Océ CS9360 User manual

Océ CS9360
Eco Solvent
Operation Instructions
AP-40802_1.0

Operation Instructions CS9360
AP-40802 - Revision 1.0 3
Copyright notice
COPYRIGHT © 22/5/12 Océ-Technologies B.V.All rights reserved.
Océ-Technologies B.V. reserves the right to modify the information contained in this manual at
any time without prior notice.
This document may not be reproduced by any means, in whole or in part, without written
permission of the copyright owner.
This document is furnished to support the Océ CS9360 series printers. In consideration of the
furnishing of the information contained in this document, the party to whom it is given,
assumes its custody and control and agrees to the following:
The information herein contained is given in confidence, and any part thereof shall not be
copied or reproduced without written consent of Océ-Technologies B.V.
This document or the contents herein under no circumstances shall be used in the
manufacture or reproduction of the article shown and the delivery of this document shall not
constitute any right or license to do so.
22 May 2012
Published: Océ-Technologies B.V.,
St. Urbanusweg 43
Venlo, The Netherlands,
P.O. Box 101, NL 5900 MA Venlo

Operation Instructions CS9360
4AP-40802 - Revision 1.0

Operation Instructions CS9350
AP-40802 - Revision 1.0 5
Table of contents
Chapter 1 Safety instructions- - - - - - - - - - - - - - - - - - - - - - - - - 9
1.1 Types and meanings of warnings - - - - - - - - - - - - - - - - - - - - - 9
1.2 Important safety instructions - - - - - - - - - - - - - - - - - - - - - - - 10
1.3 Air ventilation requirements - - - - - - - - - - - - - - - - - - - - - - - - 13
Instructions for use of an APS - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
1.4 Warning labels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14
Handling the warning labels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14
Location and type of warning labels - - - - - - - - - - - - - - - - - - - - - - - 14
1.5 Operating Instruction Labels - - - - - - - - - - - - - - - - - - - - - - - 16
Cautions on Handling the Operating Instruction Labels - - - - - - - - 16
Locations and Types of Operating Instruction Labels - - - - - - - - - 16
Chapter 2 Product overview- - - - - - - - - - - - - - - - - - - - - - - - - 17
2.1 Names of parts and functions - - - - - - - - - - - - - - - - - - - - - - - 17
Front section- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17
Rear section - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18
Operation panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19
2.2 Printer status - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
Normal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
Setup menu display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
Changing printer status - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
Chapter 3 Before using - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23
3.1 Switching the power ON/OFF - - - - - - - - - - - - - - - - - - - - - - - 23
Switching the power ON - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23
Switching the power OFF - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23
3.2 Loading media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26
Loading roll media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26
Setting Roll Media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 28

Operation Instructions CS9350
6AP-40802 - Revision 1.0
Setting the User Type Setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - 31
3.3 Test print - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 34
Nozzle check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 37
Mode print - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38
Setup print - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39
3.4 Adjust Print- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40
Standard Adjust Print - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40
Custom Adjustment Pattern - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 50
Chapter 4 Handling the printer - - - - - - - - - - - - - - - - - - - - - - - 65
4.1 Media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66
Media type- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66
Cautions on handling media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 67
Precaution on storing media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 67
Printing area - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 68
Head height adjustment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 68
Media feed compensation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 71
4.2 Menu setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 76
Menu setup procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 76
Panel setup menu overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 78
4.3 Operating from the operation panel- - - - - - - - - - - - - - - - - - - 79
Feeding media- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 79
Stopping printing operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 79
Cutting media - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 80
Cutting media manually- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 81
Changing and confirming settings while printing - - - - - - - - - - - - - - 82
Pausing printing- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 83
Start Printing during Warm up - - - - - - - - - - - - - - - - - - - - - - - - - - - - 84
4.4 Using spectrophotometer - - - - - - - - - - - - - - - - - - - - - - - - - - 85

Operation Instructions CS9350
AP-40802 - Revision 1.0 7
Chapter 5 Menu-overview - - - - - - - - - - - - - - - - - - - - - - - - - - 97
Chapter 6 Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - 99
6.1 Replacing consumable components - - - - - - - - - - - - - - - - - - 99
Replacing ink cartridges - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 99
Replacing Cutter- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 107
6.2 Cleaning the printer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 113
Cleaning the outer case - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 114
Cleaning the inside of the printer - - - - - - - - - - - - - - - - - - - - - - - - 114
Head cleaning- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 116
Cleaning the cleaning wiper - - - - - - - - - - - - - - - - - - - - - - - - - - - - 117
Cleaning around the print head - - - - - - - - - - - - - - - - - - - - - - - - - 123
6.3 Disposal of waste fluids - - - - - - - - - - - - - - - - - - - - - - - - - - 130
6.4 Moving or transporting the printer - - - - - - - - - - - - - - - - - - 132
Moving the printer- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 132
Transporting the printer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 134

Operation Instructions CS9350
8AP-40802 - Revision 1.0

CS9350 OPERATION MANUAL
1-9
Chapter 1 Safety
instructions
This chapter explains the installation of this printer, warning terms that operators need to know, caution
items and warning labels on the printer main unit.
WARNING
When installing and operating this printer, be sure to follow the directions and warnings in
this book.
1.1 Types and meanings of warnings
The warnings in the Operation Manual and the warning labels attached to the printer are categorized into
three stages.
Understand the meanings of the following warning terms and follow the contents (instructions) in this
manual.
Warning Meaning
Used for dangerous situations where death or serious injury may be caused.
Used for dangerous situations that may cause slight or medium injury, or when all or
parts of products are damaged.
Used for special cautions and for information that needs to be emphasized.
WARNING
CAUTION
NOTE

CS9350 OPERATION MANUAL
1-10
1.2 Important safety instructions
Do not install this printer in the following places.
It may cause an injury if the printer falls down.
• On a shaky stand
• Slanting location
• Places where vibration of other machines etc. is transmitted
Do not step on this printer or place heavy things on top of it.
It may cause an injury if the printer falls down.
Do not block the vent by covering the printer with cloths, such as a blanket or tablecloth.
If the vent is blocked, heat may accumulate inside the printer and it may cause fire.
Do not install the printer where it is humid or dusty.
It could lead to an electric shock and fire.
Do not use a damaged power cable.
It could lead to an electric shock and fire.
Do not pull out or insert the power plug with a wet hand.
This could lead to an electric shock.
Do not connect an earth wire to the following places.
• Gas pipes
There is a possibility of ignition and explosion.
• Earth wire of telephone cables and lightning rods
Heavy current might flow whenever lightning strikes.
• Water pipe and faucet
The earth might not work if a plastic pipe is connected in the middle of the metal pipe.
Do not insert or drop metal or flammable objects into the printer through openings such as a vent.
It could lead to an electric shock or fire.
Do not spill flammable liquid on the platen.
This could lead to a fire.
Do not place any combustible materials on the platen while the heater is working.
There may be a risk of fire.
If foreign substances or liquids such as water entered the printer, do not use the printer as it is.
It could lead to an electric shock or fire.
Immediately switch OFF the power switch, disconnect the power plug from the electric socket, and contact your
local Océ representative.
Wire the various cords as directed in the Operation Manual.
Mistaken wiring could cause fire.
Be sure to use the specified power cable.
Using power cables other than the specified can cause an electric shock or fire.
Make sure to use only the specified power supply (AC 100 V to 120 V or AC 220 V to 240 V).
If a power supply other than the specified voltage is used, it could cause an electric shock and fire.
WARNING

CS9350 OPERATION MANUAL
1-11
Take power for the printer directly from the power socket (AC 100 V - 120 V or AC 220 V - 240 V).
Do not use multiple plugs on the same socket.
This could generate heat and might cause fire.
Be sure to use a dedicated power socket with earth wire for the power supply, and connect it to the earth wire.
If the earth wire is not connected, an electric shock or fire may occur.
The waste fluid from the printer falls under the category of waste oil (waste ink) of industrial waste (out of the 19
items of general waste from business activities).
You are obligated to properly dispose of waste fluid in compliance with Wastes Disposal and Public Cleansing Act
and local ordinances.
Delegate disposal to an industrial waste disposal contractor.
Pay attention to the following points when handling power cable.
• Do not tamper with the power cable.
• Do not put heavy objects on the power cable.
• Do not bend, twist or pull the power cable by force.
• Do not route the power cable near heating appliances.
Pay attention to the following points when handling the power supply plug.
Any mishandling of the power cable could cause a fire.
• Make sure that no foreign substances such as dust etc. are stuck to the power plug.
• Make sure that the power plug is firmly inserted to the edge of the power socket.
When handling ink cartridges, pay attention so that ink does not get into your eyes or stick to your skin.
If ink gets into your eyes or sticks to your skin, immediately wash it off with water.
Failing to do so might cause irritation or light inflammation of eyes.
In case of any abnormality, consult a physician immediately.
Do not disassemble ink cartridges.
If disassembled, there is a possibility that ink might come into contact with eyes or skin.
Do not operate the media loading lever during the initial operation or printing.
The print head portion may touch the pressurizing roller portion, and cause a malfunction.
Do not use volatile solvents such as thinner, benzene, or alcohol.
These solvents could cause damage to the paint.
Do not touch the media guide while printing.
The media guide becomes very hot and you could burn yourself.
Do not touch the media feed slot, platen, and media guide while the heater is working.
The media feed slot, platen, and media guide become very hot and you could burn yourself.
Be careful that no moisture enters the printer.
There is a possibility that the electric circuit inside the printer is short circuited.
Do not open covers attached using screws under any circumstances.
This may cause an electric shock or a malfunction.
When cleaning the cleaning wiper,
• Do not touch the cleaning wiper and head cap unit.
Head cleaning may not be performed correctly because of oil from your hands.
• Make sure to wipe the print head using the cleaning stick.
A wet cleaning stick may cause the print head to clog.
• Do not reuse the cleaning stick.
The attached dust, etc may damage the print head.
CAUTION

CS9350 OPERATION MANUAL
1-12
When cleaning around the print head,
• Do not touch the nozzles of the print head.
Doing so may damage the print head.
• Do not touch the tip of the cleaning stick.
The print head may be damaged because of oil from your hands.
• Never put water, etc on the tip of the cleaning stick.
Doing so may damage the print head.
• Do not reuse the cleaning stick.
The attached dust, etc may damage the print head.
Do not slant the printer, prop it against a wall or turn it upside down.
There is a possibility that ink inside the printer may leak.
Moreover, normal operation after shifting (to these positions) cannot be guaranteed.
Unpacking or moving this printer must be done by the following number of people.
• CS9350: more than three persons
Installing the dedicated stands on the printer must be done by the following number of people.
• CS9350: more than three persons
When installing the dedicated stands, make sure to switch OFF the printer and unplug the power cable.
There may be a risk of electric shock.
When you do not use the printer for a long period, make sure to pull out the power plug from the power socket for
safety.
Make sure to connect an earth wire to the earth connection that meets the following standards.
• Earth terminal of power socket
• Earth wire with copper plate which is buried at 650 mm or more, deep in the ground.
Before operation, make sure to read the Material Safety Data Sheet (MSDS).
Ventilate the workplace.
Not doing so may make you feel sick or may lead to a fire.
Right after printing, the media guide becomes very hot.
Allow the media guide to cool down before the next operation.
When loading the roll media, place it on a flat surface such as a desk.
If the roll media is loaded with the scroller up, the scroller may be damaged.
Pay attention to the following points when cutting roll media.
Mishandling the razor blade may cause a cut on your finger or hand.
• When you hold media, do not place your finger on the media cut groove.
• Move the razor blade along the media cut groove.
When cleaning the areas other than the wiper, make sure to switch OFF the power and unplug the power cable.
Move the printer maintaining a horizontal position.

CS9350 OPERATION MANUAL
1-13
1.3 Air ventilation requirements
The Océ IJC932 ink contains volatile organic compounds (VOCs). The concentration of VOCs in the
print room during operation of the Océ CS93x0 depends on multiple factors: room volume, ventilation
rate, print speed, number of prints, print mode, number of printers in the room, heater settings, kind of
media, etc.
In order to avoid any health risk related to VOCs and to ensure a safe work environment, Océ advises
to use this ink only in a well ventilated area. The user needs to take all necessary precautions in
accordance with all applicable local, state and federal regulations.
Table 1: Recommended room volume and ventilation for Océ CS93x0 using IJC932-inks
(*) Use an Air Purification System (APS) with an active carbon filter (Filter 05).
1.3.1 Instructions for use of an APS
To connect an APS system to the Océ CS93x0, please refer to the manual.
For instruction on safe use and maintenance of an APS, please refer to the User's Guide
Type of ink APS Used (*) Minimum room
volume
Required ventilation rate Hourly
ventilated
volume
Océ IJC932
Eco Solvent ink
Yes, optional 50m³ Additional local exhaust
ventilation 200 m³/h
No 150 m³ Room ventilation, 3 times
per hour 450 m³/h
Note
The recommended room ventilation should be applied in case the printer is used at
nominal printing speed (8 m2/h) at daily print volumes of 55 m2/day (3 times average
intended use). In case of even more intensive use of the printer, the ventilated volume
should be increased accordingly.
The required hourly ventilated volume is independent of the room volume. In case the
Océ CS93x0 is placed in a larger room, the ventilation rate may be lowered accordingly,
as long as the hourly ventilated volume is equal to or larger than indicated in table 1.
The (hourly) ventilated volume is required for each Océ CS93x0 that is installed in the
room. In case multiple machines are installed, either the room volume or the room
ventilation has to be increased accordingly
The total ventilated volume may be either a general room ventilation or a combination of
a lower general room ventilation with additional extra local exhaust ventilation.
The concentration of VOCs will be higher in the vicinity of the equipment. Part of the
VOCs will be originating from the printed matter. To ensure no nuisance will occur, Océ
advises to always use additional local exhaust ventilation directly above the heated
media guide platen, even when an APS is used.

CS9350 OPERATION MANUAL
1-14
1.4 Warning labels
Warning labels are attached to parts of the printer that need special caution.
Understand the locations and the descriptions of the danger associated with each label before operating
the printer.
1.4.1 Handling the warning labels
When handling the warning labels, be careful about the following points.
NOTE
Check whether all the warning labels can be read.
If the letters or illustrations on the label are not clear, remove the dirt from the label.
Use cloth, water and mild detergent for removing dirt from the warning label.
Avoid either organic solvents or gasoline.
It is necessary to replace the labels if they are damaged, lost or illegible.
If the warning labels have to be replaced, contact your local Océ representative.
1.4.2 Location and type of warning labels
Pasting locations of the warning labels are shown in the following figure.
(1) Front
1
2
2

CS9350 OPERATION MANUAL
1-15
(2) Rear
N° Types of warning labels
1
2
2

CS9350 OPERATION MANUAL
1-16
1.5 Operating Instruction Labels
This printer has some operating instruction labels with simplified operation procedures where special
attention is required during operation.
Make sure to fully understand the locations and contents of the labels before operating the printer.
1.5.1 Cautions on Handling the Operating Instruction Labels
When handling the operating instruction labels, note the following.
NOTE
Check if all of the operating instruction labels can be read.
If the letters or illustrations on the label are not clear, remove the dirt from the label.
When cleaning the operating instruction labels, use a cloth, water, and mild detergent.
Avoid either organic solvents or gasoline.
It is necessary to replace the operating instruction labels if they are damaged, lost or
unreadable.
If the operating instruction labels have to be replaced, contact your local Océ
representative.
1.5.2 Locations and Types of Operating Instruction Labels
Locations of the operating instruction labels are shown in the following figure.
N° Types of the operating instruction labels Reference
16.1.1 Replacing ink
cartridges
1

CS9350 OPERATION MANUAL
2-17
Chapter 2 Product overview
2.1 Names of parts and functions
2.1.1 Front section
N° Name Function
1Media loading lever Used for fixing or releasing media.
2Operation panel Operation condition setting, printer display and various function settings are
performed.
3Front cover Used for preventing a user from coming in contact with the driving mechanism during
the printer operation. Opened and closed when media is set or jammed.
It is normally closed.
4Stand Used when installing the printer on a flat floor.
5Media guide Used for feeding media smoothly when the media is set or printed.

CS9350 OPERATION MANUAL
2-18
2.1.2 Rear section
6Media cut groove Used to cut media straight.
7Pressurizing rollers Installed inside of the front cover.
Press and hold the media when printing.
8Platen Installed inside of the front cover.
Stabilizes the print side of the media.
9Maintenance cover Used to prevent the user from touching the inner mechanical section.
Open and close in the following cases.
• When cleaning the cleaning wiper
• When cleaning around the print head.
• When replacing the cutter
It is normally closed.
10 Connector Used to install spectrophotometer.
N° Name Function
1AC inlet Used for connecting the power cable.
2Network interface cable connector Connects a network interface cable.
3Scroller holder Set the scroller here when using the roll media.
4Media feed slot Used for feeding media.
5Ink cartridge slot Insert the ink cartridge.
6Media guide Used for feeding media smoothly when the media is set or printed.
N° Name Function
9

CS9350 OPERATION MANUAL
2-19
2.1.3 Operation panel
Used to set the operating conditions, to display the status of the printer, and to set various functions.
Names of each operation key and status display along with the functions are explained.
TIP
Refer to the following for details regarding the operation method of the operation panel.
When performing menu setting from the operation panel: 4.3 Menu setups on the
operation panel
When performing various operations in the operation panel: 4.4 Operating from the
operation panel
7Waste fluid tank Used for collecting waste ink discharged from the printer.
8Waste fluid valve Open and close when discharging the waste fluid from the waste fluid tank.
It is normally closed.
9Book holder Quick reference etc can be stored.
N° Name Function
8, 9
3
15
17
16
6
5
11
12
1
13
14
10
27
4

CS9350 OPERATION MANUAL
2-20
(1) Operation keys
NOTE
The operation keys are assigned with different functions and names depending on printer
status (Normal or Setup menu display).
For details about printer status, refer to “2.3 Printer status”.
N° Name Normal Setup menu display
1[Menu] key Shifts to the Setup menu. Shifts from Setup menu display to Normal.
2[Enter] key Restarts printing when the printing is
suspended.
• Select the menu to be set, and shifts to the
next hierarchy.
• The setting is determined and saved.
[Cutting] key Cuts the media when pressed for more than
two seconds.
—
3[Pause] key Pauses printing. —
[Cancel] key • When printing:
When pressed for more than two seconds,
forcefully terminates printing and deletes
one file of the remaining data.
• When receiving or analyzing data:
When pressed for more than two seconds,
deletes the data already received and
analyzed.
• Returns to the previous menu hierarchy.
Changes made in the setting are discarded.
• Shifts from Setup menu display to Normal.
4[<] key — —
[Nozzle Check] key Press and hold this key for two seconds or
more to perform Nozzle Check printing.
—
5[>] key • Sets Cleaning Mode.
• The lamp of Cleaning Mode that you set
lights up in green.
Down the menu level in the directory tree.
[Cleaning] key When pressed for more than two seconds,
cleaning starts.
—
6[Backward↑] key Media is fed in the reverse direction. —
[+] key —• Changes to the previous item in the
displayed menu.
• The setting is changed to the reverse
direction.
• The numeric value is increased during
numerical input.
7[Forward↓] key Media is fed in the forward direction. —
[–] key —• Changes to the previous item in the
displayed setting.
• The setting is changed to the forward
direction.
• The numeric value is decreased during
numerical input.
8[Power] key switches the printer ON and OFF. switches the printer ON and OFF.
