Olmo OL-S1M Assembly instructions

Installation Instructions and Homeowner s Manual
,
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
WARNING! IF INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AFIRE OR
EXPLOSION MAYRESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY, DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
ELECTRIC FIREPLACE
MODEL NO. OL-S1M

Table Of Contents
IMPORTANT: Read all instructions and warnings carefully before starting installation.
Failure to follow these instructions may result in a possible electric shock,
fire hazard and will void the guarantee.
Thank you and congratulations on your purchase of
a OLMO fireplace.
1
Installation Instructions
Locating Your Fireplace
Hearth
Electrical Specifications
Electrical Connection
Service Instructions
Maintenance of Motors
Replacing the Light Bulbs
Operating Instruction
Manual Operation
Remote Control Operation
Guarantee
Assembling Instruction
2
3
3
3
5
6
7
7
4
4
Glass Information
4
Measure
3
General
7

Hot air extra
Power/Flame switch
0.9kw output
1.8kw output
,
678mm
275mm
26.69
10.83
,
745mm
29.33
,
Measure
2

3
Installation Instructions
General
1. Read all instructions before using the appliance.
2. This appliance is hot when in use. Toavoid
burns, do not let bare skin touch hot surfaces. If
provided, use handles when moving this appliance.
Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at
least 3 feet (1m.) from the front of this appliance.
3. CAUTION: Extreme caution is necessary when
any heater is used by or near children or inva-
lids and whenever the heater is left operating
unattended.
4. If possible, always unplug this appliance when not
in use.
5. Do not operate any heater with a damaged cord or
plug or after the appliance malfunctions, has been
dropped or damaged in any manner.
6. Any repairs to this fireplace should be carried out by
a qualified service person.
7. Under no circumstances should this fireplace be
modified. Parts having to be removed for servicing
must be replaced prior to operating this fireplace
again.
8. Do not use outdoors.
9. This heater is not intended for use in bathrooms,
laundry areas and similar indoor locations. Never
locate this appliance where it may fall into a bathtub
or other water container.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runners or the like. Arrange cord
away from traffic areas and where it will not be
tripped over.
11. To disconnect this appliance, turn controls to the
off position, then remove plug from outlet.
12. Connect to properly grounded outlets only.
13. This appliance, when installed must be electrically
grounded in accordance with local codes.
14. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause
an electric shock, fire, or damage the appliance.
15. To prevent possible fire, do not block air intakes or
exhaust in any manner. Do not use on soft surfaces,
like a bed, where openings may become blocked.
Voltage
Total Amps
Total Watts
Heater Ratings
220VAC/50Hz
8.70Amps
2000Watts
1800Watts
16. This appliance has hot and arcing or sparking parts
inside. Do not use it in areas where gasoline, paint,
or flammable liquids are used or stored. This
fireplace should not be used as drying rack for
clothing, nor should Christmas stockings or
decorations be hung on or near it.
17. Use this appliance only as described in this
manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or
injury to persons.
18. Avoid the use of an extension cord because the
extension cord may overheat and cause a risk of
fire. However, if you have to use an extension cord,
the cord shall be NO. 14AWG minimum size and
rated not less than 2000 Watts. The extension cord
must be three wire cord with grounding type plug
and cord connector. The extension cord shall not be
more than 20 feet in length.
19. SAVE THESE INSTRUCTIONS.
Your new electric fireplace may be installed virtually
anywhere in your home. However, when choosing a
location for your new fireplace, ensure that the general
instructions are followed. Also, for best effect, install
the fireplace out of direct sunlight.
Locating Your Fireplace
Hearth
A hearth is not mandatory but it is recommended for
aesthetic purposes. We recommend a non-combustible
hearth which does not obstruct heater openings.
Electrical Specifications

A 10 AMP,220 Volt, 50 Hz circuit with a properly
grounded outlet is required. Preferably, the fireplace
will be on a dedicated circuit as other appliances on
the same circuit may cause the circuit breaker to trip or
the fuse to blow when the heater is in operation.
The unit comes standard with a three wire cord, exiting
from the rear of the fireplace. Plan the installation to
avoid the use of an extension cord. If an extension cord
must be used, it must be a minimum 14AWG, three wire
with grounding type plug connector and rated not less
than 1875 Watts. The extension cord shall not be more
than 20 feet in length.
WARNING: Electrical outlet wiring
must comply with local building codes
and other applicable regulations to
reduce the risk of fire, electrical shock
and injury to persons.
WARNING: Do not use this fireplace if
any part of it has been under water.
Immediately call a qualified service
technician to inspect the fireplace and
replace any part of the electrical system.
WARNING: This fireplace comes with
an ES. In case the fireplace is not
operating disconnect the power and reset
the ES. If the fireplace is still not
operating immediately call a qualified
service technician to inspect the
fireplace.
Service Instructions
WARNING: Disconnect power before
attempting any maintenance or cleaning
to reduce the risk of fire, electrical shock
or personal injury.
Maintenance of Motors
The motors used on the fan and the flame generator
assembly are prelubricated for extended bearing life
and require no further lubrication. However, periodic
cleaning/vacuuming of the fan/heater unit is recom-
mended.
WARNING: Make sure that the power is
turned off before proceeding.
Replacing the Light Bulbs
4
1.Under no circumstances should this product be
operated with missing or broken glass.
2.Do not strike or slam the glass.
3.Do not use abrasive cleaners to clean the glass.
4.This product uses tempered glass. Replacement
should be carried out by a qualified service person.
Glass information
Electrical Connection

Replacing the Light Bulbs
This fireplace uses one or two clear 220Volt, 60 Watt,
E-14 socket base light bulbs (small base, chandelier
candle type). The 60 Watt bulbs are located under the
log set/ember bed.
WARNING: Do not exceed 60 watts per
bulb for lights beneath the ember bed.
Use of higher rated bulbs may result in
a fire, causing property damage or
personal injury.
5
Bulb
Fig 1
Fig 2
1. Turn off the power switch and unplug the power cord.
2. Let fireplace cool if it has been operation.
3. Remove the screws securing the ember bed positi
-onin the front of the ember.(see fig 1).
4.Lift ember bed and take it off.(see fig 2)
5.Replace the bulb.(see fig 2)
6.Reinstall the ember bed, the glass and the frame.
Ember bed

Assembling Instruction
6
Item #
01
02
03
04
05
06
07
08
09
10
11
12
13
14
Mantel
Ribbon Bracket
Backing Strip
Screen Bracket
Acrylic Screen
Heater Fan
Heating Element
Cast Iron Block
Remote Receiver
Ember Bed
Bottom
Bulb/Holder
Flame Fan
Part Description
Bulb Bracket
Wiring Loom
Wire
Background Sheet
Terminal Block
Cable Clamp
Swing Apparatus
Power Switch
Item #
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Part Description
0202
0101
0303 0606
0505 0707
0808
1010
1414
1111
1212
1313
1515
1717
1616
//
2/22/2
1/21/2
1818
2020
1919
2222
2121
0909
Part #
3004231
1002080
1002070
3004240
1002090
1002250
5006310
1002111
1002112
Heating Switches
Part #
3004124
3004133
3004143
3004275
1002106
3004167
3004220
1002050
3004206
3004516
1002030
1002012
1002260
2323
10
04
Screw 3004144

Operating Instruction
Manual Operation
Fig6
The power switch is the right one of the three switches.
The downside of the power switch is for hand control
and flame on, and the upside for remote control. While
either side of the power switch is pushed, the power is
turned off.
The middle switch is for first heater on with the totally
0.9KW.
The left switch is for second heater on with totally 1.8KW.
Before turn it on , the middle switch must be pushed.
While all upside of the three switches are pushed, the
way of control is changed to remote control.
Remote Control Operation
WARNING: During any service of this appliance, the power to the unit must be turned off. It is not
just accept to use the power switch to meet the requirement.
We provide a twelvemonth guarantee in the respect of the electric fires ranges.
Be sure to keep your purchase receipt.
The twelvemonth guarantee applies to:
1 The 'product' has been purchased from the retailer authorized by the manufacturer and in respect of
2 The initial installation; and in favour of
3 The original purchase
The twelvemonth guarantee does not apply to
1 Damage or inferior workmanship practices while the 'product' is being installed
2 Damage caused by the misuse of the 'product' or where normal standards of care and use have not been
complied with the instruction
3 Damage or defects due to ,misuse, accident or unauthorized alterations.
During the twelve month after the 'product' has been supplied, the guarantee covers the making good(whether
by repair or replacement at the company's option )of defects arising from defective manufacture of 'product' .
On inquiring service contact the retailer who supplied your product and will assist and advise you as necessary.
Guarantee
7
Power switch
First heater on with totally 0.9kw
Second heater on with totally 1.8kw
There are three switches located at the right-hand
downside of the fireplace.
Fig7
Begin remote controlafter all upsideof the three
switches are pushed. See Fig7.
The remote receiver is behind the screen. Aim at the
center of thescreen when presskeys on the remote
controller.
On/Flame Effect
This button willturn on thepower and flame.
Heating
Low
This button willturn on thefirst heater.
High
This button willturn on thesecond heater.
On/Flame Effect
Heating
All upside are pushed.
Off
This button willturn off the power.
Off
