Olin DVR-140 User manual

Dear Customers
We would like to thank you for purchasing this unit. It is a progressive scan DVD Recorder. you
the ability to create your own DVD discs from you home movies, favorite TV programs and more.
Because of the outstanding compatibility of DVD + R / RW discs, the discs you create will be suitable for playback in
most DVD Recorders.
This product provides
You can record from the unit's built-in TV tuner or external video source like a video camera.
When you are ready to watch your recordings or commercial DVD movies, you can enjoy them in the highest quality
with your new DVD Recorder.
TABLE OF CONTENTS
PLAYABLE DISCS
05
ADVANCED PLAYBACK 15
LANGUAGE CODE LIST
33
SYSTEM SETUP 23
SAFETY PRECAUTIONS 01
IMPORTANT SAFETY INSTRUCTIONS 03
NOTICE 04
FRONT PANEL 07
REAR PANEL AND ACCESSORIES 08
BASIC CONNECTION 09
REMOTE CONTROL 12
INITIAL SETUP 13
BASIC PLAYBACK 14
SPECIAL FUNCTION PLAYBACK
17
DVD RECORDING 18
TROUBLE SHOOTING 30
PARENTAL LOCK & SCREEN SIZE 31
SPECIFICATIONS 32

SAFETY PRECAUTIONS
01
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE, DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER
SERVICING TO QUALIFIED PERSONNEL ONLY.
When replacing the unit's plug or power cord, the replacement must be the exactly
the same ;or one recommended by the manufacturer.
The lightning flash with arrowhead symbol, within an equila-
teral triangle, is intended to alert the user to the presence
of uninsulated "dangerous voltage " within the product's en-
closure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
This Digital Video Disc player employs a laser system.
The symbol for CLASS II (Double Insulation).
Use of controls, adjustments or the performance of procedures other than those
specified may result To prevent direct expo-
sure to laser beam, do not try to open the enclosure.
DO NOT STARE INTO BEAM.
in hazardous exposure to radiation.
WARNING:
CAUTION:

"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
SAFETY PRECAUTIONS
02
Manufactured under license from Dolby Laboratories. " Dolby " and the double-D
symbol are trademarks of Dolby Laboratories. Confidential unpublished works.
Copyright 1992-1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection technology that is protected by
methods claims in certain U. S. Patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Consumers should note that not all high definition television sets are fully compatible
with this product and may cause artifacts to be displayed in the picture.
In case of 525 or 625 progressive scan picture problems, it is recommended that the
user switch the connection to the "standard definition" output. If there are questions
regarding our TV set compatibility with this model 525p and 625p DVD player, please
contact our customer service centre.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product, it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the government
or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact
your city office, waste disposal service or the shop where you purchased the product.

03
Slots and openings in the cabinet are provided for ventilation
and to ensure correct operation of the product. These protect
it from overheating. These openings must not be blocked or
covered. The openings should never be blocked by placing
the product on a bed, sofa, rug or other.
must
must ever
placed
power boards
do this

following situations.
04
an vehicle
ELECTRICAL DISTURBANCE
suffer from condensation under the
connecting will ensure

PLAYABLE DISCS
05
Playback and Recording: Playback only:
DVD+R
DVD+RW
RW
DVD-RW
DVD-R
DVD+RW:
Media handling and cleaning
DVD-RW:
Misubishi 2x
Misubishi 1x
TDK 4.7GB
Maxell/victor*JVC
RiData 1x
Pioneer 2x
TDK 1x
Ritek 1x
Ritek 2x/Ridata 2x
Prodisc 1x
Princo 1x
Princo 2x
Melody/Imation
TDK 2x
CMC 2x
JVC
OPTO 2x
Meida MID Write Speed
2X
MCC 01RW11n9
MCC-00RW11N9
TDK401saku=3
JVC/VictorT7
RITEK004V11-
PVCW00V00245
TDK501saku]3
RITEK000V11A
RITEW01----
ProdiscDVDRW
PRINCO------
PRINCO------
OPTODISCK001
TDK502sakuM3
CMCW02------
JVC-VictorW7
OPTODISCW02
1X
Ricoh, Ridata 2.4x
Mitsubishi 2.4x
Ritek 2.4x
Ricoh, Ridataa 4x
Mitsubishi 4x
Infodisc 2.4x
Prodisc 2.4x
CMC & Philips & 2.4x
Ritek 4x
Nanya 2.4x
Optodisc
Sentinel 2.4x
Daxon 4x
CMC 4x
Philips 4x
MBI 2.4x
infodisc 4x
Prodsic 4x
Nanya 4x
OPTO 4x
Philips 2.4x
Meida MID Write Speed
2X
RICOHJPN
MCC------
RITEK----
RICOHJPN
MKM-----
INFODISC
PRODISC-
CMC-MAG-
RITEK----
NANYASC--
OPTODISC
SENTINEL
DAXON---
CMC-MAG-
PHILIPS-
MBIPG101
INFODISC
PRODISC-
NANYA
OPTODISC
PHILIPS-
Media
type
W01
A01
001
W11
A02
A01
W01
W01
004
DRW
OP1
W01
D41
W02
041
W03
A10
W02
DRW
OP4
010
Playback only:
WMA TM
Designed for
TM
Windows
Media
DVCD
CD+G
CD+G
HDVD
The Player does not support discs types which are not listed above.
Non-standardized discs, even if they may be labeled as above can not be played.
The performance of recorded disc is depend on the method and quality of disc-burning. In some cases,
the disc may not be played.

PLAYABLE DISCS
06
DVD+R:
Meida MID Write Speed
Ricoh RICOHJPNR00
MCC---002
CMC-MAG-F01
YUDEN000T01
PITEK---R01
PRODISC-R01
RICHJPNR01
CMC-MAG-R01
NANYA--DR--
LD------001
RITEK---R02
PRODISC-R02
MEDIA-ID001
OPTODISCOR4
OPTODISCOP1
SKYMEDIAR01
AML-----01
--------001
MPOMEDIA001
BEALL-P0001
RITEK---R03
DAXON---AZ1
YUDEN000T02
PRODISC-R03
YUDEN000T01
MCC-----003
CMC-MAG-F01
CMC-MAG-E01
Philips-081
LONGTEN-002
MBIPG101R03
NANYA---RJB
DAXON---AZ1
AML-----002
OPTODISCOP2
MPOMEDIA040
GSC502--002
MUST-002---
RITEK---M02
MAXELL--002
INFODISCR10
SONY----D01
LD------A02
VDSPMSAB001
IS01----001
PITSEXP-002
MCC 4X
CMC 4X
Taiyoyuden
PITEK
Prodisc
RICOH
CMC
NANYA
Lead Data
PITEK
Prodis
MELODY
OPTO
OPTO
NASHUA
AML
CHINA
VIDEOB
BEALL
RITEK
DAXON
Taiyoyuden
PRODIS
Taiyoyuden
MCC
CMC
CMC
Philip
LONGTE
MBI
NANYA
DAXON
AML
OPTO
MPO
GIGA
MUST 4X
PITEK 4X
MAXELL 4X
INFODISC 4X
SONY 4X
LEAD DATA4X
RI/HENG 4X
Aotian/Clone/PDK/T-Bird
Pan 4x
2X 4X
MCC---001MCC 2X
DVD-R:
Meida MID Write Speed
RITEKG03----
MCC-00RG200-
MXL-RG01----
PVC001001---
TAIYOYUDEN--
NANYA-P1861-
MBI---------
GSC001------
CMC-MAG.----
SONY--------
LD----------
TAROKO-X2---
PRODISCG02--
PRINCO------
TDKG02000000
opt0d1sck001
TDKG010000d9
BeALL-G00001
PRINCO------
MCC-01RG20--
PVCR001002--
TYG01------
RITEKG04----
CMC-MAG.-AF1
GSC001------
SCK-Co.,Ltd.
NANYA.JC001-
PRICO
LEADDATA01--
PRODISCS03--
MEI-00V001--
GSC001------
LONGTEN-001-
DAXON004----
MBI-01RG20--
OPTODISCK001
AML---------
TAROKO.MX4--
AN31--------
ME-153------
POSG04------
ONIDTECH----
MXL-RG02----
AN32--------
Yi-Jhan-001-
OPTODISCR004
VANGUARD----
LONGTEN-009-
Ritek
MCC
Maxell
Fujifilm
Taiyoyuden
NANYA
MBI
GIGA
CMC
SONY
Lead Date
TAROKO
PRODISC
PRINCO
TDK
OPTO
TDK
BEALL
PRINCO
MCC
Pioneer
Taiyoyuden
Ritek
CMC
GIGA
SKC
NAYA
PRICO
LD
PRODISC
PANSIC
GIGA
LONGTEN
DAXON
MBI
OPTO
AML
TAROKO
AN31
MJC
POSTECH
ONIDTECH
NUMBER
CYBERSTO
Yi Jhan
OPTO
VANGUARD
LONGTEN
2X

DV IN L
VIDEO R
AV2 I N
CH- CH+ REC
DVR- 140
DVD RECORDER AND DVD/CD/MP3/CD-R/CD-RW/DVD+R/DVD+RW PLAYER
FRONT PANEL
07
FRONT PANEL
1. STANDBY/ON Switch on or off: to switch off or on, interrupt a function.
12
2. POWER INDICATOR indicator: green (working), red (standby).
3. CHANNEL-
CHANNEL+
5. RECORD Record:
6. PLAY/PAUSE Play: playback a disc. Pause:
7. STOP Stop:
8. OPEN/CLOSE Open/Close: open/close disc tray.
9. REMOTE CONTROL RECEIVER Receives the signal from the remote control.
D SCREEN
11. DV INPUT DV input socket: connection of digital video camera.
. VIDEO INPUT (F-A/V) C
13. L/R AUDIO INPUT ( F-A/V) C
TV Program Number: To select a lower program number.
4. TV Program Number: To select a higher program number.
Records the current source selected.
Temporarily pauses DVD playback or recording.
Stops playback/recording.
10. LE Displays information related to the unit such as Time, Current Chapter,
Disc Tray Status, etc.
onnection for external equipment using the Yellow Video (RCA) Cable.
onnection for external equipment using the Red/White Audio (RCA) Cables.
12 13 14
138910
12
11
NOTES ON POWER STATES
There are 3 power states for this unit:
OFF - The unit draws no power and cannot be turned on by the remote control.
STANDBY -
ON - The STANDBY button on the remote control or the STANDBY/ON button on the front panel has been
pressed. The unit is ready to use.
The unit draws a slight amount of power to enable the remote control receiving circuit and to
retain basic settings such as the Time and Recording Settings.
114 2 6 75
13
2

ON
OFF
RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEO IN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CH AUDIO OUT
Y
CB / PB CR / PR
COAXIAL
OPTICAL
VIDEO OUT / DIGITAL AUDIO OUT
AUDIO IN
L
R
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Manufactured under license from Dolby
Laboratories. " Dolby " and the double-D
symbol are trademarks of Dolby Labor-
atories. Confidential unpublished works.
Copyright 1992 - 1997 Dolby Laborator-
ies. All rights reserved.
Apparatus Claims of U.S.
Patent Nos. 4,631,603;
216; 4,819,098 and
4,907,093 licensed for
uses only.
4,577,
limited viewing
"DTS" and "DTS Digital Out"
are trademarks of Digital
Theater Systems, Inc.
CLASS 1 LASER PRODUCT
N14142
110V-240V~ 50/60Hz
MODEL: DVR-140 AC: 110V-240V~ 50/60Hz
POWER: 35W
S/N:
DVD RECORDER
For Warranty Please Call 1800 656 630
Made In China
REAR PANEL and ACCESSORIES
08
REAR PANEL
ACCESSORIES
Owner's manual x 1
Batteries x 2
Audio/Video cable x 1
Warranty Certificate x 1
Remote control x 1
Quick Install Guide x 1
PROG
SETUP
1
0
23
456
789
VOLUME
ANGLE
MUTE
V.MOD E
REPEAT AUDIO
TITLE/PBC
SUBTITLE
INTRO
ZOOM
A-BRPT
SLOW
N/POSD
BOOKMARK
DVD
SOURCE
CHAPMARK
EDIT
PAUSE/ STEP STOP
MENU
CH-CH+
REC
TIMER
QUALITY
DISC
DVR-140
3
2456910 12
78
1.
. L/R AUDIO INPUT(R-A/V, R-SV) Audio input connection for external audio devices.
3. VIDEO INPUT
.
1
RF IN/OUT Aerial output: for Antenna or Cable TV.
2
(R-A/V) Composite Video input for recording.
4. S-VIDEO INPUT(R-SV) S-VIDEO input for recording.
5. VIDEO OUTPUT Standard Video Output supported by most TVs.
6. S-VIDEO OUTPUT Connect to TVs with S-VIDEO in for better picture quality than
standard composite video.
7. 5.1-CH AUDIO OUTPUT Connect to TVs or other Audio equipment supporting 5.1CH audio in.
8. YUV OUTPUT Use this output with TVs supporting Component Video or
Progressive Scan input for best video quality.
9 COAXIAL OUTPUT Use a special coaxial digital audio connector to send the raw coded
digital signal to devices supporting digital decoding.
0. OPTICAL OUTPUT Use a special optical digital audio connector to send the raw coded
digital signal to devices supporting digital decoding.
11. AC INLET Main socket: connection to the main supply.
12. POWER SWITCH Switch: switch on or off.
This output is the coded digital signal.
11
Owner's manual
Owner's manual
Warranty Certificate
WARRANTY
CERTIFICATE
Quick Install Guide
Quick Install Guide

RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEO IN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CH AUDIO OUT
Y
CB / PB CR / PR
COAXIAL
OPTICAL
VIDEO OUT / DIGITAL AUDIO OUT
AUDIO IN
L
R
RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEOIN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CHAUDIO OUT
Y
CB/ PB CR/ PR
COAXIAL
OPTICAL
VIDEOOUT / DIGITAL AUDIO OUT
AUDIOIN
L
R
RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEOIN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CHAUDIO OUT
Y
CB/ PB CR/ PR
COAXIAL
OPTICAL
VIDEOOUT / DIGITAL AUDIO OUT
AUDIOIN
L
R
BASIC CONNECTION
To record from an analog cable TV signal, connect the cable to the RF In jack.
09
If the TV has an S-video input,
When using an S-video cable, do not connect the yellow video cable.
connect the DVD player to the TV with an S-video cable
Note: By this connection, you must set the unit standby when watching TV only.
A B
Traditional RF Connection RF Connection When Using A Splitter Box
To record from devices such as DVD Players using the rear connections
ANTENNA or
TV signal cable
SPLITTER
LR VIDEOS-VIDEO
DVD
DS-N809 DVDVideo/DVD Audio/VCD/HDCD/JPEG/MP3 PLAYER
Red WhiteYellow
To Audio input(Red, White)
To Video input(Yellow)
To S-Video input
Yellow
Red White
Connecting to an audio system and TV equipped with YUV video input
RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEO IN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CH AUDIO OUT
Y
CB / PB CR / PR
COAXIAL
OPTICAL
VIDEO OUT / DIGITAL AUDIO OUT
AUDIO IN
L
R
To audio inputs of the amplifier
Red
Red White White
To Y video input
To CB/PB video input
To CR/PR video input
To Y video output To CB/PB video output To CR/PR video output

RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEO IN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CH AUDIO OUT
Y
CB / PB CR / PR
COAXIAL
OPTICAL
VIDEO OUT / DIGITAL AUDIO OUT
AUDIO IN
L
R
BASIC CONNECTION
10
Connecting to an amplifier equipped with a digital audio input and TV
To connect DV (IEEE-1394) devices that you will be recording from.
Note: the connect of AV2 is the same as AV1.
To OPTICAL
type digital
audio input
Connect either
Optical digital cable
Coaxial cable
To COAXIAL
type digital
audio input
To Y video output To CB/PB video output To CR/PR video output
To Y video input
To CB/PB video input
To CR/PR video input
DV
VIDEO
AV2 IN
LR
DV IN

RF
IN
OUT
VIDEO
S-VIDEO
VIDEO
S-VIDEO
VIDEO IN VIDEO OUT
FL
FR
SL
SR
CENTER
SUB-WOOFER
5.1-CH AUDIO OUT
Y
CB / PB CR / PR
COAXIAL
OPTICAL
VIDEO OUT / DIGITAL AUDIO OUT
AUDIO IN
L
R
Connecting to an amplifier equipped with 5.1ch audio input and TV
BASIC CONNECTION
11
To 5.1ch audio inputs
To video input
To 5.1ch audio outputs
Audio cable
Front (L)
Surround(L) Surround(R)
Subwoofer
Center
Front (R)

PROG
SETUP
1
0
23
456
789
VOLUME
ANGLE
MUTE
V.MODE
REPEAT AUDIO
TITLE/PBC
SUBTITLE
INTRO
ZOOM
A-B RPT
SLOW
N/POSD
BOOK MARK
DVD
SOURCE
CHAP MARK
EDIT
PAUSE/STEP STOP
MENU
CH-CH+
REC
TIMER
QUALITY
DISC
DVR-140
PROG
PROG
SETUP
SETUP
1
0
23
456
7 8 9
VOLUME
VOLUME
ANGLE
MUTE
V.MODE
V.MODE
REPEAT
REPEAT
AUDIO
AUDIO
TITLE/PBC
TITLE/PBC
SUBTITLE
SUBTITLE
INTRO
INTRO
ZOOM
ZOOM
A-B RPT
A-B RPT
SLOW
N/P
N/POSD
BOOK MARK
BOOK MARK
DVD
SOURCE
SOURCE
CHAP MARK
CHAP MARK
EDIT
EDIT
PAUSE/STEP
PAUSE/STEP
STOP
STOP
MENU
MENU
CH-CH+
REC
REC
TIMER
QUALITY
QUALITY
DISC
STANDBY/ON
REMOTE CONTROL
REMOTE CONTROL
12
Distance: About 7m (23 feet) from the
front of the remote sensor.
o
Angle: About 30 in each direction
of the front of the remote
sensor.
About 7m
FunctionFunction
1
2
4
6
7
8
9
10
11
12
14
16
18
20
21
22
23
13
15
17
19
3
5
24
25
27
29
30
31
32
33
34
36
38
39
26
28
40
1. OPEN/CLOSE DISC TRAY
2. Video Output Mode
3. TITLE/PBC
4. REPEAT
5. A-B REPEAT
6. DIGITS 0-9 BUTTONS
7. On Screen Display (OSD)
8. NTSC/PAL
9. SETUP
10. PLAY/ENTER
11. ZOOM
12. CHANNEL up
13. RECORD
14. TIMER
15. QUALITY
16. FAST REVERSE
17. FAST FORWARD
18. PAUSE/STEP
19. STOP
20. DVD Title Screen
21. MUTE
22. SOURCE
23. BOOK MARK
24. STANDBY
25. MENU
26. SUBTITLE
27. AUDIO
28. ANGLE
29. INTRO
30. CURSOR
31. PROGRAM
32. CHANNEL down
33. DISC
34. NEXT
35. PREVIOUS
36. SLOW FORWARD
37. SLOW REVERSE
38. VOLUME+/- (Volume Control)
39. CHAPTER MARK
40. EDIT
35
37

This chapter will show you how to start the initial set up, After successfully connecting your DVD recorder to
the TV set and other additional devices as described in the previous chapter .
ENTER OK
Next
Initial Setup Wizard
Before using your recorder
Please complete this setup
1/7
INITIAL SETUP
13
Back
Clock Setting 2/7
OK
Choose
:
4653 pm
/ /
11 2006
ENTER
OK
Back
Complete
Setup has been completed
Enjoy using your recorder
7/7
Finish
ENTER
Back
OSD Lang 3/7
English
OK
Choose ENTER
Back
Country setting 4/7
UK
Australia
OK
Choose ENTER
Germany
Auto Scan 5/7
OK
Choose
Back Cancel
80%
ENTER
Channels Found 35
6. "CH List" will edit channel list,
.
please consult
page 29
1.Press button for next page
CH List 6/7
OK
Choose
PR CH Name Skip
OK Cancel Back
Skip
01 CH3 Off
02 S2 Off
ENTER
2.
buttons to input " date " and " time ",
press to confirm and go on next setting.
Use direction button to select clock entry fields.
Use number
Highlight "Back" and press to back to previous
page.
3. Use UP/DOWN button to select OSD Language,
press to confirm and go on next setting.
Highlight "Back" and press to back to previous
page.
4. Use UP/DOWN button to select Country Setting,
press to confirm and go on next setting.
Highlight "Back" and press to back to previous
page.
5. "Auto Scan" will start automatically from this step,
but you can also cancel by pressing .
7. If you are sure that all steps are correct, please
highlight "Finish" button and press to end the
setup and
If not, please highlight "Back" button and press
to
enjoy using your new DVD recorder.
re-enter the initial set-up info.
Deutsch

BASIC PLAYBACK
14
Previous and Next
During playback, press PREV key to return to start
of the current chapter. Pressing again will skip back
to the start of the previous chapter. This will occur
until the 1st chapter of the disc is reached. (Note:
disc function may differ depending on disc format).
Pressing of the NEXT key during playback will skip
the current chapter and play the next one.
Fast forward and Fast reverse
1. Press F.FWD to fast forward through the disc.
Each time the F.FWD button is pressed, the
fast forward motion
2. Press to resume normal playback.
3. Press F.REV to fast reverse through the disc.
Each time the F.REV button is pressed, the
fast reverse motion
4. Press to resume normal playback.
speed changes (2x, 4x, 8x,
16x, 32x)
speed changes (2x, 4x, 8x,
16x, 32x)
Slow
Press SLOW to play a disc in
Each time the SLOW button is pressed, the
slow
Press to resume normal playback;
Press SLOW to play a disc in slow reverse. Each
time the SLOW button is pressed, the slow
Press to resume normal playback;
Note: This function is invalid for CD and MP3.
slow motion forward.
motion speed changes (1/2, 1/4 , 1/8, 1/16)
motion speed changes (1/2, 1/4 , 1/8, 1/16)
NOTES:
1. may appear on the TV screen during
operation. A means that the operation is
permitted by the unit or the disc.
2.
3.
not
This unit is controlled by CPU, under setting mode,
there may be screen saver, press any key to activate
the unit . If you can not use this function, you can
set SCREEN SAVER to OFF in GENERAL SETUP
of SYSTEM SETUP.
To prevent damage, do not restart the device within
5 seconds of turning off.
1. Press PAUSE/STEP first time to pause playback
(still mode). The sound will be muted during still
mode.
2. Press PAUSE/STEP continuously to single step
forward to the next frame in the video.
3. Press to resume normal playback.
Pause/Step playback
1. Press STOP button to go to stop mode, the unit
will change to input source automatically, the unit
can recall the location where stopped.
2. Press or DVD button to resume playback from
the location where playback is stopped or from the
beginning of the disc.
3. Press STOP twice to stop completely.
Stop playback
Basic playback
1. Press power switch on the rear panel to " ON " ,
then press "STANDBY/ON" on the front panel or
press " " on the remote to turn the unit ON, the
unit will change to input source automatically, after
the TV screen displays the start logo for a few
seconds.
2. Press OPEN/CLOSE to open the disc tray,
the dialog box shows "Open". Place a disc on the
disc tray.
There are two different disc sizes. Place the
disc in the correct guide on the disc tray. If the
disc is out of the guide, it may damage the disc
and cause the unit to malfunction.
Do not place a disc which is unplayable in this
unit.
3. Press OPEN/CLOSE to close the disc tray, the
dialog box shows " Loading " the playback will
automatically start.
Some discs may not playback automatically;
you can press button to start playback.
4. Some discs may start playback with a menu.
use the cursor button on the remote controller to
select menu options and press to start,
or alternatively, you can use digits if available on
the DVD menu to select a menu option directly.

ADVANCED PLAYBACK
15
IMPORTANT NOTE:
THE FOLLOWING FUNCTIONS ARE APPLICABLE ONLY TO DVD DISCS. IF OTHER DISC FORMATS ARE
PLAYED, SCREEN DISPLAY AND OPERATIONS MAY BE DIFFERENT.
OSD (On-Screen Display)
During playback, press this button to view available
information, Press again to cancel the control menu.
ANGLE
If the video on the DVD was recorded with multiple
angles, you have the option to change the camera
angle of the scene you are watching.
Pressing ANGLE button during playback will display
the angle mark on screen.
Note: the angle function will not work if your DVD
disc does not contain the multiple angle features.
A-B REPEAT
During playback , when you reach the start of the
segment you want to repeat, press the A-B REPEAT
button(Ponit A), at the end of the segment(Ponit B),
the player will automatically return to point A and start
to repeat playback of the selected segment(A-B).
press A-B REPEAT button to resume normal playback.
ZOOM
Press to zoom in on the incoming AV
signal and to cycle through all the levels. A small
PIP(picture-in-picture) display indicating the zoom
rate will appear on the lower right-hand side of the
screen during playback mode. This is accompanied
by a number on the lower-left side of the screen
showing actual zoom rate.
You can use the cursor buttons to move around the
image. This will display the parts of the image that do
not appear on-screen when the image is zoomed in.
Press the ZOOM button repeatedly to return to normal
viewing.
this button
AUDIO
The toggles the display of the Audio Track
Menu. An audio field with the given audio type will
be displayed on the top left hand corner of the
screen.
button
Present/Total Title Select to choose an available
title to playback by inputting numbers.
Present/Total Chapter Select to choose an available
chapter to playback by inputting numbers.
Remainder / Elapsed Time Check remaining or
elapsed time for entire movie/disc (TITLE) or remain-
ing or elapsed time per chapter. Pressing UP or DOWN
key cycles through the different modes.
Repeat Repeats playback of current title (if disc
contains more than 1 title), Chapter, All (entire disc).
Press REPEAT repeatedly to cycle through different
options.
Repeat A_B Repeat playback specific segment.
Audio Select your desired audio setting, if available.
Subtitle Select your desired subtitle language, if it
is supported by the disc; Select OFF to hide the subtitle.
OSD Language Select your desired On_Screen
Display language.
Playback Mode Select ON to playback random or
select OFF to playback normally.
1
LANG
Off
12 3
Off
AB
Off
Off
0:00:00
TT
03/20
CH
02/28
TT
V.MODE
This can set video output to " CVBS ", " YUV ",
" P-SCAN ".
TITLE/PBC
You can locate a specific title or track using this
button.
According to some VCD discs, if PBC is ON, the
user can use the digits buttons to select track only
in the menu, if PBC is OFF, the user can select the
track by digits buttons directly.
REPEAT
During playback, press this button and select repeat
mode. You can repeat an entire disc, title or chapter.

BOOK MARK
Press BOOK MARK button during playback display
a message on screen and remind you that a bookmark
has been inserted at present position a thumbnail
will be added into the bookmark list.
Press BOOKMARK button for a few seconds to dis-
play the bookmark list.
Use UP/DOWN/LEFT/RIGHT to select the thumbnail
from the list and press
Note: the bookmarks will vanish as long as you open
the tray.
to start playing the
selected bookmarked portion of the disc.
This function can also be controlled in the INTRO
interface
16
ADVANCED PLAYBACK
VOLUME and MUTE
Press " + " at the right of VOLUME to increase
volume , " - " to decrease to volume . Press the
MUTE button to temporarily cancel the audio signal
at any time a screen will display Mute, Pressing
again will resume normal audio.
NTSC/PAL (N/P)
Pressing this button will switch between NTSC, PAL
and Auto.
QUALITY
The record quality setting determines the quality
of your recordings as well as the maximum amount
of video you can record on a disc. The higher the
quality, the less video recording time .
Press this button and select the record quality, it is
including: HQ, SP, LP, EP, SLP, SEP.
SOURCE
The video input source that will be used for the
recording: Tuner, Front AV, Rear AV, Rear SV, DV.
INTRO
Move the cursor to select an item.
PROGRAM
Press this button during playback, the program
window will display on the screen:
Title Digest
Chapter Digest
Title Interval
Chapter Interval
Exit
Select
Digest
use UP/DOWN/LEFT/RIGHT button to select the box
and input the available title and chapter by number
buttons. after that, the unit will play with program mode,
If you want to cancel this function, press STOP button.
Note: If power off or tray out, the program list will be
erased.
SUBTITLE
Subtitles are useful for viewing movies in a foreign
language or for hearing-impaired viewers.
This function can select up to 32 languages displayed
on screen.
Prev page
Input digits
0-9 ENTER OK
Clear
Next page
List Title Chapter
1
2
3
4
5
-
List Title Chapter
6
7
8
9
10
-
Play Exit
Program
--
--
--
--
--
--
--
--
--
TT: CH:
This provides a thumbnail-like summary of disc titles
(if there is more than 1 title recorded) or chapter in
both Digest and Interval modes.
Press this button, the screen display:
MENU
If available on the DVD, pressing this button to
display the Root Menu selects items according to
your preference. This menu is the first of possibly
many layers, and is therefore known as the Root
Menu.
DVD
Pressing this button will play the disc if the disc being
used supports this function.
Note: This function is invalid to DVD+R/RW disc.

SPECIAL FUNCTION PLAYBACK
17
Kodak Picture CD Playback
Playback (Normal)
When a Kodak Picture CD is inserted in the unit, an automatic slide show is launched. Each picture in the
Kodak Picture CD will be displayed consecutively in a slide-show fashion and will be scaled to fit in the whole
TV screen.
To display an image and keep it on the screen, To view the next or previous picture, press NEXT or
PREV buttons. To resume the slide show, press the button.
Image Rotation
There are four modes to rotate a picture: "Inver", "Mirror", Left", and "Right". These operations are allowed
only when a picture is being displayed normally and will be canceled automatically when a new picture is
displayed. The arrow key is used to select the different rotation modes:
Up - Invert/Normal Left - Turn left
Down - Mirror/Normal Right - Turn right
Digest
The STOP button is used to display thumbnail size pictures. After it is enabled, scaled-down thumbnail pictures
will be displayed on the screen. The NEXT and PREV buttons can be used to display the next / prev pictures
in the Kodak Picture CD.
You can select any of the displayed thumbnails by using the Arrow buttons and pressing the button.
The thumbnail will be enlarged to fit the TV screen and the slide show will start. If you desire to display an
image and keep it on the screen, To view the next or previous picture press NEXT or PREV button.
To resume the slide show press the button.
IMPORTANT NOTE: The quality of pictures displayed on the screen is highly dependent on the viewing
device (TV).
MP3 PLAYBACK
When playing a MP3 disc, a menu will be displayed automatically if the disc is loaded in successfully. In
the menu, use the UP / DOWN buttons to select a file to play. Alternatively, you can press TITLE/PBC button
and input the available file via the number buttons, then press to start playing the selected file of the disc.
Note:
MP3 files must be stored on discs with the extension
"MP3", such as "song1.mp3", otherwise the files
will not be recognized.
You can have a maximum of 250 files or folders.
DISC
- +
MP3_01
MP3_02
MP3_03
MP3_04
MP3_05
MP3_06
Preview
MP3_07
MP3_08
00:00 / 00:00
JPEG FILES
When playing JPEG disc, a navigation menu will be displayed automatically if the disc is loaded successfully.
In the menu, use UP or DOWN in the cursor to select a file, then press button, the file will be play with a
slide-show. Press PREV or NEXT to select the previous or the next picture and press PAUSE to pause the
current picture press button to return to normal playing. Press ZOOM to start zoom function. When ZOOM
is on, press F.REV and F.FWD to select different enlargement ratio, press CURSOR button to move the
enlarged picture.

18
DVD RECORDING
Recording Type
There are two ways to record on a DVD disc:
1 ) Overwrite a current recording, existing titles will
be overwritten with the new content.
Start of new recording
End of new recording
End of new recording
A) Original recording
B) New Title(D) is shorter than old Title B
C) New Title (D) is longer than old Title B
Title A Title B Title C
Title A Title D Title B Title C
Title A Title CTitle D
2) Record at the end of the disc (appending), the
new content will be written on free space.
The new title is shorter than the old (Title B).
Because the new title is shorter, a portion of the
previous title will remain on the disc. The unit will
automatically update the thumbnail and content
information of Title B as needed. Anew Title D will
be created automatically. You can use the unit edit
functions to delete Title B.
The new title is longer than the old Title B.
Because the new title is longer, part of the old Title
C will be overwritten as well. The unit will remove
Title B, create a new Title D, and update the Title
C recording time.
This unit will accept four disc types for :
DVD+RW / DVD+R / .
Recording
DVD-RW / DVD-R
DVD+R : These discs can only be written once.
Existing recordings can be hidden but not deleted.
Once a disc is finalized, no further record-
ings can be made. Although DVD + R offers less
recording flexibility than DVD + RW , the lower cost
per disc and the fact that the material can not be
erased or edited make it the best choice for large
distributions of recordings to friends or clients.
DVD+RW DVD+RW discs can be written to and
erased multiple times . Existing recordings can be
deleted and disc space regained. These discs do
not require a finalization procedure.
If the disc has never been used, the format window
will be displayed on the screen:
Select OK and press button,
If the disc has been used, please consult page 19.
Therefore, any disc space already used by a recording
cannot be regained. A recorded DVD+R disc must be
Finalized before it will be compatible with other DVD
recorders.
formatting will
start automatically:
Introduction to Recording Recording Quality
The recorder can offer five kinds of quality. Recording
time is less
if the recording quality is better. Please
consult and setup on page 23.
Quality
HQ
SP
EP
SLP
Level
High Quality 1:03:47 9.716 mbps
5.037 mbps
2.537 mbps
2:03:12
4:07:13
Standard Play
Extended Play
Recording Time MBPS Resolution
D1 resolution, MPEG-2 CBR
CBR and VBR
CBR and VBR
D1 resolution, MPEG-2
LP resolution, MPEG-2
Encoding Type
LP 3.382 mbps
3:03:21Long Play CBR and VBR
LP resolution, MPEG-2
Note: Please select the Quality required in the SETUP
menu, and press REC button at the first time to
record full disc. Pressing this REC button conti-
nuously records 30 minute intervals until the
disc is full. Recording time is an approximation
only.
Recording source
You can record to your DVD recorder from the
following sources:
TV Tuner: this unit features a built-in TV Tuner that
can be connected to a cable TV hookup or standard
antenna to record your favorite TV shows. You can
also auto-scan for available channels and add or
delete channels from the channel list.
AV Inputs(Composite/S-Video): use the Audio/Video
inputs to record from consumer electronics devices,
such as your camcorder or VCR, satellite receiver,
cable box, DVD player, etc.
To the A/V inputs- basically any video device that has
a S-Video or Composite Video output.
1.691 mbps
6:11:26
Super Long Play CBR and VBR
SLF resolution, MPEG-2
SEP 1.268 mbps
8:03:21
Super Extended Play CBR and VBR
SEP resolution, MPEG-1
Init Disc
OK Cancel
Init Disc
Auto Initializing
Please wait ...
20%
