Chenbro RB238 Series User manual

RB238 2U Server
RB238G13-U08 User Manual
August 2019Version 1.1
A document provides an overview of product features, functions, architecture, and support specifications

Revision History
Refer to the table below for changes made on this version of the RB238G13-U08 Server User
Manual.
Date
Version
Updates
10/03/2019 V1.00
Copyright Notice
© Copyright 2018 Chenbro Micom Co., Ltd
The information contained herein is subject to change without notice. The only warranties for
Chenbro Micom Co., Ltd products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. Chenbro Micom Co., Ltd shall not be liable for technical or
editorial errors or omissions contained herein.
Links to third-party websites take you outside the Chenbro Micom Co., Ltd website. Chenbro
Micom Co., Ltd has no control over and is not responsible for information outside the Chenbro
Micom Co., Ltd website.
Microsoft®, Windows®, and Windows Server® are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
Intel® is a trademark or registered trademark of Advanced Micro Devices, Inc. in the United
States and/or other countries.
CE Notice
Warning: This equipment is compliant with Class A of EN55032. In a residential environment,
this equipment may cause radio interference.
Avertissement: Cet équipement est conforme à la classe A de la norme EN55032. Dans un
environnement résidentiel, cet équipement peut provoquer des interférences radio.
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

Table of Contents 3
Table of Contents
Revision History.............................................................................................................................2
Copyright Notice............................................................................................................................2
CE Notice.......................................................................................................................................2
FCC Notice .....................................................................................................................................2
System Tour ......................................................................................................................................6
Front panel identification ..............................................................................................................6
24-bay 2.5" HDD/SSD configuration ..................................................................................................................................6
Rear panel identification................................................................................................................7
Server components........................................................................................................................8
24-bay 2.5" HDD/SSD configuration....................................................................................................................................8
Mainboard components ................................................................................................................9
SAS expander board components.................................................................................................10
16-CH SAS BPB components .......................................................................................................11
8-CH NVMe BPB components.......................................................................................................12
Fan locations ...............................................................................................................................13
DIMM slot locations ....................................................................................................................13
Status LED indicators ...................................................................................................................15
Front panel LED indicators ................................................................................................................................................15
Rear panel LED indicators..................................................................................................................................................16
Serial label pull tab ......................................................................................................................17
Operations......................................................................................................................................18
Power down the server................................................................................................................18
Using Power Control function through BMC.....................................................................................................................18
Wistron BMC ...............................................................................................................................19
Using BMC.........................................................................................................................................................................19
Firmware Information .......................................................................................................................................................19
Firmware Update ..............................................................................................................................................................20
HPM Firmware Update......................................................................................................................................................24
Remove the top covers ................................................................................................................26
Install the top covers ...................................................................................................................28
Setup ..............................................................................................................................................30
Overview.....................................................................................................................................30
Powering up the server................................................................................................................30
Powering on and selecting boot options in BIOS setup ....................................................................................................30

Table of Contents 4
System utilities................................................................................................................................31
BIOS setup...................................................................................................................................31
Accessing the BIOS setup menu screen ............................................................................................................................31
Navigating the BIOS setup menu screen ...........................................................................................................................33
Remote Flash BIOS ............................................................................................................................................................33
BIOS setup menu screen ..............................................................................................................34
Main menu ........................................................................................................................................................................34
Advanced menu ................................................................................................................................................................36
Chipset menu ....................................................................................................................................................................54
Socket Configuration menu...............................................................................................................................................59
Server Management menu ...............................................................................................................................................71
Security menu .................................................................................................................................................................77
Boot menu .......................................................................................................................................................................82
Wistron menu .................................................................................................................................................................83
Save & Exit menu ..............................................................................................................................................................86
System upgrades.............................................................................................................................87
Required tools .............................................................................................................................87
Safety considerations (Considérations de sécurité).......................................................................87
Preventing electrostatic discharge ....................................................................................................................................87
Symbols on equipment .....................................................................................................................................................87
Warnings and cautions......................................................................................................................................................88
Preparation procedures ...............................................................................................................89
2.5" HDD/SSD storage..................................................................................................................90
Air baffle .....................................................................................................................................96
Memory options..........................................................................................................................98
Memory module population rules ....................................................................................................................................99
Memory Reliability, Availability, and Serviceability (RAS) features .................................................................................100
DIMM identification ........................................................................................................................................................102
Replacing the DIMM .................................................................................................................. 103
M.2 SSD module ........................................................................................................................ 105
M.2 22110 SSD Module...................................................................................................................................................105
M.2 2280 SSD Module.....................................................................................................................................................107
Heatsink .................................................................................................................................... 110
Processor................................................................................................................................... 113
PCIe add-on card ....................................................................................................................... 117
Fan module ............................................................................................................................... 119
Fan carrier/bracket .................................................................................................................... 121
SAS expander board................................................................................................................... 124
System battery .......................................................................................................................... 126
Mainboard ................................................................................................................................ 128

5
Cabling ......................................................................................................................................... 131
Cabling overview ....................................................................................................................... 131
24-bay SAS/SATA/NVMe Storage .............................................................................................. 131
SAS expander board to HBA add-on card........................................................................................................................132
8-CH NVMe BPB ..............................................................................................................................................................133
16- CH SAS BPB to 8-CH NVMe BPB ................................................................................................................................134
Front I/O Board ......................................................................................................................... 134
Specifications................................................................................................................................ 135
Environmental specifications ..................................................................................................... 135
Server specifications.................................................................................................................. 135
System rating............................................................................................................................. 136

System Tour 6
System Tour
Front panel identification
24-bay 2.5" HDD/SSD configuration
Item Description Item Description
1 2.5" NVMe SSD slot 1 16 2.5" SATA/SAS HDD/SSD slot 16
2 2.5" NVMe SSD slot 2 17 2.5" SATA/SAS HDD/SSD slot 17
3 2.5" NVMe SSD slot 3 18 2.5" SATA/SAS HDD/SSD slot 18
4 2.5" NVMe SSD slot 4 19 2.5" SATA/SAS HDD/SSD slot 19
5 2.5" NVMe SSD slot 5 20 2.5" SATA/SAS HDD/SSD slot 20
6 2.5" NVMe SSD slot 6 21 2.5" SATA/SAS HDD/SSD slot 21
7 2.5" NVMe SSD slot 7 22 2.5" SATA/SAS HDD/SSD slot 22
8 2.5" NVMe SSD slot 8 23 2.5" SATA/SAS HDD/SSD slot 23
9 2.5" SATA/SAS HDD/SSD slot 9 24 2.5" SATA/SAS HDD/SSD slot 24
10 2.5" SATA/SAS HDD/SSD slot 10 25 USB 2.0 port
11 2.5" SATA/SAS HDD/SSD slot 11 26 Serial label pull tab
12 2.5" SATA/SAS HDD/SSD slot 12 27 USB 2.0 port
13 2.5" SATA/SAS HDD/SSD slot 13 28 Reset button
14 2.5" SATA/SAS HDD/SSD slot 14 29 UID button/LED
15 2.5" SATA/SAS HDD/SSD slot 15 30 Power button/LED

System Tour 7
Rear panel identification
Item Description
1 Redundant power supply unit 2
2 2.5" SATA HDD rear dummy cover
3 RJ45 for BMC management LAN
4 PCIe add-on card slots
5 Rear UID button/LED
6 1G/10G LAN port 1
7 1G/10G LAN port 2
8 USB 3.0 port
9 Debug UART
10 VGA port
11 Redundant power supply unit 1

System Tour 8
Server components
24-bay 2.5" HDD/SSD configuration
Item Description
1 2.5" SATA/SAS HDD and NVMe SSD (24)
2 8-CH NVMe SSD backplane board (1)
3 SAS expander board (1)
4 System fan (4)
5 Mainboard (1)
6 RTC battery (1)
7~8 M.2 SSD (2)
9 PCIe add-on card (4)
(support low profile PCIe add-on cards only)
10 Heatsink (2)
CPU (2)
11 2.5" SATA HDD/SSD dummy cover (1)
12 Redundant power supply unit (2)
14 DIMM slots (16)
15 16-CH HDD/SSD backplane board (1)
NOTE: Boards shown in blue color will change to green color during mass production.

System Tour 9
Mainboard components
Item Description Item Description
1 PCIe x8 slot 13 CPU2 socket
2 PCIe x16 slot 14 DIMM A1/A2/B1/C1 slots
3 PCIe x16 slot 15 DIMM J1/J2/K1/L1 slots
4 PCIe x16 slot 16 M.2 connectors
5 CPU1 socket 17 CPU2 storage connector
6 CPU1 8-pin ATX power connector 18 CPU2 storage connector
7 DIMM D1/D2/E1/F1 slots 19 CPU2 storage connector
8 CPU1 storage connector 20 Front board USB2 signals connector
9 DIMM G1/G2/H1/I1 slots 21 Front board side-band signal
connector
10 24-pin ATX power connector 22 BPB side-band signal connector
11 RPSU side-band signal connector 23 RTC battery socket
12 CPU2 8-pin ATX power connector 24 TPM connector

System Tour 10
SAS expander board components
Item Description
1 Fan 1 connector
2 Fan 2 connector
3 SAS signal input connector
4 SAS signal input connectors
5 SAS signal output connectors
6 Fan 3 connector
7 Fan 4 connector
8 Sideband signal connector
9 BPB power connector

System Tour 11
16-CH SAS BPB components
Item Description
1 BPB power connector
2 BPB power connector
3 SATA/SAS signal connector
4 Sideband signal connector
5 SATA/SAS 9~24 connectors

System Tour 12
8-CH NVMe BPB components
Item Description
1 BPB power connector
2 Sideband signal connector
3~10 PCIe input signal connectors
11 NVMe SSD 1~8 connectors

System Tour 13
Fan locations
Item
Description
1 Fan 1
2 Fan 2
3 Fan 3
4 Fan 4
DIMM slot locations

System Tour 14
DIMM slots are labeled alphabetically (A through L) and must be populated sequentially, i.e.
from A1 to A2 to B1 to C1, up to L1. There are six (6) channels per processor numbered
sequentially from 1 to 6.
Item Description Item Description
A1 CPU1 DIMM Slot 1 G1 CPU2 DIMM Slot 1
A2 CPU1 DIMM Slot 2 G2 CPU2 DIMM Slot 2
B1 CPU1 DIMM Slot 3 H1 CPU2 DIMM Slot 3
C1 CPU1 DIMM Slot 4 I1 CPU2 DIMM Slot 4
D1 CPU1 DIMM Slot 5 J1 CPU2 DIMM Slot 5
D2 CPU1 DIMM Slot 6 J2 CPU2 DIMM Slot 6
E1 CPU1 DIMM Slot 7 K1 CPU2 DIMM Slot 7
F1 CPU1 DIMM Slot 8 L1 CPU2 DIMM Slot 8

System Tour 15
Status LED indicators
The status LED indicators aid in problem diagnosis by indicating the status of system
components and operations of the server.
Front panel LED indicators
Item Function Status Status Description
1* System Power Off Blue
Blue (blinking)
System is off / No AC power
Powered on
Stand by
2* Unit identification Off
Blue UID is off UID is on
3 HDD activity indicator Off
Amber (blinking) No HDD installed HDD is active
4* System status indicator Off
Red System is off/normal System fault
5 and 6 LAN activity indicator Off Green
Green (blinking)
No connection
Linked to network
Network is active
7 HDD cage status indicator Off
Blue No HDD installed HDD is installed
8 HDD cage activity indicator
Off
Green
Red (solid)
Red (4Hz-blinking)
Red (1Hz-blinking)
HDD not active
HDD is active
HDD error
Locate
Re-build
NOTE: *This LED is hardware and software controlled.

System Tour 16
Rear panel LED indicators
Item Function Status Status Description
1 and 2 Power Supply
Off
Green
Amber
Not installed / fault
Active
Failure; AC cord unplugged / No AC
power
3 NIC Link (left) Off
Yellow (blinking) No connection Linked and activity on the network
4 NIC Link (right)
Off
Green
Amber
Yellow
No connection
Linked to 100Mbps network
Linked to 1G network
Linked to 10G network
5* Unit identification Off
Blue UID is off UID is on
NOTE: *This LED is hardware and software controlled.

System Tour 17
Serial label pull tab
The serial label pull tab contains important information about the server like the BMC
username and password.
To access the serial tab:
A. Pull the serial label tab from the chassis.

Operations 18
Operations
Power down the server
Before powering down the server for any upgrade or maintenance procedures, perform a
backup of critical server data and programs.
IMPORTANT:
When the server is in standby mode, auxiliary power is still being provided to
the system.
To power down the server, use one of the following methods:
•Press and release the Power On/Standby button.
This method initiates a controlled shutdown of applications and the OS before the server
enters standby mode.
•Press and hold the Power On/Standby button for more than 4 seconds to force the server
to enter standby mode.
This method forces the server to enter standby mode without properly exiting applications
and the OS. If an application stops responding, you can use this method to force a
shutdown.
•Use a virtual power button selection through BMC.
This method initiates a controlled remote shutdown of applications and the OS before the
server enters standby mode.
Before proceeding, verify that the server is in standby mode by observing that the system
power LED is amber.
Using Power Control function through BMC
The following options are available when using Power Control function through BMC:
•Power On—Similar to press and release of the Power On/Standby button
•Power Off—Similar to the press and hold of the Power On/Standby button more than 4
seconds.
•Power Cycle—Power off and then power on the server
•Hard Reset—A forced reboot that does not reach standby

Operations 19
Wistron BMC
BMC is a remote server management processor embedded on the system boards of
RB238G13-U08 servers. BMC enables the monitoring and controlling of servers from remote
locations. Wistron BMC management is a powerful tool that provides multiple ways to
configure, update, monitor, and repair servers remotely. BMC (Standard) comes preconfigured
on Chenbro servers without an additional cost or license.
Using BMC
To log-in, you need to enter your username and password. You can find this information
printed in the serial label pull-tab (Link).
Firmware Information

Operations 20
To check the current firmware version that is installed in your server, from the BMC menu bar,
click Maintenance > Firmware Information.
The current firmware information will be displayed.
Firmware Update
