nvent SCHROFF 11850-016 User manual

User Manual
1 U MTCA Shelf
Product Number:
11850-016
Doc-No: 63972-350_R1.0 February 2016

R1.0 February 2016 Initial release
Impressum:
Schroff GmbH

Langenalber Str. 96 - 100
75334 Straubenhardt, Germany
The details in this manual have been carefully compiled and
checked - supported by certified Quality Management System
to EN ISO 9001/2000
The company cannot accept any liability for errors or misprints.
The company reserves the right to amendments of technical
specifications due to further development and improvement of
products.
Copyright2016
All rights and technical modifications reserved.

11850-016
R1.0, February 2016 I
1 Safety ....................................................................................................................... 1
1.1 Safety Symbols used in this document.............................................................................. 1
1.2 General Safety Precautions ............................................................................................... 1
1.3 References and Architecture Specifications...................................................................... 1
2 Hardware Platform ................................................................................................... 2
2.1 Front and Rear View.......................................................................................................... 3
2.2 ESD Wrist Strap Terminal .................................................................................................. 3
3 Backplane ................................................................................................................. 4
3.1 Backplane Topology .......................................................................................................... 4
3.2 Fabric Interface ................................................................................................................. 5
3.2.1 Common Options............................................................................................... 5
3.2.2 Fat Pipe .............................................................................................................. 5
3.2.3 Extended Fat Pipe .............................................................................................. 5
3.3 Intelligent Platform Management Bus (IPMB) .................................................................. 5
3.3.1 IPMB-L................................................................................................................ 5
3.4 Power Management.......................................................................................................... 5
4 Cooling ..................................................................................................................... 6
4.1 Air Filter............................................................................................................................. 6
4.2 Air filter swap .................................................................................................................... 6
4.3 Cooling .............................................................................................................................. 6
4.4 Power Supply..................................................................................................................... 7
5 EMCH (Embedded MicroTCA Carrier Hub)................................................................. 8
5.1 Front Panel and LEDs......................................................................................................... 9
5.2 Comand Line Interface (CLI) ............................................................................................ 10
5.2.1 COM-Settings ................................................................................................... 10
5.3 Firmware Update ............................................................................................................ 11
6 Technical Data ........................................................................................................ 12

11850-016
II R1.0, February 2016

11850-016
R1.0, February 2016 Safety 1
1 Safety
The intended audience of this User’s Manual is system integrators and hardware/software
engineers.
1.1 Safety Symbols used in this document
1.2 General Safety Precautions
• Use of this product in a manner not specified by the manufacturer may impair the safety protec-
tion of this equipment.
• Service personnel must know the necessary electrical safety, wiring and connection practices for
installing this equipment.
• Install this equipment only in compliance with local and national electrical codes.
• For additional information about this equipment, see the PICMG MicroTCA 
Specification (www.picmg.com).
1.3 References and Architecture Specifications
•PICMG
®MTCA.0 Specification
(www.picmg.com)
•PICMG
®AMC® Base Specification
(www.picmg.com)
Hazardous voltage!
This is the electrical hazard symbol. It indicates that there are dangerous voltages inside the
Shelf.
Caution!
This is the user caution symbol. It indicates a condition where damage of the equipment or
injury of the service personnel could occur. To reduce the risk of damage or injury, follow all
steps or procedures as instructed.
Danger of electrostatic discharge!
The Shelf contains static sensitive devices. To prevent static damage you must wear an ESD
wrist strap.
Warning!
Voltages over 60 VDC can be present in this equipment. As defined in the PICMG 3.0 Speci-
fication, this equipment is intended to be accessed, to be installed and maintained by

qualified and trained service personnel only.

11850-016
2Hardware Platform R1.0, February 2016
2 Hardware Platform
The Schroff 11850-016 is an 1 U/2slot MicroTCA Shelf with EMCH (Embedded MicroTCA
Carrier Hub) for AMC Single Full-size or Mid-size modules (with 2 HP filler panel).
Features:
• Shielded steel case
• 2 AMC single Full-size slots
• MicroTCA Backplane
• EMCH (Embedded MicroTCA Carrier Hub) with basic MicroTCA functionality for switching
and managing two AMCs (Advanced Mezzanine Cards)
• Power management controller on the backplane
• Active cooling through: 
4 fans for cooling the AMC modules
1 fan for cooling the power supply
• Easy removable air inlet filter
• Integrated 150 W AC Power Supply with wide range AC input and 12 V DC output.
• AC mains/line module with IEC 320-C14 connector, integrated mains/line fuses and line
filter

11850-016
R1.0, February 2016 Hardware Platform 3
2.1 Front and Rear View
Figure 1: Front and RearView
2.2 ESD Wrist Strap Terminal
The ESD Wrist Strap Terminal (4 mm banana jack) is located left to the card cage.
1ESD Wrist Strap Terminal 5EMCH interfaces
22 HP Filler panel 6Ground Terminal (Equipotential bonding)
3AC input 7PSU
4Mains/line switch 8EMCH
Danger of electrostatic discharge!
The Shelf contains static sensitive devices. To prevent static damage you must wear an ESD
wrist strap.

11850-016
4Backplane R1.0, February 2016
3 Backplane
• 3.3 V management power generation on the backplane
• Hot-Swap circuitry for enabling the management power and payload power by the EMCH
• Fan connectors on the backplane (4-pin fan connectors)
3.1 Backplane Topology
Figure 2: Backplane Topology
AMC1 AMC2
Fabric 1/A (1000Base-BX)
Clocks - FCLKA AMC
(1:1 connection)
Clocks - TCLKB AMC (Output)
Clocks - TCLKC AMC
Clocks - TCLKD AMC (Output)
Clocks - TCLKA AMC
IPMB_L
DC/DC
Converter
+3,3V
HotSwap
AMC Port 2 (SATA)
AMC Port 3 (SATA)
MCH
AMC Port 4-7
(FAT PIPE)
Port 0
Port 1
Fabric 2/A (1000Base-BX)
Common Options
Port 2
Port 3
A
4Port 4-7
A
BB
CC
DD
FAN1 FAN 2 FAN3
FAN4 FAN 5
+12V
FAN _Control
PPWR_2
PPWR_1
PPWR
MP_2
PRESENT_1
MP
I²C
Carrier Number
+12V FAN_Tacho
5
EN_HSC_1
Current
Sense
EEPROM
FRU
PRESENT_2
EN_AMC1
MP_1
EN_AMC2
IR_HotSwap
4
AMC Port 8-11
(EXT.FAT PIPE)
Port 8-11

11850-016
R1.0, February 2016 Backplane 5
3.2 Fabric Interface
3.2.1 Common Options
MCH Fabric Port 1 is routed to AMC 1 Port 0.
MCH Fabric Port 2 is routed to AMC 2 Port 0.
MCH Fabric Port 3 is routed to AMC 1 Port 1.
MCH Fabric Port 4 is routed to AMC 2 Port 1.
AMC Ports 2 and 3 are direct slot to slot connections between both AMC slots.
3.2.2 Fat Pipe
AMC slots Port [4:7] are direct slot to slot connections between both AMC slots.
3.2.3 Extended Fat Pipe
AMC slots Port [8:11] are direct slot to slot connections between both AMC slots.
3.3 Intelligent Platform Management Bus (IPMB)
MicroTCA uses an Intelligent Platform Management Bus (IPMB) for management
communications.
3.3.1 IPMB-L
Radial IPMB from MCH to both AMCs.
3.4 Power Management
The integrated power management circuitry on the backplane provides 12 V payload power
distribution branches to the AMC Slots. It also generates the 3.3 V management power and
distributes it to all slots.
The current to the AMC slots is limited to:
•8A(PayloadPower)
• 250 mA (Management Power)

11850-016
6Cooling R1.0, February 2016
4 Cooling
4.1 Air Filter
Figure 3: Air Filter
4.2 Air filter swap
The system provides a replaceable air filter. The air filter can be pulled out after removing the top
cover. The filter meets the requirements of the Telcordia Technologies Generic Requirements GR-78-
CORE specification.
4.3 Cooling
Figure 4: Airflow
The MicroTCA Shelf is equipped with four 12 VDC fans for cooling the AMC modules and one 12 VDC
fan for cooling the power supply. The fans are controlled as a group by the EMCH.
e
1Air Filter

11850-016
R1.0, February 2016 Cooling 7
4.4 Power Supply
The system has a 150 W open frame AC power supply with wide range AC input and 12 V DC output.
The DC output is connected directly to the power management circuitry on the backplane.
The power input is provided by an AC mains/line module with IEC 320-C14 connector, integrated
mains/line fuses, line filter and a mains/line switch.
Fuse value is T2AH250V.
Figure 5: AC Input
Table 1: Data AC Power Supply
e
Hazardous voltage!
Parts of the power supply may be exposed with hazardous voltage. 
Always remove mains/line connector before carry out any assembly work.
Caution!
The unit is designed in accordance with protection class 1! It must therefore be operated with protec-
tive earth/GND connection. Use only a three conductor AC power cable with a protective earth

conductor that meets the IEC safety standards!
Caution!
There is a ground terminal at the right side. This ground terminal is only for equipotential bonding.
Grounding is achieved through the protective earth conductor of the power cable!
1AC Input 3Equipotential bonding
2Mains switch 4Fuse holder
Input voltage 100 - 240 VAC
Mains Frequency 50 / 60 Hz
Output (max.) 150 W
Output voltage 12 V DC
Output voltage ripple and noise 120 mVpp
Operating Temperature -5° C - +55° C

11850-016
8EMCH (Embedded MicroTCA Carrier Hub) R1.0, February 2016
5 EMCH (Embedded MicroTCA Carrier Hub)
The EMCH (Embedded MicroTCA Carrier Hub) is intended to provide basic MicroTCA
functionality for switching and managing two AMC (Advanced Mezzanine Card) modules.
It delivers switching and hub functionality for the system fabric gigabit ethernet (GbE) as
defined in the AMC.0 standard series.
Furthermore it supports the typical hot swap management and its transition state machine
(M0 to M6) for each AMC module. In addition to that, the embedded MCH monitors and
verifies local sensor data of the chassis and installed FRU devices and supplies MicroTCA
power and cooling concepts by accessing the chassis integrated power supply and fan
coolers.
Remote administration can be done locally over the CLI (Command Line Interface) served by
the front USB port.
Figure 6: EMMC Block Diagram
Microcontroller
1000Base-BX#2
MII
1000Base-BX#1
1000Base-T
(Uplink)
IPMB-L#2
IPMB-L#1
Gigabit-
Ethernet-
Switch
FAN Tacho/PWM
PS1#[0,1]
EN#[0,1]
Hot-Swap
Controller
Current
Sensor
I2C
I²C
Backplane
USB-Serial
Port
HSC_CTL
AMC#2
1000Base-BX
IPMB-L
EN# / PS#
AMC#1
1000Base-BX
IPMB-L
EN# / PS#
Power
Supply
FANs
FAN Tacho/PWM
12V
eMCH
FRU
EEPROM
1000Base-BX#2 1000Base-BX#1
1000Base-BX 1000Base-BX
MP
Generaon
Status-
LEDs
MP
PP
Frontpanel

11850-016
R1.0, February 2016 EMCH (Embedded MicroTCA Carrier Hub) 9
5.1 Front Panel and LEDs
The EMCH front panel consists of two status LEDs for the AMCs, and each one LED (OK, FAIL)
for the system’s operation status. In addition to the LEDs, you can find sockets for a RJ45 plug
and a micro USB cable.
Figure 7: EMMC Front Panel
Table 2: EMCH front panel
- Note: When executing the bootloader, all LEDs will be put on.
OK
FAIL
12
AMC
Type Function
LED AMC1 Blink Short: Reading FRU information (M1)
Blink Slow: Waiting for HS-Handle being closed (M1)
ON: FRU operating state (M4)
OFF: No Module installed
LED AMC2 Blink Short: Reading FRU information (M1)
Blink Slow: Waiting for HS-Handle being closed (M1)
ON: FRU operating state (M4)
OFF: No Module installed
LED OK Blink Slow: -
Blink Short: Test Mode
ON: Normal operating status. No error
OFF:-
LED FAIL Blink Slow: -
Blink Short: -
ON: Hard fault
OFF: -
Micro USB Type A Used for virtual COM-Port. Direct connection to PC
RJ45 Gigabit-Ethernet 1000Base-T Uplink for remote control

11850-016
10 EMCH (Embedded MicroTCA Carrier Hub) R1.0, February 2016
5.2 Comand Line Interface (CLI)
The EMCH is providing a low level command line interface (CLI) which allows to set certain
operational parameters and to display run time information from the MCH and the system.
5.2.1 COM-Settings
The CLI can be accessed over the front MicroUSB port. To establish a connection to a host PC,
use a serial terminal program e.g. Terra-Term, HTerm, Putty, e.g.
Configure the COM port settings as followed:
Table 3: COM port settings
If the terminal is opened, press enter to see if the connection is established successfully.
You can now type “help” to see the list of available commands. Press enter to call the
previous command again.
NOTE: Depending on your operating system, you need to download and install the FTDI-chip
driver manually. Drivers can be downloaded at http://www.ftdichip.com/FTDrivers.htm.
Installing the driver automatically by the windows update may take up to a few minutes.
Table 4: CLI Commands
Baudrate 115200
Data 8 bit
Parity None
Stop 1 bit
Flow control None
COM The devices COM address defined by host
Command Parameter Description
bi Board Information
Prints the vital product information record (i.e. Serial num-
ber, Hardware revision and release codes).
ip <ip>
<netmask>
<gateway>
IP configuration
Configures IP addresses, net mask, broadcast address and
gateway. Parameters have to be in dotted representation
<x.x.x.x>
ni Print network configuration
ti Print task information
bl Starts the bootloader
show_localsensors Show local sensor information of the chassis
show_fru Show all FRU’s
show_fruinfo <fru_id> FRU contents
Shows the contents of a FRU device selected by <fru_id>.
For valid FRU numbers please refer to MTCA R1.0 table 3-3
show_sensorinfo <fru_id> Shows the sensor values of the selected FRU
show_pm Power Module Status
Shows the actual power allocation status for all AMC mod-
ules
reboot Reboot the eMCH
password <old_password>
<new_password>
Changes the web password for accessing the update ser-
vice

11850-016
R1.0, February 2016 EMCH (Embedded MicroTCA Carrier Hub) 11
5.3 Firmware Update
The EMCH serves a web based front end to easily upgrade the devices firmware in field. To
use this utility, first establish an ethernet link over the EMCH uplink port. If not changed, the
standard interface config is as followed:
Table 5: Standard interface configuration
Type http://192.168.1.138/ in your web browser or type “bl” in the command line interface
to call the bootloader. Your browser should show the index page with a button “call
bootloader”. By clicking on this button, a software reset will be triggered and the system will
boot into the bootloader. Wait a few seconds and call http://192.168.1.138/ again. The page
should have changed slightly and will prompt you to enter a password. By default, the
password is “nat”. To leave the bootloader without touching anything, just click on “Leave
Bootloader”.
By clicking on “submint” the upload page should open.
Now select a proper firmware image with the file extension “.srec”. Click upload to flash the
image into the device memory.
NOTE: The upload process will take a few seconds, please don’t interrupt or close the browser
while upgrading.
If succeed, the Message “File Upload Done” is shown. Click on “Reset MCU” to trigger a
software reset. The device should now boot into the new firmware.
NOTE: If something went wrong during the firmware upgrade (e.g. lost of power or
communication during file transfer), the device will boot into the bootloader again instead of
loading the firmware. In this case you can easily repeat the firmware upgrade.
IP address: 192.168.1.138
Netmask: 255.255.255.0
Gateway: 0.0.0.0

11850-016
12 Technical Data R1.0, February 2016
6 Technical Data
Table 6: Technical Data
Physical Dimensions
Height 43.60 mm (1 U)
Width 265 mm
Depth approx. 302 mm
Weight
Weight completely assembled approx. 2.7 Kg
Power Supply
Input Voltage 100 VAC to 240 VAC
Mains Frequency 50 Hz to 60 Hz
Input Current 1,2 A at 100 VAC; 0,5 A at 240 VAC
Input Fuse (2x) T2AH250V
Environmental
Ambient temperature -5°C…+45°C (long term)
Ambient temperature -5°C…+55°C (short term)
Humidity +5%...+85%, non-condensing

Schroff GmbH

Langenalber Str. 96 - 100
75334 Straubenhardt, Germany 
Tel [phone]
Fax [phone]
Doc-No: 63972-350_R1.0
