Odys Shark User manual

EN
ODYS Shark
- 1 -
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings, install in accordance with
the instructions.
8) Do not install near any heat sources such as radiations, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not alter the safety purpose of the polarized plug. If the
provided plug does not fit into your outlet, consult an electrician for
replacement.
10) Protected the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Unplug this apparatus during lighting storms or when unused for
long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as damage to the power-supply cord or plug, liquid or other objects
have entered the apparatus, the apparatus has been exposed to
rain or moisture, the apparatus does not operate normally, or has
been dropped.
14) Removing the plug from the main outlet will completely disconnect
the device from its electrical source. While in use, the main outlet
must be free of all obstruction to insure readily accessibility.
15) The ventilation openings should be free at all times. Do not cover
the ventilation openings with items, such as newspapers, table-
cloth, curtains, etc.
16) Do not place items or open flames (candles, etc) on this apparatus.
17) Attention should be drawn to the environmental aspects of battery
disposal.
18) Use this apparatus only in moderate climates.
WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
WARNING: The batteries should not be exposed to excessive heat such as
direct sunlight, fire or other heat sources.

EN
ODYS Shark
- 2 -
The symbol indicates that dangerous voltages and risk of electric shock
are present within this unit.
The symbol indicates important operating and maintenance instructions
within the literature accompanying this unit.
The symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts. When
servicing use only identical replacement parts.
CAUTION:
Should the apparatus be exposed to electrostatic
electricit
y
, it ma
y
malfunction and ma
y
re
q
uire a reset.
Tips regarding environmental protection
At the end of its operating life, this product may not be
disposed of by way of your normal household waste.
Instead, it must be delivered to a collection point for
recycling electrical and electronic equipment. The icon
on the product, in the operating instructions or on the
packaging, indicates this.
The materials used in manufacturing this product are
recyclable, depending on their identifying markings. By
recycling this equipment, by recycling its components, or
through other procedures of re-using outdated
equipment, you are making an important contribution to
the protection of our environment. Please ask you local
municipal administration for the location of the
correspondin
g
rec
y
clin
g
point.
Battery Recycling
In order to ensure the environmentally friendly disposal
of batteries, please do NOT dispose of used
batteries through normal household waste. Please take
the batteries to your local retail or community collection
point for recycling.
The following may be an indication of a discharged
battery: The device cannot be switched on. The
device switches off automatically and "Battery Empty" is
shown in the display. The device and or battery do not
function properl
y
.

EN
ODYS Shark
- 3 -
Support
URL: http://www.odys.de
See our website for the latest information concerning this product, other
products manufactured by our company and our company itself. If you have
questions or problems, please read the FAQs on our website or contact our
customer support service center: [e-mail].
Appropriate use
Device is designed for playing music in commonly used formats and
transferring sound from a Music or Sound source to its speakers using a cable
or Bluetooth connection. It is exclusively meant for this purpose and must only
be used for the same.
This also includes paying attention to all information contained in this
operating manual, especially in the safety instructions. Any other usage is
considered to be improper and may lead to material damages and even
personal injuries. Moreover, it will result in the immediate loss of guarantee.
The manufacturer does not bear any liability for damages caused due to
improper use.
This manual may not reflect your actual device’s operation. All
information is subject to change without prior notification. Please
follow your actual device’s operational procedures.

EN
ODYS Shark
- 4 -
Content
Content.............................................................................................- 4 -
1Specifications ..........................................................................- 5 -
2PACKAGE CONTENTS..........................................................- 5 -
3MAIN UNIT..............................................................................- 5 -
4REMOTE CONTROL ..............................................................- 6 -
5POWER SUPPLY....................................................................- 7 -
6Setup the unit ..........................................................................- 7 -
6.1 SLEEP TIMER SETTING....................................................- 7 -
6.2 HOW TO SET TIME............................................................- 7 -
6.3 TIMER SETTING ................................................................- 7 -
7USB & SD CARD PLAYBACK ................................................- 8 -
8BLUETOOTH OPERATING....................................................- 9 -
8.1 Pairing.................................................................................- 9 -
8.2 RE-CONNECT TO A BLUETOOTH AUDIO SOURCE.......- 9 -
9Basic Function.......................................................................- 10 -
9.1 MUTE THE UNIT ..............................................................- 10 -
9.2 VOLUME LEVEL/TREBLE/BASS ADJUSTMENT............- 10 -
9.3 EQ EFFECTS....................................................................- 10 -
9.4 PROFESSIONAL AUDIO MODES ...................................- 10 -
10 FM RADIO.............................................................................- 10 -
10.1 TUNING THE FM RADIO.............................................- 10 -
10.2 STORING YOUR FAVORITE RADIO STATION..........- 11 -
11 CONNECTING WITH OTHER DEVICES .............................- 11 -
11.1 AUDIO IN......................................................................- 11 -
11.2 LINE IN .........................................................................- 11 -
11.3 OPTICAL INPUT...........................................................- 12 -
12 TROUBLE SHOOTING.........................................................- 12 -
13 Warranty condition ................................................................- 13 -

EN
ODYS Shark
- 5 -
1 Specifications
1) Compatible with bluetooth devices and other devices containing AUX
output connections.
2) Easy operation using the buttons located on the top of the device.
2 PACKAGE CONTENTS
ODYS Shark, Manual, Remote Control, 2 Wall mounting brackets, 2 feet,
Line-In Cable, AUX-In Cable
3 MAIN UNIT
12345
8910
11 12 13 11
1
5
1
6
67
14
1. VOLUME - BUTTON
2. VOLUME + BUTTON
3. POWER BUTTON
4. MODE BUTTON
5. PAIR/PLAY/PAUSE BUTTON
6. SD CARD SLOT
7. USB PORT
8. LCD DISPLAY
9. BLUETOOTH INDICATOR
10. REMOTE SENSOR
11. HANGING HOLES
12. FM ANTENNA
13. AC CORD
14. OPTICAL IN JACK
15. AUX IN JACKS
16. LINE IN JACK

EN
ODYS Shark
- 6 -
4 REMOTE CONTROL
Attention:
Connecting the device to the main power source while in operation may
cause damage to the amplifier and or DVD player.
We recommend connecting all components, which includes the
SOUNDBAR to the main power supply before attempting to operate this
device.
Damage resulting from improper power use is not covered within the
guarantee guidelines.
1. SLEEP BUTTON
2. MODE BUTTON
3. CLOCK BUTTON
4. TIMER BUTTON
5. NUMERIC BUTTONS
6. VOICE BUTTON
7. EQ BUTTON
8. BASS +/- BUTTONS
9. TREBLE +/- BUTTONS
10. MUTE BUTTON
11. POWER BUTTON
12. TUNING/SKIP/SEARCH BACKWARD
13. TUNING/SKIP/SEARCH FORWARD
14. MEM BUTTON
15. PAIR/PLAY/PAUSE BUTTON
16. MUSIC BUTTON
17. MOVIE BUTTON
18. VOL +/- BUTTONS
19. CH+/- BUTTONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

EN
ODYS Shark
- 7 -
5 POWER SUPPLY
Plug AC plug into the outlet socket on the unit for connecting the main power.
NOTE: If not any audio signal inputs to the unit in about 10 minutes, the unit
will enter to standby mode automatically (except at FM mode).
6 Setup the unit
6.1 SLEEP TIMER SETTING
You can set the sleep timer at power on modes as following instructions:
During playback, press the SLEEP button on the remote control repeatedly to
cycle through the sleep time options, Release the SLEEP button when your
desired sleep time shows on the screen. Once the sleep time is expired, the
unit will be switched off.
During playback, press SLEEP button once to check the remaining sleep time.
6.2 HOW TO SET TIME
At the standby mode, press and hold the CLOCK button on the remote until
Hour flashes on the screen; use the TUNING/SKIP/SEARCH buttons on the
remote to adjust the hour and confirm your adjustment by pressing the
CLOCK button on the remote; Minute starts blinking on the screen, press the
TUNING/SKIP/SEARCH buttons on the remote to set the minute accordingly,
press the CLOCK button on the remote again to confirm your setting.
During playback, press and hold the CLOCK button on the remote to check
the current time.
Note: The time only could be set at standby mode.
6.3 TIMER SETTING
1. At standby mode, press and hold the TIMER button on the remote. The
hour on the display will begin blinking on the screen with the flashing timer
icon “T”.
2. Press the TUNING/SKIP/SEARCH buttons on the remote to adjust the
hour.
3. Press the TIMER button to confirm. The minute on the display will begin
blinking.
4. Press the TUNING/SKIP/SEARCH buttons on the remote to adjust the
minute.

EN
ODYS Shark
- 8 -
5. Press the TIMER button on the remote to confirm your setting.
6. After the set time is reached, the unit will power on to the radio
automatically.
7. The timer function can be deactivated or activated by short pressing the
TIMER button on the remote.
7 USB & SD CARD PLAYBACK
1. Power on the unit, insert an USB or a SD card into the unit.
2. Press MODE button repeatedly to switch to USB or card mode. The
playback will start automatically.
3. Press the TUNING SKIP/SEARCH FORWARD button on the remote to skip
to the next track; press and hold to search through the track forward.
4. Press the TUNING SKIP/SEARCH BACKWARD button on the remote to
skip to the previous track; press and hold to search through the track
backward.

EN
ODYS Shark
- 9 -
8 BLUETOOTH OPERATING
8.1 Pairing
This unit can receive stereo audio signal from a BLUETOOTH stereo audio
source device.
1. Power on the unit, switch to BLUETOOTH mode by pressing MODE button
repeatedly.
2. LED indicator rapid blinking while it is pairing.
3. Enable the Bluetooth of the Bluetooth audio source device.
4. Pair and connect to ODYS Shark (MIB668A) on the audio source device. If
prompted for password, enter “0000”.
5. Pairing successful (LED indicator blue), ready to stream music.
6. During playback, press PLAY/PAUSE button to cease or resume the
playback.
7. During playback, press TUNING/SKIP/SEARCH FORWARD button to skip
to the next track; press TUNING/SKIP/SEARCH BACKWARD button twice
to skip to the previous track.
8. During playback, press and hold TUNING/SKIP/SEARCH buttons to search
through the current track forward or backward.
Note:
Pairing mode is cancelled after 1.5 minutes.
Pairing the playback device with the ODYS SHARK is only possible when
the ODYS SHARK is in the pairing mode and the LED blinks blue.
The above are generic steps to pair a BLUETOOTH device, for more
specific instructions on BLUETOOTH connectivity for your device, please
consult your manufacturer’s manual.
8.2 RE-CONNECT TO A BLUETOOTH AUDIO SOURCE
If the device is already paired with the ODYS Shark, but became unconnected
even with both Bluetooth devices turned on. You can re-connect them by
following steps:
1. Press and hold the PAIR button on the unit or on the remote to re-link the
audio source device. The Bluetooth indicator will blink for about 1.5
minutes for connecting.
2. Select the ODYS Shark (MIB668A) on the audio source device for
connecting. Bluetooth indicator will turn to solid blue if the ODYS Shark
(MIB668A) and the device have been re-connected successfully.
3. You can also re-connect the ODYS Shark (MIB668A) by using Bluetooth
operation of the device to be connected.

EN
ODYS Shark
- 10 -
9 Basic Function
9.1 MUTE THE UNIT
During playback, press the MUTE button on the remote to switch off the
audio. Press the button again to resume the audio.
9.2 VOLUME LEVEL/TREBLE/BASS ADJUSTMENT
Press the VOLUME +/- buttons or TREBLE +/- buttons or BASS +/- buttons
on the remote to adjust the volume output level or treble effect or bass effect.
9.3 EQ EFFECTS
During playback, press EQ button on the remote repeatedly to cycle through
the EQ options; when your desired EQ effect shows on the screen, release
the button.
9.4 PROFESSIONAL AUDIO MODES
During playback, press the VOICE, MUSIC or MOVIE buttons on the remote
to switch among voice, music and movie audio modes for getting high sound
quality. The audio modes can reveal the characters and details of the sound
of the voice, music and movie and make you liked being there.
10 FM RADIO
10.1 TUNING THE FM RADIO
1. Power on the unit, switch to FM (RADIO) mode by pressing MODE button
repeatedly.
2. Press the TUNING/SKIP/SEARCH buttons on the remote to fine tune radio
station. Press and hold the TUNING/SKIP/SEARCH buttons on the remote
to auto search radio station forward or backward respectively (When an
available station will be found, the unit will broadcast it immediately and the
searching will be stopped). During auto searching, press the
TUNING/SKIP/SEARCH buttons on the remote to stop the searching.
3. At radio mode, it is possible to access the frequency via numeric buttons on
the remote control. For example, press buttons 8, 9 and 8 to get to 89.8
MHz.
