OADOBO ht-cs01 Color Touch User manual

1
Color Touch Heating Thermostat –HT-CS01
The HT-CS01 Thermostat is a digital thermostat, which is designed for electric floor
heating system or water heating system. Using 4.3inch color touch LCD display, the
working status can be easily understood. With built-in four languages, you can select the
languages you want to display.
With five modes, the system can work according to your desired pre-set temperature
conveniently. And the 5+1+1 days programmable function, which is easy-to-program
on/off settings per day.
Simple regulation which sends On/Off commands to the heating system according to a
pre-selected temperature variation. The thermostat control algorithm includes an
anticipation function which reduces the discrepancy between the thermostat reading
and the temperature at the centre of the room.
Choose from three (3) sensor setting: Ambient (built-in sensor)- to control the air
temperature; Floor - to control the temperature using the floor probe; Ambient and
Floor - to control the ambient air, and show floor temperature by using the floor probe.
•4.3inch Color Touch Screen Operation
•Electric Heating System( Max.16A) or Water Heating System(Max.3A)
•Adjustable Comfort Mode, Economy Mode, Party Mode, Holiday Mode and Program
Mode Control
•5+1+1 Days Programmable
•External and Internal Sensor Select
•Four languages select: English, French, Germany, Dutch
•Clock and Date Display
•Temp. Clibration
•Temp. Protection
•86*86mm mounting
•Voltage: 230V, 50/60Hz
•Load Current: 16A(Max)
•Temp. Setting Range: 5~35℃
•Ambient: 0~50℃
•Sensor: NTC3950，10Kohms at 25℃
•Accuracy: ±0.5℃
•Protection Class: IP30
Technical Data
Product Features

2
Screen and Display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

3
1
ON/OFF Button
Use to turn on/off Thermostat
2
Mode Button
Use to Choose Working Mode
3
Menu Button
Use to Menu Settings
4
Down Button
Decrease Temp. or other parameter setting
5
Up Button
Increase Temp. or other parameter setting
6
External Temp.
Show Floor Temp.
7
Room Temp.
Show Actual Room Temp.
8
Set Temp.
Range: 5-35℃
9
Room Temp. Icon
Room Temp. Icon
10
Mode Icon
Show Current Working Mode
11
Clock Icon
Show Current Time & Enter Parameter Setting
12
Weekday Icon
Show Current Weekday
13
Heating Icon
Will Show When in Heating
14
Mode Icon
Show Current Working Mode
15
Date &Time Button
Use to Set Weekday and Time
16
PRG. Schedule Review
Button
Use to Check 5+1+1 Days Programmable Schedule
17
Mode Temp. Pre-set
Button
Use to Pre-set Mode’s Working Temp.
18
Language Select Button
Use to Select English, French, German & Dutch
Language
19
Protection Temp. Set
Button
Use to Set Over Protection Temp. & Low Protection
Temp.
20
Comfort Mode Button
Once Select, Thermostat Will Work According to
Pre-set Temp. of Comfort Mode.
21
Economy Mode Button
Once Select, Thermostat Will Work According to
Pre-set Temp. of Economy Mode.
22
Party Mode Button
Once Select, Thermostat Will Work According to
Pre-set Temp. of Party Mode.
23
Holiday Mode Button
Once Select, Thermostat Will Work According to
Pre-set Temp. of Holiday Mode.
24
PRG. Mode Button
Once Select, Thermostat Will Work According to
Pre-set Temp. of 5+1+1 PRG.Mode.
Schedule Review & Edit
Press Menus Button, press , then you
can review weekly schedule. You can press the
three column to change the 5+1+1 events.
Schedule Setting

4
For example, if you want to edit Sat. schedule,
you can press Sat. column, then you will enter
the edit page as picture shows. Every setting
can be finish by pressing or button.
1. In Sun. column, there are six periods. You can press or button to choose the period you
are going to change. Whichever period is selected, will display.
2. After period is selected, you can set hour, minute and temperature by pressing and
button.
3. After new schedule is set, pls. press “APPLY”to save the new schedule.
Press Menu button, choose button to edit
date and time by or button. After setting
pls. press “APPLY”to save the changes.
Press Menu button, choose button to
pre-set mode working temp. by and
Button. After setting, pls. press “APPLY”to
save the changes.
Press Menu then select button to enter
Protection Settings page. You can set High
Protection temp. & Low Protection temp. by
and button. After setting, pls. press
“APPLY”to save the changes.
Edit Date and Time
Mode Pre-set Temp. Settings
Protection Settings

5
High Protection: It uses external sensor to probe floor temp. When floor temp. over set protection
temp. the system will be shut off automatically.
Low Protection: It functions only when thermostat under OFF mode. It uses internal sensor to
probe room temp. When room temp. below set protection temp, then the system will be shut on
automatically.
Press Menu button, then select button
to enter languages select page. You choose the
languages you need, after selected then press
“APPLY”to save the changes.
Within 3S after turning thermostat to OFF mode, press for 2 seconds, then will enter
parameter setting, you can set the desired value by pressing “<<”or “>>”, and go to other pages
by pressing “Pre”or “Next”.
Menu
Description
Range
01
Temp. Offset
-8 ℃~8℃
02
Dead Zone
0℃~3℃
03
Set Point Max.
5 ℃~35℃
04
Set Point Min.
5 ℃~35℃
05
NTC Select(Internal, External)
I only, E only, I & E, I or E
06
Low Protection Max.
5 ℃~10℃
07
Low Protection Min.
5 ℃~10℃
08
High Protection Max.
5 ℃~90℃
09
High Protection Min.
5 ℃~90℃
10
Backlight off Time after Operation.
3s~180s
11
Min. Backlight Brightness of Standby Status
1%~100%
12
Relay Delay Time
0s~250s
13
Relay Output
Normal(NO); Inverted(NC)
14
Restore
<< or >>
Parameter Settings
Languages Select

6
Electric Heating System Water Heating System
Voltage-Free System
Using a screw driver to open the upper and lower body part, then connect the wiring to terminals tightly,
then fix the lower body part into wall with attached screws.
Front(unit:mm)
Thickness (unit:mm)
Mounting Hole (unit:mm)
Wiring Diagrams
Installation
Dimension (mm)
