ODES UTVS Raider User manual

- 1 -
WARNING
● Operation of this UTV by anyone under the age of 16 may increase the risk of
severe injury or death!!! This vehicle can roll if not driven properly!!!
● Adult supervision is always required.
● Anyone under the age of 16 may NOT operate this UTV.
● Overloading the UTV may adversely affect the handling of this vehicle.
● Operator use only, excess passengers prohibited.
● This vehicle is designed and manufactured for OFF-ROAD use only.
● Driving Off Road Vehicles on public streets, roads, or highways is illegal.
●All Riders MUST wear helmet and other protective equipment.
● Do NOT operate this vehicle during/after consumingAlcohol or Drugs.
● Don’t do drugs. It’s not healthy for you.
● When refueling, you must shut off the engine to avoid spark or fire risk.
● Read owner's manual carefully before operating this vehicle.

- 2 -
INTRODUCTION
Dear Valued ODES Customer,
Congratulations and thank you for choosing to become a part of our ODES family
with the purchase of your new ODES UTV. We have designed this vehicle with you,
the customer, in mind, providing you with great power, stability, and functionality with
your UTV. This UTV was designed for OFF Road use only.
This Operator’s Manual is here to familiarize any operators of all proper operating
procedures. It also includes important and required information about the general
care and maintenance of your ODES UTV.
Read the following pages regarding safety warnings, active riding skills, and
precautions for your own safety and the safety of others around you. Children and
adults have different skill levels, physical abilities, and use of judgment. Anyone
under the age of 16 is NOT permitted to drive this vehicle. Parents should always
supervise their child’s (anyone under 16) use of this UTV at all times.

- 3 -
All information in this manual is based on the latest product data and specifications
available at the time of printing. ODES, the Manufacture of this UTV, reserve the right
to make product changes and improvements, which may effect the illustrations,
layout, or explanations without notice.
If you have any other questions regarding our UTV’s operation or maintenance,
please contact any authorized dealer.
Product and specifications are subject to change without notice.
