QUICK GUIDE E-M1X
E-M1X
QUICK GUIDE

2
QUICK GUIDE E-M1X
Preface
This Quick Guide provides an quick introductory overview of the E-M1X. For detailed information and instructions on using
your Olympus camera, lens and ash, please see the respective user manuals, which can be found on the support pages
of the Olympus website.To accompany your adventures in photography, Olympus has created MyOLYMPUS featuring
a great mix of technical, community and educational content – all for free.
my.olympus-consumer.com
1. Overview 3
Frontside, Backside 3
Topview, Sideview Right 4
Sideview Left 5
2. Handling 6
3. Super Control Panel 7
4. Custom Modes / B Mode 8
C1, C2 8
C3, C4, B 9
5. Autofocus 10
6. PRO Lenses / Flashes 11
7. PRO Service 12

3
QUICK GUIDE E-M1X
Overview
Frontside
Shutter
Shutter
Menu
Erase
Charge Lamps
Card Select
Speaker
White Balance Lock Lever
On/O Lever
Live View
Diopter Adjustment Dial
FN Button / Lever
Depth of eld Preview
One Touch
White Balance
Front Dial
Backside
Hot Shoe (Flash / Audio Devices)
External Flash Terminal
Lens Release
DC Connector
Front Dial
Rear Dial
AEL/AFL
AEL/AFL
Rear Dial
Multi Selector
Arrow Pad / OK
Card Access Lamp
Playback
Multi Selector
Info
AF auxiliary light / Self Timer Lamp

4
QUICK GUIDE E-M1X
Topview
UHS-II Compatible
Dual Card Slots
Sideview Right
Shutter
Exposure
Compensation
Mode Dial Lock
Hot Shoe (Flash / Audio Devices)
Mode Dial
ISO
Movie
BKT
ON / OFF Lever
AF
Flash
Sequential Shooting
Self-Timer
Stereo Microphone
ISO
Exposure Compension
Card Compartment Cover Lock
Remote Cable Terminal

5
QUICK GUIDE E-M1X
Dual Battery
Battery Compartment Lock Battery Charge Lamps
Microphone Jack
Headphone Jack
HDMI Connector
USB Connector Type C
Sideview Left
The E-M1X can be used with two batteries simultaneously or with a single battery. The USB charging time with power
delivery is 2 hours for both batteries. If there is at least one battery in the camera, it is also possible to supply the camera
with power via a powerbank. The battery cartridge makes it easy to swap out the battery without removing your monopod
or tripod. With closed cover all connections are IPX1 weather resistant – even when a cable is connected to the remote
cable, microphone jack or headphone jack.

6
QUICK GUIDE E-M1X
Handling
The same button
layout horizontally
and vertically
600mm equivalent
M.Zuiko Digital ED 300mm F4.0 IS PRO
Ergonomics
The E-M1X is built for comfort. It starts with an integrated
vertical grip featuring a deep nger rest that feels secure
and comfortable in your hand. Buttons and controls are
strategically placed for both vertical and horizontal
shooting - use the same nger motion to nd the controls
no matter how you hold the camera.
Button Layout
The button layouts are the same in horizontal and vertical
position. This allows the photographer to rely on their
muscle memory and reduces the chance of mistakes.
Portability
Unrivaled portability that can only be realized with the compact and lightweight Micro Four Thirds System. In comparison
with 35 mm cameras the equivalent lenses are even smaller and lighter. This offers you the possibility of handheld shooting
even with tele lenses and allows photographers to take advantage of the mobility of the system.

7
QUICK GUIDE E-M1X
ISO Sensitivity
White Balance
Autofocus FIield
Selection
OK BUTTON
LIVE VIEW
(switch to static SCP)
Image Stabilisation Photo
Image Stabilisation Video
Picture Settings
Button function assignment
Highlight & Shadow Control
Storage Options
Shooting Modes
Metering Mode
Aspect ratio
Movie Image Quality
Sequential Shooting/Self-Timer
(drive Mode)
Face Priority
File Format / Size
Super Control Panel
All shooting options can be accessed via the Super Control Panel (SCP). It enables a quick and comfortable way to get
an overview of all settings and an easy way to adjust them. You activate the SCP as an overlay by pressing the OK Button.
If you shoot with viewnder you can display the SCP at all time by pressing the Live View Button. That allows you to take
easily control over all your camera settings. The touchscreen makes the operation easy, quick and compfortable.

8
QUICK GUIDE E-M1X
Modes
Mode C1-C4 are memory slots which give you quick and easy access to
your individual settings. They can be customized to your needs.
Here are some examples how you can programme the C1-C4 modes.
C1 // Moving subject AF
Don‘t miss a single snapshot! Whether you are facing a lion hunt or a herd of
elephants from your viewpoint, this mode keeps fast-moving subjects in focus.
C2 // Pro Capture Mode
Pro Capture starts shooting the moment you press the shutter release
button down halfway, with a buer that can be set to capture up to 35
frames in full resolution. This way you get the exact moment you want
to capture without any lag.
Shooting mode P
Image quality mode LSF + RAW
AF mode C-AF
AF target ALL
AF target display ON2 (Cluster display)
Drive mode Sequential L
Frame rate (EVF) High speed
AF targeting pad ON
Line display Three-way split composition
Display color (line display) White
Shooting mode P
Image quality mode LSF + RAW
AF mode S-AF
AF target 5-point cross pattern
AF target display ON1
Drive mode Pro Cap H
Frame rate (EVF) High speed
AF targeting pad ON
Line display Reticle
Display color (line display) White

9
QUICK GUIDE E-M1X
C3 // Low-light AF
Do you prefer to take pictures in the evening? With this mode you achieve
optimal results, capturing subjects even in dimly-lit scenes.
C4 // Handheld High Res
In case you need highest possible resolution for landscape photography
you can use the Hand Held HighRes mode.
B Mode
The B Mode gives a quick and easy access to the „Live Modes“:
The camera shows you how the images develops and you can
stop exposure as soon as it is well exposed.
„Live Composite“ only adds composites of the sections
with changes in brightness.
„Live Bulb“ keeps the shutter open while the shutter
release button is pressed.
„Live Time“ opens the shutter on the rst push and closes
it on the second push of the shutter release button.
Shooting mode P
Image quality mode LSF + RAW
AF mode S-AF
AF target 1-point
AF target display ON1
Drive mode Sequential H
Frame rate (EVF) High speed
AF targeting pad ON
Line display Three-way split composition
Display color (line display) White
Shooting mode A
Image quality mode LSF + RAW
AF mode Single AF
AF target ALL
AF target display ON1
Drive mode Handheld High Res mode
AF targeting pad ON
Line display Three-way split composition
Display color (line display) White
Live Composite

10
QUICK GUIDE E-M1X
Autofocus
Re-Developed AF
Gain complete freedom over the composition and capture
subjects steadily with the 121-point all cross-type on-chip
phase detection AF sensor. On-chip phase detection AF has
no light ux limitations delivering high-precision AF.
Fully Customizable AF
AF customization makes it possible to individually set the AF
target and AF area position for vertical and horizontal shooting.
AF areas can be dened and placed anywhere to deal with
subject movement.
Shift your AF areas quickly and easily with the multi selector
while looking through the viewnder even during sequential
shooting or video recording.
Intelligent AF
The new algorithm is developed by using deep learning
technology – a kind of articial intelligence. It detects specic
subjects and focuses on and tracks the optimal points.
Two TruePic VIII Image Processors make
real-time processing possible during sequential shooting.
The camera can quickly track subjects that move unpredictably.
C-AF + TR and all AF areas have to be enabled.
Detected subject (up to 8) AF Tracking position (helmet)
3
9
Gear (icon) > A2 > Target Mode Settings
Gear (icon) > A2 > Mode Settings
Gear (icon) > A3 > Tracking Subject

11
QUICK GUIDE E-M1X
M.Zuiko Digital ED
7-14mm
F2.8 PRO
35mm equivalent: 14-28mm
M.Zuiko Digital ED
12-100mm
F4.0 IS PRO
35mm equivalent: 24-200mm
M.Zuiko Digital ED
45mm
F1.2 PRO
35mm equivalent: 90mm
Electronic ashes & Wireless
communiucation ash accessories
STF-8 Macro FlashTeleconvertors 1.4X | 2.0X*
* This product is scheduled to go on sale in Summer 2019
M.Zuiko Digital ED
8mm
F1.8 FISHEYE PRO
35mm equivalent: 16mm
M.Zuiko Digital ED
17mm
F1.2 PRO
35mm equivalent: 34mm
M.Zuiko Digital ED
40-150mm
F2.8 PRO
35mm equivalent: 80-300mm
M.Zuiko Digital ED
12-40mm
F2.8 PRO
35mm equivalent: 24-80mm
M.Zuiko Digital ED
25mm
F1.2 PRO
35mm equivalent: 50mm
M.Zuiko Digital ED
300mm
F4.0 IS PRO
35mm equivalent: 600mm
M.Zuiko PRO Lenses / Flashes

12
QUICK GUIDE E-M1X
PRO Service
Benet from fast support, camera repair, replacement rental camera and much more - we meet your requirements
as a professional photographer so that you can continue to concentrate fully on your shots.
Priority customer support
Reach Olympus experts for priority assistance with every issue surrounding your
professional shooting system - via phone, e-mail or video call.
Repair with camera loan
Get free express repair transportation and fast-lane repair of your OM-D E-M1 Mark II and
OM-D E-M1X - or loan out professional OM-D equipment throughout the complete time of
repair to keep you shooting on assignment.
Yearly system maintenance
Keep your equipment ready to perform its best. We optimise the performance of your
shooting system and clean it to make sure it feels like new for your next session.
Further Informations on olympus.eu/proservice
Select your PRO Service package
Level 1 Level 2 Level 3
STANDARD PLUS ADVANCED ELITE

13
QUICK GUIDE E-M1X
