Olympus OEV261H User manual

INSTRUCTIONS
HIGH DEFINITION LCD MONITOR
OEV261H

Contents
i
High definition LCD monitor OEV261H
Contents
Labels and Symbols ..................................................................... 1
Important Information — Please Read Before Use.................... 3
Intended use ............................................................................................ 3
Instruction manual .................................................................................... 3
Instrument compatibility ........................................................................... 4
Repair and modification ........................................................................... 4
Signal words.............................................................................................. 5
Dangers, warnings and cautions .............................................................. 5
Outline....................................................................................................... 12
Chapter 1 Checking the Package Contents............................ 13
Chapter 2 Controls and Their Functions ................................ 14
2.1 Video monitor unit ........................................................................... 14
2.2 Front panel...................................................................................... 15
2.3 Rear panel ...................................................................................... 17
2.4 AC adapter...................................................................................... 19
Chapter 3 Installation and Connection ................................... 20
3.1 Installing the monitor....................................................................... 21
3.2 Installing the AC adapter................................................................. 23
3.3 Connection to an AC mains power supply ...................................... 24
Chapter 4 Inspection and Setup Before Use .......................... 26
4.1 Power supply .................................................................................. 26
4.2 Inspection of the displayed image................................................... 27
Chapter 5 Screen Menu and Operation of Front Panel.......... 28
5.1 PRESET button............................................................................... 28
5.2 INPUT button .................................................................................. 35
5.3 MENU button .................................................................................. 36
5.4 PIP button ....................................................................................... 38
5.5 POP button ..................................................................................... 39
5.6 SCAN button ................................................................................... 40
5.7 FUNCTION buttons (F1, F2/ENTER).............................................. 40
5.8 Status display.................................................................................. 41

Contents
ii High definition LCD monitor OEV261H
Chapter 6 Submenu Operations .............................................. 44
6.1 INPUT CONFIG .............................................................................. 44
6.2 COMP. ............................................................................................ 46
6.3 VIDEO CONFIG .............................................................................. 48
6.4 WHITE BALANCE........................................................................... 49
6.5 VIDEO INPUT ................................................................................. 51
6.6 SYSTEM CONFIG .......................................................................... 62
6.7 FUNCTION...................................................................................... 64
6.8 WINDOW CONFIG ......................................................................... 66
6.9 REMOTE CONFIG.......................................................................... 71
6.10 CONTROL ...................................................................................... 73
Chapter 7 REMOTE Specifications.......................................... 75
7.1 GPI terminals .................................................................................. 75
Chapter 8 Care, Storage, and Disposal ................................... 78
8.1 Care ................................................................................................ 78
8.2 Storage ........................................................................................... 79
8.3 Disposal .......................................................................................... 79
Chapter 9 Inspections............................................................... 80
Chapter 10 Troubleshooting ...................................................... 81
10.1 Troubleshooting guide .................................................................... 81
10.2 Returning the monitor for repair ...................................................... 83
Appendix........................................................................................ 84
System chart ............................................................................................ 84
Transportation, storage, and operation environment/specifications.......... 90
EMC information........................................................................................ 94
Maintenance .................................................................................. 98

Labels and Symbols
1
High definition LCD monitor OEV261H
Labels and Symbols
Safety-related labels and symbols are attached to the instrument at the locations
shown below. If labels or symbols are missing or illegible, contact Olympus.
High definition LCD monitor
Serial number
Potential equalization
terminal
Electrical rating

2
Labels and Symbols
High definition LCD monitor OEV261H
AC adapter
Serial number
Electrical rating
The rating plate of the AC adapter is
on the underside of the adapter.

Important Information — Please Read Before Use
3
High definition LCD monitor OEV261H
Important Information — Please Read
Before Use
Intended use
This instrument has been designed to be used with Olympus endoscopes, light
source, video system center, camera control units and endoscopic ultrasound
centers for endoscopic diagnosis and video observation.
Do not use this instrument for any purpose other than its intended use.
Instruction manual
This instruction manual contains essential information on using this instrument
safely and effectively. Before use, thoroughly review this manual and the
manuals of all equipment that will be used during the procedure and use the
equipment as instructed.
Keep this and all related instruction manuals in a safe, accessible location. If you
have any questions or comments about any information in this manual, please
contact Olympus.
Terms used in this manual
Video system center:
The video system center is a device that converts signals from a
videoscope or video converter into monitor images.
Camera control unit:
The camera control unit is a device that converts signals from a fiberscope
or rigid endoscope into monitor images.
Ultrasound center:
The ultrasound center converts the ultrasonic signals from an ultrasonic
endoscope or probe into monitor images.
Light source:
The light source provides light and electrical signals to the endoscope.
Wall mains socket outlet:
An electrical outlet that has a terminal used exclusively for grounding.

4
Important Information — Please Read Before Use
High definition LCD monitor OEV261H
Instrument compatibility
Refer to the “System chart” in the Appendix to confirm that this instrument is
compatible with the ancillary equipment being used. Using incompatible
equipment can result in patient or operator injury and/or equipment damage. It
may also impair the functionality of the instrument.
This instrument complies with medical electrical equipment edition 2
(IEC 60601-1-2: 2007). However when connecting with an instrument that
complies with medical electrical equipment edition 1 (IEC 60601-1-2: 1993), the
whole system complies with edition 1. (See, “EMC information” on page 94 for
EMC compliance level.)
Repair and modification
This instrument does not contain any user-serviceable parts. Do not
disassemble, modify or attempt to repair it; patient or operator injury and/or
equipment damage can result.
Some problems that appear to be malfunctions may be correctable by referring
to Chapter 10, “Troubleshooting”. If the problem cannot be resolved using the
information, contact Olympus.
Aspect ratio:
It is a unit that expresses a rate of a screen side and a vertical length.
The aspect ratio of 4:3 is used usually for SDTV.
The aspect ratio of 16:9 is used usually for HDTV.
VESA mounting standards:
These are the standards to be applied when mounting an LCD panel on a
monitor mount or stand. These standards were defined by the Video
Electronics Standards Association (VESA), a US-based organization
concerned with computer display devices.
Mobile workstation:
The mobile workstation is a special trolley on which this monitor is placed.
PIP (Picture in Picture)
The sub display is put in the main display.
POP (Picture out Picture)
The sub display by the side of the main display.

Important Information — Please Read Before Use
5
High definition LCD monitor OEV261H
Signal words
The following signal words are used throughout this manual:
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also
be used to alert against unsafe practices or potential
equipment damage.
Indicates additional helpful information.
Dangers, warnings and cautions
• Strictly observe the following precautions. Failure to do so
may place the patient and medical personnel in danger of an
electric shock:
−Keep fluids away from all electrical equipment. If fluids are
spilled on or into the monitor, immediately stop operating
it and contact Olympus.
−Do not prepare, inspect or use this instrument with wet
hands.
• Never install and operate this instrument in locations where:
−The concentration of oxygen is high.
−Oxidizing agents (such as nitrous oxide (N2O)) are
present in the atmosphere.
−Flammable anesthetics are present in the atmosphere.
Otherwise, explosion or fire may result because this monitor
is not explosion-proof.

6
Important Information — Please Read Before Use
High definition LCD monitor OEV261H
• To reduce the risk of fire or shock hazard, do not expose this
equipment to rain or moisture.
• To reduce the risk of fire or shock hazard, keep this
equipment away from all liquids. Use and store only in
locations which are not exposed to the risk of dripping or
splashing liquids, and do not place any liquid containers on
top of the equipment.
• Do not use this instrument beyond the rated outlets and
wiring, otherwise it may result in fire or an electrical shock.
• Always power the monitor with the voltage specified in this
manual. Supplying a nonspecified voltage to the monitor may
result in fire or an electric shock.
• This product has a fluorescent lamp that contains a small
amount of mercury. It also contains lead in some
components. Disposal of these materials may be regulated in
your community due to environmental considerations. For
disposal or recycling information, please contact your local
authorities or the Electronics Industries Alliance.
• Strictly observe the following precautions for the power cord.
Damaging the power cord may result in fire or an electric
shock:
−When placing the power cord, take care that it is not
crushed in the space between the monitor and a wall,
mobile workstation or a shelf.
−Do not modify or damage the power cord.
−Do not stretch or place a heavy object on the power cord.
−Do not place the power cord near heating equipment or
expose it to excessive heat.
−Always grasp and pull the plug when unplugging the
power cord. Do not pull on the cord itself.
• Be sure to use the supplied AC adapter. Do not use the
supplied AC adapter for powering other devices. The
equipment may fail or the power cord may burn.
• If an irregularity is suspected during use of the instrument,
stop operation of the monitor. Some problems may be
correctable by referring to the following procedure. Damage
or irregularity in the instrument may compromise patient or
operator safety and may result in more severe equipment
damage.

Important Information — Please Read Before Use
7
High definition LCD monitor OEV261H
−In case of a loss of the endoscopic image or a frozen
image:
Turn off the monitor, and turn on it again after 10 seconds.
Also turn off the ancillary equipment to be used in
combination with this monitor and turn on it again, as
described in the instruction manuals for the equipment. If
the problem cannot be resolved by the described remedial
action, stop using the monitor and gently withdraw the
videoscope, fiberscope, rigid endoscope or ultrasonic
endoscope from the patient’s body as indicated in the
endoscope’s instruction manual.
−In case other abnormalities:
Immediately stop operation of the monitor, withdraw the
videoscope, fiberscope, rigid endoscope or ultrasonic
endoscope from the patient as indicated in the
endoscope’s manual, and take remedial action as
described in Chapter 10, “Troubleshooting”. If the problem
cannot be resolved by the described remedial action, be
sure to contact Olympus for repair as described in Section
10.2, “Returning the monitor for repair” on page 83.
• When installing this instrument on the mobile workstation or a
trolley with a clamping table, be sure to provide the mobile
workstation or trolley with a toppling/movement prevention
measure. If such a measure is not taken, the mobile
workstation or trolley could move or fall during the procedure,
which could cause patient and/or operator injury.
• Before using high-frequency electrosurgical equipment,
make sure that any signal noise emitted from the equipment
does not affect the observation of the surgical procedures. If
high-frequency electrosurgical equipment is used without
such confirmation, patient injury may result.
• To prepare for unexpected equipment failure, be sure to
prepare spare equipment.
• It is recommended that only Olympus high-frequency
electrosurgical equipment be used with this unit.
Non-Olympus equipment can cause interference on the
monitor display or a loss of the endoscopic image.
• Always establish the system with equipment that complies
with relevant EMC standards for safety reasons. Equipment
which does not comply with EMC standards may cause
interference and its function or performance may be affected.

8
Important Information — Please Read Before Use
High definition LCD monitor OEV261H
• To protect its components from excessive heat, the monitor
will turn itself OFF if its internal temperature rises to a level at
which equipment damage could occur. If this happens during
the procedure, immediately stop the examination and gently
withdraw the videoscope, fiberscope, rigid endoscope or
ultrasonic endoscope from the patient as indicated in the
endoscope’s instruction manual, and contact Olympus.
• Always use the power cord and connection cables that were
shipped with the monitor or mobile workstation. Using other
power cords or connection cables may result in an electric
shock or malfunction.
• Always use the monitor cables designated in this instruction
manual. Using non-designated monitor cables may result in
production of monitor noise at a level that may affect the
observation and treatment or loss of observation image.
• This apparatus must be grounded. To ensure safe operation,
the three-pin plug must be inserted only into a standard
three-pin power outlet which is effectively grounded through
normal household wiring.
• Extension cords used with the equipment must be three-core
and be correctly wired to provide connection to the ground.
Incorrectly wired extension cords can be extremely
hazardous.
• The fact that the equipment operates satisfactorily does not
imply that it is grounded, and the installation is not necessary
safe. For your safety, if in any doubt about the effective
grounding of the equipment or power outlet, please consult a
qualified electrician.
• Do not place the AC adapter in area accessible to the
patients. Ensure the patients cannot touch the device, as it
can reach high temperature under continuous use.
• In order to maintain adequate ventilation, do not install or
place this unit in a bookcase, built-in cabinet or any other
confined space. To prevent risk of electric shock or fire
hazard due to overheating, ensure that curtains and any
other materials do not obstruct the ventilation.
• When installing the instrument, reserve a space of 10 cm or
larger between the instrument and any walls or other
equipment. Lack of such a space will interfere with the
monitor’s internal cooling and may lead to malfunction or
equipment damage.

Important Information — Please Read Before Use
9
High definition LCD monitor OEV261H
• This product has a fluorescent lamp that contains mercury.
Disposal may be regulated in your community due to
environmental considerations. For disposal or recycling
information, please contact your local authorities.
• Be sure that this instrument is not used adjacent to or
stacked with other equipment (other than the components of
this instrument or system) to avoid electromagnetic
interference.
• Electromagnetic interference may occur on this instrument
near equipment marked with the following symbol or other
portable and mobile RF (Radio Frequency) communications
equipment such as cellular phones. If electromagnetic
interference occurs, mitigation measures may be necessary,
such as reorienting or relocating this instrument, or shielding
the location.
• Do not install the instrument in a place exposed to direct
sunlight, high temperature (more than 60°C). Otherwise, it
may damage the cabinet or internal parts, result in fire.
• Be sure to plug the power cord securely, otherwise it may
result in fire and an electric shock.
• Unplug the power cord if the monitor is not used for a long
time. Otherwise, it may result in fire.
• Remove the dust on the plug of the power cord regularly,
otherwise it may result in fire and an electric shock.
• Be sure to turn the monitor OFF and unplug the power cord
before proceeding to maintain the monitor. If the power cord
is left plugged in, an electric shock may result.
• Check the installation at least once a year. An improper
installation could cause the monitor to fall off resulting in
personal injury.
• To reduce the risk of fire or shock hazard and annoying
interference, use the recommended accessories only.
• Attach this instrument to the wall by professional company
only. Otherwise, this instrument may fall due to improper
attachment, injury may result.
• Remove the wall-hanging bracket when not used. Otherwise
people moving in the vicinity of the monitor could get caught
on the bracket and be injured.

10
Important Information — Please Read Before Use
High definition LCD monitor OEV261H
• When installing this instrument, be sure to attach it securely
to the monitor mount. Otherwise, the instrument may fall.
This may cause patient and/or operator injury and may
damage the instrument.
• Do not move the monitor while the power cord and
connection cables are connected. Otherwise, damage to the
monitor, power cord and connection cables, fire or an electric
shock may result.
• When installing or using the monitor, take care not to strike
against a corner of the monitor. Otherwise, injury may result.
• Install this instrument in a stable location. Otherwise, the
instrument may fall. This may cause operator injury and may
damage the instrument.
• Do not try to lift the monitor by grabbing the panel.
• Do not expose the LCD panel to heavy pressure or pressure
from pointed objects. Take care especially during
transportation. Exposing the LCD panel to heavy pressure
may result in blurring or other damage.
• This monitor is intended for use in an electromagnetic
environment specified in “EMC information” on page 94.
• Exposing the LCD screen to intense light sources will impair
its characteristics and lower image quality.
• The mains plug of the power supply cord shall remain readily
operable. The AC receptacle (mains socket outlet) shall be
installed near the equipment and shall be easily accessible.
• To completely disconnect this equipment from the power AC
mains, disconnect the power cord plug from the AC
receptacle.
• In an environment exposed to drastic temperature
fluctuations, condensation may build up on inside the LCD
screen. This may lower the quality of the screen and may
damage it.
WRONG

Important Information — Please Read Before Use
11
High definition LCD monitor OEV261H
• The LCD screen is manufactured to precise specifications.
Although over 99.99% of the pixels function normally, 0.01%
of the pixels are either missing or constantly lit (red, blue or
green). This is normal and not a cause for concern.
• The liquid crystal protection panel is a specially
manufactured component. Wiping it with a hard cloth, or
rubbing it vigorously will scratch the surface.
• If a still image is displayed for an extended period of time, it
may generate a temporary afterimage (phosphor burn-in).
(However, such images can be removed by displaying
normal video for awhile.)
• The response speed and brightness of liquid crystal varies
with ambient temperatures.
• Some video images may appear blurred on the screen.
• Leaving the unit in a location exposed to high temperature
and humidity for an extended period of time may damage the
LCD screen and cause blurring.
• This monitor may become hot after an extended period of
operation, but this does not indicate a malfunction.
• High-frequency electrosurgical equipment can cause slight
interference on the monitor display.

12
Important Information — Please Read Before Use
High definition LCD monitor OEV261H
Outline
The 26 inch OEV261H LCD display panel has been designed for use as a
medical monitor. The OEV261H is an LCD monitor designed to be used with
Olympus endoscopes, light sources, video system centers, camera control units
and ultrasound centers. Do not use the monitor for any other purpose.
Designed for medical applications
• Complies with IEC 60601-1 (Ed.2 and 3) and IEC 60601-1-2 (Ed.3)
• Sheet switches and the protective screen panel have been specifically
designed for use in the medical field.
WUXGA (1920 × 1200 pixels) high-resolution IPS LCD panel
10-bit 3DLUT (look-up-table) for accurate color reproduction
10-bit signal processing for smooth color transitions
Instant output of input signals
• The OEV261H incorporates a function that eliminates time delay of field
units caused by IP conversion minimizing delays between input and
image display.
Supports multiple formats
• Capable of handling SDI (both HD and SD), VIDEO, Y/C, YPBPR/RGB
and DVI-D video input signals.
• Supports both NTSC and PAL TV systems.
• It supports computer (COMP) input signals such as analog signal input
via RGB and HD15 terminals as well as digital signal input via DVI-D
terminal.
A host functions
• PIP (Picture in Picture) and POP (Picture out Picture) dual screen display
functions
• ENDOSCOPE, 1.8,1.95, 2.0, 2.2, 2.4, 2.6, and PACS gamma
• Upside-down (180° rotation) and reverse (flip horizontal) functions
• GPI and RS-232C external control functions

Chapter 1 Checking the Package Contents
13
High definition LCD monitor OEV261H
Chapter 1 Checking the Package
Contents
Match all items in the package with the components shown below. Inspect each
item for damage. If the instrument is damaged, a component is missing or, you
have any questions, do not use the monitor; immediately contact Olympus.
High definition LCD monitor
(OEV261H)
AC adapter Power cord
Power cord hook DC cord
Screw (for securing power cord)
1pcs
Screw (for attaching LCD arm)
6pcs Instruction manual

14
Chapter 2 Controls and Their Functions
High definition LCD monitor OEV261H
Chapter 2 Controls and Their Functions
2.1 Video monitor unit
Front
Rear
Tally
Rear panel (page 17)
Front panel (page 15)
Tally lamp
When a LCD panel backlight or inverter circuit is malfunctioning, the lamp flashes orange.

Chapter 2 Controls and Their Functions
15
High definition LCD monitor OEV261H
2.2 Front panel
POWER switch (the POWER switch is located at the bottom)
This switch turns the power On and Off.
POWER LED
When the power goes On, the LED (green) lights.
PRESET button ( )
Previously recorded input settings and image quality settings can be
selected from PRESET (10 settings), USER (20 settings) and FACTORY
(one setting).
INPUT button ( )
Selects the input terminal for PORT A and PORT B signals. Two images
displayed in PIP or POP are called PORT A and PORT B in this manual.
∗Operates only when the AC POWER switch on the AC adapter is set to
On and the AC adapter operates.
PRESET : Settings made at the factory
USER : Settings saved by the user in the SYSTEM CONFIG
menu.
FACTORY : Factory default settings
POWER switch
Turns the power off.
Turns the power on.

16
Chapter 2 Controls and Their Functions
High definition LCD monitor OEV261H
MENU ( ), PIP ( ), POP ( ), SCAN ( ), F1 ( ), F2/ENTER ( )
button
Use these buttons to display menus, select and adjust settings and confirm
menu selections.
The buttons are made of plastic film. Do not use pointed
objects such as fingernails, pens or screwdrivers to press the
buttons, as the resulting damage or deformation could
prevent proper contact.
MENU : Displays and exit menus.
PIP : Switches from the normal screen, dual PIP screen and
PIP mode. When a menu is open, it moves the cursor to
the left and selects items.
POP : Switches from the normal display to the dual POP screen
and to POP mode. When a menu is open, it moves the
cursor to the right and selects items.
SCAN : Magnifies the single screen display and the large screen
in PIP mode. When a menu is open, it moves the cursor
downwards and selects items.
F1 : Executes (confirms) items assigned to FUNCTION1 in a
menu. When a menu is open, it moves the cursor
upwards and selects items.
F2/ENTER : Executes (confirms) items assigned to FUNCTION2 in a
menu. Press to confirm settings in a menu or to go to a
submenu.
