Nvidia nForce 650i Ultra SLI User manual

USER'S MANUAL
Of
NVIDIA nForce 650i SLI
And
NVIDIA nForce 430 Chipset
Based
M/B for LGA775 Quad Core Ready
Intel Core Processor Family
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
NO. G03-N650GE--FR10
Rev: 2.0
Release date: July 2007

ii
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize pollution and
ensure environment protection of mother earth, please recycle.

ii
USER’S NOTICE.....................................................................................................................iii
MANUAL REVISION INFORMATION ..............................................................................iii
COOLING SOLUTIONS........................................................................................................iii
CHAPTER 1 INTRODUCTION OF NFORCE 650I SLI AND NFORCE430 MOTHERBOARDS
1-1 FEATURES OF MOTHERBOARD.................................................................................... 1
1-1.1 SPECIAL FEATURES OF MOTHERBOARD.................................................... 2
1-2 SPECIFICATION.................................................................................................................. 3
1-3 PERFORMANCE LIST........................................................................................................ 4
1-4 LAYOUT DIAGRAM & JUMPER SETTING................................................................... 5
CHAPTER 2 HARDWARE INSTALLATION
2-1 HARDWARE INSTALLATION STEPS............................................................................. 7
2-2 CHECKING MOTHERBOARD'S JUMPER SETTING.................................................. 7
2-3 INSTALL CPU....................................................................................................................... 8
2-3-1 GLOSSARY............................................................................................................. 8
2-3-2
ABOUT INTEL LGA775 CPU............................................................................ 9
2-3-3 LGA 775 CPU INSTALLATION GUIDE............................................................. 10
2-4 INSTALL MEMORY............................................................................................................ 19
2-5 EXPANSION CARD ............................................................................................................. 20
2-5-1 PROCEDURE FOR EXPANSION CARD INSTALLATION............................ 20
2-5-2 ASSIGNING IRQ FOR EXPANSION CARD...................................................... 20
2-5-3 PCI-EXPRESS SLOT............................................................................................. 21
2-5-4 SLI BRIDGE FOR NVIDIA SLI TECH. SUPPORTED VGA CARDS............. 22
2-6 CONNECTORS, HEADERS................................................................................................ 23
2-6-1 CONNECTORS....................................................................................................... 23
2-6-2 HEADERS ............................................................................................................... 27
2-7 STARTING UP YOUR COMPUTER ................................................................................. 30
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP.............................................................................................................. 31
3-2 GETTING HELP................................................................................................................... 31
3-3 THE MAIN MENU................................................................................................................ 32
3-4 STANDARD CMOS FEATURES........................................................................................ 33
3-5 ADVANCED BIOS FEATURES.......................................................................................... 34
3-6 ADVANCED CHIPSET FEATURES.................................................................................. 36
3-6-1 DRAM TIMING SETTINGS................................................................................ 36
3-7 INTEGRATED PERIPHERALS......................................................................................... 37
3-7-1 ONCHIP IDE FUNCTION ................................................................................... 38
3-7-2 ONCHIP DEVICE FUNCTION........................................................................... 39
3-7-3 ONCHIP SUPER IO FUNCTION........................................................................ 39
3-8 POWER MANAGEMENT SETUP ..................................................................................... 40
3-9 MISCELLANEOUS CONTROL........................................................................................ 41
3-9-1 IRQ RESOURCES.................................................................................................. 41
3-10 PC HEALTH STATUS........................................................................................................ 42
3-11 THERMAL THROTTLING OPTIONS ............................................................................ 43
3-12 POWER USER OVERCLOCK SETTINGS ..................................................................... 43
3-13 PASSWORD SETTINGS .................................................................................................... 45
3-14 LOAD STANDARD/OPTIMIZED DEFAULTS............................................................... 45
CHAPTER 4 DRIVER & FREE PROGRAM INSTALLATION
MAGIC INSTALL SUPPORTS WINDOWS 9X/ME/NT4.0/2000/XP ....................................... 46
4-1 NFORCE INSTALL NFORCE INTEGRATED DRIVER.......................................... 47
4-2 SOUND INSTALL ALC888 HD CODEC AUDIO DRIVER.................................... 48
4-3 LAN INSTALL REALTEK GIGABIT ETHERNET NIC DRIVER.................. 49
4-4 USB2.0 INSTALL INTEL USB2.0 DRIVER............................................................. 50
4-5 DIRECTX9 INSTALL DIRECTX9 DRIVER ................................................................ 50
4-6 PC-CILLIN INSTALL PC-CILLIN 2006 ANTI-VIRUS PROGRAM........................... 51
4-7 PC-HEALTH INSTALL MCP51 RAIDDISK ................................................................ 52
4-8 RAIDDISK INSTALL MYGUARD HARDWARE MONITOR UTILITY................ 53
4-9 HOW TO UPDATE BIOS....................................................................................................... 53
4-10 NFORCE4 PLATFORM RAID FUNCTION INSTALLATION..................................... 54
4-11 PRO MAGIC PLUS FUNCTION INTRODUCTION........................................................ 56
TABLE OF CONTENT

iii
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARES DESCRIBED IN IT MAY BE
REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR
BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED FOR THE UTILIZATION OF
NFORCE 650I SLI INTEL EDITION MOTHER-BOARDS TO MEET THE USER’S REQUIREMENTS.
BUT IT WILL CHANGE, CORRECT AT ANY TIME WITHOUT NOTICE. MANUFACTURER
PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND
THEY ARE USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S
BENEFIT, WITHOUT INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
2.0 Second Edition July 2007
Item Checklist
5nForce 650i SLI and nForce 430 chipset based Motherboard
5Cable for IDE
5CD for motherboard utilities
□Optional SLI Technology Supported Bridge
5Cable for Serial ATA IDE Port
5nForce 650i SLI and nForce 430 chipsetbased Motherboard User’s Manual
Intel Core Processor Family
Cooling Solutions
As processor technology pushes to faster speeds and higher performance, thermal management
becomes increasingly crucial while building computer systems. Maintaining the proper thermal
environment is the key to reliable, long-term system operation. The overall goal in providing the
proper thermal environment is keeping the processor below its specified maximum case temperature.
Heat sinks induce improved processor heat dissipation through increased surface area and
concentrated airflow from attached fans. In addition, interface materials allow effective transfers of
heat from the processor to the heat sink. For optimum heat transfer, Intel recommends the use of
thermal grease and mounting clips to attach the heat sink to the processor.
When selecting a thermal solution for your system, please refer to the website below for collection of
heat sinks evaluated and recommended by Intel for use with Intel processors. Note, those heat sinks
are recommended for maintaining the specified Maximum T case requirement. In addition, this
collection is not intended to be a comprehensive listing of all heat sinks that support Intel processors.
For vendor list of certified heat sinks and cooling fans, please visit :
http://developer.intel.com/design/Pentium4/components/index

1
Chapter 1
Introduction of nForce 650i SLI and nForce 430 chipset based Motherboards
1-1 Features of Motherboard
The nForce 650i SLI and nForce 430 chipset motherboard series are based on NVIDIA nForce
650i SLI chipset and nForce430 MCP (Media and Communication Processor) chipsets (C55SLI +
MCP51) technology which supports the innovative 65nm Quad-Core, Dual-Core Intel® Core 2
Quad, Core 2 Duo (Code Name: Conroe) processors, 90nm Dual-Core Intel® Pentium® D
Processor 8 and 9 Series processors , Pentium 4 and Celeron D with Intel® Hyper-Threading
Technology.
The nForce 650i SLI and nForce 430 chipset Based motherboard series deliver the
revolutionary levels of performance enabling vivid, high-definition experiences and
multi-tasking responsiveness from state-of-the-art Intel dual-core and quad-core technologies
and NVIDIA Scalable Link Interface Technology. Through the high bandwidth of dual
channel DDR2 800 / 667MHz system memories which are expandable to 16GB and the next
generation PCI Express interface for the latest graphics cards from both NVIDIA & ATI, the
nForce 650i SLI and nForce 430 chipset motherboard series are absolutely the ultimate
solution for game enthusiasts and applications, and it also meets the demanding usage of
computing of gaming, multimedia entertainment and business applications.
The NVIDIA nForce 650i SLI and nForce 430 chipset motherboard series support Front Side
Bus 1333 MHz data transferring rate and provide with 400MHz/333MHz memory clock
frequency for Dual channel DDR2 800/667MHz memory DIMMs expandable to 16GB . The
NVIDIA nForce430 MCP (Media and Communication Processor) chipset offers ULTRA ATA
133, Serial ATA2 RAID 0, 1 and 0+1 functions to accelerate hard disk drives and guarantee
the data security without errors of advanced computing performance.
The nForce 650i SLI and nForce 430 chipset Based motherboard provides Gigabit LAN function
by using the Realtek RTL8111B PCI-E Gigabit LAN which supports 10M / 100M / 1Gbps
data transfer rate. Embedded Azalia 8-channel CODEC is fully compatible with Sound
Blaster Pro®standards that offer you with the home cinema quality and absolutely software
compatibility.
The nForce 650i SLI and nForce 430 chipset Based motherboard series offer three PCI-Express
x16 graphics slots (Two symmetrical PCI-Express x16 graphics slots in the same color deliver
up to 2 Gbyte/sec data transfer rate at each relative direction which is fully compatible with
the latest NVIDIA SLI Technology in 8 lane + 8 lane SLI mode. The other PCI-Express x16
graphics slot offers 4 Gbyte/sec data transfer rate at each relative direction which get 3.5
times of bandwidth more than AGP8X and up to 8 Gbyte/sec concurrent bandwidth at full
speed) to guarantee the fully operational multi-GPUs graphics power and avoid the possible
SLI hardware installation error. One PCI Express x1 I/O slot offers 512Mbyte/sec
concurrently, over 3.5 times more bandwidth than PCI at 133Mbye/sec, tackling the most
demanding multimedia tasks nowadays. Two 32-bit PCI slots guarantee the rich connectivity
for the I/O of peripherals.

2
Embedded USB and optional VIA 6307 IEEE1394 controllers as well as capability of
expanding to 8 of USB2.0 functional ports and 2 of IEEE1394 9-pin block delivering
480Mb/s and 400 Mb/s bandwidth of rich connectivity, these motherboards meet the future
USB demands which are also equipped with hardware monitor function on system to monitor
and protect your system and maintain your non-stop business computing.
Some special features---CPU Thermal Throttling/ CPU Vcore 7-shift/ CPU Smart Fan/
Debug Port in this motherboard are designed for power user to use the over-clocking function
in more flexible ways. But please be caution that the over-clocking maybe cause the fails in
system reliabilities. This motherboard provides the guaranteed performance and meets the
demands of the next generation computing. But if you insist to gain more system performance
with variety possibilities of the components you choose, please be careful and make sure to
read the detailed descriptions of these value added product features, please get them in the
coming section.
1-1.1 Special Features of motherboard
CPU Thermal Throttling Technology---(The CPU Overheat Protection Technology)
To prevent the increasing heat from damage of CPU or accidental shutdown while at high
workload, the CPU Thermal Throttling Technology will force CPU to enter partially idle
mode from 87.5% to 12.5% according to preset CPU operating temperature in BIOS (from 40
℃to 90℃). When the system senses the CPU operating temperature reaching the preset
value, the CPU operating bandwidth will be decreased to the preset idle percentage to cool
down the processor. When at throttling mode the beeper sound can be optionally selected to
indicate it is in working.
Debug Port--- ( The Professional Hardware Diagnosis System )
Being bugged of abnormal system failure through the tossed and turned nights no more, the
embedded Hardware Debug Port offers you the real-time visual system healthy for the
demanding usage of computing. No more bugging by unknown system failure and no more
time wasted in the first moment of 24-hour nonstop ping business computing, the embedded
Debug Port will turn you into a well training hardware professional with the seeing system
situation. (The Post Code please refer Appendix)
CPU Smart Fan---( The Noise Management System )
It’s never been a good idea to gain the performance of your system by sacrificing its acoustics.
CPU Smart Fan Noise Management System is the answer to control the noise level needed for
now-a-day’s high performance computing system. The system will automatically increase the
fan speed when CPU operating loading is high, after the CPU is in normal operating condition,
the system will low down the fan speed for the silent operating environment. The system can
provide the much longer life cycle for both CPU and the system fans for game use and
business requirements.
CPU Vcore 7-Shift--- ( Shift to Higher Performance )
The CPU voltage can be adjusted up by 8 stages for the precisely over-clocking of extra
demanding computing performance.

3
1-2 Specification
Spec Description
Design ∗ATX form factor 4 layers PCB size: 30.5x23.5cm
Chipset ∗NVIDIA nForce 650i SLI (C55SLI)Chipset
∗NVIDIA nForce 430 (MCP51) chipset
CPU Socket
LGA775
∗Support Intel Pentium 4, Celeron D, Pentium D, Core 2 Duo and
Core 2 Quad 775-Land LGA Package utilizes Flip-Chip Land
Grid Array (FCLGA) package processor
∗Support FSB Frequency 533MHz / 800 / 1066/1333MHz
Memory Socket ∗240-pin DDR2 Module socket x 4
∗Support 4 pcs DDR2 533 / DDR2 667 /DDR2 800MHz DDR2
Modules Expandable to 16.0GB
∗Support Dual channel functions
Expansion Slot ∗PCI-Express x16 slot 3pcs ; the two PCI-E x16 slots in same
color support the NVIDIA SLI Technology with 4GB/s
concurrent bandwidth in 8 lane + 8 lane Mode; the third
PCIE-x16 slot deliver up to 8GB/s concurrent bandwidth
∗PCI-Express x1 slot 1pcs delivers up to 512MB/s concurrent
bandwidth
∗32-bit PCI slot x 2pcs
Integrate IDE and
Serial ATA2 RAID
∗Two PCI IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions that
deliver the data transfer rate up to 133 MB/s;
∗Four Serial ATA ports provide 300 MB/sec data transfer rate
with RAID 0, 1, 0+1 functions
Gigabit LAN
∗Integrated Realtek RTL8111B PCI-Express Gigabit LAN
function.
∗Supports Fast Ethernet LAN function provide 10Mb/100Mb/
1Gb /s data transfer rate
8CH-Audio ∗Realtek ALC888 Azalia 8-channel Audio Codec integrated
∗Support 8-channel 3D surround & Positioning Audio
∗Audio driver and utility included
BIOS ∗Award 4MB Flash ROM
Multi I/O ∗Optional IEEE1394a port of 9-pin block x1
∗Optional IEEE1394a port x1
∗PS/2 keyboard and PS/2 mouse connectors
∗Floppy disk drive connector x1
∗ESATAx1
∗Serial port header x1
∗IR connecter with 5-pin block x1
∗USB2.0 port x 6 and headers x 2 (connecting cable option)
∗Audio connector (Line-in, Line-out, MIC/ 8CH Audio)

4
1-3 Performance List
The following performance data list is the testing result of some popular benchmark testing
programs. These data are just referred by users, and there is no responsibility for different
testing data values gotten by users (the different Hardware & Software configuration will
result in different benchmark testing results.)
Performance Test Report
CPU:
Intel Core 2 Duo Conroe E6400 2.13G (C1E disable)
DRAM: AD ATA 512M DDR2-800 X 2 1Gbyte Memory
VGA Card: Nvidia Geforce 6800XT 128M (1024X768X32BIT Color)
Hard Disk Driver: Seagate Barracude 7200.9 SATA2
BIOS: Award Optimal default
OS: Windows XP Professional (SERVICE PACK 2)
SLI / 200/266 Dual channel
3D Mark 2001SE 21932
3D Mark 2003 8222
3D Mark 2005 3004
AQUAMRK3 1904
PCMark2005
System / CPU / Memory 5559 / 5446 / 4867
Graph / HDD 3550 / 5712
Content Creation Winstone 2004 38.1
Business Winstone 2004 30.9
Winbench 99 V2.0:
Business/Hi-end Disk Winmark99 10800 / 26300
Business/Hi-end Graphic Winmark 1130 / 1930
SISMark 2004: SISMark Rating(Internet Content Creation / Office Productivity )
SISMark 2004
3D Creation / 2D Creation
/ Web publication
Communication / Document Creation
/ Data Analysis
SISOFT Sandra 2004 : 1.CPU Arithmetic Benchmark 2.Memor
y
bandwidth Benchmark 3.CPU
Multi-Media Benchmar
k
1.Dhrystone ALU MIPS 19496
Whetstone FPU iSSE2 FLOPS 13512
2.Int/Float Buffered iSSE2 MB/S 5389 / 5414
3.Integer/Floating-Point SSE2 IT/S 116568 / 63178
UT2003 Benchmark (flyby/botmatch) 116568 / 63178
DOOM3 FPS
Return to Castle Wolfenstein FPS 26s
Super Pi (1M) Second 266.7 / 400.0 / 2133.5
CPUZ System / CPU Clock 266.7
/
400.0 / 2133.5

5
1-4 Layout Diagram & Jumper Setting
USB heade
r
PS/2 Mouse
PS/2 Keyboard
USB1
Clear CMOS (JBAT)
nForce 650i SLI
Chipset
Speaker/Power
LED Connector
LGA775 Socket
DDR2 667 / 533
DIMMs
ATX Power Connecto
r
CD Audio In
32-bit PCI Slots
8-CH Azalia Audio Codec
2n
d
PCI-E x8 for SLI
PS2 KB/Mouse Port
CPU FAN
Audio Connector
KB
/
MS Power On Jumpe
r
(JP1)
ATX 12V Power Conn.
RJ45 Over USB Conn.
1st PCI-E x8 for SLI
PCI EXPRESS x1
RTL8111B Gigabit LAN nForce 430
MCP
Gigabit LAN
Serial-ATA2 Connector
(D-SATA1, 2)
IR Connector
UL1
USB Port
4-pin PWR Connector
Surround
CEN/LFE
Surrback
MIC-IN
Line-OUT
SFAN2
Optional
IEEE1394B
Front Panel Connector
Floppy
Connector
USB Power
On Jumper (JP3)
Front Panel Audio
USB Power On Jumper (JP2)
UL1
Line IN
Optional
IEEE1394 ESATA
ESATA
/
USB Port
Serial-ATA2 Connector
(SATA5)
ATA 133 IDE
Connector
(IDE1)
PCI EXPRESSx16
SYS FAN
ATA 133 IDE
Connector
(IDE2)
COM1
Optional IEEE1394A

6
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.7
JP1 Keyboard/USB0,1 Power On Enabled/Disabled 3-pin Block P.8
JP2 USB Power On Enabled/Disabled 3-pin Block P.8
JP3 USB Power On Enabled/Disabled 3-pin Block P.8
Connectors
Connector Name Description Page
ATXPWR24P ATX Power Connector 24-pin Block P.23
ATX12V ATX 12V Power Connector 4-pin Block P.24
J1 Large 4-PIN Power Connector 4-pin Block P.24
PS2KB/MS PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female P.24
USB1 USB Port Connector 4-pin Connector P.24
UL1 USB2.0 Connnector USB Connector P.24
UL2 RJ45 LAN Port Over USB Conn. RJ-45 Connector P.24
AUDIO1 / SURROUND1 8-CH Audio Connector 6 phone jack Connector P.24
FDD Floppy Driver Connector 34-pin Block P.25
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.25
SATA1~4 Serial ATA2 Connector 7-pin Connector P.26
ESATA External Serial ATA2 Connector 7-pin Connector P.26
1394A(Optioanl) IEEE1394a Connector 7-pin Connector P.26
Headers
Header Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.27
USB2, USB3 USB Port Headers 9-pin Block P.27
SPEAK PC Speaker connector 4-pin Block P.27
PWR LED Power LED 3-pin Block P.27
JW_FP
(PW LED/Reset/
IDE LED/PW Switch)
Front Panel Header
(including Power LED/ IDE activity
LED/Reset switch / Power On Button lead)
9-pin Block P.27
CPUFAN FAN Headers 4-pin Block P.28
SFAN1, SFAN2 FAN Headers 3-pin Block P.28
CDIN CD Audio-In Header 4-pin Block P.28
IR IR Header 5-pin Block P.29
1394B(Optioanl) IEEE1394a Header 9-pin Block P.29
COM1 Serial Port COM Header 9-pin Block P.29
Expansion Sockets
Socket/Slot Name Description Page
LGA 775 Socket CPU Socket LGA 775 CPU Socket P.9
DIMM1~4 DDR2 Module Sockets 240-pin DDR2 Module Sockets P.19
PCI1∼PCI2 PCI Slot 32-bit PCI Local Bus Expansion slots P.21
PE1 PCI-Express x1 Slot PCI-Express x1 Expansion Slot P.21
PE3 PCI-Express x16 Slot PCI-Express x16 Expansion Slot P.21
PE2,PE4 PCI-Express x16 Slot PCI-E x 8 Bandwidth for SLI Tech. P.21

7
Chapter 2
Hardware Installation
2-1 Hardware installation Steps
Before using your computer, you had better complete the following steps:
1. Check motherboard jumper setting
2. Install CPU and Fan
3. Install System Memory (DIMM)
4. Install Expansion cards
5. Connect IDE Front Panel /Back Panel cable
6. Connect ATX Power cable
7. Power-On and Load Standard Default
8. Reboot
9. Install Operating System
10. Install Driver and Utility
2-2 Checking Motherboard’s Jumper Setting
(1) CMOS RAM Clear (3-pin) : JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Note: When should clear CMOS
1. Troubleshooting
2. Forget password
3. After over clocking system boot fail
CMOS RAM Clear Setting
2-3 Closed Clear CMOS
JBATJBAT
1-2 Closed Normal

8
(2) Keyboard function Enabled/Disabled: JP1
(3) USB Power On function Enabled/Disabled: JP2 / JP3
USBPower-OnSetting
2-3 closed USB Power On Enabled
JP2 / JP3JP2 / JP3
1-2 closed USB Power On Disable
(Default)
2-3 Install CPU
2-3-1 Glossary
Chipset (or core logic) - two or more integrated circuits which control the interfaces between
the system processor, RAM, I/O devises, and adapter cards.
Processor slot/socket - the slot or socket used to mount the system processor on the
motherboard.
Slot (PCI-E, PCI, RAM) - the slots used to mount adapter cards and system RAM.
AGP - Accelerated Graphics Port - a high speed interface for video cards; runs at 1X
(66MHz), 2X (133MHz), or 4X (266MHz), or 8X (533MHz).
PCI - Peripheral Component Interconnect - a high speed interface for video cards, sound
cards, network interface cards, and modems; runs at 33MHz.
PCI Express- Peripheral Component Interconnect Express- a high speed interface for video
cards, sound cards, network interface cards, and modems.
Serial Port - a low speed interface typically used for mouse and external modems.
Parallel Port - a low speed interface typically used for printers.
PS/2 - a low speed interface used for mouse and keyboards.
USB - Universal Serial Bus - a medium speed interface typically used for mouse, keyboards,
scanners, and some digital cameras.
Sound (interface) - the interface between the sound card or integrated sound connectors and
speakers, MIC, game controllers, and MIDI sound devices.
LAN (interface) - Local Area Network - the interface to your local area network.
BIOS (Basic Input/Output System) - the program logic used to boot up a computer and
Keyboard/Mouse & USB Power On Setting
2-3 Closed KB/USB Power ON Enabled
JP1
JP1
1-2 Closed KB/USB Power ON Disable (Default)

9
establish the relationship between the various components.
Driver - software, which defines the characteristics of a device for use by another device or
other software.
Processor - the "central processing unit" (CPU); the principal integrated circuit used for
doing the "computing" in "personal computer"
Front Side Bus Frequency - the working frequency of the motherboard, which is generated
by the clock generator for CPU, DRAM and PCI BUS.
CPU L2 Cache - the flash memory inside the CPU, normal it depend on CPU type.
2-3-2 About Intel Pentium 4 LGA775 CPU
This motherboard provides a 775-pin surface mount, LGA775 Land Grid Array socket,
referred to as the LGA775 socket supports Intel Pentium 4 processor in the 775 Pin package
utilizes Flip-Chip Land Grid Array (FC-LGA4) package technology.
The CPU that comes with the motherboard should have a cooling FAN attached to prevent
overheating. If this is not the case, then purchase a correct cooling FAN before you turn on
your system.
WARNING! Be sure that there is sufficient air circulation across the processor’s heat
sink and CPU cooling FAN is working correctly, otherwise it may cause
the processor and motherboard overheat and damage, you may install an
auxiliary cooling FAN, if necessary.
To install a CPU, first turn off your system and remove its cover. Locate the LGA775
socket and open it by first pulling the level sideways away from the socket then upward to a
90-degree angle. Insert the CPU with the correct orientation as shown below. The notched
corner should point toward the end of the level. Because the CPU has a corner pin for two
of the four corners, the CPU will only fit in the orientation as shown.
CPU LGA775 Socket
Colden Arrow
LGA775
When you install the CPU into the LGA775 socket, there’s no force required CPU insertion;
then press the level to locate position slightly without any extra force.

10
2-3-3 LGA 775 CPU Installation Guide
Socket Preparation
1. Opening the socket:
Note: Apply pressure to the corner with right hand thumb while opening/closing the load lever,
otherwise lever can bounce back like a “mouse trap” and WILL cause bent contacts (when
loaded)
i. Disengage Load Lever by depressing down and
out on the hook to clear retention tab
ii. Rotate Load Lever to fully open position at
approximately 135degrees
iii. Rotate Load Plate to fully open position at
approximately 100degrees
2. Remove PnP Cap (Pick & Place Cap)
i. With left hand index finger and thumb to support the load plate edge, engage PnP cap with right
hand thumb and peel the cap from LGA775 Socket while pressing on center of PnP cap to assist in
removal.
ii. Set PnP cap aside. Always put PnP cap back on if the processor is removed from the socket.
iii. Visually inspect PnP cap for damage. If damage observed, replace the PnP cap.
Note: After PnP cap removal, make sure socket load
plate and contacts are free of foreign material; Refer to
Overview Module for FM cleaning.
Note: Optionally, remove PnP cap after CPU insertion.
This will compromise the ability to visually inspect
socket.
Socket Load
Lever Open
Socket Load
Plate Open

11
3. Visually inspect for bent contacts (Recommend at least 1stpass visual inspection)
NOTE:Refer to the Handling and Inspection Module for 1stand 2ndpass inspection details.
NOTE: Glove images are for illustrative purposes only. Please consult local safety guidelines for
specific requirements
NOTE: Recommend not to hold the load plate as a lever, instead hold at tab with left hand, removing
the PnP cap with right hand
775- Land LGA Package Insertion
1. Lift processor package from shipping media by
grasping the substrate edges ONLY.
Note: Orient processor package such that the Pin 1
triangle mark is on bottom left and both key notches are
on left side
2. Land Side Cover Handling: Remove land side cover
with the opposite hand by depressing larger
retention tab and peeling the cover away
3. Set and reserve the land side cover aside.
Note: Always keep the land side cover on the processor
when not in the socket.
4. Visually inspect the package gold pads: Scan the
processor package gold pad array for presence of
foreign material. Refer to Overview Module for FM
cleaning recommendations
5. Orient the package with IHS up. Locate Pin 1 and
the two orientation key notches
6. Carefully place the package into the socket body
using a purely vertical motion
CAUTION: Using Vacuum Pen for installation is not recommended
7. Verify that package is within the socket body and
properly mated to the orient keys
8. Close the socket by
i. Rotating the Load Plate onto the package HIS
ii. While pressing down lightly on Load Plate, engage
the Load Lever.
iii. Securing Load Lever with Load Plate tab under
retention tab of Load Lever
Press to remove
Pin 1 Indicator
Alignment Key

12
775- Land Package Removal 1. Open the Load Plate/Lever with both hands:
With left hand index finger and thumb to support
the load plate edge, engage PnP cap with right hand
thumb and peel the cap from LGA775 Socket while
pressing on center of PnP cap to assist in removal.
2. Pick up 775-land LGA package:
By Vacuum Pen: Place a minimum 9-mm cup at
approximately the center of IHS.
Recommend not to place Vacuum Pen on IHS edge.
Risk of dropping and causing bent contact.
Recommend not to use Vacuum Pen for inserting CPU
By Hand: Index finger to hold load plate hinge
side and thumb to hold load lever side
3. Lift the package straight up and away.
4. Assemble processors land side cover immediately
to prevent contamination.
i. While holding the processor by the 3 corners, the
other hand lift land side cover from work surface by
grasping at the large retention tabs. Ensure
retention tabs and package are pointing each
other.
ii. Orientate so that land side cover chamfer is
matching with package Pin 1 location.
iii. Hook the first large retention tab on the package
substrate. Then press the opposite tab onto the
substrate.
iv. Place processor with land side cover installed onto
proper shipping media or other ESD approved work
surface
Chamfer on Land Side
Cover (align this with
pin 1 mark on 775-land
LGA package)
Large Retention Tabs
(pointing towards user)
Hold at corners

13
5. Visually inspect socket contact array
1. First Pass Inspection
i. Scan socket contact array at varying angles noting the presence of any foreign material
ii. If foreign material can’t be blown off by compressed air, or mechanical damage (Mode1 or 4)
observed, reject the motherboard for further evaluation or socket replacement.
2. Second Pass Inspection
i. Repeat 2 more times to sight down the rows and columns from each of the 4 sides of the socket to
ensure all contacts within the array are inspected
ii. Inspect for Mode2, Mode3, and Mode5 failures
Note: Refer to the Test Module for detail visual inspections
6. Assemble LGA775 socket PnP cap
i. Secure/Hook the back side of PnP cap.
ii. Snap down the front side to fully secure
7. Close the Socket
Intel Reference Thermal Solution Assembly
NOTE: Depending on the configuration, Thermal Solution Integration procedure could perform with
M/B alone or with M/B in the Chassis.
1. Place motherboard on support structure providing
minimum 0.150-inch backside clearance
2. Apply 300 mg of Thermal Interface Material (Shin-
Etsu G751) onto center of IHS
0.150-inch backside
clearance for fastener
installation
Fan cabled on side
closest to MB heade
r
Fastener slots
pointing straight out

14
NOTE: Thermal Solutions that come with IntelR boxed
processor use pre-applied thermal interface material
and not grease.
3. Remove Heat Sink (HS) from packaging media
4. Place HS onto the LGA775 Socket
•Ensure fan cables are oriented on side closest to
fan header
•Align Fasteners with MB through-holes
5. Inspection
•Ensure cables are not trapped or interfere fastener
operation
•Ensure fastener slots are pointing straight out from
heatsink
6. Actuate fasteners
•While holding HS to prevent tilting, press down on
fastener caps with thumb to install and lock
Repeat with remaining fasteners
7. Inspection
•Verify the fasteners are properly seated
•Ensure both fastener cap and base are flush with
spring and motherboard
8. Connect fan header with Board header
9. Secure excess cable with tie-wrap to ensure cable
does not interfere with fan operation or contact
other components.
Apply Thermal
Interface Material
Fastener Cap not
resting against spring Fastener flush against MB
Press Down
(4 Places)
Both fastener
halves are flush
against spring
Fastener flush
against spring

15
Intel Reference Thermal Solution Disassembly
1. Rotate fastener cap. turn to un-lock
2. Pull up fastener cap to un-seat 12
1. Disconnect fan cable from motherboard header
2. Turn fastener caps (4) counter-clock wise
90degrees to the un-locked position
•A flat-bladed screwdriver may be used if required
3. Pull up on fastener caps to unseat
4. Manually remove HS with gentle twist motion.
5. To re-assemble the HS, reset the fastener caps to
their original position with the slot perpendicular to
the HS. Then, follow the assembly instructions.
Note: Thermal grease should be reapplied
TIM and Grease Removal from CPU
1 2
3 4

16
1. Remove the heatsink from the socket
2. Gently push loose thermal interface material (TIM) to center of processor (pictures 2 and 3)
3. Remove pieces with dry cloth (picture 4)
4. Wipe with dry, lint-free cloth to remove most of the material (picture 5)
5. Wet another lint-free cloth with isopropyl alcohol (IPA) and wipe to clean remaining material
(picture 6)
6. Be careful to remove material from gaps between processor and load plate
7. For thermal grease removal use Step 4-6
TIM and Grease Removal from Heat-sink
Note: Remove and replace the TIM from the heatsink if you are re-using the heatsink on a new
processor
1. Use dry, lint-free cloth and wipe package to remove most of the material
2. Wet another lint-free cloth with isopropyl alcohol (IPA) and wipe heatsink to clean remaining
material
5 Dr
y
6 IP
A
Removal TIM from heatsink
1Dr
y
