Olsson The FUZZTNER User manual

This product is manufactured by
OLSSON AMPS
www.olssonamps.com
Notes:
The FUZZTNER is protected against wrong DC eliminator
polarity.
Olsson Amplication pedals carry 2 years limited
warranty.
Olsson Amplication The FUZZTNER
ELECTRICAL SPECIFICATION:
• Current consumption 5 mA
• Voltage range 9V to 12V
• Input impedance 600K ohms
• Output drive capability 10K ohms
• Power requirement supplied via 2.1 mm DC socket
• Input and output connections via 1/4” phone jack
• True bypass
Power requirements:
6F22 9V battery or DC eliminator 2.1 mm plug centre
negative and positive sleeve.

Congratulations on your purchase of
The FUZZTNER
The FUZZTNER is an amazing combination of
a great octavia fuzz and an extraordinary great
sounding fuzz with two modes, normal and gated.
It has been developed in collaboration with
Staffan Astner who is one of Sweden’s most well-
respected guitar wizards. With FUZZTNER you
can create unique sounds and it’s so fun to play
that you will never stop.
A few things to think about when you use it in
Octavia mode. First, to get the most octavia
effect, use the neck pickup and also turn the tone
control of your guitar down a bit. Second, do not
set the Fuzz control to high, around twelve o’clock
is a good start. Also notice that the octaves will be
heard mostly on higher notes and that’s perfectly
normal. Another tip is to play different two note
intervals in a staccato manner. This will create a
lot of different sub notes and depending on the
interval you will have the craziest sounds. Also
try different playing techniques and you will be
amazed what you can achieve.
Welcome to the Olsson Amplication family!
OLSSON AMPS - THE FUZZTNER - USER’S GUIDE
Starting up The FUZZTNER
Important notice:
When you power up the pedal it takes from 10-30
seconds before it has been ”warmed up”. If you
run it on battery, insert a guitar cable into the input
jack to power up the pedal. With an adapter, its
powered up as soon as the adapter is connected.
Before it has warmed up there is no or very odd
sound when you play.
Controls:
FUZZ: Adjust the amount of Fuzz.
LEVEL: The output level from the pedal
TONE: Adjusts the tone. About at at 12 o’clock
SWITCH O/F: Switches between Octavia mode
(O) and normal Fuzz mode (F).
SWITCH N/G: Toggles between Normal Fuzz
mode (N) and Gated Fuzz Mode (G). This Switch
is just working in Fuzz mode.
