedby hearingprotectors whilethis unitis in
operation.
DURATION PER DAY (HOURS) 8 6 4 3 2 1
SOUND LEVEL (dB) 90 93 95 97 100 103
THISSYMBOLISINTENDEDTOALERTTHEUSERTOTHEPRESENCE
OFNON-INSULATED "DANGEROUSVOLTAGE"WITHINTHE
PRODUCT'SENCLOSURETHATMAYBEOFSUFFICIENTMAGNITUDE
TOCONSTITUTE ARISKOFELECTRICSHOCKTOPERSONS.
THISSYMBOLISINTENDEDTOALERTTHEUSERTOTHEPRESENCE
OFIMPORTANTOPERATINGANDMAINTENANCE(SERVICING)
INSTRUCTIONSINTHELITERATUREACCOMPANYINGTHE UNIT.
1. Read all safety and operating instructions before using this
product.
2. All safety and operating instructions should be kept for future
reference.
3. Read and understand all warnings listed on the operating
instructions.
4 . Follow all operating instructions to operate this product.
5. This product should not be used near water, i.e. bathtub, sink,
swimming pool, wet basement, etc.
6. Only use dry cloth to clean this product.
7. Do not block any ventilation openings, It should not be placed flat
against a wall or placed in a built-in enclosure that will impede the
flow of cooling air.
8. Do not install this product near any heat sources ; such as,
radiators, heat registers, stove or other apparatus (including heat
producing amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug.Apolarized plug has two blades with one wider than the
other.Agrounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord being walked on or pinched, particularly at
plugs, convenience receptacles and the point where they exit
from the apparatus. Do not break the ground pin of the power
supply cord.
11 . Only use attachments specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer or sold with the apparatus. When a cart is used,
use caution when moving cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Care should be taken so that objects do not fall and liquids are
not spilled into the unit through the ventilation ports or any other
openings.
15. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way;
such as, power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally
or has been dropped.
16. WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE CHASSIS. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR.
CAUTION
APPARATUSSHALLNOT BE EXPOSEDTO DRIPPING ORSPLASHING
ANDTHATNOOBJECTS FILLED WITHLIQUIDS,SUCHASVASES,
SHALLBE PLACED ONTHEAPPARATUS.
1

2
FRENCH
DURE EN HEURES PAR JOUR 8 6 4 3 2 1
INIVEAU SONORE CONTINU EN dB 90 93 95 97 100 103
Danger
L‘exposition a des niveaux eleves de bruit peut provoquer une perte
permanente de l’audition, Chaque organisme humain reagit
differemment quant a la perte de l’audition, mais quasiment tout le
monde subit une diminution de I’acuite auditive lors d’une exposition
suffisamment longue au bruit intense. Les autorites competentes en
reglementation de bruit ont defini les expositions tolerees aux niveaux
de bruits:
Selon les autorites, toute exposition dans les limites citees ci-dessus,
peuvent provoquer certaines pertes d’audition. Des bouchons ou
protections dans l’appareil auditif ou sur l’oreille doivent etre portes lors
de l’utilisation de ce systeme d’amplification afin de prevenir le risque
de perte permanente de l’audition, Dans le cas d’expositions
superieures aux limites precitees il est recommande, afin de se
premunir contre les expositions aux pressions acoustiquese I evees
potentielIement dangeure u ses, aux personnes exposees aux
equipements capables de delivrer de telles puissances, tels ce
systeme d’amplification en fonctionnement, de proteger l’appareil
auditif.
ATTENTION:AFIN DE LlMlTER LE RISQUE DE CHO ELECTR/QUE, NE
PAS ENLEVER LE CHASSIS. NE CONTIENT PAS DE
PIECES POUVANT ETRE REPAREE PAR L’UTILISATEUR.
CONFER LE SERVICEAPRES-VENTEAUX
REPARATEURS
ATTENTION
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR.
CESYMBOLEAPOURBUTD'AVERTIRL'UTILISATEUR DELAPRESENCE
DEVOLTAGEDANGEREUXNON-ISOLEAL'INTERIEUR DECE PRODUIT
QUI PEUTETRE DE PUISSANCE SUFFISAMMENTIMPORTANTEPOUR
PROVOQUERUNCHOCELECTRIQUEAUX PERSONNES.
CESYMBOLEAPOURBUTD'AVERTIRL'UTILISATEUR DELAPRESENCE
D'INSTRUCTIONSD'UTILISATIONETDEMAINTENANCEDANSLES
DOCUMENTSFOURNISAVECCEPRODUIT.
IMPORTANTES INSTRUCTIONS DE SECURITE
1. Lire avec attention toutes les recommandations et précautions
d'emploi avant d'utiliser ce produit.
2. Toutes les recommandations et précautions d'emploi doivent être
conservées afin de pouvoir s'y reporter si nécessaire.
3. Lire et comprendre tous les avertissements énumérés dans les
précautions d'emploi.
4. Suivre toutes les précautions d'emploi pour utiliser ce produit.
5. Ce produit ne doit pas être utilisé près d'eau, comme par exemple
baignoires, éviers, piscine, sous-sol humides ... Etc.
6. Utiliser exclusivement un chiffon sec pour nettoyer ce produit.
7. Ne bloquér aucune ouverture de ventilation. Ne pas placer le
produit tout contre un mur ou dans une enceinte fernée, cela
gênerait le flux d'air nécessaire au refroidissement.
8. Ne pas placer le produit près de toute source de chaeur telle que
radiateurs, arrivées d'air chaud, fourneaux ou autres appareils
générant de la chaleur (incluant les amplificateurs producteurs
de chaleur) .
9. Ne pas négliger la sécurité que procure un branchement polarisé
ou avec raccordement à la terre, Un branchement polarisé
comprend deux fiches dont l'une est plus large que l'autre. Un
branchement à la terre comprend deux fiches plus une troisième
reliée à la terre. Si la fiche secteur fournie ne s'insert pas dans
votre prise de courant. consulter un 'électricien afin de remplacer
votre prise obsolète.
10. Protéger le cordon d'alimentation de tout écrasement ou
pincement, particulièrement au niveau des fiches, des
réceptacles utilisés et à l'endroit de sortie de l'appareil. Ne pas
casser la fiche de terre du cordon d'alimentation.
11. Utiliser uniquement les accessoires spécifiés par le constructeur.
12. Utiliser uniquement avec le chariot de transport, le support, le
trépied, la console ou la table spécifiés par le constructeur ou
vendus avec l'appareil. Lors de l'utilisation d'un chariot, bouger
avec précaution l'ensemble chariotlappareil afin d'éviter les
dommages d'un renversement.
13 Débrancher cet appareil lors d'orages ou s'il n'est pas utilisé
pendant une longue période.
14. Des précautions doivent être prises afin qu'aucun objet ne tombe
et qu'aucun liquide ne se répande à l'intérieur de l'appareil par
les orifics de ventilation ou n'importe quelle autre ouverture.
15. Pour toutes interventions techniques s'adresser à un technicien
qualifié.L'intervention technique est nécessaire lorsque l'appareil
a été endommagé de n'importe quelle façon, comme par
exemple si le cordon secteur ou sa fiche sont détériorés,si du
liquide a coulé ou si des objets sont tombés à l'intérieur de
l'apparei1,si l'appareil a été exposé à la pluie ou à l'humidité, s'il
ne fonctionne pas normalement ou s'il est tombé.
16. ATTENTI0N:Pour réduire le risque d'incendie ou de choc
electrique ne pas exposer l'appareil à la pluie ou à l'humidité.
AFINDEREDUIRELES RISQUÉD'INCENDIE ETDEDECHARGE
ELECTRIQUE,NEPASEXPOSERCETAPPAREILALAPLUIE OUA
L'HUMIDITE.

3
Introduction
WelcometotheM3AudioServerandtheworldoftruewhole-homemusicenjoyment.TheM3istheperfectmarriageofsimplicity
andfullrangemusicaccessibility.AsingleUSBconnectionwithanyPCallowsWindows®MediaPlayertoautomaticallysync
storedmusicfileswiththeM3's160gigharddrive.Oncesynced,theM3andGrandConcertomakebrowsingmusicbyartist,title,
genreandalbumassimpleasapushofabutton.
R
OUTPUT POWER OUTPUT POWER
20W/6OHM X2 20W/6OHM X2
SYS ON
EXT. MUTE
L
R
L
R
L
R
VARIABLE
OUTPUT
FIXED
OUTPUT
SUM1
3033 118
CUS
CON FORMS T O
UL ST D.65 00
CER TIFIE D TO
CAN /CSA S TD.E 6006 5
NuVo Tec hnolo gies C incin nati Oh io USA
FUS E:T5 A
120V 60Hz 500W
MODE L NV-I8 DM
SIX SO URCE EI GHT ZON E
AUDI O DISTR IBUTI ON SYST EM
www.nuvotech nologies.com
OUTPUT POWER
OUTPUT POWER
OUTPUT POWER
20W/6OHM X2
20W/6OHM X2
20W/6OHM X2
TIP=L
RING=R
VARIABLE
OUTPUT
FIXED
OUTPUT
TIP=L
RING=R
VARIABLE
OUTPUT
FIXED
OUTPUT
TIP=L
RING=R
VARIABLE
OUTPUT
FIXED
OUTPUT
TIP=L
RING=R
VARIABLE
OUTPUT
FIXED
OUTPUT
TIP=L
RING=R
VARIABLE
OUTPUT VARIABLE
OUTPUT
FIXED
OUTPUT FIXED
OUTPUT
TIP=L
RING=R TIP=L
RING=R
1 2 3 4 5 6
1 2 3 4 5 6
2 3 41 2 3
RS-232
CON NECT TO
NV-I8X
USE N V-SLC1
CABLE
CON NECT TO
NV-I8X
USE N V-SLC1
CABLE
CON NECT TO
NV-I8EZP1
USE N V-NC1
CABLE
USE CNLY WITH 250V FUSE
456SUM2
5 6 7 8
OUTPUT POWER
20W/6OHM X2
ZONE 6ZONE 6 ZONE 7&8
SYSTEM ZONE TRIGGER OUTPUTS
SOURCE LINK
SOURCE INPUTS
ZONE 1
NETWORK
EMITTER OUTPUTS DIGITAL LINK
ZONE 3 ZONE 4 ZONE 5
ZONE 2 PROGRAM
6
45
31
2
SOURCE STATUS INPUTS
1
OUTPUT
PASS
THRU
INPUT
IR NuVoNet
SYSTEM
RS 23 2
1
R
LL
R
2 3
USB
100~240V 50~60Hz 40W
MAD E IN CHIN A
Model NV-M3
THR EE SOUR CE MUSI C SERVE R
www.nuvotechnologies.com
N183 9
3033 118
R
T
E
E
T
K
N
I
CM
NuVo Te chnol ogies LLC •Hebron, K Y USA
Devi ce 1
Conn ect to
NV-I8 GM
Conc erto E Z Port
Mode l NV-I8 GEZP
www.n uvotec hnol ogies. com
NuVo Tech nologi es LLC H ebron, K entu cky USA
Devi ce 2 De vice 3
Devi ce 4 De vice 5 Devi ce 6
MENU OK
ModernRock
Drift-FollowTheDay
LivingFor
AM/FM 3:09pm
Diagram refers to the M3 and Grand Concerto in music playback mode NV-M3 Wiring
Diagram

4
OUTPUT
PASS
THRU
INPUT
IR NuVoNet
SYSTEM
RS 23 2
1
R
LL
R
2 3
USB
100~240V 50~60H z 40W
MADE I N CHINA
Model NV-M 3
THRE E SOURC E MUSIC S ERVER
www.nuvo technol ogies.com
N1839
303311 8
R
T
E
E
T
K
N
I
CM
NuVo Te chnol ogies L LC•He bron, K Y USA
1234567
BackPanelFeatures
FrontPanelFeatures
1. OUTPUT: TheM3featuresthreeindependentaudiosourceoutputsfromitssingleharddrive.Theconnectionismade
withstandardstereoRCAcables.
2. IRInput: IRcontrolcanbedoneusingtheIRinputonthebackpanelusingamonomini3.5mmpatchcable.This
replacestheneedfortheplacementofanIRemitteroverthefrontpanelIRreceiver.
3. IRPassThru: AnyIRinformationcomingintotheM3canbepassedthroughtootherdevicesthroughthisoutput.
4. USB: AllmusicfilesaresyncedtotheM3harddriveusingthisUSBconnection.Thesynchappensautomaticallywith
anyPCrunningWindowsMediaPlayerversion11.TheUSBconnectionisalsousedtodownloadM3firmwareupgrades.
5. NuVoNet: TheRJ-45connectionallowscompletecommunicationwiththeGrandConcertodistributedaudiosystem
usingasingleCAT5cable.
6. RS232: ThisDB9portisusedforbidirectionalcommunicationwiththirdpartyhomeautomationsystems.Thenecessary
communicationprotocolisavailableontheNuVowebsiteProzone.
7. ACPower: AstandardIEC2-wirepowercableisusedtoconnecttheM3toanavailableACpowersource.
STANDBY
THREE SOURCE MUSIC SERVER
NV-M3
MENU
OK
Artist
Album
Genres
12
3
45
6
8
7
9
1. STANDBY: ThisblueLED(lightemittingdiode)indicatesthattheM3ispluggedintoanACpowersource.
2. OLEDDisplay: TheM3featuresathreelineorganiclightemittingdiodedisplaythatindicatestheactivityofeachofthe
threeserveroutputs.
3. MENU: TheMENUbuttonisusedtoaccessthebrowsingandsetupoptionsavailabletotheuserandreturntoprevious
menus.
4. Power: ThepowerbuttonisusedtotoggletheM3'soperatingstatebetweenstandbyandfulloutput.
5. Play/Pause: Thisbuttontogglesbetweenplayingtheselectedmusicoutputandatemporarypausestate.
6. PreviousandNext: Thispairofarrowbuttonsisusedtocycleforwardandbackwardbetweentrackswithinalistening
selection.Thesebuttonsarealsousedasshortcutstothefirstandlastmenuselectioninmenumode.
7. IRReceiver: TheM3allowsforwirelessIRcontrolthroughitsfrontpanelIRreceiver.
8. OK: Thisbuttonisusedtoselectahighlightedmenuormusicalselection.
9. Scroll: Theseupanddownarrowbuttonsareusedforverticalscrollingthroughbrowselistsandmenuitems.

5
I. InstallingtheM3Server
AudioConnections
TheM3hasthreeindependentanalogaudiooutputs.
Althoughalltheavailablemusicfilesarestoredonasingle
160gigharddrive,eachoftheaudiooutputsistreatedasa
separateaudiosource.Theconnectiontotheaudiooutputis
madewithastandardstereoRCAcable,fig.1.
SettingtheM3asGrandConcertoNuVoNetSources
Animportantstepinallowingpropercommunication
betweentheM3andtheGrandConcertoSystemissetting
eachofthethreeaudiooutputsasaspecificnumberedinput
fortheGrandConcerto.TheM3isdesignedtopromptyou
throughthisprocessatthefrontpanelcontroluponinitial
startup.ThechoicesareNuVoNetsource1–6orstandalone.
Standaloneisthefirstchoiceandmustbeusedforanything
otherthantheGrandConcertoSystem.
WhentheM3isfirstpluggedintoanACpowersource,the
frontpaneldisplaywillreadPressOKtoselectNuVoNet
Source.Thetoplineofthedisplay,whichcorrespondswith
thefirstaudiooutput,willbehighlighted,fig.2.PressOKto
enterthenextlevelofsetup.ThechoicesStandalone,Source
1,Source2,Source3,Source4,Source5,andSource6will
display.TheStandalonesettingwillbehighlighted.Using
theArrowUpandDownbuttons,scrolltothedesiredsource
numberandpressOK,fig.3.Oncethefirstsourceis
selected,thedisplaywillhighlightthesecondsource
output.Repeattheabovestepsforsourcestwoandthree.
ToresettheNuVoNetsourcesPressMENUandscrolltothe
lastchoicewhichisSettingsandpressOK. Thiswilltakeyou
tothenextmenu.SelectResetMemory,andreturntothe
NuVoNetSourceMenu,fig.4.
SOURCE LINK
SOURCE INPUTS
ZONE 1 ZONE 3
ZONE 2
CONNECT TO
NV-I8X
USE NV-SLC1
CABLE
1 2 3 4 5 6
1 2 3 4 5 6
ZONE 1 ZONE 3
ZONE 2
OUTPUT POWER OUTPUT POWER OUTPUT POWER
20W/6OHM X2 20W/6OHM X2 20W/6OHM X2
VARIABLE
OUTPUT VARIABLE
OUTPUT VARIABLE
OUTPUT
FIXED
OUTPUT FIXED
OUTPUT FIXED
OUTPUT
TIP=L
RING=R TIP=L
RING=R TIP=L
RING=R
L
R
OUTPUT
L
R
1 2 3
Fig. 1
Fig. 2
Fig. 3
Fig. 4
NuVoNet Setup Out.1
Out1:PressOKto
Out2:PressOKto
Out3:PressOKto
Address Out.1
Standalone
Source1
Source2
Settings Out.1
Version
OperatingMode
ResetMemory

6
II. MakingtheNuVoNetConnection
CommunicationwithGrandConcerto'sNuVoNetisdonewith
asingleCAT5cable.A10'pre-terminatedNetworkcableis
includedwiththepackage.Notethatthiscableisterminated
usingstandard568Anetworkwiringandcanbealongcable
ifnecessaryfortheinstallation.
ToenableNuVoNetcommunicationoncetheinitialNuVoNet
sourcesettingismadeonthefrontpaneloftheM3,connect
theNetworkcableonthebackpanelandintooneofthesix
availablePeripheralSourceinputsonthefrontoftheGrand
ConcertoEZPort,fig.5. Onceconnected,theGrandConcerto
ControlPadswilldisplayapromptto“PressMenuto
Browse”.
Devi ce 1
Conn ect to
NV-I8 GM
Conc erto E Z Port
Mode l NV-I8 GEZP
www.n uvotec hnol ogies. com
NuVo Tech nologi es LLC H ebron, K entu cky USA
Devi ce 2 De vice 3
Devi ce 4 De vice 5 Devi ce 6
PASS
THRU
INPUT
IR NuVoNet
SYSTE M
RS 232
USB
Fig. 5
Fig. 6
Fig. 7
III. UsingtheM3Menu
YoucandocompletemusicbrowsingfromanyoftheGrand
ConcertoControlPads,orfromthefrontpaneloftheM3.The
musicbrowsingselectionsare,Playlists,Artists,Albums,
Tracks,Genres,andM3Options,fig.6.
WiththeexceptionofM3Optionsthecontentsofeachofthe
menuitemsisdeterminedbyWindowsMediaPlayer.When
musicisdownloadedfromamusicwebsite,orrippedfroma
CD,MediaPlayeraccumulatestheavailablealbum,artistand
trackinformationandappropriatelycatalogsit.Whenmusic
issyncedfromMediaPlayertotheM3allofthemusic
catalogingisalsosynced.
M3Options
Thissetupmenuhasthreebasicchoices,Shuffle,Repeat,
andEditFavorites,fig.7.EditFavoritesallowsanyplaylists
createdinMediaPlayer,(seeGettingAcquaintedwithMedia
Player),tobesyncedwiththeM3andplacestheminthe
FavoritesmenuoptionatthetopoftheControlPad'smain
menu.Theseareglobalfavoritesaccumulatedfromallthe
availableGrandConcertosourcesforeasyaccess.Whena
playlistisaddedtotheglobalfavoritestheGrandConcerto
SystemwillautomaticallygotoanunusedM3outputand
playtheassociatedmusicalselections.
TopLevel Out.1
Playlists
Artists
Albums
Options Out.1
Shuffle
Repeat
EditFavorites

7
IV. GettingAcquaintedwithWindows
MediaPlayer
MediaPlayeristheresidentmusicarchivingandcataloging
softwarewithMicrosoft'sXPoperatingsystem.Itis
importanttoknowthatMediaPlayer11wasdevelopedfor
thenewVistaoperatingsystem.WhenaCDisinsertedinto
theCDtrayofacomputerrunningXP,itwillautomatically
promptyoutoripthefilestoMediaPlayer.Intheripping
process,MediaPlayersearchestheInternettofindthe
associatedalbumandartistinformation.Whenthe
informationisattained,itcatalogstheinformation
appropriately.Theuseralsohastheoptionofpurchasing
anddownloadingmusicfromavarietyofmusicdownload
sites.Oncerippedordownloadedthemusicisstoredonthe
computer'sharddriveanddisplayedinMediaPlayer's
library,fig.8.
NotethatyoumusthaveMediaPlayerversion11.Notall
versionsofMediaPlayer10arecompatible.Thisisavailable
asafreedownloadfromtheMicrosoftWebsite.
PlaylistsareeasilycreatedinMediaPlayerbychoosingthe
Playlistoptionandcreatinganame.Songsandalbumscan
thenbeaddedbydraggingthemtotherightcolumn,which
automaticallyaddsthemtothelist.Click“SavePlaylist”and
alloftheassociatedalbumsandtracksaresaved.Playlists
createdinMediaPlayercanbesyncedwiththeM3,fig.9.
TheOnlineStoresbuttondisplayslinkstoavailablemusic
downloadsitesforquickandeasyaccess.Musicpurchased
anddownloadedcanbesyncedwiththeM3,fig.10,(see
SyncingMusicFileswiththeM3Server).
NotethattheWMAlosslessformattedMusicGiantsfiles
cannotbeplayedonthecurrentversionM3.
Fig. 8a
Fig. 9
Fig. 8

8
V. SyncingMusicFileswiththeM3
Server
AnymusicfilesstoredinMediaPlayer,whetherrippedfrom
aCDordownloadedfromanonlinemusicstore,canbe
syncedandenjoyedthroughtheM3.Thesyncprocessis
accomplishedwithasingleUSBcableconnection.Bydesign
whentheUSBconnectionismadefromtheM3toacomputer
usingtheMicrosoftXPoperatingsystem,thecomputerwill
recognizetheM3andpromptyoutosync,fig.11.
NotethattheM3onlyrequiresaUSBconnectionwitha
computerandACpowerforsynchronization.Itisnot
necessarytobeconnectedtoNuVoNet.TheUSBmustbe
disconnectedfornormalplaybackmode.
Whenconnected,youcanchoosetosyncspecificfilesby
draggingthemtothesynccolumnontherightsideofthe
MediaPlayerwindow.ClickingontheStartSyncbuttonwill
beginsyncingtheselectedfiles,fig.12.
Theotherchoiceistosynctheentirelibrary.Thisis
suggestedfortheinitialsync.Itisbesttodothiswitha
standardUSBcable,fig.13.Oncecompleted,theentire
musiclibrarywillbeduplicatedontheM3'sharddrive.
ToaccessthesyncoptionsfortheM3,clickonthedown
arrowundertheMediaPlayerSyncbuttonwhiletheM3USB
isconnected. ThereyoucanscrolldowntotheM3menu
optiontorevealtheavailablesyncoptions,fig.14.
DeletingFilesfromtheM3Library
TheleftsideofMediaPlayerallowsaccesstotheconnected
M3harddrive.Whenyouselectalbumorsongswithinthe
M3,itslibrarywillbedisplayed.Youcanthenhighlightthe
specificgenres,artists,albumsortracksyouwishtodelete
andrightclick.Thiswillbringupamenuthatwillallowyou
tochoosedelete,fig.15.
Fig. 10
Fig. 11
Fig. 12

9
Fig. 13 Fig. 14
Fig. 15

10
Specifications
System Description
ServerConfiguration: HardDisk-based,threeoutput
Paralleloperationcapability: Alloutputscapableofsimultaneousindependent browsing(viaNuVonet)orplayback
Applicableindustrystandards: MicrosoftWindowsMediaDigitalRightsManagement10(WMDRM10)forPortableDevices
MicrosoftPlaysForSurecertification(pendingasofDecember28,2006)
Real-TimeClockCapability: SecureClockfortime-limitedDRM-protected musiccontent perMicrosoftWMDRM10
specifications).
Outputs: Threestereoanalog,eachwithdualRCAjacks
ControlNetworkInterface: NuVoNetproprietarycontrolnetwork,RS485physicallayer,230.4KBaud
OtherControlPorts: RS232withcustomprotocolforbrowse/playback,57.6KBaudfull-duplex,threeoutputs
independentlyaddressable
LocalControlInterface-Display: OLED,EleganceYellow,1.6"diagonal,128x64pixels
LocalControlInterface-Controlkeys: Touchsensing-Power,Menu,FFWD/next,REW/previous,Play/Pause,OK,UP,DOWN
Musicsynchronization(downloading)port: UniversalSerialBus(USB)2.0-compatible
RecommendedmusicdownloadingPCapplication: MicrosoftWindowsMediaPlayer11
AlsocompatiblewithotherWindowsapplicationsutilizingcurrentMicrosoftMediaTransfer
Protocol(MTP)
IRControlCapability(withnon-Concertosystems): Power,Menu,FFWD/next,REW/previous,Play/Pause,OK,UP,DOWNFavorites
NOTE-IRcapabilitynotimplementedinversionspriorto1.10
IRSensorLocation: Frontpanel,center
OtherIRControlInputs: WiredIRinputvia 3.5mm2-circuitjack,-3Vpeakto12Vpeak,38KHzmodulated
pulsepatternNuVopulsedefinitions,NECformat
IRControlOutput: IRPass-throughparallelledwithwiredIRinput
HardDiskDrivesize: 160Gigabyte
OutputLevel: Full-scaledigitaloutput=1.12Vrms(4.5Vpeak-to-peak)
Fileformatssupported: MP3,32Kilobitpersecond(Kbps)to320Kbps,sampleratesto44.1KHzasdictatedbyfile
WMAfixedbitrate,withorwithoutWMDRM10encoding,fixed,48kbpsto192kbps
WMA,variablebitrate,withorwithoutWMDRM10,to355kpbs
WAV(uncompressedlinearPCM),16-bit,samplerates to44.1KHz(1411.2kbps)
Powerrequirements: 100-240VAC,50/60Hz,35Wmaxstartup(lessthan2seconds),10Woperating
Dimensions(notincludingrackearsorfeet): 167/8"Wx101/4"D15/8"H(1rackunit)
Weight,actual: 6.85pounds(3.11kilograms)

www.nuvotechnologies.com
2395 Arbor Tech Dr. Hebron, Kentucky USA
859-817-7200
NuVo Technologies LLC
M3 0705
